Analyzing Simulated Data Matthew Turk There is only one sky. (but there are many simulation codes) Different methods, data structures, assumptions, IO methods, units, variable names, ... Analysis. astro-ph/1011.3514 yt-project.org

slide-1
SLIDE 1

Analyzing Simulated Data

Matthew Turk
slide-2
SLIDE 2

There is only one sky.

(but there are many simulation codes)

slide-3
SLIDE 3
slide-4
SLIDE 4

Different methods, data structures, assumptions, IO methods, units, variable names, ...

slide-5
SLIDE 5
slide-6
SLIDE 6
slide-7
SLIDE 7

Analysis.

slide-8
SLIDE 8

astro-ph/1011.3514 yt-project.org

slide-9
SLIDE 9
slide-10
SLIDE 10
slide-11
SLIDE 11
slide-12
SLIDE 12

install script: Full dependency stack Source code Development environment GUI Sample data

slide-13
SLIDE 13

yt has been designed to address physical, not computational, entities.

slide-14
SLIDE 14

Process

◮ Read ◮ Correlate ◮ Process ◮ Visualize
slide-15
SLIDE 15
slide-16
SLIDE 16

The Universe is full of gas, dark matter and stars. yt makes it easy to access that material.

slide-17
SLIDE 17

Transparent IO, masking of overlapping data, load-on-demand, geometric and non- geometric selection, field generation, and common interfaces to different datatypes.

slide-18
SLIDE 18

Enzo, Orion, CASTRO, FLASH Chombo, Tiger, Athena, ART, RAMSES

yt is designed to be the lingua franca

  • f astrophysical codes.
slide-19
SLIDE 19

Objects (conceptual, uniformly accessible NumPy stores)

slide-20
SLIDE 20

Objects

Orthogonal Rays Non-orthogonal Rays 1D Slices Oblique Slices Projections 2D Spheres Rectangular Prisms Disks/Cylinders Inclined Boxes Clumps Extracted Regions Boolean combinations 3D

slide-21
SLIDE 21

Objects All respect unified interface: from yt.mods import * pf = load(“DataDump0155.dir/DataDump0155”) ray = pf.h.ray([0.1, 0.2, 0.5], [0.4, 0.9, 0.1]) print ray[“Density”]

slide-22
SLIDE 22

Objects All respect unified interface: from yt.mods import * pf = load(“DataDump0155.dir/DataDump0155”) sl = pf.h.slice(0, 0.5) print sl[“Density”]

slide-23
SLIDE 23

Objects All respect unified interface: from yt.mods import * pf = load(“DataDump0155.dir/DataDump0155”) sp = pf.h.sphere(100.0/pf[‘au’], ‘max’) print sp[“Density”]

slide-24
SLIDE 24

from yt.mods import * pf = load(“DataDump0155.dir/DataDump0155”) v, c = pf.h.find_max(“Density”)

slide-25
SLIDE 25

Adding new fields should be easy.

slide-26
SLIDE 26

from yt.mods import * @derived_field(“Pressure”) def Pressure(field, data): return (data.pf["Gamma"] - 1.0) * \ data["Density"]*data["ThermalEnergy"]

slide-27
SLIDE 27

Scripts should be simple and clear.

slide-28
SLIDE 28

from yt.mods import * pf = load(“DataDump0155.dir/DataDump0155”) pc = PlotCollection(pf) pc.add_phase_sphere(1000.0, ‘au’, [“Density”, “Temperature”, “H2I_Fraction”]) pc.save()

slide-29
SLIDE 29

from yt.mods import * pf = load(“DataDump0155.dir/DataDump0155”) pc = PlotCollection(pf) pc.add_phase_sphere(1000.0, ‘au’, [“Density”, “Temperature”, “CellMassMsun”], weight = None) pc.save()

slide-30
SLIDE 30

Slices

slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33 from yt.mods import * pf = load(’galaxy0030/galaxy0030’) p = SlicePlot(pf, 2, ’Density’, ’c’, (200,’kpc’)) p.save(’Galaxy’)
slide-34
SLIDE 34
slide-35
SLIDE 35 from yt.mods import * pf = load(’galaxy0030/galaxy0030’) p = SlicePlot(pf, 2, ’Density’, ’c’, (200,’kpc’)) p.set_width(20, ’kpc’) p.save("GalaxyZoom")
slide-36
SLIDE 36
slide-37
SLIDE 37

(px, py, pdx, pdy, z)

Projections

slide-38
SLIDE 38
slide-39
SLIDE 39 from yt.mods import * pf = load(’galaxy0030/galaxy0030’) p = ProjectionPlot(pf, 2, ’Density’, ’c’, (20,’kpc’)) p.save(’Galaxy’)
slide-40
SLIDE 40
slide-41
SLIDE 41

Oblique Slices

slide-42
SLIDE 42

Off-axis Projection

slide-43
SLIDE 43

Project once, pixelize many

slide-44
SLIDE 44

(px, py, pdx, pdy, z)

Image Buffer

slide-45
SLIDE 45

(px, py, pdx, pdy, z)

Image Buffer

slide-46
SLIDE 46

Parallelism

slide-47
SLIDE 47

Parallelism

Embarassingly Parallel Spatial Decomposition Decomposed by load or IO characteristics Helper functions to decompose the domain

slide-48
SLIDE 48

Parallelism

Embarassingly Parallel Spatial Decomposition Quantities Profiles Slices Projections Volume Rendering Halo Finding

slide-49
SLIDE 49
slide-50
SLIDE 50
slide-51
SLIDE 51

Multi-level parallelism: dynamic workgroups, communicators, subgroups and task queues

slide-52
SLIDE 52

Volume Rendering

slide-53
SLIDE 53

dIν ds = jν − ανIν

Designed around integrating through a volume: visualization is a side effect.

slide-54
SLIDE 54
slide-55
SLIDE 55

from yt.mods import * pf = load(“DD1701/DD1701”) v, c = pf.h.find_max("Density") L = [1.0, 1.0, 1.0] W = 100.0/pf['mpc'] tf = vr.PlanckTransferFunction() cam = pf.h.camera(c, L, W, 1024, tf) cam.snapshot()

slide-56
SLIDE 56
slide-57
SLIDE 57
slide-58
SLIDE 58
slide-59
SLIDE 59

Canned Analysis Tasks

slide-60
SLIDE 60

Absorption Spectrum Coordinate Transformations Halo Finding Mass Functions Merger Trees Halo Profiling Level Sets Light Cones Light Rays Time Series Star Analysis Two-Point Analysis

slide-61
SLIDE 61

Level Sets

slide-62
SLIDE 62

Synthetic Spectra

slide-63
SLIDE 63

Two-Point Functions

slide-64
SLIDE 64

Three Halo Finders: Standard HOP Friends of Friends Parallel HOP Rockstar (beta)

slide-65
SLIDE 65
slide-66
SLIDE 66

co-scheduled & in situ viz

slide-67
SLIDE 67

Simulation yt

Process

Thin NumPy wrappers and stop-n-go

slide-68
SLIDE 68

On Disc → In-situ

slide-69
SLIDE 69

Simulation yt

Inter-comm

Fire and forget, no embedded interpreter

slide-70
SLIDE 70

Developing as a Team

slide-71
SLIDE 71

Code review: eyes on (nearly) every changeset

slide-72
SLIDE 72

Forky development: very low barrier to entry; everything comes in the box.

slide-73
SLIDE 73

Testing: answer as well as integration tests get run every 30 minutes.

slide-74
SLIDE 74

80,000 lines of code Python, Cython, C 20 contributors (60+ users) Contributors from 10+ institutions

8AM 6PM

slide-75
SLIDE 75
slide-76
SLIDE 76
slide-77
SLIDE 77
slide-78
SLIDE 78
slide-79
SLIDE 79
slide-80
SLIDE 80
slide-81
SLIDE 81
slide-82
SLIDE 82
slide-83
SLIDE 83

Contributors

Tom Abel David Collins Andrew Cunningham Nathan Goldbaum Cameron Hummels Ji-hoon Kim Steffen Klemer Kacper Kowalik Michael Kuhlen Eve Lee Chris Malone Chris Moody Andrew Myers Jeff Oishi Jean-Claude Passy Thomass Robitaille Anna Rosen Anthony Scopatz Devin Silvia Sam Skillman Stephen Skory Britton Smith Geoffrey So Casey Stark Elizabeth Tasker Rick Wagner John Wise John ZuHone
slide-84
SLIDE 84

How to get started

http://yt-project.org/ http://yt-project.org/issac2012/
