A direct successor to the Westinghouse Iso Phase Bus Plant in Cinn Ohio Credentials 24/7 Private Ownership We pick up the phone after 5pm 513-312-8527 Chad Shell 914-968-4440 Bruce Hack Owners Crown Electric In 2006 Crown

slide-1
SLIDE 1
slide-2
SLIDE 2

A direct successor to the Westinghouse Iso Phase Bus Plant in Cinn Ohio

slide-3
SLIDE 3
slide-4
SLIDE 4

Credentials

slide-5
SLIDE 5

24/7

slide-6
SLIDE 6

Private Ownership

We pick up the phone after 5pm

slide-7
SLIDE 7

513-312-8527 Chad Shell 914-968-4440 Bruce Hack

Owners – Crown Electric

slide-8
SLIDE 8

In 2006 Crown Electric built the Newest IPB factory in North America

slide-9
SLIDE 9
slide-10
SLIDE 10
slide-11
SLIDE 11
slide-12
SLIDE 12

In 2010 – in the middle of the worst recession the US has had since the Great Depression Crown Electric doubled our factory and added 6,500 sq. ft. of

  • ffice space.
slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15

And 50,000 sq ft

  • f fenced in area

for delivery staging.

slide-16
SLIDE 16
slide-17
SLIDE 17

Crown Electric is partnered with some of the Industry’s largest OEM’s

slide-18
SLIDE 18

Crown Electric furnishes and installs IPB for GE Generator Circuit Breakers

slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23

Crown Electric furnishes and installs IPB for Siemens Energy Services

slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26

Crown Electric is the industry’s successor to Westinghouse and their Circular Non Seg Bus Duct

slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33

Crown Electric introduced its

  • wn line of

Disconnect Switches to 30,000 Amps

slide-34
SLIDE 34
slide-35
SLIDE 35
slide-36
SLIDE 36
slide-37
SLIDE 37
slide-38
SLIDE 38
slide-39
SLIDE 39
slide-40
SLIDE 40
slide-41
SLIDE 41

Crown Electric developed the Joule-ious 105

  • nline thermal

monitor

slide-42
SLIDE 42
slide-43
SLIDE 43
slide-44
SLIDE 44

Crown Electric is the only North American IPB manufacturer with full factory based field service and installation capabilities.

slide-45
SLIDE 45

Crown Electric the people who build your IPB, install your IPB

slide-46
SLIDE 46
slide-47
SLIDE 47
slide-48
SLIDE 48
slide-49
SLIDE 49
slide-50
SLIDE 50
slide-51
SLIDE 51
slide-52
SLIDE 52

Crown Electric provides material & services to the nuclear industry

slide-53
SLIDE 53
slide-54
SLIDE 54
slide-55
SLIDE 55

Engineering submittals in 3D CAD

slide-56
SLIDE 56
slide-57
SLIDE 57
slide-58
SLIDE 58

Computerized welding

slide-59
SLIDE 59
slide-60
SLIDE 60
slide-61
SLIDE 61
slide-62
SLIDE 62
slide-63
SLIDE 63
slide-64
SLIDE 64
slide-65
SLIDE 65
slide-66
SLIDE 66

Crown Electric’s

computerized welds are all capable of being certified

slide-67
SLIDE 67

And Crown Electric’s most

senior design engineer(s) are CWI’s

slide-68
SLIDE 68

Crown

manufactures all manners of custom cabinetry, medium voltage switchgear & outdoor houses

slide-69
SLIDE 69
slide-70
SLIDE 70
slide-71
SLIDE 71
slide-72
SLIDE 72
slide-73
SLIDE 73

Crown Electric designs, fabricates & installs IPB replacement and uprated coolers – to nuclear plant size

slide-74
SLIDE 74
slide-75
SLIDE 75

Crown Electric does more GSU change-outs than anyone. And we do them turn-key

slide-76
SLIDE 76
slide-77
SLIDE 77
slide-78
SLIDE 78

IPB Specification Considerations

slide-79
SLIDE 79

Crown’s insulator support windows are a thoughtfully designed system.

slide-80
SLIDE 80
slide-81
SLIDE 81

There is great value in having

IPB insulator support windows that allow for visual inspection and cleaning.

slide-82
SLIDE 82
slide-83
SLIDE 83
slide-84
SLIDE 84
slide-85
SLIDE 85
slide-86
SLIDE 86
slide-87
SLIDE 87
slide-88
SLIDE 88
slide-89
SLIDE 89

Crown Electric requires only one (1) insulator per support point.

slide-90
SLIDE 90
slide-91
SLIDE 91
slide-92
SLIDE 92
slide-93
SLIDE 93

Lets get to know

ANSI/IEEE C29

Iso Phase Bus insulators should be Dew Point rated

slide-94
SLIDE 94
slide-95
SLIDE 95
slide-96
SLIDE 96

Lets look at C29.1 section 4.6

slide-97
SLIDE 97
slide-98
SLIDE 98
slide-99
SLIDE 99

Lets look at C29.1 0 Table 2

slide-100
SLIDE 100
slide-101
SLIDE 101
slide-102
SLIDE 102
slide-103
SLIDE 103

Dew Point rated insulators mean you never need pressurization and it is totally passive.

slide-104
SLIDE 104

No leaks. No pressurization systems to maintain. No loss of BIL. No down time

slide-105
SLIDE 105

Never accept pressurization without applying an evaluation penalty.

slide-106
SLIDE 106
slide-107
SLIDE 107

The Westinghouse slider mounting design allows insulators to harmonize with thermal expansion and better dissipate short circuit forces.

slide-108
SLIDE 108
slide-109
SLIDE 109
slide-110
SLIDE 110
slide-111
SLIDE 111
slide-112
SLIDE 112
slide-113
SLIDE 113

Windows hold space heaters and can be field upgraded well after initial install.

slide-114
SLIDE 114
slide-115
SLIDE 115
slide-116
SLIDE 116

Windows accept electric conduit connections on either side.

slide-117
SLIDE 117
slide-118
SLIDE 118

Windows use “O” rings not gaskets.

slide-119
SLIDE 119
slide-120
SLIDE 120
slide-121
SLIDE 121
slide-122
SLIDE 122

Windows hold drain plugs and breathers

slide-123
SLIDE 123
slide-124
SLIDE 124

Now lets discuss the IPB’s Enclosure

slide-125
SLIDE 125

I have two questions for you that we can discuss in more depth at some later time off-line.

slide-126
SLIDE 126

1 – Did you know that IPB enclosure current is more or less equal to the conductor current ? For all practical purposes – IPB is a transformer with a 1:1 turns ratio.

slide-127
SLIDE 127
slide-128
SLIDE 128

Your specs could well improve the IPB product you get if they clearly state that enclosure max. temperature of 80 degree C shall be calculated at 100 % of the same maximum current value as the IPB conductor

slide-129
SLIDE 129

2 – If you evaluate and charge for losses in transformers – why don’t you do the same evaluation for IPB ? It’s the same electrons and the same heat ( energy ) lost from the production process.

slide-130
SLIDE 130

Something to notice

  • n

Enclosures for connecting IPB to capital equipment.

slide-131
SLIDE 131
slide-132
SLIDE 132

Notice the Covers

slide-133
SLIDE 133
slide-134
SLIDE 134

See how they mount?

slide-135
SLIDE 135
slide-136
SLIDE 136
slide-137
SLIDE 137

Those raised welded mounting frames takes:

Engineering

Drafting Fabrication Welding Finishing

slide-138
SLIDE 138

Those raised welded mounting frames…

slide-139
SLIDE 139

$ Cost money $

slide-140
SLIDE 140

If you want them. You need to specify them.

slide-141
SLIDE 141

BTW

slide-142
SLIDE 142

Shipping sections

slide-143
SLIDE 143

#’s of shipping sections Points of break in shipping sections All cost installation $$’s

slide-144
SLIDE 144

Consider discussing this issue with your bidders during the evaluation process

slide-145
SLIDE 145

As we wind down- allow me to point out two more things worth knowing about…

slide-146
SLIDE 146

1 – Shunts

slide-147
SLIDE 147
slide-148
SLIDE 148
slide-149
SLIDE 149

Shunts are made of bundles of very thin laminates of

  • aluminum. And they

move (often).

slide-150
SLIDE 150
slide-151
SLIDE 151

The shunt bundles should be welded on the inside – not the

  • utside. A broken

laminate can bend

  • utward toward the

ground plane !

slide-152
SLIDE 152
slide-153
SLIDE 153
slide-154
SLIDE 154

2 – know your connection points. They should be quality silver plated. The silver plating should be per a certified procedure.

slide-155
SLIDE 155
slide-156
SLIDE 156

Spec 3-5 mils. And vendor should provide certification with their bid.

slide-157
SLIDE 157

NEVER accept wipe-on silver plating.

slide-158
SLIDE 158

Silver Plating A Special Process at Crown Electric

slide-159
SLIDE 159 When Crown Electric began using the Electrodeposited silver plating machines, the instructions with the machines were vague in what was needed to meet the standards of our industry. The instructions showed how to plate, but lacked the information on how much or how long to deposit the silver to achieve the desired results. We researched and purchased the standards that apply to the process. The first standard is for adhesion ASTM B571-97; we needed to know that the silver stayed in place. The second is the standard for thickness ASTM B700-08. According to the standard ASTM B700-08 the thickness for electrical contact connectors of limited wear is 2.5 micrometers. At Crown we wanted a margin greater than 2.5m to ensure supply of a consistent and superior
  • product. So we embarked on the task of preparing coupons and plating at
incremental times, then sending them out to a second party laboratory for testing and documented results.
slide-160
SLIDE 160 Because the testing process results in destruction of the samples, we needed to validate our process and document a procedure to set in place for our quality standards as well as to meet our ISO program requirements. The process began by making the coupons out of the material we use for our
  • product. We prepared them for plating as standard process and recorded the
rub time per coupon, then sent the coupons to the lab. Our first couple of coupons passed the adhesion tests. After burnishing test neither specimen developed blisters, lifting or peeling. This satisfies the requirement in paragraph 4.1 of ASTM B571.
slide-161
SLIDE 161 However one fell short on thickness and the other was predominantly at the standard thickness with some valleys that showed under the microscope to be less than desirable. Silver coating is discontinous and measured thickness is less than the 2.5 μm minimum thickness specified in ASTM B700. (Average ~ 1 μm) Silver coating is continous and measured thickness is between 1.5 - 5 μm, with a predominant thickness
  • f ~ 2.5 μm.
slide-162
SLIDE 162 Then we prepared and plate additional coupons with a longer rub time. They were sent to the lab for evaluation. We were pleased with our test results; again the adhesion test satisfied the standard and the thickness tests came out far exceeding the standards hallmark. Silver coating is continuous and predominant thickness is between 10 and 20 μm.
slide-163
SLIDE 163 The information from the testing has been written into a Crown Electric ISO Silver Plating Procedure for use in-house, as well as on customer sites should the need arise. We now have second party laboratory results which show that Crown’s silver plating exceeds the standards and complements the Crown Electric products high standards.
slide-164
SLIDE 164
slide-165
SLIDE 165
slide-166
SLIDE 166
slide-167
SLIDE 167
slide-168
SLIDE 168

I guess the point I’m trying to make is –

slide-169
SLIDE 169

Iso Phase Bus may be boring

slide-170
SLIDE 170

But there are engineering differences to be cognizant of

slide-171
SLIDE 171
  • Dew point rated

stand off supports

slide-172
SLIDE 172
  • Dew point rated stand off supports
  • Forced

pressurization should be penalized

slide-173
SLIDE 173
  • Forced pressurization should be penalized
  • Insulator in-situ

visibility and accessibility should be positively evaluated

  • Dew point rated stand off supports
slide-174
SLIDE 174
  • Insulator in-situ visibility and accessibility should

be positively evaluated

  • Welding should be

able to be certified

  • Forced pressurization should be penalized
  • Dew point rated stand off supports
slide-175
SLIDE 175
  • Insulator in-situ visibility and accessibility should

be positively evaluated

  • Welding should be able to be certified
  • Forced pressurization should be penalized
  • Dew point rated stand off supports
  • Enclosures should

have welded raised frames for bolting

  • n covers.
slide-176
SLIDE 176
  • Insulator in-situ visibility and accessibility should

be positively evaluated

  • Welding should be able to be certified
  • Forced pressurization should be penalized
  • Dew point rated stand off supports
  • Enclosures should have welded raised frames for

bolting on covers.

  • Enclosure’s

amperage should be specified

slide-177
SLIDE 177
  • Insulator in-situ visibility and accessibility should

be positively evaluated

  • Welding should be able to be certified
  • Forced pressurization should be penalized
  • Dew point rated stand off supports
  • Enclosures should have welded raised frames for

covers

  • Enclosures amperage should be specified
  • IPB losses should

be evaluated

slide-178
SLIDE 178

Always remember

slide-179
SLIDE 179
