A Scientific Guide to Hobby Rocketry

A Guide to Everything You Need to Know Before Launching Your First High Power Rocket

slide-2
SLIDE 2

Aerodynamics

  • One of the three primary forces in hobby rocket flight
  • Can greatly affect performance (altitude, etc.)
  • Drag force can rip fins apart or cause structural buckling
  • D=​1/2 ρ​v↑2 ​C↓D ​A↓ref
  • Open Rocket can give you the drag coefficient

– Other variables easy to calculate

slide-3
SLIDE 3

Aerodynamic Flight Regimes

Low ¡speed ¡ Compressible ¡ Transonic ¡ Supersonic ¡ Hypersonic ¡

0.3 0.3 0.7 0.7 1.2 1.2 5 5 Mach

slide-4
SLIDE 4

Drag in Compressible Flows

  • In subsonic flow

​C↓D ≈​C↓D,0 /√⁠1−​M↓∞↑2

  • In supersonic flow

​C↓D ≈​C↓D,0 /√⁠​M↓∞↑2 −1

  • Drag actually still increases in

supersonic flow because of the dependence on v∞

2!

slide-5
SLIDE 5

Nose Cone Aerodynamics

  • Various geometries have

different drag coefficients

  • Minimum drag bodies like the

von Karman ogive have best across-the-board performance

  • Some shapes perform best in

certain Mach regimes

  • Model rocketry nose cones are

generally ogives

slide-6
SLIDE 6

Effect of Rocket Length

  • Longer rockets lead to increases in skin friction drag
  • Increased length-to-diameter ratio (fineness ratio) leads to

a decrease in pressure drag per rocket volume

  • Longer rockets are subject to extreme bending moments
slide-7
SLIDE 7

Fin Aerodynamics

Rectangular ¡cross ¡sec:on ¡

  • Simple ¡to ¡manufacture ¡
  • Rela:vely ¡high ¡drag ¡coefficient ¡for ¡airfoils ¡with ¡similar ¡thickness-­‑to-­‑chord ¡ra:os ¡

Rounded ¡cross ¡sec:on ¡

  • Not ¡too ¡difficult ¡to ¡manufacture ¡
  • Decent ¡aerodynamic ¡performance, ¡but ¡not ¡the ¡best ¡

Airfoil ¡cross ¡sec:on ¡

  • Op:mal ¡fin ¡cross ¡sec:on ¡for ¡subsonic ¡rockets, ¡but ¡prone ¡to ¡high ¡drag ¡and ¡shocks ¡at ¡supersonic ¡speeds ¡
  • Should ¡have ¡a ¡symmetric ¡cross ¡sec:on ¡

Wedge ¡cross ¡sec:on ¡

  • Good ¡aerodynamic ¡performance ¡at ¡supersonic ¡speeds ¡
  • Decent ¡aerodynamic ¡performance ¡at ¡subsonic ¡speeds ¡
slide-8
SLIDE 8

Stability

  • Stability margin defined as:

m=​x↓CG −​x↓CP /Max ¡body ¡diameter

– Unstable: m<1 – Marginally stable: m=1 – Stable: 1<m ≤ 2 – Overstable: m>2

  • Always mark the CP on your rocket

– Will not change with added weight/internal features like CG will

slide-9
SLIDE 9

Stable Rockets

Center of mass Center of presssure Net aerodynamic force Net rotation of rocket

slide-10
SLIDE 10

Unstable Rockets

Center of mass Center of presssure Net aerodynamic force Net rotation of rocket

slide-11
SLIDE 11

Why Stability Matters

  • Unstable rockets – BAD

– Can spiral out of control under slight disturbances

  • Stable rockets – GOOD

– Trajectory not perturbed by wind

  • Over-stable rockets – OKAY

– Tend to weathercock, or fly into the wind – Not terrible, but can lead to horizontal flight on windy days

slide-12
SLIDE 12

Effect of Geometry on Stability

  • Based on weighted average of normal force coefficient ​

C↓N,α

  • Control surfaces such as fins have high values of ​C↓N,α

– Larger surfaces have greater effects

  • To move CP aft, place large control surfaces further behind

the old CP location

– Note, larger surfaces also contribute more mass

  • ​x↓CP =​∑↑▒​C↓N,α ↓i ​x↓i /∑↑▒​C↓N,α ↓i
slide-13
SLIDE 13

Effect of Weight on Stability

  • Center of gravity should be above center of pressure
  • CG shifts upwards when mass is added above the old CG,

and downwards when mass is added below the old CG

  • CG moves more quickly when mass is added further from
  • ld CG (from the concept of a moment arm)
  • Common solution to add dead weight (or payload) to the

nosecone

  • ​x↓CG =​∑↑▒​x↓CG,i ​m↓i /∑↑▒​m↓i
slide-14
SLIDE 14

Effect of Speed on Stability

  • Like drag, normal force coefficient varies with Mach number
  • In subsonic flow

​C↓N,α ≈​C↓N,α,0 /√⁠1−​M↓∞↑2

  • In supersonic flow

​C↓N,α ≈​C↓N,α,0 /√⁠​M↓∞↑2 −1

  • In general, stability margin drops approaching Mach 1
slide-15
SLIDE 15

Structures

  • Cardboard tubes with plywood interior structure generally

suitable for low-thrust, low-speed flight

  • Thicker structural materials needed for heavier, higher-

thrust flights

  • Fiberglass and other composites become necessary for

high-speed flight

  • Ductile metals as structural materials only permitted when

deemed absolutely critical for structural integrity

slide-16
SLIDE 16

Weight

  • Heavier rockets require more robust structures
  • Landing can cause poorly constructed components to be

crushed from impact force or moments when tipping over

  • Heavy-weight rockets require much larger parachutes to

land at safe speeds

– Also need high-thrust motors to leave the launch pad at safe speeds

slide-17
SLIDE 17

Fin Shapes

  • Stress tends to accumulate in sharp (acute) corners
  • Avoid highly swept fins with sharp corners

– If sweep is necessary, use right or obtuse angles with reasonably large side lengths

  • Tapered fins that are not swept aft of the rocket tend to

work really well

  • Same rules apply to forward sweep
slide-18
SLIDE 18

Fin Dimensions

  • Fins with a long span can break easily due to excessive

bending moments from aerodynamics and ground impacts

  • Thicker fins can carry much more load and bend less
  • Try to minimize aspect ratio (span/chord) to minimize

chance of breaking a fin

– Too low of an aspect ratio leads to bad stability characteristics

slide-19
SLIDE 19

Adhesives

  • Super glue

– Forms bond almost instantly – Weak, brittle bond – Suitable for placing a component – Not suitable as only bond

  • Wood glue

– Works well on porous materials – Forms moderate strength bond (sufficient for some high power) – Great for fillets

  • 5-minute epoxy

– Short set time, but the bond is not as high in strength – Good for quick repairs

  • 1-hour epoxy

– Ideal for most structural components – Can use additives to enhance various properties

  • JB Weld

– High strength, but more brittle

slide-20
SLIDE 20

Recovery

  • Good recovery is key for ensuring rocket safety
  • Landing speed should be slow, but not too slow

– Too fast: things break – Too slow: things float forever and get lost

  • Ideal landing speeds are 15-20 ft/s

– Some rocketeers recommend 17-22 ft/s

  • Typically achieved by one or two parachutes
slide-21
SLIDE 21

Sizing a Parachute

  • Goal of parachute is to decelerate rocket

– Ideally, the rocket will reach terminal velocity (​dv/dt =0) – Statics problem (F = ma = 0), or weight equals aero forces

  • W=​1/2 ρ​v↓term↑2 ​C↓D A
  • Area=​2W/ρ​v↓term↑2 ​C↓D and Diameter=2√⁠​Area/π
slide-22
SLIDE 22

Sizing a Parachute

  • Diameter=​2/​v↓term √⁠​2W/ρπ​C↓D
  • What values to use?

– W: weight of your rocket (after propellant burns out) – vterm: usually 15-20 ft/s (use higher end for light rockets) – ρ: approximately 1.12-1.2 kg/m3 at our launch site – CD: parachute drag coefficient, about 0.7-0.9 for Level 1 TFR

  • Always check your units! You will have to do conversions!
slide-23
SLIDE 23

Shock Cord

  • Ejection charges usually apply 8-15 psi in a rocket

– Up to 106 lbf on a 3” rocket, 189 lbf on a 4” rocket – Leads to high separation velocity – Quick deceleration at full shock cord extension and parachute inflation

  • Recall F≈​m∆v/∆t , where Δt is usually pretty small
  • Shock cord must be able to load at full extension and also

entire rocket weight (much smaller) during descent

slide-24
SLIDE 24

Shock Chord

  • Rocket structure (materials and adhesives) must be

capable of supporting loads, too

  • To reduce F during full shock cord extension, reduce Δv

– Use drag force of rocket body to your advantage – Drag takes away some separation velocity so Δv is smaller

  • To maximize effect of aerodynamics, make shock cord

infinitely long

– Not very practical, so use a minimum of 20 ft

slide-25
SLIDE 25

Recovery Materials

Parachutes

  • Plastic

– Melts easily – Does not support large loads, mainly for low power applications

  • Ripstop nylon

– Traditional parachute material – Easy to manufacture, buy

  • Mylar

– Expensive

  • Traditional fabrics

– Heavy

Shock cord

  • Elastic

– Absorb ejection energy via stretching – Burn easily, so not suitable for HPR

  • Tubular nylon (climbing webbing)

– High strength, but moderately heavy – Low cost, easily available – Preferred sizes 9/16” or 1”

  • Kevlar

– Very high strength, flame resistance, and cost – Low in weight (typically use ¼” or ½”)

slide-26
SLIDE 26

Recovery Protection

  • Most recovery devices can be burned and damaged by

hot gases from ejection charge

  • Fireproof cellulose insulation (aka “dog barf”) can be

stuffed between ejection charge and recovery device

– Wadding functions similarly for low power rockets

  • Kevlar or Nomex sheets often used to wrap parachutes

– Much more expensive, but reusable and high quality

  • Strategically placed baffles reduce exposure to hot gas
slide-27
SLIDE 27

Launching a Rocket

  • Rockets launched using a rod or rail
  • As rocket accelerates, the rod or rail points the rocket in

the correct direction

– Rocket cannot achieve reasonable stability at low speeds

  • Rule of thumb: velocity of any rocket off the rod or rail

should be at least 50 ft/s

– Much easier to accelerate light rocket than heavy rocket

slide-28
SLIDE 28

Launch Lugs

  • Generally only used for low power rockets
  • Interface with launch rod (circular metal rod)
  • Common sizes are 1/8”, 3/16”, 1/4”, 3/8”, and 1/2”
  • Not used much for high power since the rod tends to

“whip”

  • Single or multiple lug (cardboard tube) aligned axially with

rocket to keep motion near vertical

  • Rods vary in length depending on compatible motor sizes
slide-29
SLIDE 29

Rail Buttons

  • Used for high power rocketry
  • “Rail buttons” screw into rocket and slide

down the launch rail

  • Common sizes are 1010 (1”) and 1515

(1.5”)

  • Use two rail buttons aligned axially with the rocket
  • Bottom rail button should be ~2 inches from aft of rocket
  • Second rail button should be 12-18 inches forward
slide-30
SLIDE 30

Rail Buttons

  • If the front rail button is too far forward, the rocket can

pivot about the aft rail button once the first button has cleared the rail but velocity is not sufficient

  • Anchor rail buttons into rocket using expanding rubber

well nut or a tee nut

– Aft button usually requires well nut – Forward rail button can be placed (with planning) using tee nut

  • Rail length usually 8-10 ft for 1010 and 12+ ft for 1515
slide-31
SLIDE 31

Propulsion

  • Commercial, off the shelf solution for hobby rockets
  • Uses an ammonium perchlorate (AP) composite propellant

for high power, black powder (BP) for low power

– Space Shuttle SRB used an AP-based propellant

  • Fine-grained AP in HTPB rubber binder with other

chemicals for effects

  • Solid propellant with annular grain geometry (generally)
slide-32
SLIDE 32

Thrust & Impulse

  • Thrust is a function of time
  • Impulse=∫↑▒Tdt

– Also approximately average thrust times burn time

  • Average thrust should be at

least five times the rocket weight

  • Very high thrust motors can

cause rocket to go supersonic

slide-33
SLIDE 33

What’s in a Name?

Impulse class Average thrust (N) Propellant type Ejection charge delay

slide-34
SLIDE 34

How High Will It Go?

  • Depends on a number of factors, but you can use some
  • rder of magnitude estimation:
  • h=​1/2 ​t↓burn↑2 (​T/m −10)(​T/10m )

– h: apogee (m) tburn: motor burn time (s) T: average thrust (N) m: initial rocket mass (kg)

  • Does not account for all forces and effects
slide-35
SLIDE 35

National Rocketry Clubs

  • Must be a registered member of National Association of

Rocketry (NAR) or Tripoli Rocket Association (Tripoli) to launch and attempt high power certifications

  • We are a NAR club, so NAR memberships help us

maintain NAR national benefits

– NAR members get a nice bi-monthly magazine

  • Tripoli Level 2 members may use experimental propellant

– But not the Georgia Tech Fire Marshal…

slide-36
SLIDE 36
slide-37
SLIDE 37
slide-38
SLIDE 38
slide-39
SLIDE 39

High Power Rocketry

  • Refers to any launch where any of the following are true:

– Total impulse exceeds 160 Ns (H motor and above) – Average thrust > 80 N – Propellant mass > 125 g – Rocket weight > 1500 g – Airframe includes ductile metal – Rocket uses a hybrid motor

  • You must be a registered member of NAR or Tripoli

before you can attempt a high power launch

slide-40
SLIDE 40

High Power Rocketry

slide-41
SLIDE 41

Certifications

  • Level 1 certification procedures nearly the same for both

NAR and Tripoli

  • Must construct and fly a rocket on a single Level 1 high

power motor and safely recover the rocket

– Must not lose any components in flight – Must not break any components (zippering is at the discretion

  • f the certifier)

– Generally, given a new motor, you should be able to immediately fly the rocket again without modification

slide-42
SLIDE 42

Certifications

  • Things that disqualify you

– Landing in a tree or lake – Motor CATO – Landing without successfully deploying a parachute

  • For NAR members

– I can sign off on your certification and would be happy to do so

  • For Tripoli members

– Local Prefect must sign off on your certification paperwork

  • Must have certification form ready at the launch
