THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING COLLEGE OF ENGINEERING Aegir Hosting System One Drupal to Rule Them All THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING Agenda: Aegir Hosting System Introduction Challenges maintaining

slide-1
SLIDE 1

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Aegir Hosting System

One Drupal to Rule Them All

COLLEGE OF ENGINEERING

slide-2
SLIDE 2

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Agenda: Aegir Hosting System

  • Introduction

– Challenges maintaining sites – How Aegir can help

  • Using Aegir

– Core components – Servers, sites, and platforms – Live demo

  • Advanced Topics

– Details – Gotchas – Awesomeness – References

slide-3
SLIDE 3

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Intro: Aegir Hosting System Aegir @ Ohio State University

– 3-4 known Aegir instances – 300+ sites in Aegir and rapidly growing.

My Experience

– Almost 2 years starting with 0.4 – Written some internal extensions. – 100+ sites

Why Aegir?

– Encourages some best practices. – Order of magnitude efficiency savings with high volumes of sites. – Works for few or many sites (once you understand it).

slide-4
SLIDE 4

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Intro | Challenges: Create a Site from Scratch

  • 1. Create a database
  • 2. Create a database user
  • 3. Copy Drupal files out to a web server
  • 4. Set appropriate file permissions
  • 5. Configure Apache
  • 6. Run Drupal installer
slide-5
SLIDE 5

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Intro | Challenges: Upgrade a Site

  • 1. Take site offline (maintenance mode)
  • 2. Make a backup
  • 3. Update files
  • 4. Run update.php
  • 5. Apply any manual configuration changes.
  • 6. Take site out of maintenance mode.
slide-6
SLIDE 6

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Intro | Challenges: Other Concerns

  • 1. Testing changes
  • 2. Staging environments
  • 3. Regular backups
  • 4. Software audits
  • 5. Repeatable deployments
  • 6. General administration
slide-7
SLIDE 7

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Intro | Challenges: Options

  • Maintain by hand

– You manage everything – Easy to start out – Doesn’t scale well

  • Become a Drush ninja

– You manage everything Now with scripts! – Scales as well as you

  • Use Aegir

– Setup requires knowledge – Novice can manage sites – Expert can use Drush-fu – Encourages best practices

slide-8
SLIDE 8

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Intro | Challenges: #Drupal Sites vs Cost to Sanity

slide-9
SLIDE 9

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Intro | Aegir: One Drupal to Rule Them All Aegir can manage

  • Apache, Nginx
  • MySQL
  • Drupal sites & platforms
  • Upgrades
  • Backups

But wait, there’s more!

  • Free Drush CLI!
  • Learn best practices!
  • So easy, anyone can use!
  • Now midi-chlorian free!
slide-10
SLIDE 10

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Intro | Aegir: Hosting - a website to manage websites

slide-11
SLIDE 11

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Intro | Aegir: Provision - Drush extension backend

Sh-3.2$ drush | grep provision provision-backup Generate a back up for the site. provision-backup_del Delete a backup file. provision-clone Clone a site between platforms. provision-delete Delete a site. provision-deploy Deploy an existing backup to a new url. provision-disable Disable a site. provision-enable Enable a disabled site. provision-import Import site to provision provision-install Provision a new site using the provided data. provision-lock Lock a platform from having any other sites. provision-login_rese Generate a one-time login reset URL. provision-migrate Migrate a site between platforms. provision-restore Restore the site to a previous backup. provision-save Save Drush alias provision-unlock Unlock a platform provision-verify Verify the framework is correctly installed. provision-zone Manipulate a zonefile

slide-12
SLIDE 12

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Servers: Web or Database

Web Servers

  • Apache
  • Nginx

Database

  • MySQL

Servers have:

  • IP Address(es)
  • Port(s)
  • Credentials
  • Etc
slide-13
SLIDE 13

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Servers: Web or Database

slide-14
SLIDE 14

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Platforms: Root of a Multi-Site Install

OpenAtrium-rc1

  • puppies.com
  • kittens.org

OpenPublic-beta1

  • billthecat4pres.com
  • toonces4gov.com

A platform can have multiple sites but can reside only on one web server.

slide-15
SLIDE 15

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Platforms: Create a Platform

http://www.youtube.com/watch?v=A_QIvMLoouI

slide-16
SLIDE 16

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Sites: Your Websites

OpenAtrium-rc1 @ server1

  • puppies.com
  • kittens.org

OpenPublic-beta1 @ server2

  • billthecat4pres.com
  • toonces4gov.com

Sites are tied to a DB server and platform. The platform determines which web server the site runs on.

slide-17
SLIDE 17

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Sites: Create a Site

http://www.youtube.com/watch?v=jbJefaWUE-0

slide-18
SLIDE 18

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Migrations: Upgrade One or Many Sites

  • 1. Create a new platform with the upgraded code.
  • 2. Migrate sites (or entire platforms) to the new platform.

Open Atrium Beta 2

Site 1 Site 2 Site 3

Open Atrium Beta 2

slide-19
SLIDE 19

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Upgrades: Upgrade One or Many Sites

http://www.youtube.com/watch?v=KD5KQTkj4Lk

slide-20
SLIDE 20

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Backups: Manual and Automatic

  • Upgrades and other actions automatically create backups.
  • You can manually create/restore backups from web ui.
  • Backups are stored locally (/var/aegir/backup)
  • You can restore backups to another Aegir instance (with a

little work)

slide-21
SLIDE 21

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Backups: How to Backup / Restore a Site

http://www.youtube.com/watch?v=YCIRmtf_RV4

slide-22
SLIDE 22

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Using Aegir | Cloning: Make a copy of your site

  • Works just like an upgrade/migration.
  • Great way to test a migration.
  • Can be a way to get a test copy of a site.
slide-23
SLIDE 23

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Migrate+Rename/Cloning: Under the Hood

When we migrated/cloned from puppies.com to the-puppy.com… How did this… <img src=“/sites/puppies.com/files/vienna-sausages.png”> Get changed to this… <img src=“/sites/the-puppy.com/files/vienna-sausages.png”> Aegir fixes some content programmatically. It also adds this alias /files/vienna-sausages.png

slide-24
SLIDE 24

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Hooking In: vhost configuration

Aegir regenerates your vhost configuration (all the time). /var/aegir/.drush/<whatever>.drush.inc

<?php function <whatever>_provision_apache_vhost_config($uri, $data) { if ($uri == “abc.com") { return array("php_value upload_max_filesize 100M", "php_value post_max_size 200M"); } } ?> See also pre.d and post.d vhost configuration http://community.aegirproject.org/node/341

slide-25
SLIDE 25

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Hooking In: settings.php

Aegir regenerates your settings.php file (all the time). This file is included at the end of your Aegir controlled settings.php /var/aegir/platforms/sites/<yoursite>/local.settings.php For example, you might want to configure a maintenance theme.

<?php $conf['maintenance_theme'] = 'themeName'; ?>

slide-26
SLIDE 26

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Installation: Easy or Hard Vanilla Aegir

  • If you use Ubuntu/Debian, you can use apt-get.

http://community.aegirproject.org/node/400

  • If you use RHEL/Centos/etc, you can use the manual instructions.

It’s pretty well documented, but budget a couple hours. http://community.aegirproject.org/installing/manual

Omega8cc Alternatives to Vanilla (on d.org/projects)

Barracuda

Barracuda is a bash script to install and/or upgrade, tuned for high performance, Aegir Master Instance with all related system services.

Octopus

Octopus is a bash script to install and/or upgrade, tuned for high performance, Aegir Satellite Instances, compatible with Barracuda

slide-27
SLIDE 27

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Gotchas: Multi-Server Architecture Hub Spoke Model

Master Server

  • Has a copy of everything (sort of).
  • Migrations go through it.
  • Web Server 1
  • Platform A
  • Site 1
  • Web Server 2
  • Platform B
slide-28
SLIDE 28

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Gotchas: Multi-Server $#@! Data Loss

There is a long standing data loss bug in which the files directory on the hub sometimes

  • verwrites data on the spoke.

There are various patches in the issue queue none of which quite work. We solved it by hacking our Aegir instance to rsync files from the spoke to hub prior to many

  • ther actions.

Bug Report http://drupal.org/node/1083366 Why! Why was I programmed to feel pain?

slide-29
SLIDE 29

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Gotchas: Site Specific Modules/Themes

Site-specific modules/themes not super well supported in multi-server. The original recommendation was to make a site specific install profile and put them there. At some point they made the hub the authority but this doesn’t work with things like apps so it’s still debated. Bug Report http://drupal.org/node/1561102

slide-30
SLIDE 30

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Gotchas: Multi-Server Cron Runs Where?

Cron can run two ways:

  • Wget (on spoke)
  • Drush (on hub)

If your cron works with files (creating, updating, reading), you can’t use drush via Aegir in a Multi-Site environment. Feature Request Aegir 2.0 http://drupal.org/node/1080758

slide-31
SLIDE 31

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Gotchas: Security

Traditional mod_php issues apply. In addition… Aegir user has access to all sites/dbs/web-roots/servers. Site X’s code can run as Aegir user

  • hook_init
  • drush.inc
  • etc

Bug Report http://drupal.org/node/762138 Provision ACL helps http://drupal.org/project/provisionacl

slide-32
SLIDE 32

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Awesomeness: SaaS Business Models

Couples buy a wedding website. Order page is an Aegir signup form. Purchase immediately provisions a new site. Blog post on it.

http://scotthadfield.ca/2010/06/15/overview-site-building-wedful-drupal-install-profiles-aegir-and-features

Clients purchase subscriptions to Open Atrium instances which are deployed through Aegir. DrupalCon London Talk

http://london2011.drupal.org/conference/sessions/aegir-based-business-models

Writeup:

http://community.openatria.com/team/saas-business-model

slide-33
SLIDE 33

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | Awesomeness: Continuous Integration

Mig5 (an Aegir developer) has a wonderful tutorial on continuous integration with Jenkins and Aegir. Also, Mike Butsko (OSU ASC tech) presenting on Jenkins later today and he uses Aegir too.

http://mig5.net/content/zero-touch-drupal-deployment-jenkins-aegir-git-fabric-and-drush.html

slide-34
SLIDE 34

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | References: Aegir Vendors

All vendors on this page are core Aegir developers. Koumbit provides upper end Aegir IaaS and SaaS solutions (in addition to development and traditional web hosting. Omega8.cc specializes more in Aegir. Their

  • ffering is very slick and arguably the

cheapest/fastest way to get into Aegir. Mig5 offers consulting services. He’s probably the best company in Aegir consulting and can help with things like dev-ops workflows.

slide-35
SLIDE 35

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | References: Other Aegir Tricks

Clients http://community.aegirproject.org/node/28 SSL keys and certificates http://community.aegirproject.org/content/content/administrator/po st-install-configuration/using-ssl Aegir can manage DNS zonefiles http://community.aegirproject.org/administrator/dns Aegir notes on Varnish and Memcache http://community.aegirproject.org/node/388

slide-36
SLIDE 36

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Advanced | References: Extensions

Ubercart (w\quotas) HTTP basic auth HTTP basic LDAP Feeds Rules Git Subfolders Backup Garbage Collection Services Puppet Remote Import Varnish Boost ACLs CivilCRM Koumbit Platforms CDN New Relic Etc… More here…. http://community.aegirproject.org/contrib-modules

slide-37
SLIDE 37

THE OHIO STATE UNIVERSITY COLLEGE OF ENGINEERING

Questions:

What questions do you have?
