a spa w yman & a ssociates (ASPA FILTERS) (ASPA FILTERS) Better Filtration Better Times 18 o 3142 N, 73 o 4957 E Aspa W Wym yman & & A Associ ciates (Filte (Filters Di Divn). ). We introduce ourselves as one

SLIDE 1

aspa wyman & associates

(ASPA FILTERS) (ASPA FILTERS)

Better Filtration – Better Times 18o31’42” N, 73o49’57” E

SLIDE 2 We introduce ourselves as one of the leading quality manufacturers of Air Handling Filters for FCU, AHU, Supply Fans, Activated Carbon Filters, Chemical Filters, Humidity absorbent filters & HEPA Filters widely used in Air-conditioning, Ventilation, Sterile or Clean Room Filtration, Dust Collection Systems, Electrostatic Filtration Equipments, Radioactive Fume Hoods for Nuclear Medicine Departments, & Kitchen Exhausts in Hospitality Industry. Our product range consists of : Pre-Filters Fine Filters Activated Carbon Filters for Fume & Odor adsorption. HEPA & Mini Pleat HEPA Filters. Roll-O-Mat & Bag Filters for Paint Booths & Polyester Yarn Industries. Our product is used by various leading industrial houses, Atomic Energy Establishments, Thermal & Hydro Power Stations, Aeronautical Industries, Hospitals, Pharmaceuticals, Railways, Polyester Fiber Manufacturing Units, Star Hotels, Multiplex / Auditoriums etc. (Please find enclosed customer list). We undertake designing & manufacturing of air filters as per buyers specifications & standards …………………

Aspa W Wym yman & & A Associ ciates (Filte

(Filters Di Divn). ).

SLIDE 3

“ASPA” – make FAN COIL UNIT FILTERS

Metallic Mesh Media Synthetic Interlocked Mesh Media Double Knitted Twisted Polymer Media

Special Features:

Available in 10 & 15 micron rating (Depends on static

pressure of the fan).

Pressure drop of 3mm to 5mm of W.C. across the filter.
These filters are used in fan coil units & ductable splits of

comfort & industrial air-conditioning.

Available in 10, 15 & 25 mm thickness.

SLIDE 4

“ASPA” – make PRE FILTERS

Available with an efficiency of 15 micron & 10 micron rating

Filter media consists of Double Knitted Twisted Polymer Fabric,

aluminium expanded metal & stiffeners on both sides of filter media.

Media does not distort after washing.
Suitable as a pre-filter for comfort & industrial air handling

units.

Available in 25mm & 50mm thickness
Water washable.
High Service Life.

SLIDE 5

“ASPA” – make METALLIC VISCOUS FILTERS

Available in 20 micron rating.
A combination of flat & corrugated layers of metallic mesh.
Available with GI / Aluminium / SS mesh.
Fineness of the mesh increases towards the air leaving side.
Suitable as a paint booth exhaust and kitchen hood exhaust filter.
To be used instead of baffle filters in Kitchen Hood .
Oil & Grease particles are arrested at source. The duct remains clean.

SLIDE 6

“ASPA” – make FINE FILTERS

The filter casing can be fabricated with/without flange as per customer requirements.
Available in casing thickness of 1.5 mm in variants of Mild steel/Galvanized steel /

Aluminium/Stainless steel with a surface finish of enamel paint /powder coating /anodized finish.

Non-Woven Polyester fiber is used as filtration media. Other types of filtration media

are available on specific request.

6 to 11 Pleats per running foot depending upon the application & air flow.
Synthetic adhesives & separators are used to seal frame with media.
Initial pressure drop of 6-8 mm WC.
Filtration efficiency of 5 & 3 microns.
Washable with compressed air or high speed blower & water.

SLIDE 7

”ASPA” – make HEPA FILTERS

Deep Pleat Mini Pleat Details of Gasket Joints ASPA - make HEPA filters are available in the standard sizes for deep pleat version. Non-Standard sizes can also be manufactured as per customer’s

requirements. The filter can be assembled with/ without flanges. Available

in casing thickness of 1.5 mm in variants of Aluminium / Stainless Steel. Anodizing is the standard surface finish offered for Aluminium casings. Filtration media is submicronic micro glass paper, which is fire retardant HEPA filter media manufactured by M/s.Lydall Inc, USA. Aluminium separators made from 36 swg. aluminium foil are used in the case of deep pleat version. High impact polystyrene separators are used in the case of mini pleat version. Flanges are fixed with synthetic soft rubber gaskets. Deep pleat filters have a initial pressure drop of 22 - 25 mm WC Mini pleat filters have a initial pressure drop of 15-18 mm WC These filters have efficiency of 0.3 microns. All filters are particle counted and DOP leak tested. Each filter is accompanied by a test certificate.

SLIDE 8

“ASPA” – make BAG FILTERS

Available in casing thickness of 1.5 mm in variants of Mild steel /

Galvanized steel /Aluminium/Stainless steel with a surface finish of enamel paint / anodisation or powder coated finish

Media consists of Non-Woven Polyester fabric chemically bonded with a

layer of High density polyethylene (HDPE) mesh for support on the exit side resulting in a mechanically strong media.

Bags are intra stitched to prevent bag ballooning.
Stitch holes are sealed using synthetic sealants.
Bags are sealed with frame using synthetic sealants.
Initial pressure drop of 8 mm WC.
Filtration efficiency available is from 20 micron to 3 microns.

ASPA - make bag filters are available in any size as per customer requirements, depending upon the air volume required to be handled. The pockets of Bag filters can handle high air volume in less area. The filters can be fabricated with/without flange as per customer's choice.

SLIDE 9

“ASPA” – make ACTIVATED CARBON FILTERS

How activated carbon is made? Most active carbon, as used for gas or vapor trapping, is made from coconut shell. The shells are heated to over 2,000°C under high pressure, which causes fissures on the surface of the carbon, creating a high quality, small pore activated carbon. The fissure system is extensive, creating a very large surface area in a small package, and it is in these fissures that other gases and particles are trapped. A single activated carbon filter has a flattened surface area of a football field and can absorb up to 60% of their own weight in gases! How does activated carbon remove odors? Activated Carbon has the ability to capture gas molecules and hold them. The accumulation of molecules of a gas to form a thin film on the surface of a solid is called adsorbtion. The carbon surface is made up of millions of tiny pores, the gas and odors fall into these pores and are trapped there until the pad is recharged or

disposed. Other methods to get rid of odors such as sprays & deodorants, only fool

you sense of smell - the odors still exist. Activated carbon air filters are the most effective type of filter against chemicals, gases, cigarette smoke and other odors. (list mentioned) Activated carbon air filters consist of a vast system of pores of molecular size. These pores are highly adsorbent, forming a strong chemical bond or attraction to odorous, gaseous, and liquid contaminates. Activated Carbon Filtration is commonly used in water and air purification. HVAC applications, which require the removal of odors include air filtration and air purification in medical, pharmaceutical, electronics, semiconductor, hospital, and oil- free environments.

SLIDE 10

“ASPA” – make ACTIVATED CARBON FILTERS For FCU / Trap Doors For AHU / TFA / Draft Ventilation

SLIDE 11

TECHNICAL SPECIFICATION OF GRANULAR ACTIVATED CARBON

Appearance Black Granular Particle Size Any sieve size viz. 4 / 8, 8 / 16, 12 / 30, 4 / 16, 8 / 30,16 / 30 Iodine Adsorption 500 mg / gm ± 25 750 mg / gm ± 25 850 mg / gm ± 50 950 mg / gm ± 50 1100 mg / gm ± 50 pH 9 to 10 9 to 10 9 to 10 9 to 10 9 to 10 Moisture 5% 5% 5% 5% 5% Total Surface Area 500 m2 / gm. 750 m2 / gm. 850 m2 / gm. 950 m2 / gm. 1100 m2 / gm. Bulk Density 0.55 ± 0.05 gm. / CC 0.53 ± 0.05 gm. / CC 0.51 ± 0.05 gm. / CC 0.50 ± 0.05 gm. / CC 0.48 ± 0.05 gm. / CC Ball Pan Hardness no. 90 85 80 80 70 Ash Content 5.% Max 5.% Max 5.% Max 5.% Max 5.% Max

SLIDE 12

“ASPA” – make ACTIVATED CARBON FILTERS

Activated Carbon is effective at removing the following types of chemicals: Acetaldehyde Cyclohexanol Hydrogen fluoride Paint & redecorating odors Acetic Acid Cyclohexanol Hydrogen iodide Palmitic Acid Acetic anhydride Cyclohexene Hydrogen selenide Paradichlorbenzine Acetone Decane Hydrogen sulfide Pantane Dibromoethane Incensen Pentanone Acrolem Dichlorobenzene Indole Pentylene Acrylic Acid Dichlorodifluoromethane Iodine Pentyne Acrylonitrile Dichloroethane Iodoform Perchloroethylene Alcoholic Beverages Dichloroethylene Irritants Perfumes, cosmetics Amines Dichloroethyl Isophorone Phenol Ammonia Dichloromonofluormethane Isoprene Phosgene Ameyl acetate Dichloronitroethane Isopropyl acetate Pitch Amyl alcohol Dichloroprpane Isopropyl alcohol Poison gases Amyl ether Dichlorotetrafluoroethane Isopropyl ether Pollen

SLIDE 13 Aniline Diesel fumes Kerosene Poultry odors Asphalt fumes Diethylamine Kitchen

dors

Propane Automobil e Exhaust Diethyl ketone Lactic acid Propionaldehy de Benzene Dimethylaniline Dimethyls ulfate Propionic acid Body

dors

Dimethylsulfate Menthol Propyl acetate Borane Dioxane Mercapta ns Propyl alcohol Bromine Diproyl ketone Methil acetate Propyl chloride Burned Flesh Ether Menthyl acrylate Propyl ether

“ASPA” – make ACTIVATED CARBON FILTERS

Burned Food Ethyl acetate Methyl alcohol Propyl mercaptan Butadiene Ethyl acrylate Methyl bromide Methyl bromide Butane Ethyl alcohol Methyl butyl ketone Propylene Butanone Ethyl amine Methyl cellosolve Propyne Butyl acetate Ethyl benzene Methyl cellosolve acetate Putrefying substances Butyl alcohol Ethyl bromide Methyl chloride Putrescine Butyl cellosolve Ethyl chloride Methyl chloroform Pyridine Butyl chloride Ethyl ether Methyl ether Resins Butyl ether Ethyl formate Methyl ethyl ketone Rubber Butylene Ethyl mercaptan Methyl formate Sauerkraut Activated Carbon is effective at removing the following types of chemicals:

SLIDE 14 Butyne Ethyl silicate Methyl isobutyl ketone Sewer odors Butyraldehyde Ethylene chlorhydrin Methyl mercaptan Skalote Butyric acid Ethylene dichloride Methylcyclohexane Slaughtering odors Camphor Ethylene oxide Methylcyclohexanol Smog Caprylic acid Essential oils Methylcyclohexaone Sour milks Carbolic acid Eucalyptole Methylene chloride Stoddard solvent Carbon disulfide Fertilizer Monochlorobenzene Styrene monomer Carbon dioxide Film processing odors Monofluorotri cloromethane Sulfur dioxide Carbon tetrachloride Fish odors Naphtha Sulfur trioxide Cellosolve Floral scents Naphthziene Sulfuric acid Cellosolve acetate Fluorotrichloromethane Nitric acid Tetrachloroethane Cheese Formaldehyde Nitro benzenes Tetrachloroethylene Chlorine Formic acid Nitroethane Tobacco smoke odor Chlorobenzene Gangrene Nitrogen dioxide Toilet odors Chlorobutadiene Garlic Nitroglycerine Toluene Activated Carbon is effective at removing the following types of chemicals:

“ASPA” – make ACTIVATED CARBON FILTERS

SLIDE 15 Chloroform Gasoline Nitromethane Toluidine Chloronitropropane Heptane Nitropropane Trichlorethylene Chloropicrin Heptylene Nitrotoluene Trichloroethane Citrus and other fruits Hexane Nonane Turpentine Cleaning compounds Hexylene Octalene Urea Coal smoke Hexyne Octane Uric acid Creosote Organic Chemicals Onions Valeric acid Cresol Hydrogen bromide Varnish fumes Valericaldehyde Crotonaldehyde Hydrogen chloride Ozone Xylene Cychlohexane Hydrogen cyanide Packing house odors Activated Carbon is effective at removing the following types of chemicals:

“ASPA” – make ACTIVATED CARBON FILTERS

SLIDE 16

TESTING FACILITY

1. Our Factory test lab is equipped with test rigs to test & certify the performance of
ur products.
2. Hepa filter construction and test rig as per recommendations of IES-RP-001.
3. Hepa filter compliance to FED:STD:209E and EN779.
4. Fine and Pre filter compliance to IS7613.
5. Batch testing is done for fine and pre filters.
6. Cent percent testing in the case of Hepa filters.
7. We are equipped with all the latest instruments like Particle counter, Photometer,

DOP generator, Anemometer, dust feeding arrangement, test duct, blower with damper, electronic weighing machine etc. to conduct various tests on our products.

Anemometer DOP (DIOCTYLPHTHALATE) Generator Particle Counter Photometer

SLIDE 17

We manufacture only high quality filters which are at par having International Standards Globally, our company is known for …………………. QUALITY & SERVICE We definitely feel proud to consider

urselves to be a part of your organisation…..

QUALITY ASSURANCE

SLIDE 18 Bhabha Atomic Research Centre. (Department of Atomic Energy). Indian Explosives Ltd. Armament Research Design Establishment - Pashan. (MES Approved) ONGC (Uran) BASF – Mangalore. Naval Armament Depot - Karanja, Tunir, Akbar etc. – Uran. INHS Asvini Hospital – Mumbai Pam + Glatt Pharma Technologies Ltd. Asian Heart Institute & Research Centre – Mumbai Lilavati Hospital & Research Centre - Mumbai. Godrej Memorial Hospital – Mumbai. Manikchand Hospital - Shirur. Dr.D.Y.Patil Hospital & Research Centre - Pune. Sahyadri Hospital - Pune. Jehangir Nursing Home – Pune N.M.Wadia Hospital – Pune Tata Institute Of Fundamental Research. Tata Electric Company. MSEB - Koyna Hydro Electric Project. - Generating Station. MSEB - Gas Turbine Power Station - Uran. The Tata Hydro-Electric Power Supply Company Ltd. The Andhra Valley Power Supply Company Ltd. Airport Authority Of India. Hindustan Aeronautics Limited - Nasik. M.V.I.R.C. World Trade Centre - Mumbai. Bombay Stock Exchange. Research Design & Standards Organisation (Railways).

We are proud to be associated with ……….

SLIDE 19 Central Railways. (A/C Coaches , Electric Loco Engines, Hospitals etc). The Carriage & Wagon Works (Central Railways - Matunga). Electric Locomotive Shed - (Central Railways - Kalyan Divn). Broadcasting Corporation Of India. (Prasar Bharati). Mahanagar Telecom Nigam Limited. Department of Telecom. Indian Petrochemicals Corporation Ltd - Baroda. Aventis Pharma Ltd - Goa. Novartis. Cipla - Mumbai / Bangalore. Knoll Pharmaceuticals. Sandoz. Hindustan Antibiotics. Cadilla Laboratories. Glaxo Laboratories. Fairdeal Corporation - Roha & Mumbai. Wallace Pharmaceuticals. Kimberly Clark Lever Ltd. Tablets India Ltd. Merck Sharp & Dohme of India. Parke Davis. Rohne-Poulenc Duphar Interfran. Biostar Pharmaceuticals. Genpharma Ltd Cadbury India Ltd. Ravalgaon Sugar Farms. Fritolays India Ltd. Essar House.

SLIDE 20 Sandvik Asia Voltas India. Kirloskar Pneumatics. Godrej & Boyce Co. Pvt. Ltd. Indian Aluminium Co. (INDAL) Infosys Ltd. Oberoi Flight Services. The Le-Meridien Group (Mumbai & Pune). The East India Hotels (The Oberoi’s / The Hilton Towers) - Mumbai. Grand Hyatt – Mumbai. Hyatt Regency - Kathmandu. Hyatt Regency - Mumbai. Park Hyatt Resorts & Spa - Goa. Raddison White Sands Resorts - Goa. The Indian Hotels Company Ltd. (Taj Group of Hotels). Taj Mahal - Mumbai , Taj Residency - Aurangabad, Taj President - Mumbai, Taj Lands End - Mumbai, Taj Exotica - Goa, Fort Aguada Beach Resorts - Goa, Taj Holiday Village - Goa, Taj Blue Diamond - Pune etc. J.W.Marriott - Mumbai. Renaissance & Marriott Resorts – Powai, Mumbai. Marriott – Goa Marriott - Hyderabad Club Mahindra Resorts - Goa.

SLIDE 21 Majorda Beach Resorts - Goa. ITC Grand Maratha Sheraton. Hotel Leela. Hotel Holiday Inn. (Mumbai - Pune). Hotel Ajanta Ambassador - Aurangabad. Hotel The Residence - Mumbai. Hotel Shalini Palace - Kolhapur. Center One Shopping Mall - Mumbai. Essar House. Welspun Syntex Limited Orkay Polyesters. J.V.G. Polyesters. Konkan Synthetic Fibres (Century Enka) Bombay Dyeing & Manufacturing Co. Ltd. Rajasthan Petro Synthetics. Siemens - Mumbai. Ceat Tyres Limited - Mumbai. Yashmun Engineers Ltd. Godfrey Phillips. Warana Dairy. Amul Dairy Air-conditioned auditoriums / theatres (including IMAX Adlabs, INOX Leisure, Xexon, Fun Republic, City Pride I & II, City Pavilion, Regal etc.) Air-conditioned buses (Prasanna, Metrolink, Varun, Maharaja, Konduskar, Autorolla / Sai Service) etc………….

SLIDE 22 For further assistance / technical details, please feel free to contact :-

M/s. ASPA WYMAN & ASSOCIATES (ASPA Filters)

ASHOK PABALKAR ENTERPRISE

Head Office: 43/4, 'MANIK', Srikrishna Nagar, Senapati Bapat Road, Pune - 411 016.Maharashtra, INDIA. Tel / Fax: +91 - 20 - 25653427 / 27422736. Cell No: 98220 40006 / 90110 46006 / 88060 40006 e-mail: customercare@aspawyman.com / rahul@aspawyman.com

…………. THANK YOU
