A Multi-agent Approach for Semantic Resource Allocation Jorge Ejarque , Ral Sirvent and Rosa M. Badia Grid Computing and Clusters Group - Barcelona Supercomputing Center (BSC) Arti ficial Intelligence Research Institute - Spanish National

slide-1
SLIDE 1

A Multi-agent Approach for Semantic Resource Allocation

Jorge Ejarque, Raül Sirvent and Rosa M. Badia

Grid Computing and Clusters Group - Barcelona Supercomputing Center (BSC) Artificial Intelligence Research Institute - Spanish National Research Council (IIIA-CSIC)

IEEE CloudCom 2010 December 3, 2010 Indianapolis

slide-2
SLIDE 2

2

Outline

  • Motivation
  • Previous Work.

– Resource Allocation Ontology – Centralized Semantic Scheduling

  • Distributed Approach

– Multi-agent distribution

  • Implementation and Evaluation
  • Conclusions and Future Work
slide-3
SLIDE 3

Motivation

  • SP has to allocate the user’s tasks in their available

resources.

  • Resources are heterogeneous and can be supplied by

different providers.

  • SP users specify requirements in different SLA terms

which must be satisfied.

  • Users and providers use their own terms. There is a

need of semantic interoperability

Service Users Clouds Grids Clusters Service Provider 3

slide-4
SLIDE 4

Motivation

  • SP Infrastructure can change

– New resources can be added or removed from the SP infrastructure

  • Resource can fail

– Performance Degradation

  • Resource Allocation must be adapted according

to customer and provider preferences

  • Agent technologies provide:

– Adaptation to infrastructure changes – Distributed resource allocation according to several customer and provider preferences

4

slide-5
SLIDE 5

Previous work

  • Centralized approach

5

C l i e n t M a n a g e r Semantic Metadata Repository Semantic Scheduler Resource Manager

  • 0. Resource description

registration

  • 1. Get Resource

Candidates

  • 2. Schedule

Job

  • 3. Get descriptions
  • 4. Update scheduling
  • 5. Execute

Job

C l i e n t M a n a g e r Resource Manager

Manage the customer’s tasks requests Stores semantic descriptions of system elements Create executions environments, execute customers tasks Allocates resources on the different customer’s tasks (semantic descriptions)

slide-6
SLIDE 6

Resource Allocation Ontology

  • Based on Grid Resource Ontology
  • Extension to describe basic resource allocation concepts

– Resources properties, Collections, Abstract task (resource requirements, time constraints) and Process (abstract task allocation), Actors, Providers, etc.

6

slide-7
SLIDE 7

Semantic Scheduler

7

  • Rule-based semantic scheduling
slide-8
SLIDE 8

Decentralized motivation

  • Scalability
  • Reduce single point of failure
  • Customer and providers has different

interests and they should be taken into account in the allocation process.

– Different rules depending on the customers and providers or resource types

8

slide-9
SLIDE 9

Client Manager Agent Platform Jobs Job Agent Container Scheduler Jobs Scheduler Client Manager Jobs Job Agent Container Scheduler Jobs Scheduler Scheduler Resource Provisioning

  • Res. Agent Container
  • Res. Man

Scheduler

  • Res. Man

Scheduler Resource Provisioning

  • Res. Agent Container
  • Res. Man

Scheduler

  • Res. Man

. . .

. . .

. . . . . . . . . . . .

Private Clouds Clusters Grids Public Clouds

EC2, ... Semantic Metadata Repository

Distributed Architecture

Resource Allocation Ontology Resource Allocation Rules

  • Distributed approach

9

slide-10
SLIDE 10

System Agents

  • Distributed resource allocation

– Scheduling functionalities distributed across the system agents – Based on a negotiation between the system agents. (CNP) – Agents platforms can be distributed across multiple hosts

  • Two parts

– Client Management (Job Agents)

 Management of jobs  Resource selection

– Resource Provisioning (Resource Agents)

 Management of resources  Resource allocation proposals

  • Belief-Desire-Intention agent modeling

– Define data, goals and plans for each agent

10

slide-11
SLIDE 11

Job Agent

  • Semantic annotation of tasks.
  • Initiate the negotiation and select the best proposal

for the customer interests.

  • Adapt the task allocation to the system events.

(Rescheduling)

  • React to status changes (Fault tolerance)

11 Belief ( Status) Goal Plans

Requested Get Resources Annotate task description Negotiate allocation Scheduled Find Better Allocation Negotiate allocation Running Monitor execution Check performance Update requirements Increase resources Suspended Recover Suspended Evaluate work done Update requirements Negotiate allocation Stopped Recover Stopped Negotiate allocation Non Scheduled Recover Non Scheduled Negotiate allocation Cancelled Cancel Job Remove allocation

slide-12
SLIDE 12

Resource Agent

  • Semantic annotation of resource descriptions
  • Make proposal according to resource interests
  • Create execution environments and execute tasks

by means of a resource management interface

  • React to resource events (Failures)

12 Belief Goal Plans

Scheduled Jobs Monitor Scheduled Jobs Check scheduled job Perform execution Running Jobs Monitor Running Jobs Check running jobs Notify status changes Status Failed Recover Failure Try local rescheduling Notify affected jobs agents Status Running Register Resource Annotate resource description

slide-13
SLIDE 13

Distributed Resource Allocation

  • Resource allocation negotiation sequence

13

  • 1. Select candidate resources
  • 2. Send call for resource allocation

to selected resource agents

  • 3. Evaluate requirements,

discard imposible allocations (resource full, license terms) and apply other provider's rules

  • 4. Send back proposed resource allocations
  • 5. Apply customer selection rules
  • 6. Accept selected proposal

SELECT DISTINCT ?id ?host WHERE { ?host tech:isProvidedBy ?rm . ?rm biz:actor_name ?id . ?host tech:containsResource ?proc . ?proc rdf:type gro:Processing . ?proc gro:hasResourceProperty ?memory . ?memory rdf:type tech:MemoryCapacity . ?memory tech:hasValue ?mem_cap . FILTER (?mem_cap >= 1024ˆˆxsd:int) . ?host tech:containsResource ?image . ?image rdf:type tech:Image . ?image tech:containsResource gro:Software_XX } [Evaluate_Deadline: (?job rdf:type gro:Execute_Task), (?job gro:hasActionState tech:requested), (?job tech:hasDeadline ?deadline), (?job gro:incarnatedToProcess ?incarnation), (?incarnation gro:hasPlannedEnd ?job_end), lessThan(?deadline, ?job_end),

  • >

drop(3,4)] [Used_Hosts_First: (?job rdf:type gro:Execute_Task), (?job gro:hasActionState tech:requested), (?job gro:incarnatedToProcess ?incarnationA), (?incarnationA gro:usesResource ?candidateA), (?candidateA gro:containsResources ?HostA), hasValue(?HostA gro:isUsedBy), (?job gro:incarnatedToProcess ?incarnationB), (?incarnationB gro:usesResource ?candidateB), (?candidateB gro:containsResources ?HostB), noValue(?HostB, gro:isUsedBy)

  • >

drop(6,7)] [Earliest_Start_Date: (?job rdf:type gro:Execute_Task), (?job gro:hasActionState tech:requested), (?job gro:incarnatedToProcess ?incarnationA), (?incarnationA gro:hasPlannedStart ?stDateA), (?job gro:incarnatedToProcess ?incarnationB), (?incarnationB gro:hasPlannedStart ?stDateB), lessEqual(?stDateA, ?stDateB),

  • >

remove(4,5)] [Priority_AtoB: (?job rdf:type gro:Execute_Task), (?job gro:hasActionState tech:requested), (?job gro:incarnatedToProcess ?incarnationA), (?incarnationA gro:usesResource ?candidateA), (?candidateA gro:containsResources ?resourceA), (?resourceA tech:isProvidedBy biz:ResourceProviderA), (?job gro:incarnatedToProcess ?incarnationB), (?incarnationB gro:usesResource ?candidateB), (?candidateB gro:containsResources ?resourceB), (?resourceB tech:isProvidedBy biz:ResourceProviderB)

  • >

remove(6,7)]

slide-14
SLIDE 14

Implementation

  • System agents: Jadex BDI Engine
  • Semantic Capabilities: Jena 2

Framework

– RDF, OWL APIs – Jena Rule Engine (Scheduler Module) – SPARQL queries

14

slide-15
SLIDE 15

Evaluation

  • Qualitative evaluation

– BDI Agents facilitate coordination of complex tasks (job and resource management) – Resource Allocation Classes mapped to different schemas

 EC2

– Instances -> Host Class – Instance Storage, Memory, ECU -> Storage, Processing Resource

 GLUE schema

– ComputeElementType -> Host Class – CE properties -> Storage, Processing Resource properties

 Ganglia schema

– HostType-> Host Class – Ganglia metrics -> Resource properties

15

slide-16
SLIDE 16

Evaluation

  • Centralized vs Decentralized allocation time

16

slide-17
SLIDE 17

Evaluation

17

  • Centralized vs. Distributed
slide-18
SLIDE 18

Evaluation

  • Different agent deployment configuration

18

slide-19
SLIDE 19

Conclusions

  • Resource allocation framework which

combines several technologies

– Semantics for unifying data sources – Multi-agents for adapting to a changing environment – Rule scheduling promising approach

  • Negotiation combines customer and

providers preferences

– Different rule examples

  • Evaluation

– Annotations from different schemas – Agents introduce a negotiation overhead – Trade-off between number of resources per agent and agents per machine.

19

slide-20
SLIDE 20

Future Work

  • Improve performance reducing
  • verheads
  • Exploit the benefits of rule-based

resource allocation

– Dynamic scheduling policies with rules

  • Introduce semantics in the resource

management interface interoperability

– Not only in the resource description

20

slide-21
SLIDE 21

Thank you for your attention. Questions?
