ANGLUIN'S ALGORITHM FOR LEARNING REGULAR SETS Ullas Aparanji DISCLAIMER The speaker takes no responsibility for any mental, psychological, emotional or spiritual mutilation or damage caused as a result of this talk. Construct a DFA to

slide-1
SLIDE 1

ANGLUIN'S ALGORITHM FOR LEARNING REGULAR SETS

Ullas Aparanji

slide-2
SLIDE 2

DISCLAIMER

  • The speaker takes no responsibility for any

mental, psychological, emotional or spiritual mutilation or damage caused as a result of this talk.

slide-3
SLIDE 3
slide-4
SLIDE 4

Construct a DFA to accept all strings

  • ver {a,b} which have an even

number of a's and an even number

  • f b's
slide-5
SLIDE 5

THE END

slide-6
SLIDE 6

L* Algorithm

  • Learns a DFA
  • Teacher
  • Oracle
  • Membership queries
  • Equivalence queries
  • Minimally Adequate Teacher
slide-7
SLIDE 7
slide-8
SLIDE 8

NOTATIONS

  • U: Unknown language to be learnt
  • A: Alphabet
slide-9
SLIDE 9

OBSERVATION TABLE

  • S: Non-empty finite prefix-closed set of strings
  • E: Non-empty finite suffix-closed set of strings
  • T: Mapping from finite set of strings to {0,1}
  • T(u) = 1 iff u belongs to U
slide-10
SLIDE 10

Which of these sets are prefix- closed?

  • {1110, 10, 1}
  • {011, 0, λ, 11, 01}
  • {110, 1, 0, λ, 11}
  • {0, λ, 10, 010}
slide-11
SLIDE 11

Which of these sets are suffix- closed?

  • {1110, 10, 1}
  • {011, 0, λ, 11, 01}
  • {110, 1, 0, λ, 11}
  • {0, λ, 10, 010}
slide-12
SLIDE 12
slide-13
SLIDE 13

OBSERVATION TABLE

  • Rows: Elements of S U S.A
  • Columns: Elements of E
  • Entry in row s and column e contains T(s.e)
  • Initially S = E = { λ }
  • row(s) denotes row of the table corresponding

to s

slide-14
SLIDE 14

What is row(a)? row(λ)?

slide-15
SLIDE 15

TWO CRUCIAL PROPERTIES

  • CLOSED: An observation table is closed if for

all t belonging to S.A, there exists an s belonging to S such that row(t) = row(s)

  • CONSISTENT: An observation table is

consistent if whenever s1, s2 (both belonging to S) satisfy row(s1) = row(s2), then for all a belonging to A, row(s1.a) = row(s2.a)

slide-16
SLIDE 16

Is this closed?

λ a aa aaa λ 1 a b 1

slide-17
SLIDE 17

Is this closed?

λ a λ 1 a 1 aa ab aaa 1 aab

slide-18
SLIDE 18

Is this closed?

λ a λ 1 a 1 1 aa ab aaa 1 aab

slide-19
SLIDE 19

Is this closed?

λ a λ 1 a aa ab aaa aab

slide-20
SLIDE 20

Is this consistent?

λ a aa aaa λ 1 a b 1

slide-21
SLIDE 21

Is this consistent?

λ a λ 1 a 1 aa ab aaa 1 aab

slide-22
SLIDE 22

Is this consistent?

λ a λ 1 a 1 1 aa ab aaa 1 aab

slide-23
SLIDE 23

Is this consistent?

λ a λ 1 a aa ab aaa aab

slide-24
SLIDE 24

Is this closed? Is it consistent?

slide-25
SLIDE 25

The DFA

  • Construct a DFA M(S, E, T) corresponding to

closed and consistent table.

  • Alphabet A
  • State set Q
  • Initial state q0
  • Accepting state set F
  • Transition function δ
slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31

Assume counterexample = bb

slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34

Let counterexample = abb

slide-35
SLIDE 35
slide-36
SLIDE 36
slide-37
SLIDE 37
slide-38
SLIDE 38

Construct DFA that accepts all binary strings divisible by 3

slide-39
SLIDE 39

THE END

slide-40
SLIDE 40
  • Angluin, Dana. "Learning regular sets from

queries and counterexamples." Information and computation 75.2 (1987): 87-106.
