SLIDE 1

PLOS 2017 October 28

Kevin Boos Lin Zhong Rice Efficient Computing Group Rice University

Theseus: A State Spill-free Operating System

SLIDE 2

Problems with Today’s OSes

Modern single-node OSes

are vast and very complex

Results in entangled web  
f components
Nigh impossible to decouple
Difficult to maintain,

evolve, update safely,   and run reliably

2

SLIDE 3

Easy Evolution is Crucial

Computer hardware must

endure longer upgrade cycles[1]

Exacerbated by the (economic)

decline of Moore’s Law

Evolutionary advancements  
ccur mostly in software
Extreme example: DARPA’s

challenge for systems to   “remain robust and functional   in excess of 100 years”[2]

3

[2] DARPA seeks to create software systems that could last 100 years. https://www.darpa.mil/news-events/2015-04-08. [1] The PC upgrade cycle slows to every ve to six years, Intel’s CEO says. PCWorld article.

SLIDE 4

What do we need?

Easier evolution by reducing complexity without reducing size (and features). We need a disentangled OS that:

allows every component to

evolve independently at runtime

prevents failures in one component

from jeopardizing others

4

SLIDE 5

– the astute audience member

“But surely existing systems have solved this already?”

5

SLIDE 6

Existing attempts to decouple systems

1. Traditional modularization
2. Encapsulation-based
3. Privilege-level separation
4. Hardware-driven

6

SLIDE 7

Existing attempts to decouple systems

1. Traditional modularization
2. Encapsulation-based
3. Privilege-level separation
4. Hardware-driven

7

Decompose large monolithic

system into smaller entities of related functionality   (separation of concerns) Achieves some goals: code reuse

Often causes tight coupling,

which inhibits other goals

Evidence: Linux is highly modular,

but requires substantial effort to realize live update [3, 4, 5, 6]   and fault isolation [7, 8, 9]

[3] J. Arnold and M. F. Kaashoek. Ksplice: Automatic rebootless kernel updates. EuroSys, 2009. [4] M. Siniavine and A. Goel. Seamless kernel updates. DSN) 2013. [5] G. Altekar, I. Bagrak, P. Burstein, and A. Schultz. OPUS: Online patches and updates for security. USENIX Security, 2005. [6] K. Makris and K. D. Ryu. Dynamic and adaptive updates of non-quiescent subsystems in commodity OS. EuroSys, 2007.

[7] M. M. Swift, M. Annamalai, B. N. Bershad, and H. M. Levy. Recovering device drivers. OSDI, 2004. [8] M. M. Swift, B. N. Bershad, and H. M. Levy. Improving the reliability of commodity operating systems. SOSP, 2003. [9] C. Jacobsen, et al. Lightweight capability domains: Towards decomposing the Linux kernel. SIGOPS Oper. Syst. Rev., 2016.  

SLIDE 8

Existing attempts to decouple systems

1. Traditional modularization
2. Encapsulation-based
3. Privilege-level separation
4. Hardware-driven

8

Group related code and data

together into a single entity

Strict boundaries between entities,

e.g., classes in OOP Achieves better maintainability  and adaptability

Similar problems as traditional

modularization, i.e., inextricably coupled entities that are difficult to interchange [10, 11]

[10] C. A. Soules, et al.. System support for online reconfiguration. Usenix ATC, 2003. [11] F. M. David, E. M. Chan, J. C. Carlyle, and R. H. Campbell. CuriOS: Improving reliability through operating system structure. OSDI, 2008.

SLIDE 9

Existing attempts to decouple systems

1. Traditional modularization
2. Encapsulation-based
3. Privilege-level separation
4. Hardware-driven

9

Aims to decouple entities by forcing

them into separate domains with boundaries based on privilege levels

Microkernels, virtual machines

Achieves fault isolation

Coarse spatial granularity [12]
Evolution remains difficult because

microkernel userspace servers   must still closely collaborate [13]

[12] J. N. Herder, H. Bos, B. Gras, P. Homburg, and A. S. Tanenbaum. MINIX 3: A highly reliable, self-repairing operating system. ACM OS Review, 2006. [13] C. Giuffrida, A. Kuijsten, and A. S. Tanenbaum. Safe and automatic live update for operating systems. ASPLOS, 2013.

SLIDE 10

Existing attempts to decouple systems

1. Traditional modularization
2. Encapsulation-based
3. Privilege-level separation
4. Hardware-driven

10

Choose entity bounds based on the

underlying hardware architecture  (cores, coherence domains)

Barrelfish [14], Helios [15], fos [16],

K2 [17] Achieves scalable and   energy-efficient performance

Does not facilitate evolution,

runtime flexibility, or fault isolation

[14] A. Baumann, et al. The multikernel: A new os architecture for scalable multicore systems. SOSP, 2009. [15] E. B. Nightingale, et al. Helios: Heterogeneous multiprocessing with satellite kernels. SOSP, 2009. [16] D. Wentzlaff, et al. An operating system for multicore and clouds. SoCC, 2010. [17] Felix Lin, et al. K2: a mobile OS for heterogeneous coherence domains. ASPLOS, 2014

SLIDE 11

Key Insight: state spill is the root cause

f entanglement within OSes

 

verlooked by existing

decoupling strategies

SLIDE 12

What is state spill?

When one software entity’s state undergoes a lasting change

as a result of handling an interaction with another entity.

12

Prevalent and deeply ingrained

in modern system software

Causes entanglement
Individual entities cannot be

easily interchanged

Multiple entities share fate
Hinders other goals as well

[EuroSys’17]

Kevin Boos, et al. A Characterization of State Spill in Modern Operating Systems. EuroSys, 2017.

SLIDE 13

– the skeptical audience member

“Why is state spill a useful concept?”

13

SLIDE 14

Modern OSes under the light of state spill

14

task mgmt

nano-core

kern el cons

le

input event mux key boar d indir ecti

n

laye r s c h e d u l e r CFQ policy FCFS policy RR policy mouse indirection layer VGA indirection layer graphics mux filesystem PIC IRQ PIT clock IRQ event dispatcher syscall dispatcher sysc all indir ecti

n

laye r heap allocator frame allocator stack allocator

userspace processes

PIC IRQ s c h e d u l e r filesystem PIC IRQ PIC IRQ filesyst em fil e s y st e m

(a) Monolithic Kernel (b) Microkernel OS (c) Theseus Kernel

module submodule entanglement via state spill

s c h e d u l e r filesyst em s c h e d ul er

Web of interacting modules spill state into each other
Larger modules contain submodules that cannot be managed independently

task mgmt

nano-core

kern el cons

le

input event mux key boar d indir ecti

n

laye r s c h e d u l e r CFQ policy FCFS policy RR policy mouse indirection layer VGA indirection layer graphics mux filesystem PIC IRQ PIT clock IRQ event dispatcher syscall dispatcher sysc all indir ecti

n

laye r heap allocator frame allocator stack allocator

userspace processes

PIC IRQ s c h e d u l e r filesystem PIC IRQ PIC IRQ filesyst em fil e s y st e m

(a) Monolithic Kernel (b) Microkernel OS (c) Theseus Kernel

module submodule entanglement via state spill

s c h e d u l e r filesyst em s c h e d ul er

SLIDE 15

Theseus: a Disentangled OS

15

task mgmt

nano-core

kern el cons

le

input event mux key boar d indir ecti

n

laye r s c h e d u l e r CFQ policy FCFS policy RR policy mouse indirection layer VGA indirection layer graphics mux filesystem PIC IRQ PIT clock IRQ event dispatcher syscall dispatcher sysc all indir ecti

n

laye r heap allocator frame allocator stack allocator

userspace processes

PIC IRQ s c h e d u l e r filesystem PIC IRQ PIC IRQ filesyst em fil e s y st e m

(a) Monolithic Kernel (b) Microkernel OS (c) Theseus Kernel

module submodule entanglement via state spill

s c h e d u l e r filesyst em s c h e d ul er task mgmt

nano-core

kern el cons

le

input event mux key boar d indir ecti

n

laye r s c h e d u l e r CFQ policy FCFS policy RR policy mouse indirection layer VGA indirection layer graphics mux filesystem PIC IRQ PIT clock IRQ event dispatcher syscall dispatcher sysc all indir ecti

n

laye r heap allocator frame allocator stack allocator

userspace processes

PIC IRQ s c h e d u l e r filesystem PIC IRQ PIC IRQ filesyst em fil e s y st e m

(a) Monolithic Kernel (b) Microkernel OS (c) Theseus Kernel

module submodule entanglement via state spill

s c h e d u l e r filesyst em s c h e d ul er

Implemented  from scratch using Rust Runtime   composable Inspired by distributed computing

SLIDE 16

Our Namesake: Ship of Theseus

The ship wherein Theseus and the youth

f Athens returned from Crete had thirty
ars, and was preserved by the Athenians

down even to the time of Demetrius Phalereus, for they took away the old planks as they decayed, putting in new and stronger timber in their places, in so much that this ship became a standing example among the philosophers, for the logical question of things that grow;

ne side holding that the ship remained

the same, and the other contending that it was not the same.  — Plutarch (Theseus)

16

TODO: picture of ship

SLIDE 17

Theseus Directives

17

Primary Directive

no state spill

Secondary Directive

elementary modules

eliminate state spill above all else, e.g., performance, ease of programming no submodules; modules as small as possible

SLIDE 18

Design Principles

SLIDE 19

Design Principles

Decoupling entities based on state spill (pairwise)

1. No Encapsulation
2. Stateless Communication

  Composing a Disentangled OS (multi-entity)

3. Universal, connectionless interfaces
4. Generic pattern reuse

19

SLIDE 20

P1: No Encapsulation

Encapsulation: code & data

are bundled together

Direct cause of state spill

20

Standard Encapsulation Opaque Exportation + Stateless Communication

Client state Server state

config(c) func1() func2(r1) c c, s1 c, s1, s2 r1 r1, r2 void r1 r2 a’ c r2

Client state Server state

r1 r1, r2 c

c, s1

c, s1, s2

c c, s1 config(c) func1() func2(r1) void r1 r2 c, s1 c c

c, s1

c, s1, s2 c, s1, s2

start end

Instead, eschew encapsulation
Client should maintain its own

progress with the server

Must preserve information hiding

SLIDE 21

P2: Stateless Communication

An interaction from client to server must be self-sufficient,

containing everything that the server requires to handle it

No assumption of prior interactions or state 
Implications:
Server entity is effectively stateless
No hidden global dependencies

21

fn0( ) fn1( ) fn2() void a’ c r2

( )

stateful

SLIDE 22

Select Design and Implementation Decisions

SLIDE 23

State Management via Opaque Exportation

P1 + P2 –> opaque exportation
Server returns sealed representation
f progress to client
Preserves information hiding
Client cannot inspect/modify state
Allows stateless communication
Handled transparently by compiler
Leverage Rust’s affine type system

to avoid high overhead

23

Standard Encapsulation Opaque Exportation + Stateless Communication

Client state Server state

config(c) func1() func2(r1) c c, s1 c, s1, s2 r1 r1, r2 void r1 r2 a’ c r2

Client state Server state

r1 r1, r2 c

c, s1

c, s1, s2

c c, s1 config(c) func1() func2(r1) void r1 r2 c, s1 c c

c, s1

c, s1, s2 c, s1, s2

start end

SLIDE 24

– the slightly persnickety audience member

“But can you always eliminate state spill?”

24

SLIDE 25

… some states must exist somewhere

State spill is not always avoidable, especially in low-level

OS code that interfaces directly with hardware

e.g., frame allocator, interrupt handler

25

Server

Directive 1: no state spill (above all else) Directive 2: elementary modules

Flat Module Architecture

Submodules contribute to complex entanglement

○ Extract submodules into first-order modules

Simplifies module logic → nano_core manages all
Permits communication and compositional hierarchy

Theseus: a State Spill-free Operating System

Kevin Boos and Lin Zhong

OSes are complex and entangled

Existing OSes are a web of entangled entities

○ Cannot treat entities independently

OS components should be easily interchangeable

at runtime, for fluid system evolution ○ Goal: Runtime Composability

Prior decoupling strategies are insufficient;

entanglement remains between system entities ○ Modularization ○ Encapsulation (OOP) ○ Privilege-level separation (μkernel) ○ Hardware-driven (Barrelfish)

Theseus design principles

1. No traditional encapsulation

○ Client A should maintain the state representing its progress with server B, instead of B ○ Preserve information hiding: A cannot inspect

r modify state from B
2. Stateless interactions

○ An interaction from A → B must include everything B needs to handle it ○ Implication: B can be practically stateless

3. Universal, connectionless communication

○ All entities are accessible in a uniform way ○ Do not assume ongoing existence of interfaces

4. Re-use of generic, spill-free patterns

○ Implement common OS design patterns once in a spill-free way, then re-use across system

Design & implementation decisions State Spill is the root cause

Scenario: source entity A (“client” role)

communicates with destination B (“server role).

State spill occurs when B’s state undergoes a

lasting change after handling an interaction from A.

Main goals of Theseus

Caller entity A (“client”) Callee entity B (“server”)

Initial state pre-interaction Changed state mid-interaction Lasting changes post-interaction

state spill

Encapsulation causes state spill

Standard Encapsulation Opaque Exportation + Stateless Communication

Client state Server state

config(c) fn1() fn2(r1) c c, s1 c, s1, s2 r1 r1, r2 void r1 r2

Client state Server state

r1 r1, r2 c

c, s1

c, s1, s2

c c, s1 config(c) fn1() fn2(r1)

void

r1 r2

c, s1 c c

c, s1

c, s1, s2

task mgmt kernel console input event mux keyboar d indirectio n layer sc he du ler CFQ policy FCFS policy RR policy mouse indirection layer VGA indirection layer graphics mux filesystem PIC IRQ PIT clock IRQ event dispatcher syscall dispatcher syscall indirectio n layer heap allocator frame allocator stack allocator PIC IRQ filesystem PIC IRQ PIC IRQ filesystem filesy stem

Monolithic / Microkernel OS Theseus

For disentanglement, we focus only on states and how they propagate throughout entities in the system.

schedule r

Current status and future work

Done: baseline OS from scratch, all in Rust
Now:

analyze & rethink modules and interfaces to remove state spill

Far:

no user/kernel distinction: “bag of modules”

Software-only Isolation and Safety

Modules are separate binaries: namespace isolation
Augment Rust compiler to permit minimal subset of

unsafe code necessary for basic OS functionality

Error handling is mandatory, using Option & Result

○ Panics are disallowed and transformed into errors

State Management

At some point, some entities must hold some state

System-wide entity

(e.g., hardware resource)

Client Client Client Multi-client state

Export multi-client state

as data blob jointly

wned by all clients
Clientless states are
wned by state_db

metamodule ○ Entity caches a weak reference to it

nano_core state db

W W

Multi-client states are

exported as blobs jointly

wned by every client
Clientless states are owned

by state_db metamodule,  module caches weak reference

SLIDE 26

Software-only Safety & Isolation

Problem: we need isolation between modules
For fault isolation but also for interchangeability
Easy solution: rely on Rust’s memory safety guarantees
Why not just use existing techniques? (Singularity, SPIN, Vino)
Challenge: many modules, modules are in kernel core
No support for processes, SIPs, extensions, etc

26

SLIDE 27

Building Modules in Isolation

Each module is a separate Rust crate
Compiled into individual binaries, isolated into private “namespaces”

27

Compiler Compiler/Linker

Theseus  Easy to extricate a single crate due to clear boundaries Standard OS No true distinction between modules, or blurry lines

SLIDE 28

Many modules, all at the core

✓ Naming isolation done

Problem: Hardware protection or

spatial multiplexing is infeasible   for 100+ low-level modules

Solution: shared resources
Challenge: modules implement core

kernel functionality

They need to execute unsafe code
Unsafe code can do … well, anything

28

SLIDE 29

Unsafe code is a necessary evil

Some unsafe code is okay
Port I/O & MMIO
Register access
Interrupts & descriptor tables
Most unsafe code is bad!
Dereferencing arbitrary pointers
Random type reinterpretations
Solution: augment Rust compiler

to permit minimal subset of necessary unsafe code

Principal of least privilege, per-module

29

fn keyboard_irq_handler() { let scan_code: u8 = unsafe { in_byte(0x60) }; log!("scan_code: {}", scan_code); // notify end of interrupt unsafe {

ut_byte(0x20, 0x20);

} } fn bad_boy_bad_boy() { unsafe { *(0xFFFF1234 as *mut u32) = 0xDEADF00D; } }

SLIDE 30 task mgmt

nano_core

kern el cons

le

input event mux key boar d indir ecti

n

laye r s c h e d u l e r CFQ policy FCFS policy RR policy mouse indirection layer VGA indirection layer graphics mux filesystem PIC IRQ PIT clock IRQ event dispatcher syscall dispatcher sysc all indir ecti

n

laye r heap allocator frame allocator stack allocator

userspace processes

PIC IRQ filesystem PIC IRQ PIC IRQ filesyst em fil e s y st e m

(a) Monolithic Kernel (b) Microkernel OS (c) Theseus

module submodule entanglement via state spill

s c h e d ul er

Module Management, flattened

Submodules contribute to entanglement
Must be separated out into

standalone, first-order modules   with spill-free public interfaces

nano_core can then manage

all modules indiscriminately   Two important clarifications:

1. State spill freedom does not preclude arbitrary module interaction
2. A module’s flat code structure does not preclude

compositional hierarchy amongst modules

30

SLIDE 31

Why Rust?

SLIDE 32

Beneficial Features of Rust

High-level constructs with low-level flexibility

32

fn clear_vga_screen() { range(0, 80*25, |i| { *((0xb8000 + i * 2) as *mut u16) = VgaChar::new(Black) << 12; }); }

SLIDE 33

Beneficial Features of Rust

High-level constructs with low-level flexibility

33

let &mut MemoryManagementInfo { ref mut page_table, ref mut vmas, ref mut stack_allocator } = current_mmi; match page_table { &mut PageTable::Active(ref mut active_table) => { let mut frame_allocator = FRAME_ALLOCATOR.lock(); if let Some((stack, stack_vma)) = stack_allocator.alloc_stack( ... ) { vmas.push(stack_vma); Ok(stack) } } _ => { Err("MemoryManagementInfo::alloc_stack: failed to allocate stack!") } }

SLIDE 34

Beneficial Features of Rust

High-level constructs with low-level flexibility
Functional & imperative

34

p3.and_then(|p3| p3.next_table(page.p3_index())) .and_then(|p2| p2.next_table(page.p2_index())) .and_then(|p1| p1[page.p1_index()].pointed_frame()) .or_else(huge_page) .map(|frame| { frame.number * PAGE_SIZE + offset }) sections.filter(|s| !s.is_allocated()) .map(|s| s.addr) .min()

SLIDE 35

Beneficial Features of Rust

High-level constructs with low-level flexibility
Functional & imperative
Strongly typed + type inference

35

SLIDE 36

Beneficial Features of Rust

High-level constructs with low-level flexibility
Functional & imperative
Strongly typed + type inference
Clear ownership/borrowing semantics
Explicit lifetimes

36

SLIDE 37

Beneficial Features of Rust

High-level constructs with low-level flexibility
Functional & imperative
Strongly typed + type inference
Clear ownership/borrowing semantics
Explicit lifetimes

37

let y: &u32 = { let x = 5; &x }; println!("{}", y);

error: `x` does not live long enough | 3 | &x | - borrow occurs here 4 | }; | ^ `x` dropped here while still borrowed ... 10 | println!(“{}”, y); | - borrowed value needs to live until here

SLIDE 38

Beneficial Features of Rust

High-level constructs with low-level flexibility
Functional & imperative
Strongly typed + type inference
Clear ownership/borrowing semantics
Explicit lifetimes
Compile-time checking & guarantees

38

SLIDE 39

Concluding Remarks

SLIDE 40

Current & Future Work

Applying the herein described design to transform our

existing baseline OS into state spill-free design

Evaluate and demonstrate runtime composability

Related projects using Theseus

Exploring multi-entity resource accounting with state spill
Massive MU-MIMO LTE/5G Basestation system software
Goal: bring reliability, safety, flexibility, scalability to the edge
Refactoring network stack for network provenance

and tolerance of DoS attacks

40

SLIDE 41

Theseus in conclusion

Eliminate state spill above all else
In pursuit of runtime composability

for easy long-term OS evolution

Implemented from scratch in Rust
Will be open-sourced soon!

41

Rice Efficient Computing Group

recg.org

SLIDE 42

42

SLIDE 43

Backup Slides

SLIDE 44

Rust disadvantages

Lifetime checking isn’t great
Copious overusage of panic
Must translate into normal error responses
Allocations are not as obvious as in C
Many more in paper

44

let tasklist = task::get_tasklist().read(); let mut curr_task = tasklist.get_current().unwrap().write(); let curr_mmi = curr_task.mmi.as_ref().unwrap(); let mut curr_mmi_locked = curr_mmi.lock(); curr_mmi_locked.map_dma_memory(paddr, 512, PRESENT | WRITABLE);

SLIDE 45

P3: Universal, Connectionless Interfaces

All entities should be easily accessible through a

uniform invocation and management interface

Promotes easy interchangeability
Avoids module-specific logic
No expectation of an interface’s ongoing availability
Interactions cannot be stateful, must be “connectionless”

45

SLIDE 46

Pattern Reuse

Common recurring OS design patterns should be

implemented only once and reused throughout the OS

Examples: multiplexers, dispatchers, indirection layers
Pattern must enforce the absence of state spill

regardless of specialization

Should be instantiable at compile time
Lowers development risk of adding new features

46

SLIDE 47

Modules must not jeopardize evolution

Regular Modules

In general, easy to update because modules are stateless
The nano-core relieves modules that do contain states from the burden of

implementing their own state-saving logic

(Tedious approach, commonly used in live updates for reliable systems, e.g., MINIX 3 [40])
In Theseus, compiler is the sole manager of these exported states;

it produces control routines to move them in and out of a module’s bounds,   a guaranteed-safe operation because they are not accessible at the source level

Updates can occur on demand without the modules’ cooperation or knowledge

Metamodules

Must also be easily updatable
state_db “recalls” lent-out states and externalizes them temporarily

47

SLIDE 48

Related work (abridged)

Rust OSes with different goals: Tock, Redox
Static Composability: Flux OSKit, Think, Taligent
Componentized interfaces: OpenCOM, Knit
Microservices architecture and serverless

48
