A BPA Biosensor A BPA Biosensor The Bisphenolics : Jason Gardiner, Saul Godkewitsch, Benny Hung, Christopher Kelly, David Lancaster, Anthony Lott, Justin Pahara, Kelly Robinson, Tom Tran, Winnie Xu, Saima Zamir Our Advisors: James Maclagan,

SLIDE 1

The Bisphenolics: Jason Gardiner, Saul Godkewitsch, Benny Hung, Christopher Kelly, David Lancaster, Anthony Lott, Justin Pahara, Kelly Robinson, Tom Tran, Winnie Xu, Saima Zamir Our Advisors: James Maclagan, Michael Deyholos, Doug Ridgway, Michael Ellison

A BPA Biosensor A BPA Biosensor

SLIDE 2

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Edmonton, Alberta, Canada Edmonton, Alberta, Canada

SLIDE 3

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Edmonton, Alberta, Canada Edmonton, Alberta, Canada

SLIDE 4

Meet eet t the... e...

asds

SLIDE 5

Meet eet t the... e...

SLIDE 6

Overview Overview

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

iGEM iGEM 2007 2007 Binary vector Binary vector BPA Background BPA Background Design Design Results Results Summary Summary Acknowledgements Acknowledgements

SLIDE 7

iGEM iGEM 2007 2007

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Protein gel of butanol producing pathway proteins

Operon was completed with 5 different genes synthesizing butanol. To optimize butanol production the operon requires three additional inserts:

1. ETFA : electron-transfer-flavoprotein

2. ETFB : electron-transfer-flavoprotein, β
3. Thiolase

SLIDE 8

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

iGEM: focus on prokaryotic and simple eukaryotic systems Extend scope to include plants

pCambia vector backbone
Kan and Chpc selective resistance
Reworked MCS includes BioBrick

prefix and suffix

Easy assembly

Plant Binary Vector

Gardiner/Deyholos MCS NOS Poly A Tail Right border T-DNA repeat Left border T-DNA repeat Kanamycin Resistance pVS1-REP pVS1 STA

BiobrickVector 6874 bp

pVR322 bom de pBR322 or1

SLIDE 9

Bisphenolics Bisphenolics Plastic Project Plastic Project

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Bisphenol A detecting and degrading bacteria

SLIDE 10

Plastics and Pollutants Plastics and Pollutants

Plastics: Organic polymers of high molecular weight based on synthetic materials.

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

SLIDE 11

Plastics and Pollutants Plastics and Pollutants

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

SLIDE 12

The Great Pacific Garbage Patch The Great Pacific Garbage Patch

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

SLIDE 13

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

I wouldn I wouldn’ ’t drink from that t drink from that… …

SLIDE 14

Bisphenol Bisphenol A (BPA) A (BPA)

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Bisphenol Bisphenol A A Estrogen Estrogen

SLIDE 15

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Health Hazards Health Hazards

Adipocytes Reproductive Health Breast Cancer Prostate Cancer Homeostasis and Development

SLIDE 16

To detect and degrade bisphenol A

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Objective Objective

DETECT DESTROY

SLIDE 17

BPA stimulates transcription of estrogen–regulated genes We can use estrogen receptor (ER) to detect BPA

Estrogen Receptor (ER) Estrogen Receptor (ER)

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

SLIDE 18

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

A/B A/B C C D D E E F F DNA Binding Ligand Binding Upon Dimerization Dimer

f Estrogen

Receptor α

Estrogen

receptors are intracellular transcription factors

Two forms of estrogen

receptor: ERα and ERβ – different affinities

Interested in DNA binding domain

and ligand binding domain

Estrogen Receptor (ER) Estrogen Receptor (ER)

SLIDE 19

To test ER toxicity of in our system we expressed the DNA and ligand domains in

E. coli and compared their growth rates over time.

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

ER ERα α-

1 and ER

1 and ERα α-

2 Toxicity

2 Toxicity

ERα-1: Ligand binding domain ERα-2: DNA binding domain Mueller-Fahrnow and Egner (2008) report the toxicity

f the ERα

DNA binding domain

SLIDE 20

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

ER ER-

DNA and

DNA and Ligand Ligand binding binding toxicity toxicity

Average growth rate of cultures induced with arabinose

Empty vector Ligand DNA

SLIDE 21

Transcriptional regulation differs in prokaryotic E. coli

compared to eukaryotic mammalian cells

Thus, to repress transcription we devised a method

based upon steric hindrance

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Bacteria are NOT mammals Bacteria are NOT mammals

Escherichia coli Megaptera novaeangliae

SLIDE 22

RFP ER monomer No BPA TetR +BPA= ER Dimer BisdB BisdA

OH HO

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

TetR NOT Gate

SLIDE 23

RFP with no TetR RFP with TetR

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Proof of TetR Principle

We chose RFP (Red Fluorescent Protein) as a downstream reporter in E.coli because it gives rise to visible, red colonies

SLIDE 24

How do we degrade BPA?

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

SLIDE 25

Sasaki et al. isolated two genes that can degrade BPA together

Sasaki et al. 2008

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

BisdA and BisdB Degrade BPA

SLIDE 26

115ug/ml-90ug/ml over 18 hours of incubation

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

BisdA and BisdB Degrade BPA

Sasaki et al. 2008 Empty Vector BisdB BisdA/B

SLIDE 27

ER monomer ERE No BPA TetR

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Summary: BPA Absent

Without BPA or any estrogen-like compound, ER receptor is made in the cell, as is the TetR transcription factor.

1. ER in the monomer form does

not inhibit the production of TetR. ERE is unbound

SLIDE 28

ER monomer ERE No BPA TetR

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

2. TetR

represses the transcription of RFP, BisdA, and BisdB

Without BPA or any estrogen-like compound, ER receptor is made in the cell, as is the TetR transcription factor.

Summary: BPA Absent

SLIDE 29

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

ERE ER Dimer

When BPA is present, the ER receptor dimerizes

1. ER dimer

binds to ERE, and represses TetR transcription

ER monomer + BPA =

OH HO

Summary: BPA Present

SLIDE 30

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

RFP ere ER Dimer BisdB BisdA ER monomer + BPA =

OH HO

When BPA is present, the ER receptor dimerizes

2.This allows the upregulation

target genes RFP, BisdA, and BisdB

Summary: BPA Present

SLIDE 31

System 1 (Estrogen Receptor): We have the two domains assembled and have confirmed that they are not toxic to the cell. System 2 (TetR): Assembled with the entire operon excluding ER and has been shown to successfully turn off TetR sensitive promotors. System 3 (RFP & BisdA/B): Assembled with the entire operon excluding ER and regulated by TetR. BisdA/B can degrade BPA. Optimization is required.

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Summary: 3 Systems

SLIDE 32

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

BPA and your research!

SLIDE 33

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Acknowledgements Acknowledgements Our Former Our Former Teammates Teammates Our Sponsors Our Sponsors Our Consultants Our Consultants

SLIDE 34

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

SLIDE 35

RFP ER monomer No BPA TetR +BPA= ER Dimer BisdB BisdA

OH HO

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Overview

SLIDE 36

BPA is degraded into two metabolites

UNIVERSITY OF ALBERTA UNIVERSITY OF ALBERTA

Degradation Products

Sasaki et al. 2008 BisdA & BisdB BisdB Empty vector No cells
