Advanced Networking at Flinders University, South Australia the last 6 months . Colin Carati on behalf of Flinders University colin.carati@flinders.edu.au; www.flinders.edu.au where are we ? Bariatric Surgery - 3-way live link November

slide-1
SLIDE 1

Advanced Networking at Flinders University, South Australia the last 6 months ….

Colin Carati … on behalf of Flinders University

colin.carati@flinders.edu.au; www.flinders.edu.au

slide-2
SLIDE 2

where are we ?

slide-3
SLIDE 3

Bariatric Surgery - 3-way live link

November 2005 Adelaide

Colin Carati colin.carati@flinders.edu.au

Singapore

Lim Sew Hoo

Fukuoka

Shuji Shimizu Prof Koji Okamura Ishii Motohiro Greg Morris Jummain AARNet SINET

slide-4
SLIDE 4

APAN Medical Working Group …. what was special about this event ?…

  • new nodes – Adelaide, Singapore
  • first live surgery to multiple very distant

sites

  • DVTS - PAL versus NTSC video

standards

slide-5
SLIDE 5

Advanced Network for Training in Bariatric Surgery

  • Laparoscopic gastric banding

– Flinders Medical Centre

  • training of practising surgeons
  • 1-2 day seminars using Access Grid / DTVS
  • follow-up – mentoring / guidance by real-time

HDV of first few operations

  • Kyushu University, Flinders University, NUS,
  • thers ?
slide-6
SLIDE 6

Network Configuration – Live Surgery Link – Adelaide, Kyushu, Singapore FU / FMC, Adelaide Kyushu Uni, Japan NUS, Singapore Kyushu University Computing Centre

C:¥>tracert 133.5.10.10 Tracing route to namiko.ec.kyushu-u.ac.jp [133.5.10.10]

  • ver a maximum of 30 hops:

1 <1 ms <1 ms <1 ms 129.96.120.1 2 <1 ms <1 ms <1 ms gigabitethernet1.er1.flinders.cpe.aarnet.net.au [202.158.199.225] 3 1 ms <1 ms <1 ms ge-1-0-8.bb1.a.adl.aarnet.net.au [202.158.199.201] 4 9 ms 9 ms 9 ms so-0-1-0.bb1.a.mel.aarnet.net.au [202.158.194.18] 5 21 ms 21 ms 21 ms so-0-1-0.bb1.b.syd.aarnet.net.au [202.158.194.34] 6 22 ms 21 ms 21 ms ge-0-0-0.bb1.a.syd.aarnet.net.au [202.158.194.45] 7 116 ms 116 ms 116 ms so-0-1-0.bb1.a.hnl.aarnet.net.au [202.158.194.106] 8 166 ms 166 ms 166 ms so-0-1-0.bb1.a.sea.aarnet.net.au [202.158.194.110] 9 191 ms 191 ms 191 ms sinet-1-is-jmb-776.lsanca.pacificwave.net [207.231.241.135] 10 291 ms 291 ms 291 ms nii-gate2-P1-0.sinet.ad.jp [150.99.199.13] 11 292 ms 291 ms 291 ms nii-S1-P8-0.sinet.ad.jp [150.99.198.21] 12 292 ms 292 ms 292 ms tokyo-core1-P8-0.sinet.ad.jp [150.99.197.21] 13 292 ms 292 ms 292 ms tokyo-core2-P0-0.sinet.ad.jp [150.99.197.230] 14 302 ms 302 ms 302 ms osaka-core1-P1-0.sinet.ad.jp [150.99.197.234] 15 317 ms 317 ms 317 ms kyushu-S1-P5-0.sinet.ad.jp [150.99.197.106] 16 317 ms 317 ms 317 ms kyushu-u-LAN3.sinet.ad.jp [150.99.196.86] 17 317 ms 317 ms 317 ms 133.5.9.225 18 317 ms 317 ms 317 ms 133.5.9.249 19 317 ms 318 ms 317 ms namiko.ec.kyushu-u.ac.jp [133.5.10.10]

slide-7
SLIDE 7

Southern Cross Australia Japan Cable SEAMEWE3

  • r New Cable

APCN2

slide-8
SLIDE 8
  • ptions for connecting multiple sites

QUATRE Bi-directional communication up-to 4 REFLECTOR Uni-directional communication more than 10

(uni-cast or multi-cast, IPv4, IPv6)

NTCS vs PAL

QUATRE is NTSC but laparoscopic camera is PAL

NTSC PAL

slide-9
SLIDE 9

VPN - security patient confidentiality

  • there is a need for patient confidentiality
  • peer-to-peer, C4-VPN, or IP-sec router

Allaid Telesyn AR550s

slide-10
SLIDE 10

Theatres Videoconference Room Kyushsu CC

Laparoscope - PAL External view - PAL PC NTSC room camera PC

priority stream

Data Converter PC Data PC – MSN Chat, Powerpoint etc

Reflector QUATRE

VPN

Flinders University – Planned Local Configuration

100mB link

Mixer

Audio into theatres Audio Out of Theatres Audio PC

1 GB link

Audio via Windows Media

slide-11
SLIDE 11

Theatres Videoconference Room Kyushsu

Laparoscope - PAL NTSC Camera PC NTSC room camera PC Data Converter Data PC – MSN Chat, Powerpoint etc

QUATRE Flinders University – Eventual Local Configuration

100mB link

Video Mixer

Audio Audio PC – DVTS preview PAL – Room Camera Lapel Mics PC

1 GB link

slide-12
SLIDE 12
slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15

what worked well

  • 1. flexibility and reliability of DVTS system
  • 2. good video and sound quality
  • 3. acceptable time delay – ~ 2 sec
  • 4. effectiveness of the interactions
  • 5. excellent co-operativity and organisation
slide-16
SLIDE 16

problems and solutions

1. network – work with network engineers

  • reliability -
  • time delay – shorter links
  • Firewalls – dedicated links
  • audio quality / standardising audio volumes

2. security / patient confidentiality – need to

find VPNs that don’t degrade the image

3. PAL versus NTSC – need compatible video

mixing systems

slide-17
SLIDE 17

what next ?

  • local / national interest is strong, but needs

developing

  • more links, better connections
  • how can we add value to the interactions
  • network protocol
  • more structured sessions
  • additional data / images / powerpoint
  • stop testing and start using – ‘mainstream’ the

technology

slide-18
SLIDE 18
  • linked curricula for education and research
  • live collaborative projects
  • disaster / pandemic management
  • linked databases, more integrated IT
  • public / population health
  • use of the technology across all sectors of

medicine, including in developing countries

what next ? medium term

slide-19
SLIDE 19

what next ? blue sky what next ? blue sky

  • 3-D
  • haptics
  • robotic surgery

?
