Architecture of an NLP Deployment

Michelle Casbon QCon São Paulo
 May 9, 2018

@texasmichelle

whoami

2

@texasmichelle

Agenda

Evolution of NLP architectures Components Guiding principles Implementations Future

1 2 3 4 5

3

@texasmichelle

Move along Is this a clearly defined problem? Can it be solved in a deterministic way? Do that Dive in No No Yes Yes

ML decision tree

4

@texasmichelle

Counting things is still really hard.

MACHINE LEARNING

5

@texasmichelle

2

Agenda

Evolution of NLP architectures Components Guiding principles Implementations Future

1 3 4 5

6

@texasmichelle

In the beginning Yesteryear Today Tomorrow

Evolution of NLP architectures

Hand-crafted, artisan systems Purpose-built Cobbled-together with tools from

• ther domains

Future

7

@texasmichelle

Application examples

@texasmichelle

Web application

Frontend Orchestration Layer NLP Microservice Microservice Microservice Microservice Model Store OLAP OLTP

@texasmichelle

Data Warehouse

Analytics Layer NLP Microservice ETL Model Store OLAP OLTP OLTP OLTP

@texasmichelle

Data Pipeline

NLP Microservice Model Store OLTP Formatter

Source

Lookup

Serving REST server Prediction Featurization Model retrieval Training Model building Featurization Data segmentation Training data preparation Data analysis Data validation Data transformation Data ingestion

NLP microservice(s)

Cross-validation Evaluation Prediction Featurization Data segmentation

@texasmichelle

Web application

Frontend Orchestration Layer NLP Microservice Microservice Microservice Microservice Model Store OLAP OLTP

@texasmichelle

1 2

Agenda

Evolution of NLP architectures Components Guiding principles Implementations Future

3 4 5

14

@texasmichelle

Perception

Configuration Data Collection Data Verification Analysis Tools Feature Extraction

ML Code

Monitoring Serving Infrastructure Process Management Resource Management UI Application Logic

15

@texasmichelle

Reality

Configuration Data Collection Data Verification Analysis Tools Feature Extraction

ML Code

Monitoring Serving Infrastructure Process Management Resource Management UI Application Logic

16

@texasmichelle

Feature Extraction Data Ingestion Data Exploration Data Transformation Data Validation Data Analysis Training Data Segmentation Model Building Model Validation Model Versioning Model Auditing Distributed Training Continuous Training Process Management Configuration Resource Management Monitoring Logging Continuous Delivery Authentication/ Authorization Serving Infrastructure UI Business Logic Load Balancing

Data Featurization Training Application Platform 17

@texasmichelle

2

Agenda

Evolution of NLP architectures Components Guiding principles Implementations Future

1 3 4 5

18

@texasmichelle

Guiding principles

Robustness Resiliency Fault-tolerant High availability Autoscaling Constrained resource consumption Per microservice Versioning Models Data Hyperparameters System config Continuous delivery Optimize for person- hours

@texasmichelle

Guiding principles

Everything in one place Everything in source control Automation Tests Deployment Empowerment If you don't need to manage it yourself, don't Take it with you

Store everything Positive & negative training data Add feedback to the UI Logging Monitoring Communicate progress Goals Measure Traction Transparency

@texasmichelle

2

Agenda

Evolution of NLP architectures Components Guiding principles Implementations Future

1 3 4 5

21

@texasmichelle

Duolingo legacy

Source: Rewriting Duolingo's engine in Scala

@texasmichelle

Duolingo today

Source: Rewriting Duolingo's engine in Scala

• Redesigned architecture
• Refactored code from Python to Scala
• Latency dropped from 750ms to 14ms
• Engine uptime increased from 99.9% to 100%

@texasmichelle

architecture

24

Frontend Orchestration Layer Microservice Microservice Microservice NLP Microservice NLP Microservice

@texasmichelle

Qordoba on GCP

25

@texasmichelle

Qordoba

26

@texasmichelle

@texasmichelle

GitOps

• Optimizes for person-hours
• Empowers engineers & data scientists
• Cluster state is always recoverable, with a historical record

Create a new feature PR review Create a new feature PR review Deployment Verify feature Deployment Verify feature Create a new feature PR review Deployment Verify feature Create a new feature PR review Deployment Verify feature Create a new feature PR review Deploymen

@texasmichelle

Kubeflow

Who Data scientists ML researchers Software engineers Product managers Why Because building a platform is too big of a problem to tackle alone What Portable ML products on k8s 0.1 release

https://github.com/kubeflow/kubeflow

30

Make it easy for everyone to develop, deploy, & manage portable, scalable ML everywhere

Composability Single, unified tool for common processes Portability Entire stack Scalability Native to k8s Reduce variability between services & environments Full product lifecycle Support specialized hardware, like GPUs Reduce costs Improve model performance

31

Kubeflow

Kubernetes-native platform for ML Run wherever k8s runs Use k8s to manage ML tasks CRDs for distributed training Adopt k8s patterns Microservices Manage infra declaratively Package infrastructure components together Ksonnet Move between local -> dev -> test -> prod ->

• nprem

Support multiple ML frameworks Tensorflow Pytorch Scikit Xgboost Et al.

@texasmichelle

E2E Example

• GitHub Issue Summarization

○ How to summarize text and generate features from GitHub Issues using deep learning with Keras and TensorFlow https://github.com/kubeflow/examples/tree/master/github_issue_summarization

• Kubeflow installation with ksonnet
• Persistent disk usage
• Jupyterhub

Source: Hamel Husain

@texasmichelle

Exploration/experimentation

• Choose a dataset
• Slice and dice
• Try out various means of featurization
• Train a number of models & compare
• Plot various statistics along the way
• Jupyterhub on k8s

○ Security ○ Reproducibility ○ Resource allocation ○ Scale beyond a laptop ○ Centralized storage

@texasmichelle

E2E Example

• Scaling featurization and training

○ TFJob ○ tensor2tensor

• Model deployment with SeldonIO
• Accessing via a simple web app
• Teardown

@texasmichelle

Try it yourself

• GitHub: https://github.com/kubeflow/examples/tree/master/github_issue_summarization
• Katacoda: https://www.katacoda.com/kubeflow
• http://gh-demo.kubeflow.org/

Jeremy Lewi Ankush Agarwal

Special thanks

Just the beginning

• Easier setup
• Utilize more k8s features
• Add support for packages, frameworks,

libraries, and example models

• You tell us! Get involved

○ github.com/kubeflow ○ kubeflow.slack.com ○ @kubeflow ○ kubeflow-discuss@googlegroups.com

@texasmichelle

2

Agenda

Evolution of NLP architectures Components Guiding principles Implementations Future

1 3 4 5

37

@texasmichelle

OK Google, build me a classifier.

Future Michelle

July 24-27, 2018 San Francisco g.co/next18
