Analyzing the Performance of Mobile Web: Challenges and Techniques

ARIYA HIDAYAT ENGINEERING DIRECTOR

Going Under the Hood

whoami

Overview

Performance Areas

Network Graphics JavaScript

Desktop Tools

Firebug Web Inspector dynaTrace Speed Tracer Page Speed YSlow Blaze.io WebPageTest pcapperf WebMetrics

Mobile Situation

Metrics

• framerate
• bytes transferred
• caching
• cookies
• cache manifest
• code size
• execution speed

Network Variances

2G, EDGE, 3G, 4G, LTE, ...

Continous Integration

“Too Many Phones Will Kill You...”

Stake Holders

Browser vendors Web Site Developers Application Developers Service Provider

Approaches

Inject instrumentation Read the source code Proxy High-speed Camera

Intrusive Emulation Observation

Benchmark RF Monitor Remote inspection

Strategies

1

Replicate and/or analyze on desktop

2

Tweak and insert instrumentation

Reducing complexity System level

Caveats

Concept Focus

Tools of Trade

Nexus One Gingerbread

http://source.android.com/source/building-devices.html

Headless WebKit

http://www.phantomjs.org https://github.com/ariya/phantomjs

“Full web stack. No browser required”

Source Code

WebKit V8

http://code.google.com/p/v8/ http://www.webkit.org/ http://android.git.kernel.org/?p=platform/external/webkit.git http://opensource.apple.com/

Different WebKit “Ports”

WebCore graphics

Mac iOS Chromium Android Qt Gtk CoreGraphics Skia QPainter Cairo

graphics stack

GraphicsContext

Network

“Understanding Mobile Web Browser Performance” Rajiv Vijayakumar (Qualcomm)

Wed 2:40 pm, Ballroom ABCD

Web Inspector Network

HTTP Archive (HAR)

http://www.softwareishard.com/blog/har-12-spec/

Automating Network Sniffing (Desktop)

phantomjs netsniff.js http://m.bing.com

Visualize using online HAR viewer

Android WebKit + Network Stack

WebView libwebcore

Java C++

Browser

Java JNI

Network Stack

Java

Real-time Sniffing + Postprocessing

waiting data transfer

WebCoreResourceLoader::Finished() WebCoreResourceLoader::AddData(...) WebFrame::startLoadingResource

06-12 22:57:48.430 D/webcoreglue( 1357): startLoadingResource NETWORK 0x66d368 http://en.m.wikipedia.org/wiki/ Orchid 06-12 22:57:48.710 D/webcoreglue( 1357): ReceivedResponse NETWORK handle=0x66d368 mimeType=text/html url=http:// en.m.wikipedia.org/wiki/Orchid 06-12 22:57:48.780 D/webcoreglue( 1357): startLoadingResource NETWORK 0x6a8678 http://en.m.wikipedia.org/ stylesheets/android.css 06-12 22:57:48.780 D/webcoreglue( 1357): startLoadingResource NETWORK 0x6ab388 http://en.m.wikipedia.org/ javascripts/jquery.js 06-12 22:57:48.790 D/webcoreglue( 1357): startLoadingResource NETWORK 0x6ab7e8 http://en.m.wikipedia.org/ javascripts/application.js 06-12 22:57:48.790 D/webcoreglue( 1357): AddData NETWORK 0x66d368 4162 http://en.m.wikipedia.org/wiki/Orchid 06-12 22:57:48.790 D/webcoreglue( 1357): AddData NETWORK 0x66d368 8192 http://en.m.wikipedia.org/wiki/Orchid 06-12 22:57:48.790 D/webcoreglue( 1357): AddData NETWORK 0x66d368 1361 http://en.m.wikipedia.org/wiki/Orchid 06-12 22:57:48.980 D/webcoreglue( 1357): AddData NETWORK 0x66d368 8192 http://en.m.wikipedia.org/wiki/Orchid 06-12 22:57:48.980 D/webcoreglue( 1357): AddData NETWORK 0x66d368 803 http://en.m.wikipedia.org/wiki/Orchid 06-12 22:57:49.000 D/webcoreglue( 1357): AddData NETWORK 0x66d368 4702 http://en.m.wikipedia.org/wiki/Orchid 06-12 22:57:49.000 D/webcoreglue( 1357): AddData NETWORK 0x66d368 4507 http://en.m.wikipedia.org/wiki/Orchid 06-12 22:57:49.020 D/webcoreglue( 1357): AddData NETWORK 0x66d368 8192 http://en.m.wikipedia.org/wiki/Orchid 06-12 22:57:49.050 D/webcoreglue( 1357): AddData NETWORK 0x66d368 6750 http://en.m.wikipedia.org/wiki/Orchid

Example: Orchid

adb logcat -v time | grep NETWORK

Example: Orchid

Going Offline: Cache Manifest

https://github.com/jamesgpearce/confess phantomjs confess.js http://functionsource.com

Automatic local storage optimization

Graphics

Drawing Command Analysis

GraphicsContext WebCore graphics

Skia

Log file

Example: Bing

platformInit savePlatformState translate 0,0 translate 0,0 clip 1,0 0x6.95322e-310 fillRect 0,0 800x556 color ff ff ff ff restorePlatformState platformDestroy platformInit savePlatformState translate 0,0 translate 0,0 clip 1,0 0x6.95322e-310 fillRect 0,0 800x556 color ff ff ff ff restorePlatformState platformDestroy platformInit savePlatformState translate 0,0 translate 0,0 clip 1,0 0x6.95322e-310 fillRect 0,0 800x556 color ff ff ff ff fillRect 0,0 800x556 color ff ff ff ff

Painting Traces

Display List Aproach

GraphicsContext WebKit

Skia

“SkPicture”

no overhead anmore

How Fast is the “Playback”?

#include "TimeCounter.h" bool WebViewCore::drawContent(SkCanvas* canvas, SkColor) { uint32_t timestamp = getThreadMsec(); .... painting code .... DBG_SET_LOGD("% ms", getThreadMsec() - timestamp); }

external/webkit/WebKit/android/jni/WebViewCore.cpp

Example: Google News

16:24:04.070 D/webcoreglue( 273): drawContent 11 ms 16:24:04.110 D/webcoreglue( 273): drawContent 13 ms 16:24:04.150 D/webcoreglue( 273): drawContent 13 ms 16:24:04.190 D/webcoreglue( 273): drawContent 10 ms 16:24:04.240 D/webcoreglue( 273): drawContent 10 ms 16:24:04.280 D/webcoreglue( 273): drawContent 13 ms 16:24:04.320 D/webcoreglue( 273): drawContent 13 ms 16:24:04.360 D/webcoreglue( 273): drawContent 13 ms 16:24:06.080 D/webcoreglue( 273): drawContent 12 ms 16:24:06.140 D/webcoreglue( 273): drawContent 10 ms 16:24:06.180 D/webcoreglue( 273): drawContent 13 ms 16:24:06.230 D/webcoreglue( 273): drawContent 14 ms 16:24:06.600 D/webcoreglue( 273): drawContent 26 ms 16:24:06.640 D/webcoreglue( 273): drawContent 13 ms 16:24:06.860 D/webcoreglue( 273): drawContent 33 ms 16:24:06.890 D/webcoreglue( 273): drawContent 12 ms 16:24:06.930 D/webcoreglue( 273): drawContent 13 ms 16:24:06.960 D/webcoreglue( 273): drawContent 13 ms 16:24:07.000 D/webcoreglue( 273): drawContent 13 ms

adb logcat -v time | grep drawContent

How Much is the Frame Rate?

bool WebViewCore::drawContent(SkCanvas* canvas, SkColor color) { static uint32_t frame_ref = 0; static int frame_tick = 0; ... painting code ... frame_tick++; if (frame_tick >= 10) { DBG_SET_LOGD("framerate %d fps", (int)(frame_tick * 1000 / (1 + getThreadMsec() - frame_ref))); frame_tick = 0; frame_ref = getThreadMsec(); } }

Site Mirroring

https://github.com/ariya/X2

network/netspiegel

Proxy

Intertubes port 8080 SQLite DB

Mirror

port 8081

JavaScript

Remote Console

http://github.com/senchalabs/android-tools

http://www.sencha.com/blog/remote-javascript-debugging-on-android/

Garbage Collector

bool Heap::CollectGarbage(int requested_size, AllocationSpace space) { .. some code ... PerformGarbageCollection(space, collector, &tracer); LOGD("PerformGarbageCollection %d", requested_size); .. some code ... }

external/v8/src/heap.cc

Example: Travelmate

06-13 13:24:36.470 D/v8 ( 532): PerformGarbageCollection 20 06-13 13:24:36.630 D/v8 ( 532): PerformGarbageCollection 32788 06-13 13:24:36.740 D/v8 ( 532): PerformGarbageCollection 116 06-13 13:24:36.810 D/v8 ( 532): PerformGarbageCollection 88 06-13 13:24:36.870 D/v8 ( 532): PerformGarbageCollection 52 06-13 13:24:37.000 D/v8 ( 532): PerformGarbageCollection 20 06-13 13:24:37.090 D/v8 ( 532): PerformGarbageCollection 24 06-13 13:24:37.450 D/v8 ( 532): PerformGarbageCollection 35884 06-13 13:24:39.400 D/v8 ( 532): PerformGarbageCollection 20 06-13 13:24:39.730 D/v8 ( 532): PerformGarbageCollection 3392

adb logcat -v time | grep GarbageCollection

Keyword vs Identifier

instanceof instanceComponent

requires checking 9 chars

a g h j k l m o p q x y z

Function Parsing

foobar = function(x, y, z) { .... } foobar(x, y, z);

Analyze the syntax Mark the position of function ‘foobar’ Compile and run the function ‘foobar’

Static Code Analysis

hammerjs --syntax source-file.js https://github.com/senchalabs/hammerjs

JSON syntax tree

Reflect.parse(code)

Syntax Tree

Variable Declaration Identifier Literal Constant

answer 42 var answer = 42;

keyword equal sign identifier number

"type": "IfStatement", "test": { "type": "BinaryExpression", "operator": "==", "left": { "type": "Identifier", "name": "x" }, "right": { "type": "Identifier", "name": "y" } }, "consequent": { "type": "ExpressionStatement", "expression": { "type": "CallExpression", "callee": { "type": "Identifier", "name": "foo" }, "arguments": [] } }, "alternate": null

if (x == y) foo();

Danger!

Deploy-time Pruning

function createList(position, options) { ... some code ... } createList({ x: 0, y: 0}); createList({ x: 0, y: 100});

Never used

Avoid Object Construction

startTime = new Date(); // heavy processing elapsed = (new Date()) - startTime; startTime = Date.now(); // heavy processing elapsed = Date.now() - startTime;

Create + Destroy

Irrelevant Platforms

if (typeof object.attachEvent !== 'undefined') { // Internet Explorer < 9

• bject.attachEvent('on'+ev, createWrapper(func));

} else { // DOM Level 3

• bject.addEventListener(ev, func);

}

Does not apply in Mobile

User Interactions

Event Recorder & Player

http://www.sencha.com/blog/event-recorder-for-android-web-applications/

Conclusion

Today

Replicate and analyze on desktop Find, look at, and understand the source code Tweak at the system level + post-processing

Future

More built-in instrumentation Remote inspection API for test automation

THANK YOU!

ariya.hidayat@gmail.com @ariyahidayat ariya.blogspot.com
