SLIDE 1

ASPEN: A Scalable In- SRAM Architecture for Pushdown Automata

Kevin A Angstadt∗, Arun Subramaniyan∗, Elaheh Sadredini†, Reza Rahimi†, Kevin Skadron†, Westley Weimer∗, Reetuparna Das∗

∗Computer Science and Engineering, University of Michigan †Department of Computer Science, University of Virginia This work is funded, in part, by the NSF (1763674, 1619098, CAREER-1652294 and CCF-1629450); Air Force (FA8750-17-2-0079); and CRISP, one of six centers in JUMP, a Semiconductor Research Corporation (SRC) program sponsored by DARPA.

SLIDE 2

Processing Growing Quantities of Data

2

2.5 quintillion bytes of data/day
Analysis /manipulation requires

deserializati tion

Most data use re

recursi sively- nested g grammars

XML
JSON
Poor performance on CPU
High branching

Source: Domo — Data Never Sleeps 5.0

SLIDE 3

<course> <footnote></footnote> <sln>10637</sln> <prefix>ACCTG</prefix> <crs>230</crs> <lab></lab> <sect>01</sect> <title>INT FIN ACCT</title> <credit>3.0</credit> <days>TU,TH</days> <times> <start>7:45</start> <end>9</end> </times> <place> <bldg>TODD</bldg> <room>230</room> </place> <instructor>

B. MCELDOWNEY

</instructor> <limit>0112</limit> <enrolled>0108</enrolled> </course>

XML Nesting

3

SLIDE 4

<course> <footnote></footnote> <sln>10637</sln> <prefix>ACCTG</prefix> <crs>230</crs> <lab></lab> <sect>01</sect> <title>INT FIN ACCT</title> <credit>3.0</credit> <days>TU,TH</days> <times> <start>7:45</start> <end>9</end> </times> <place> <bldg>TODD</bldg> <room>230</room> </place> <instructor>

B. MCELDOWNEY

</instructor> <limit>0112</limit> <enrolled>0108</enrolled> </course>

XML Nesting Subtree Mining

A B C A C B C C A A C B B C A C B C A A C B

4

SLIDE 5

<course> <footnote></footnote> <sln>10637</sln> <prefix>ACCTG</prefix> <crs>230</crs> <lab></lab> <sect>01</sect> <title>INT FIN ACCT</title> <credit>3.0</credit> <days>TU,TH</days> <times> <start>7:45</start> <end>9</end> </times> <place> <bldg>TODD</bldg> <room>230</room> </place> <instructor>

B. MCELDOWNEY

</instructor> <limit>0112</limit> <enrolled>0108</enrolled> </course>

XML Nesting Subtree Mining

A B C A C B C C A A C B B C A C B C A A C B S Exp Term

int * ( ) int int

Term Exp Exp Term Term

+

⊣

S → Exp ⊣ Exp → Term + Exp ∣ Term Term → int * Term ∣ ( Exp ) ∣ int

Parsing

5

SLIDE 6

Processing Growing Quantities of Data

6

Automata/RegEx help tame

analysis of big data sets

Frequent Itemset/Pattern Mining
NLP Part-of-Speech Tagging
Data Deduplication
Ensemble-Based Classification
Particle Physics Analyses
Growing number of

architectural solutions

Source: Domo — Data Never Sleeps 5.0

SLIDE 7

Automata/RegEx Processing Platforms

7

Custom A ASIC IC Existing A Architecture Von N Neumann Spa Spatia ial-Re Reconfigurable

SLIDE 8

Automata/RegEx Processing Platforms

8

Custom A ASIC IC Existing A Architecture Von N Neumann Spa Spatia ial-Re Reconfigurable

HyperScan PCRE Becchi, et al. VASim iNFAnt2 DFAGE REAPR Micron AP UAP HARE IBM PowerEN PAP Cache Automaton

SLIDE 9

Automata/RegEx Processing Platforms

9

Custom A ASIC IC Existing A Architecture Von N Neumann Spa Spatia ial-Re Reconfigurable

HyperScan PCRE Becchi, et al. VASim

CPU-Based

iNFAnt2 DFAGE REAPR Micron AP UAP HARE IBM PowerEN PAP Cache Automaton

SLIDE 10

Automata/RegEx Processing Platforms

10

Custom A ASIC IC Existing A Architecture Von N Neumann Spa Spatia ial-Re Reconfigurable

HyperScan PCRE Becchi, et al. VASim

CPU-Based

iNFAnt2 DFAGE

GPU-Based

REAPR Micron AP UAP HARE IBM PowerEN PAP Cache Automaton

SLIDE 11

Automata/RegEx Processing Platforms

11

Custom A ASIC IC Existing A Architecture Von N Neumann Spa Spatia ial-Re Reconfigurable

HyperScan PCRE Becchi, et al. VASim

CPU-Based

iNFAnt2 DFAGE

GPU-Based

REAPR Micron AP UAP HARE IBM PowerEN PAP Cache Automaton

FPGA-Based

SLIDE 12

Automata/RegEx Processing Platforms

12

Custom A ASIC IC Existing A Architecture Von N Neumann Spa Spatia ial-Re Reconfigurable

HyperScan PCRE Becchi, et al. VASim

CPU-Based

iNFAnt2 DFAGE

GPU-Based

REAPR Micron AP UAP HARE IBM PowerEN PAP Cache Automaton

FPGA-Based

Finite automata are fu fundam amental ally li limited in the kinds and complexity of analyses they support ASPE PEN is a new processor—inspired by automata processing—that supports a richer c computational m model

SLIDE 13

Automata/RegEx Processing Platforms

13

Custom A ASIC IC Existing A Architecture Von N Neumann Spa Spatia ial-Re Reconfigurable

HyperScan PCRE Becchi, et al. VASim

CPU-Based

iNFAnt2 DFAGE

GPU-Based

REAPR Micron AP UAP HARE IBM PowerEN PAP Cache Automaton

FPGA-Based

Finite automata are fu fundam amental ally li limited in the kinds and complexity of analyses they support ASPE PEN is a new processor—inspired by automata processing—that supports a richer c computational m model

SLIDE 14

Accelerated in-SRAM Pushdown EN

ENgine

Scalable processing engine that uses L

LLC s slices to accelerate Pushdown Automata computation

Custom five-stage datapath using SRAM lookups can process up to
n
ne by

byte per c cycle

Optimizing compiler supports

ts e existi ting gra grammars, packs states efficiently, and reduces the number processing stalls

Provides additional cache when not in use

ASPEN Supports Richer Analyses

14

SLIDE 15

Pushdown Automata Refresher
Architectural Design of ASPEN
Why LLC?
Datapath innovation
Optimizations
Evaluation
XML Parsing
Subtree Mining

Overview of this Talk

15

Source: https://www.flickr.com/photos/10623456@N02/45022262771 CC BY-NC 2.0

SLIDE 16

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

16

Pushdown Automata Refresher

SLIDE 17

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

17

Pushdown Automata Refresher

Finite State Control

SLIDE 18

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

18

Pushdown Automata Refresher

Finite State Control Stack Memory

SLIDE 19

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

19

Pushdown Automata Refresher

Input Symbol Match

Finite State Control Stack Memory

SLIDE 20

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

20

Pushdown Automata Refresher

Input Symbol Match Top of Stack Match

Finite State Control Stack Memory

SLIDE 21

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

21

Pushdown Automata Refresher

Input Symbol Match Top of Stack Match Stack Actions

Finite State Control Stack Memory

SLIDE 22

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

22

Pushdown Automata Refresher

Input Symbol Match Top of Stack Match Stack Actions

Finite State Control Stack Memory

Deterministic Pushdown Automata (DPDA) av avoid stack d divergence, but still support parsing of most common languages

SLIDE 23

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

23

Recognizing Palindromes with a Middle Character

SLIDE 24

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

24

Recognizing Palindromes with a Middle Character

SLIDE 25

010 1010 10c010 1010 10

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

25

Recognizing Palindromes with a Middle Character

SLIDE 26

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

1 ⊥

ST STACK

26

Recognizing Palindromes with a Middle Character

SLIDE 27

01 01010 10c010 1010 10

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

1 ⊥

ST STACK

27

Recognizing Palindromes with a Middle Character

SLIDE 28

01 01010c 0c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

1 1 ⊥

ST STACK

28

Recognizing Palindromes with a Middle Character

SLIDE 29

01 0101 010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

1 1 ⊥

ST STACK

29

Recognizing Palindromes with a Middle Character

SLIDE 30

01 0101 010c01 0101 010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

1 1 ⊥

ST STACK

30

Recognizing Palindromes with a Middle Character

SLIDE 31

01 0101 010c010 1010 10

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

1 1 ⊥

ST STACK

31

Recognizing Palindromes with a Middle Character

SLIDE 32

01010c0 c0101 010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

1 1 ⊥

ST STACK

32

Recognizing Palindromes with a Middle Character

SLIDE 33

01010c0 c01010 10

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

1 ⊥

ST STACK

33

Recognizing Palindromes with a Middle Character

SLIDE 34

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

1 ⊥

ST STACK

34

Recognizing Palindromes with a Middle Character

SLIDE 35

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

35

Recognizing Palindromes with a Middle Character

SLIDE 36

01010c0 c01010 ✓

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

36

Recognizing Palindromes with a Middle Character

SLIDE 37

ASPEN supports ho

homoge geneous DPDA

All transitions to a state occur on the same input character, stack

comparison, and stack operation

Similar in nature to homogeneous NFAs
Equal expressive power as standard DPDA
State increase is quadrati

tic i in th the w worst c t case with a fixed alphabet

Allows for efficient m

t mapping to hardware resources

Transitions decoupled from input/stack matches

Mapping DPDA Efficiently to Hardware

37

SLIDE 38

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

Five Steps of DPDA Execution Per Cycle

38

SLIDE 39

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

1. Input Match"
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

Five Steps of DPDA Execution Per Cycle

39

1"

SLIDE 40

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

1. Input Match"
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

Five Steps of DPDA Execution Per Cycle

40

1" 2

SLIDE 41

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

1. Input Match"
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

Five Steps of DPDA Execution Per Cycle

41

1" 2 3

SLIDE 42

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

1. Input Match"
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

Five Steps of DPDA Execution Per Cycle

42

1" 2 4 3

SLIDE 43

01010c0 c01010

* Pop 0 Push ‘0’ 1 * Pop 0 Push ‘1’ c * Pop 0 No Push 1 1 Pop 1 No Push Pop 1 No Push ε ⊥ Pop 0 No Push

⊥

ST STACK

1. Input Match"
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

Five Steps of DPDA Execution Per Cycle

43

1" 2 4 3 5

SLIDE 44

ASPEN repurposes LLC slices for pushdown automata computation
Location in LLC supports tighter coupling with CPU operations than

dedicated accelerator

PDA often part of a larger workflow
ASPEN similar to auxiliary functional unit in CPU (similar to FPU or vector

unit)

SRAM arrays in LLC already support necessary operations for DPDA

execution

Implementing ASPEN in LLC

44

SLIDE 45

ASPEN uses 2

arrays per bank

240 states per

bank

Full connectivity

within bank

Global switch

and stack in CBOX for large DPDA

Where is ASPEN?

45

CB CBOX Wa Way 20 Wa Way 2 Wa Way 1 AS ASPEN G-sw switc tch AS ASPEN G-sta stack AS ASPEN

SLIDE 46

Check all s

sta tates against top of stack

One column of SRAM/state
Input TOS as row address
“1”: match; ”0”: no match
In

Intersect with currently active states

Stack Match in SRAM

46

4:1 column mux Row Decoder

255

255 255

Top of Stack (TOS) Active State Vector Active States Matching Stack

SLIDE 47

Check all s

sta tates against top of stack

One column of SRAM/state
Input TOS as row address
“1”: match; ”0”: no match
In

Intersect with currently active states

Stack Match in SRAM

47

4:1 column mux Row Decoder

255

255 255

Top of Stack (TOS) Active State Vector Active States Matching Stack

S0 S0 * S1 S1 * S3 S3 * S2 S254 1 S2 S255 S2 S253 ⊥

SLIDE 48

Check all s

sta tates against top of stack

One column of SRAM/state
Input TOS as row address
“1”: match; ”0”: no match
In

Intersect with currently active states

Stack Match in SRAM

48

4:1 column mux Row Decoder

255

255 255

Top of Stack (TOS) Active State Vector Active States Matching Stack

S0 S0 * S1 S1 * S3 S3 * S2 S254 1 S2 S255 S2 S253 ⊥

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

SLIDE 49

49

ASPEN Datapath — 240 States per Two SRAM Arrays

1. Input Match!
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

240b 8-bit Input

Row Decoder

255

EN EN 255 255

4:1 column mux Row Decoder

255

255 255

4:1 column mux Active State Vector

256b 256b

256 x 256 6-T SRAM L-Switch

256b

SM Vector

240b

IM Vector

Push S

Sym. Pop #

#

8b 8b

TO TOS Local TOS

8b 8b

TOS + +1

St Stack Po Pointer

SRAM Array0 SRAM Array1

256b

SLIDE 50

50

ASPEN Datapath — 240 States per Two SRAM Arrays

1. Input Match!
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

240b 8-bit Input

Row Decoder

255

EN EN 255 255

4:1 column mux Row Decoder

255

255 255

4:1 column mux Active State Vector

256b 256b

256 x 256 6-T SRAM L-Switch

256b

SM Vector

240b

IM Vector

1. Input

Matching — One Column per State

Push S

Sym. Pop #

#

8b 8b

TO TOS Local TOS

8b 8b

TOS + +1

St Stack Po Pointer

SRAM Array0 SRAM Array1

256b

SLIDE 51

51

ASPEN Datapath — 240 States per Two SRAM Arrays

1. Input Match!
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

240b 8-bit Input

Row Decoder

255

EN EN 255 255

4:1 column mux Row Decoder

255

255 255

4:1 column mux Active State Vector

256b 256b

256 x 256 6-T SRAM L-Switch

256b

SM Vector

240b

IM Vector

1. Input

Matching — One Column per State

2. Stack

Matching — One Column per State

Push S

Sym. Pop #

#

8b 8b

TO TOS Local TOS

8b 8b

TOS + +1

St Stack Po Pointer

SRAM Array0 SRAM Array1

256b

SLIDE 52

52

ASPEN Datapath — 240 States per Two SRAM Arrays

1. Input Match!
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

240b 8-bit Input

Row Decoder

255

EN EN 255 255

4:1 column mux Row Decoder

255

255 255

4:1 column mux Active State Vector

256b 256b

256 x 256 6-T SRAM L-Switch

256b

SM Vector

240b

IM Vector

1. Input

Matching — One Column per State

2. Stack

Matching — One Column per State

3. Stack Actions —

One Row per State

Push S

Sym. Pop #

#

8b 8b

TO TOS Local TOS

8b 8b

TOS + +1

St Stack Po Pointer

SRAM Array0 SRAM Array1

256b

SLIDE 53

53

ASPEN Datapath — 240 States per Two SRAM Arrays

1. Input Match!
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

240b 8-bit Input

Row Decoder

255

EN EN 255 255

4:1 column mux Row Decoder

255

255 255

4:1 column mux Active State Vector

256b 256b

256 x 256 6-T SRAM L-Switch

256b

SM Vector

240b

IM Vector

1. Input

Matching — One Column per State

2. Stack

Matching — One Column per State

3. Stack Actions —

One Row per State

Push S

Sym. Pop #

#

8b 8b

TO TOS Local TOS

4. Local Stack —

One Row per Entry

8b 8b

TOS + +1

St Stack Po Pointer

SRAM Array0 SRAM Array1

256b

SLIDE 54

54

ASPEN Datapath — 240 States per Two SRAM Arrays

1. Input Match!
2. Stack Match
3. Action Lookup
4. Stack Update
5. State

Transition

240b 8-bit Input

Row Decoder

255

EN EN 255 255

4:1 column mux Row Decoder

255

255 255

4:1 column mux Active State Vector

256b 256b

256 x 256 6-T SRAM L-Switch

256b

SM Vector

240b

IM Vector

1. Input

Matching — One Column per State

2. Stack

Matching — One Column per State

3. Stack Actions —

One Row per State

Push S

Sym. Pop #

#

8b 8b

TO TOS Local TOS

4. Local Stack —

One Row per Entry

8b 8b

TOS + +1

St Stack Po Pointer

SRAM Array0 SRAM Array1

256b

5. Reconfigurable Transition Matrix

SLIDE 55

Av

Average of 6 65% re reduc uctio ion n in epsilon states

Optimizations

55

[A-Z] * Pop 0 No Push ε * Pop 1 Push ‘a’ … … [A-Z] * Pop 1 Push ‘a’ … … ε * Pop 1 No Push ε * Pop 1 No Push ε * Pop 1 No Push ε * Pop 1 No Push … … ε * Pop 4 No Push … …

Epsilon M Merging Multi tipop Go Goal: Reduce the number of stalls while processing input

SLIDE 56

XML Parsing
Common to many data analyses (needed to read input data)
Step in a larger pipeline: Tokenization, Parsing, Validation, DOM

construction

Pipelined with Cache Automaton for tokenization
Single Large D

DPDA w with G Global S Stack

Frequent Subtree Mining
Task of identifying subtrees occurring above a threshold frequency in a

corpus of trees

Common in recommendation systems, packet routing, NLP, etc.
Many Small D

DPDA w with L Local S Stacks

Evaluation: Two Real-World Applications

56

SLIDE 57

Co Component Max F Frequency Operating F Frequency ASPEN 880 MHz 850 MHz Cache Automaton 4 GHz 3.4 GHz

Experimental Methodology

57

Baseline E

Evaluation

CPU:

: 2.6 GHz dual-socket Intel Xeon E5-2697-v3 (28 cores total)

GPU:

: NVIDIA TITAN Xp

Pe

Performance an and Po Power: PAPI, Intel RAPL, NVIDIA nvprof

AS

ASPEN Si Simu mulation:

METIS graph partitioning framework
VASim modified for cycle-accurate DPDA simulation

SLIDE 58

ASPEN is 13

13-18x x fa faster (on average) than popular CP CPU Parsers

Performance did not

vary significantly with complexity of XML

Optimizations and

tokenization hide !- stalls

XML Parsing: Parabix, Ximpleware, UW XML

58

5 10 15 20 25

Low (< 0.3) Medium (0.3-0.7) High (>0.7) Average

Speedup (normalized to Xerces) Markup Density Xerces Expat ASPEN ASPEN-MP

SLIDE 59

ASPEN is (on

average) 67x f faster than CPUs 6x f faster than GPUs for end- to-end application

Performance on

ASPEN is independent from tree size and complexity

No !-transitions

Frequent Subtree Mining

59

Dat Datas aset Automata A Alphabets Stack A Alphabets Stack S Size T1M 16 17 29 T2M 38 39 49 TREEBANK 100 101 110

0.5 50 5000 T1M T2M TREEBANK Speedup (normalized to TreeMatcher) CPU-Kernel CPU-Full GPU-Kernel GPU-Full

SLIDE 60

Conclusion

60

SLIDE 61

Conclusion

61

CB CBOX Wa Way 20 Wa Way 2 Wa Way 1 AS ASPEN G-sw switc tch AS ASPEN G-sta stack AS ASPEN

ASPEN: P : Processor f for D DPDA A Acceleration

SLIDE 62

Conclusion

62

CB CBOX Wa Way 20 Wa Way 2 Wa Way 1 AS ASPEN G-sw switc tch AS ASPEN G-sta stack AS ASPEN

ASPEN: P : Processor f for D DPDA A Acceleration

S → Exp ⊣ Exp → Term + Exp ∣ Term Term → int * Term ∣ ( Exp ) ∣ int

Supports P Processing o

f

Re Recursively-Nested a and T Tree-Structured D Data

A B C A C B C C A A C B B C A C B C A A C B

SLIDE 63

Conclusion

63

CB CBOX Wa Way 20 Wa Way 2 Wa Way 1 AS ASPEN G-sw switc tch AS ASPEN G-sta stack AS ASPEN

ASPEN: P : Processor f for D DPDA A Acceleration

S → Exp ⊣ Exp → Term + Exp ∣ Term Term → int * Term ∣ ( Exp ) ∣ int

Supports P Processing o

f

Re Recursively-Nested a and T Tree-Structured D Data

A B C A C B C C A A C B B C A C B C A A C B

⊥

ST STACK

Homogeneous D Deterministic Pushdown A Automaton

SLIDE 64

Conclusion

64

CB CBOX Wa Way 20 Wa Way 2 Wa Way 1 AS ASPEN G-sw switc tch AS ASPEN G-sta stack AS ASPEN

ASPEN: P : Processor f for D DPDA A Acceleration

S → Exp ⊣ Exp → Term + Exp ∣ Term Term → int * Term ∣ ( Exp ) ∣ int

Supports P Processing o

f

Re Recursively-Nested a and T Tree-Structured D Data

A B C A C B C C A A C B B C A C B C A A C B

⊥

ST STACK

Homogeneous D Deterministic Pushdown A Automaton

240b 8-bit Input

Row Decoder

255 EN EN 255 255

4:1 column mux Row Decoder

255 255 255

4:1 column mux Active State Vector

256b 256b

256 x 256 6-T SRAM L-Switch

Fr From G-Sw Switch 256b 32b 32b To To G-Sw Switch

SM Vector

240b

IM Vector Input Matching — One Column per State Stack Matching — One Column per State Stack Actions — One Row per State

Push S

Sym. Pop #

# 8b 8b TO TOS Local TOS Global TOS

Local Stack — One Row per Entry

8b 8b TOS + +1 St Stack Po Pointer

SRAM Array0 SRAM Array1

256b

Custom 5 5-Stage D Datapath

SLIDE 65

Conclusion

65

CB CBOX Wa Way 20 Wa Way 2 Wa Way 1 AS ASPEN G-sw switc tch AS ASPEN G-sta stack AS ASPEN

ASPEN: P : Processor f for D DPDA A Acceleration

S → Exp ⊣ Exp → Term + Exp ∣ Term Term → int * Term ∣ ( Exp ) ∣ int

Supports P Processing o

f

Re Recursively-Nested a and T Tree-Structured D Data

A B C A C B C C A A C B B C A C B C A A C B

⊥

ST STACK

Homogeneous D Deterministic Pushdown A Automaton

240b 8-bit Input

Row Decoder

255 EN EN 255 255

4:1 column mux Row Decoder

255 255 255

4:1 column mux Active State Vector

256b 256b

256 x 256 6-T SRAM L-Switch

Fr From G-Sw Switch 256b 32b 32b To To G-Sw Switch

SM Vector

240b

IM Vector Input Matching — One Column per State Stack Matching — One Column per State Stack Actions — One Row per State

Push S

Sym. Pop #

# 8b 8b TO TOS Local TOS Global TOS

Local Stack — One Row per Entry

8b 8b TOS + +1 St Stack Po Pointer

SRAM Array0 SRAM Array1

256b

Custom 5 5-Stage D Datapath
