SLIDE 1
A WORLD LEADER IN OPEN CAST MINING AND MATERIALS HANDLING TECHNOLOGIES
SLIDE 2 2
Subsidiaries Worldwide
TAKRAF South Africa Johannesburg
TENOVA TAKRAF Italy Genoa TENOVA Brasil Sao Paolo
TAKRAF Chile Santiago TAKRAF do Brasil Belo Horizonte TAKRAF India Chennai TAKRAF Australia / Tenova SEMF Brisbane
TENOVA TAKRAF Germany Leipzig, Lauchhammer
TAKRAF Russia Moscow TAKRAF Kazakhstan Astana TAKRAF Uzbekistan Taschkent TAKRAF Romania Tîrgu Jiu TAKRAF China Beijing
TAKRAF USA, Denver TAKRAF Canada, Calgary TAKRAF Chile Santiago
TENOVA TAKRAF Germany Leipzig, Lauchhammer
TAKRAF Bulgaria Sofia
SLIDE 3
3
Innovative, traditionally!
400 projects each year Fabrication/Technical Services
Tenova TAKRAF is a worldwide supplier of more than:
450 machines and plants Bulk Materials Handling 900 machines and plants Open Cast Mining With a century of experience in the fields of open cast mining equipment and bulk materials handling systems, Tenova TAKRAF has a list of references second to none.
SLIDE 4 4
Products and Services
Open Cast Mining Equipment
- Open Cast Mining Systems
- Bucket Wheel Excavators
- Bucket Chain Excavators
- Surface Miners
- Mobile Transfer Conveyors/
Belt Wagons
- Belt Conveyor Systems
- Spreaders/
Cross Pit Spreaders (XPS)
- Conveyor Bridges
- Slope Conveyor Bridges
- Mobile and Semi-Mobile
Crushing Systems
- Transport Crawlers
- Heap-Leach Systems
Bulk Materials Handling Equipment
Systems
- Stackers
- Reclaimers
- Scraper Reclaimers
- Stacker/Reclaimers
- Ship Loaders
- Ship Unloaders
- Tube Conveyors
Fabrication/ Technical Services
- Component supplies
- Service
- Work farmed out by other
industrial contractors
- Works assemblies
- Erection
- Quality assurance
SLIDE 5 5
Customers and Products
Extraction Crushing Dumping Transporting Storage Mixing/ dosing
Handling of bulk materials
Handling of unit loads
Equipment Systems Plants Operation*)
Service
Fabrication Engineering Project Planning Electrical equipment Control instrumentation Control Diagnosis
Extraction Transport/Handling
Bucket wheel excavators Bucket chain excavators Compact units Surface Miners *) Mobile crushers Semi-mobile crushers Transport crawlers Spreaders Overburden conveyor bridges Belt wagons Belt conveyors Slope and steep angle conveyors *) Tube conveyors Bridges for belt conveyors *) Stackers/ Reclaimers, also combined Scrapers *) Bunker equipment Leach pad bridges *) Blending bed equipment Dosing equipment *) Screening stations *) Grinding mills *) Ship loaders Ship unloaders Continuous ship unloaders *) Wagon tipplers *) Special cranes *) New development
Mining companies Power stations Ports Railway systems
Goods handl. centers Metallurgical plants
SLIDE 6
6
Open Cast Mining Equipment
SLIDE 7 7
Open Cast Mining Technology for Continuous Operation
Abraum Grundwasser- absenkung Filterbrunnen
Surface Miner Belt Wagons Compact Bucket Wheel Excavators Bucket Chain Excavator Conveyor Bridges Large-Scale Bucket Wheel Excavators Belt Conveyor Systems Transport Crawlers Mobile and Semi-Mobile Crushing Systems Spreaders and Cross Pit Spreaders
SLIDE 8
8
Bucket Wheel Excavator SRs 8000 (RB 293)
Capacity: 19,120 m3/hr Site of Operation: Hambach Open Cast Mine/Germany
SLIDE 9
9
Bucket Wheel Excavator SRs 1800.28/3.0 + VR
Capacity: 5,400 m3/hr Site of Operation: Puentes Open Cast Mine/Spain
SLIDE 10
10
Compact Bucket Wheel Excavator SRs 401.15/1,0.0
Capacity: 3,100 m3/hr Site of Operation: Oslomej-Westfeld Open Cast Mine/Macedonia
SLIDE 11
11
Compact Bucket Wheel Excavator SRs-(H)1050.23/2,0 (900 kW)
Capacity: 4.800 lm³/h Site of operation: Open cast mine Brod Gneotino/ Macedonia
SLIDE 12
12
Bucket Chain Excavator ERs 500
Capacity: 1,300 m3/hr Site of Operation: Maritza Istok 1+3 Power Stations/Bulgaria
SLIDE 13
13
Spreader ARs-B 12500.90
Capacity: 12,500 m3/hr Site of Operation: Neyveli Open Cast Mine/India
SLIDE 14
14
Spreader ARs-B (K) 4000.50
Capacity: 4,000 m3/hr Site of Operation: Taldinski/Russia
SLIDE 15
15
Spreader ARs-B 6300.60
Capacity: 6,300 m3/hr Site of Operation: Radomiro Tomic/Chile
SLIDE 16
16
Spreader ARs 2800.37,5
Capacity: 2,800 m3/hr Site of Operation: Lampang/Thailand
SLIDE 17
17
Overburden Conveyer Bridge F 60
Capacity: 29,000 m3/hr Site of Operation: Klettwitz-Nord Open Cast Mine/Germany
SLIDE 18
18
Slope Conveyor Bridge SFB-R (K) 1800.25
Capacity: 5,500 t/hr Site of Operation: Kazakhstan
SLIDE 19
19
Overland Conveyor Systems
Belt Length: 9.6 km; Conveying Height: -510 m with horizontal curve Site of Operation: Handling Complex at El Abra/Chile
SLIDE 20
20
Overland Conveyor System
Belt Length: 16.8/6.3 km; (9 horizontal and 21vertical curves) Site of Operation: Henderson Mine/USA
SLIDE 21
21
Conveyor Distribution Center
Capacity: 5,000/3,600/1,400 m3/h Site of Operation: Yuan Bao Shan Open Cast Mine/China
SLIDE 22
22
Belt Wagon BRs 1800.30/34
Capacity: 4,420 m3/hr Site of Operation: Neyveli Open Cast Mine/India
SLIDE 23
23
Belt Wagon BRs (K) 1800.65
Capacity: 5,500 m3/hr Site of Operation: Bogatyr Open Cast Mine/Kazakhstan
SLIDE 24
24
Semi-Mobile Crushing Plant
Capacity: 15,000 t/hr Site of Operation: Ujina-Rosario Open Cast Mine, Collahuasi/Chile
SLIDE 25
25
Semi-Mobile Crushing Plant
Capacity: 8,800 t/hr Site of Operation: Escondida Open Cast Mine/Chile
SLIDE 26
26
Semi-Mobile Crushing Plant
Capacity: 3,600 t/hr Site of Operation: Taldinski Open Cast Mine/Russia
SLIDE 27
27
Semi-Mobile Crushing Plant
Capacity: 2,500 t/hr Site of Operation: Old Cliffe Hill Quarry/Great Britain
SLIDE 28
28
Mobile Crusher Clermont
Capacity: 12,000 t/h Site of Operation: Clermont, Australia
SLIDE 29
29
Transport Crawler RT 250 transporting a Conveyor Station
Lifting Capacity: 250 t Site of Operation: El Abra/Chile
SLIDE 30
30
Transport Crawler RT 420 transporting a Crushing Plant
Lifting Capacity: 420 t Site of Operation: Saudi Arabia
SLIDE 31
31
Surface Miner MTS 250
Capacity: 250 bm3/hr Site of Operation: Tashkura/Uzbekistan
SLIDE 32
32
Stacker
Capacity: 4,200 t/hr Site of Operation: KMS Schleenhain/Germany
SLIDE 33
33
Stacker and Stacker/Reclaimer
Site of Operation: Iron Ore Stockyard in Sishen/ISCOR/South Africa
Capacity: 3.050 t/h Capacity: 5.000 t/h
SLIDE 34
34
Stacker/Reclaimer Ks-S 3500/3500.47
Capacity: 3,500 t/h Site of Operation: Coal terminal of Seaport Ust-Luga
SLIDE 35
35
Stacker/Reclaimer
Capacity: 3,500 t/h Site of Operation: Coal terminal of Seaport Wanino
SLIDE 36
36
Stacker/Reclaimer Ks-S 3600/2500.46
Capacity: 3,600/2,500 t/hr Site of Operation: Vitoria ES/Brazil
SLIDE 37
37
Bucket Wheel Reclaimer
Capacity: 11,500 t/hr Site of Operation: Radomiro Tomic/Chile
SLIDE 38
38
Bucket Wheel Reclaimer
Capacity: 6,000 t/hr Site of Operation: Brucutu, Brazil
SLIDE 39
39
Coal Blending and Stacking Yard
Capacity: 400,000 t raw lignite coal Site of Operation: KMS Schleenhain/Germany
SLIDE 40
40
Full Gantry Reclaiming Scraper
Capacity: 1,000 t/hr Site of Operation: Phosphate Storage Yard at Kef Eddour/Tunesia
SLIDE 41
41
Drum Reclaimer
Capacity: 5,300 TPH Site of Operation: Brucutu, Brazil
SLIDE 42
42
Tube Conveyor System
Capacity: 2,860 t/hr Site of Operation: Sincor/Venezuela
