Arthur Kressner CON EDISONS ELECTRIC SYSTEM NEW YORK CITY AND WESTCHESTER COUNTY ! 3.2 million customers, 14-16 million people ! 36,000 miles of overhead lines ! 94,000 miles of underground lines ! 80 local distribution

slide-1
SLIDE 1

Arthur Kressner

slide-2
SLIDE 2

CON EDISON’S ELECTRIC SYSTEM NEW YORK CITY AND WESTCHESTER COUNTY

  • !

3.2 million customers, 14-16 million people

  • !

36,000 miles of overhead lines

  • !

94,000 miles of underground lines

  • !

80 local distribution networks

Staten Island Brooklyn Queens Manhattan Bronx Westchester County

slide-3
SLIDE 3

OVERVIEW

Substations

Transmission 37 Sub-Transmission (Area) 60 Distribution Transformer Vaults 78,700

S System Voltages

Transmission 345kV, 500kV Sub-Transmission 138kV, 69kV Primary Distribution 33kV, 27kV, 13kV, 4kV Secondary Distribution 120/208V, 460V

D Distribution Design Criteria

N-2 in high density N-1 minimum throughout entire system Low voltage distributed grid and spot networks Area Substation

slide-4
SLIDE 4

CON EDISON ELECTRIC DISTRIBUTION SYSTEM

Generating Station (electricity generated at 13.8 to 22.0 kV) Transmission Substation Area Substation (voltage stepped down to distribution voltage) Transformers (voltage stepped down to 480, 208,

  • r 120 V)

Feeders Connection To Others

60 Network Systems

Supply 86% of System Demand

Overhead System

Supplies 14% of System Demand

slide-5
SLIDE 5

UNDER THE STREETS

Is this sustainable?

slide-6
SLIDE 6

Why the “Smart GRID”?

  • ! Photovoltaic and Wind Power are getting more

efficient and lower cost – intermittent and unreliable

  • ! Electric vehicles are emerging – a mobile and large

new use for electricity

  • ! Customers want choices - to generate their own power

and buy power from others,local options

  • ! Electricity is increasingly vital to our personal,

economic and societal well being

  • ! The existing grid is aging and incompatible with these

changes

slide-7
SLIDE 7
  • ! sectionalizing and reconfigures feeders

The ROUTER for the grid

slide-8
SLIDE 8

5,000 6,000 7,000 8,000 9,000 10,000 1 3 5 7 9 11 13 15 17 19 21 23

30% PEV Market Share 20% PEV Market Share 10% PEV Market Share System Avg. Load

CON EDISON OPPORTUNITIES / CHALLENGES

MW

Time of Day PHEV Charging Occurs at 8am and 5pm (Normal Average System Peak is 8,121 MW)

Morning Commute: Charge at Work Evening Commute: Charge at Home

20%

slide-9
SLIDE 9

5,000 6,000 7,000 8,000 9,000 10,000 1 3 5 7 9 11 13 15 17 19 21 23

30% PEV Market Share 20% PEV Market Share 10% PEV Market Share NYC Avg. Load

CON EDISON OPPORTUNITIES / CHALLENGES

0% MW

Time of Day PHEV Load Fills the Load Valleys (Normal Average System Peak is 8,121 MW)

slide-10
SLIDE 10

Back Office

Smart meters / secondary model validation Home area network ~ 300 locations Remotely controlled underground switches Peer to peer web- like network Data collectors at selected building locations Integration of DG IP routable protocol Integration to private network Transformer / NWP monitoring ~ 1500 smart meters Command and control system

Switch control

Internet

slide-11
SLIDE 11

Smart Grid
