A Structural Model for Coupled Electricity Markets

Stolberg, 2014

Michael M. Kustermann | Chair for Energy Trading and Finance | University of Duisburg-Essen

Seite 2 A Structural Model for Coupled Electricity Markets |

Table of contents

Motivation Electricity Prices in France and Germany in 2010-2011 Central Western Europe Market Coupling Course of Dimensionality A Structural Model for Coupled Markets Assumptions and Requirements Demand and Fuels Market Supply Curve Cross Boarder Physical Flow Spot Prices Futures Options

Michael M. Kustermann | Stolberg | Mai 2014

Seite 3 A Structural Model for Coupled Electricity Markets | Motivation

CWE Region

Michael M. Kustermann | Stolberg | Mai 2014

Seite 4 A Structural Model for Coupled Electricity Markets | Motivation

German and French Power Prices from Jan 2010 to Dec 2011

Michael M. Kustermann | Stolberg | Mai 2014

Seite 5 A Structural Model for Coupled Electricity Markets | Motivation

German vs French Power Prices - 2010 and 2011

Michael M. Kustermann | Stolberg | Mai 2014

Seite 6 A Structural Model for Coupled Electricity Markets | Motivation

Definitions

◮ A Market Area is a set of nodes and edges in an electric network,

for which a unique energy price is calculated (’spot’ i.e. day-ahead).

◮ Two market areas A and B are interconnected, if there exists an

edge, which connects a node in A with a node in B.

◮ An edge which connects two market areas is called

interconnector.

◮ The sum over the available capacities of all interconnectors

between A and B is called available (cross boarder) transmission capacity (ATC).

◮ ’Market coupling uses implicit auctions in which players do not

actually receive allocations of cross-border capacity themselves but bid for energy on their exchange. The exchanges then use the available cross-border transmission capacity to minimize the price difference between two or more areas.’ (EPEX SPOT)

Michael M. Kustermann | Stolberg | Mai 2014

Seite 7 A Structural Model for Coupled Electricity Markets | Motivation

Course of Dimensionality

◮ Consider the case of n interconnected market areas. ◮ This network has at most N = n−1 l=1 (n − l) = n(n−1) 2

ATCs.

◮ If 1 ≤ k ≤ N Interconnectors exist with capacities [El min, El max],

then the set of all possible states of the network can be characterized as [E1

min, E1 max] × [E2 min, E2 max] × · · · × [Ek min, Ek max]. ◮ This cube has

• k

l

• 2k−l l-dimensional Volumes.

◮ Thus, the network can be in k

• l=1
• k

l

• 2k−l = 3k

different states.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 8 A Structural Model for Coupled Electricity Markets | Motivation

Course of Dimensionality - Example

◮ 1 Volume - Markets are coupled ◮ 6 Areas - Markets are coupled ◮ 12 Vertices - 1 Market is decoupled ◮ 8 Edges - Markets are completely decoupled

Michael M. Kustermann | Stolberg | Mai 2014

Seite 9 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Requirements for a Structural Model for Coupled Markets

We focus on the two market case. A structural model for coupled markets should

◮ be simple. ◮ be tractable. ◮ lead to a closed form formula for the cdf of spot prices. ◮ lead to closed form formulae for futures prices.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 10 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Economic Assumptions

Starting point for our model is the following structure of a hybrid model

◮ price independent demand ◮ market supply curve has exponential shape ◮ fuels prices shift market supply curve multiplicatively ◮ market clearing price is given as intersection of supply and

demand

Michael M. Kustermann | Stolberg | Mai 2014

Seite 11 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Model for Demand and Fuel

We assume Demand in Country i ∈ {1, 2} to be given by Di

t = f i t + ˜

Di

t

d ˜ Di

t = −ki ˜

Di

tdt + σidW i t

dW i

t dW j t = ρi,jdt

where f i

t = βi 1 + βi 2 cos(2π t

24 + βi

3)

+ βi

4 cos(2π

t 168 + βi

5) + βi 6 cos(2π

t 8760 + βi

7)

denotes the deterministic seasonal component.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 12 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Model for Demand and Fuel II

Moreover, we assume that only one fuel might be marginal and is given by d ln(St) = kS(θS − ln(St))dt + σSdW S

t

dW S

t dW 1 t = ρS,1

dW S

t dW 2 t = ρS,2.

It follows   D1

t

D2

t

ln(St)   |Fs ∼ N (µ(s, t), Σ(s, t)) The parameters µ(s, t) and Σ(s, t) are explicitely given in terms of the parameters of the SDEs.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 13 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Model for the Market Supply Curve

We assume the Market Supply Curve in Country i ∈ {1, 2}, Ci, to be given as a function of demand D and fuels price S: Ci(D, S) = Seai+biD + c. I.e. we assume

◮ constant production capacities ◮ production costs consist of fuels cost and fuel price independent

costs (labour costs,...).

◮ exponential dependence of the market clearing price on demand.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 14 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Cross Border physical Flows

We denote the physical flow from country 2 to country 1 by Et. The maximum capacity is restricted and depends on the direction of the flow: Et ∈ [Emin, Emax] , Emin ≤ 0, Emax ≥ 0. Note that, if

◮ Emin = Emax = 0, markets are not connected and thus, pricing

might be done independently.

◮ Emax = −Emin → ∞, the interconnector is never congested and

thus, one unique market price for both markets exists at all hours.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 15 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Cross Border physical Flows in case of coupled markets

In interconnected markets, only the electricity which is not imported has to be produced. Thus, the electricity price is determined as P1

t (D1 t , Et, St) = C1(D1 t − Et, St) = Stea1+b1(D1

t −Et) + c.

Here, Et is the imported amount and D1

t − Et is the residual demand

which has to be satisfied by local production. Define: A1 = {ω ∈ Ω : P1

t (D1 t , Emax, St) ≥ P2 t (D2 t , −Emax, St)}

A2 = {ω ∈ Ω : P1

t (D1 t , Emin, St) ≤ P2 t (D2 t , −Emin, St)}

A3 = Ω \ (A1 ∪ A2) Then, the cross border flow in case of coupled markets is Et(ω) =    Emax , if ω ∈ A1 Emin , if ω ∈ A2

a1−a2 b1+b2 + b1 b1+b2 D1 t (ω) − b2 b1+b2 D2 t (ω)

, if ω ∈ A3

Michael M. Kustermann | Stolberg | Mai 2014

Seite 16 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Market Clearing Prices

Given the cross border physical flow which minimizes price differences between countries, the resulting electricity price for country 1 may be stated as: P1

t (ω) = P1 t (D1 t , Et, St) =

   C1(D1

t (ω) − Emax, St(ω))

, if ω ∈ A1 C1(D1

t (ω) − Emin, St(ω))

, if ω ∈ A2 Cm(D1

t (ω) + D2 t (ω), St(ω))

, if ω ∈ A3 The function Cm can be viewed as the aggregated market supply curve for both countries and is given by Cm(D, S) = Seam+bmD + c with am = a1b2+a2b1

b1+b2

and bm =

b1b2 b1+b2 . Equivalent results hold for P2 t in

country 2.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 17 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Distribution of the market clearing prices - limiting cases

Define the generalized lognormal distribution logN(µ, σ2, c) as the distribution with density f(x) = 1 √ 2πσ(x − c) e− 1

2 ( ln (x−c)−µ σ

)2 , ∀x ∈ (c, ∞).

Then it obviously holds that Pi

t|Fs d

→ logN

• ai + bi

Tµ, bi TΣbi, c

• , if Emax = −Emin → 0+.

Here, bi = (b1, 0, 1)T if i = 1 (0, b2, 1)T if i = 2 . And Pi

t|Fs d

→ logN(am + bmµ, b

T mΣbm, c) , if Emax = −Emin → ∞.

Here, bm = (bm, bm, 1)T.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 18 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Distribution of the market clearing prices

Defining Pt =

• P1

t , P2 t

T we find the distribution function: FPt|Fs (x) = Q(Pt ≤ x|Fs) = Q ({Pt ≤ x} ∩ A1|Fs) + Q ({Pt ≤ x} ∩ A2|Fs) + Q ({Pt ≤ x} ∩ A3|Fs) . We are able to calculate above Probabilities. It turns out Q({P1

t ≤ x1} ∩ {P2 t ≤ x2} ∩ A1|Fs) = Φ3

• d(x); Bµ; BΣBT

where Φ3(y; µ; Σ) denotes the cdf at y of the (degenerate) normal distribution with mean µ and covariance Σ. The parameters are

d(x) =   ln(x1 − c) − a1 + b1Emax ln(x2 − c) − a2 − b2Emax a1 − a2 − (b1 + b2)Emax   , B =   b1 1 b2 1 −b1 b2   .

Similar expressions can be found for the other 2 terms.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 19 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Example of the resulting Copulae

Michael M. Kustermann | Stolberg | Mai 2014

Seite 20 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Futures prices in the structural model

We consider futures with hourly delivery. Denote by F i(s, t) the futures price of electricity in country i at time s for delivery in t. Under the risk-neutral measure we have

F 1(s, t) = EQ

s [P1 t ] =

• Ω

P1

t (ω)Q(dω)

=

• A1

C1 D1

t (ω) − Emax, St(ω)

• Q(dω)

+

• A2

C1 D1

t (ω) − Emin, St(ω)

• Q(dω)

+

• A3

Cm D1

t (ω) + D2 t (ω), St(ω)

• Q(dω)

and equivalent for country 2.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 21 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Futures prices in the structural model II

Similar to the calculation for the cdf, we find

• A1

C1 D1

t (ω) − Emax, St(ω)

• Q(dω) =

c · Φ  a1 − a2 − (b1 + b2)Emax − b

T 3 µ

• b

T 3 Σb3

  + ea1−b1Emax +bT

1 µ+ 1 2 bT 1 Σb1Φ

 a1 − a2 − (b1 + b2)Emax − b

T 3 µ − b T 3 Σb3

• b

T 3 Σb3

 

where b3 = (−b1, b2, 0)T. Futures prices for futures with delivery in a set T of hours are then given by F i (s, T) = 1 |T|

• t∈T

F i(s, t).

Michael M. Kustermann | Stolberg | Mai 2014

Seite 22 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Example of futures prices

Michael M. Kustermann | Stolberg | Mai 2014

Seite 23 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Plain Vanilla Calls

Define the following sets Bmax = {ω ∈ Ω : C1(D1

t − Emax, St) ≥ K}

Bmin = {ω ∈ Ω : C1(D1

t − Emin, St) ≥ K}

Bmid = {ω ∈ Ω : Cm(D1

t + D2 t , St) ≥ K}.

Then, the price of a Call with Strike K is given by

EQ

s

• P1

t − K

+ =

• A1∩Bmax

C1(D1

t − Emax, St)dQ

+

• A2∩Bmin

C1(D1

t − Emin, St)dQ +

• A3∩Bmid

Cm(D1

t + D2 t , St)dQ

− K (Q (A1 ∩ Bmax) + Q (A2 ∩ Bmin) + Q (A3 ∩ Bmid))

Michael M. Kustermann | Stolberg | Mai 2014

Seite 24 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Example of a Plain Vanilla Call

Export: The price of an at the money option increases with increasing futures price, but increasing export capacities further reduces variablility of demand and thus the call loses value.

Michael M. Kustermann | Stolberg | Mai 2014

Seite 25 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Thank you for your attention...

Michael M. Kustermann | Stolberg | Mai 2014

Seite 26 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

References

EPEX SPOT SE Data Download Center, www.epexspot.com Rouquia Djabali, Joel Hoeksema, Yves Langer COSMOS description - CWE Market Coupling algorithm, APX Endex, www.apxendex.com Rene Carmona, Michael Coulon, Daniel Schwarz Electricity Price Modeling and Asset Valuation: A Multi-Fuel Structural Approach Rene Carmona, Michael Coulon A Survey of Commodity Markets and Structural Models for Electricity Prices

Michael M. Kustermann | Stolberg | Mai 2014

Seite 27 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Appendix

Michael M. Kustermann | Stolberg | Mai 2014

Seite 28 A Structural Model for Coupled Electricity Markets | A Structural Model for Coupled Markets

Price Convergence FR - GER (hourly basis)

Figure: Price Convergence between France and Germany

Michael M. Kustermann | Stolberg | Mai 2014
