A Sensor Data Gathering Framework for Agricultural-Fields: Implementation and Experiment Report Hideya Ochiai The University of Tokyo / NICT, JAPAN 1 Background Weather stations at remote sites How can we collect sensor data ?

slide-1
SLIDE 1

1

A Sensor Data Gathering Framework for Agricultural-Fields: Implementation and Experiment Report

Hideya Ochiai The University of Tokyo / NICT, JAPAN

slide-2
SLIDE 2

2

Background

  • Weather stations at remote sites
  • How can we collect sensor data ?

引用: http://www.twin.ne.jp/~saineria/flowerknowledge/flowerknowledge01.html 引用: http://www.edu.city.yokohama.jp/sch/es/hie/6-1ho-mu/page1.htm

Weather Station Mechanical observation

slide-3
SLIDE 3

3

<< Background >>

By making use of PHS or 3G Network

Agricultural Field

PHS Access Point

PHS PHS PHS PHS PHS

○ Easy to deploy × Communication fee for carrier □ Real-time is not always important Real-time data collection from remote sites

slide-4
SLIDE 4

4

<< Proposal >> DTN-Based Data Gathering

Agricultural Field

WiFi WiFi WiFi WiFi WiFi WiFi WiFi WiFi

Use the movement of truck as a network carrier ○ Easy to deploy ○ No communication fee for carrier △ Delivery delay is physically bound to the movement of the truck

slide-5
SLIDE 5

5

What is DTN ???

  • Delay or Disruption Tolerant Networking

1 3 4 2 5 7 6

Intermittent Connectivity

8

Isolated Networks Mobile Node

A B

Message

Circle: Transmission Range

Features

slide-6
SLIDE 6

6

Sensor Truck Data Server

To deliver sensor readings to the data server

Potential

Data Flow Data Flow

: Wireless device

Routing in DTN: Potential-Based Routing (PBR)

slide-7
SLIDE 7

7

Experiment Scenario

Sensor Deploy (#1) Sensor Deploy (#2)

Data Server (#99) Mobile Node (#3) Mobile Node (#4) Mobile Node (#5)

  • 1. The sensors and the server are isolated.
  • 2. The sensors continuously send data to the server.
  • 3. The movement of "mobile nodes" carries data to

the server.

slide-8
SLIDE 8

8

Armadillo220 Battery(6.0V 2100mAh) Power Circuit Wifi 802.11g Storage(2GByte)

slide-9
SLIDE 9

9

Implementation

  • Software: http://sourceforge.net/projects/pear/files/
  • IP packet buffer: 4096 entries
  • Source code: 3225 lines in C.
  • Foot print: 34kbyte (object code)
  • OS: linux-2.6.12.3-a9-15
  • Hardware: Armadillo-220 (Atmark Techno)

PEAR for sensor data gathering

PEAR: potential-based entropy adaptive routing

  • 1. Autonomously develops routing information
  • 2. Adaptively changes message delivery form according

to the physical mobility pattern.

"Mobility entropy and message routing in community-structured delay tolerant networks", ACM AINTEC 2008.

slide-10
SLIDE 10

10

slide-11
SLIDE 11

11

slide-12
SLIDE 12

12

slide-13
SLIDE 13

13

slide-14
SLIDE 14

14

slide-15
SLIDE 15

15

Weather Station with DTN

RS232C(Serial)

Weather Sensor (WXT510/520)

  • Temperature
  • Humidity
  • Pressure
  • Rain Fall
  • Wind Direction
  • Wind Speed

DTN node (#1, #2)

Observe and send data to the data server (#99) (every ten second)

slide-16
SLIDE 16

16

Mobile Node -- Carry by hand!!

DTN node

slide-17
SLIDE 17

17

Data Server

50m

40 [min]

slide-18
SLIDE 18

18

The number of received neighbor advertisement packets. e.g., node 8 received 45 advertisement from sensor 1.

Contact Graph

Mobility Entropy2.1

slide-19
SLIDE 19

19

Potential for the Data Server

Potentials developed by PEAR potential construction algorithm

slide-20
SLIDE 20

20

Message Flow (1/2)

Red arrow: messages from sensor 1 (#1) Blue arrow: messages from sensor 2 (#2)

slide-21
SLIDE 21

21

Message Flow (2/2)

slide-22
SLIDE 22

22

Distribution of Delivery Latency

E.g., 50 = [0,100]

slide-23
SLIDE 23

23

Collected Temperature Data from Sensor 1

Delivery Rate = 100 %

slide-24
SLIDE 24

24

Collected Temperature Data from Sensor 2

Delivery Rate = 100 %

slide-25
SLIDE 25

25

Conclusion

  • DTN-Based Sensor Data Gathering

– Data server Truck Sensors

  • Implementation

– DTN-Communication Boxes – Potential-Based Entropy Adaptive Routing (PEAR)

  • Experiment

– in the University of Tokyo – 100% delivery (with 20min – 30min delay)

slide-26
SLIDE 26

26

Thank you ...

DTN Communication Boxes Sensor data delivery pattern DTN-Based Sensor Data Gathering
