NGL Recovery in CO2 Floods Options and Reasons Eric Prim Naomi Baker 6 th Annual Wyoming CO2 Conference Casper Wyoming July 11-12, 2012 Pilot Energy Solutions Develops technology in the energy sector and implements this technology as a

slide-1
SLIDE 1

NGL Recovery in CO2 Floods Options and Reasons

Eric Prim Naomi Baker 6th Annual Wyoming CO2 Conference Casper Wyoming July 11-12, 2012

slide-2
SLIDE 2
  • Develops technology in the energy

sector and implements this technology as a third party or J.V. partner

Pilot Energy Solutions

2

slide-3
SLIDE 3

Pilot Energy Patents

  • NGL recovery from LNG – Cold side
  • CO2 fractionation for capacity increases
  • HIREX – Extremely High C3+ Recovery with Low

Vapor Pressure (Low C2 Recovery)

  • NGL recovery from CO2 by Fractionation I and II
slide-4
SLIDE 4

Primary Production

Oil + Gas + NGLs

slide-5
SLIDE 5

Secondary Production

Oil + Gas + NGLs

Source: rangesources.com

slide-6
SLIDE 6

Tertiary Production

Oil Only?? No Gas, No NGLs?

slide-7
SLIDE 7

Why NGL Recovery

  • Can add 25% to field production
  • Increases recoverable reserves
  • Additional revenue stream
  • Increases CO2% in recycle (good/bad)
  • Sequester more CO2
  • Provides dehydration of recycle stream
slide-8
SLIDE 8

Processing Options

  • Ryan Holmes – most expensive
  • Membrane/Amine – close to most expensive
  • Bulk Fractionation (Pilot)– way less expensive
  • Refrigeration – least expensive
  • All are more expensive than

conventional gas processing

slide-9
SLIDE 9

Why is this so hard??

A simple analogy

  • Methane = Baby Powder
  • CO2 = Sugar
  • Ethane = Salt
  • Propane = BB’s
  • Butane = Marbles
  • Pentane = Golf Balls
  • Crude = Basket Balls
slide-10
SLIDE 10

Basis for Comparison

Case Study

  • Flow Rate = 20 MMSCFD
  • Interstage Pressure = 550 PSI
  • H2S + N2 = 2.9%
  • CO2 = 88%
  • C1 = 2.8%
  • C2 = 1.9%
  • C3 = 2.0%
  • C4 = 1.4%
  • C5+ = 1.0%
slide-11
SLIDE 11

“Typical” 20MM Plant

$0 $10,000,000 $20,000,000 $30,000,000 $40,000,000 $50,000,000 $60,000,000 Ryan Holmes Membrane Fractionation Refrigeration

Estimated Capital Cost 20 MMSCFD Recycle

slide-12
SLIDE 12

Ryan Holmes Process

Does anybody Remember Lean Oil Plants

slide-13
SLIDE 13

Amine Membrane System

New Word: Iatrogenic = suffering from a solution

100 MMSFD Pre- Treatment Refrig Sys Vapor 72 MMSCFD Liquid 28 MMSCFD LP CO2 from Treat NGL Liquid Treating Hydrocarbon 1st Stage Membrane HP Permeate 10 MMSCFD HP Permeate

LP CO2 from Treating

Compression Compression LP Permeate Compression 2nd Stage Membrane Hydrocarbons Cryogenic Processing LP Permeate HP Treating

Inlet Gas

Hydrocarbon Product

CO2 Product

slide-14
SLIDE 14

Recoveries

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% Ryan Holmes Membrane Fractionation Refrigeration

Recovery Comparison

C1 C2 C3 C4 C5+

slide-15
SLIDE 15

Value of Products

$0 $5,000 $10,000 $15,000 $20,000 $25,000 Ryan Holmes Membrane Fractionation Refrigeration Gross $/day

slide-16
SLIDE 16

Just Because You Can, Doesn’t Mean You Should

  • Methane content worth $600K/Yr, Most/all

is consumed to extract. Payout = ∞

  • Ethane: Worth more, but hard to market –

Unless you have access to an NGL pipeline, you can’t keep it.

slide-17
SLIDE 17

Estimated Annual EBITDA

$0 $2,000 $4,000 $6,000 $8,000 $10,000 $12,000 $14,000 $16,000 $18,000 Ryan Holmes Membrane Fractionation Refrigeration

slide-18
SLIDE 18

Economic Comparison

0% 5% 10% 15% 20% 25% 30% 35% 40%

  • $30,000,000
  • $20,000,000
  • $10,000,000

$0 $10,000,000 $20,000,000 $30,000,000 $40,000,000 Ryan Holmes Membrane Fractionation Refrigeration PV-10 PV-10 Simple Return

ROR

slide-19
SLIDE 19

Fractionation Position #1

Inlet Separation 50 PSI

Oil/Water Compression Stages 1,2 Compression Stages 3,4 Processing Plant (250 PSI to 650 PSI) Reservoir NGL Product

slide-20
SLIDE 20

High Pressure Inlet High Pressure Flash Low Pressure Flash Oil/Water Compression Processing Plant NGL Compression

Reservoir

Fractionation Position #2

slide-21
SLIDE 21

Monell Under Construction

21

slide-22
SLIDE 22

Monell Plant

22

slide-23
SLIDE 23

Mentone Plant

23

slide-24
SLIDE 24

Goldsmith Plant

slide-25
SLIDE 25

Cenovus Weyburn Flood

slide-26
SLIDE 26

Pilot Commercial

  • Pilot will build, own, (operate), pay 100% of the cost,

give Producer a share of $$ for no cost

  • Or
  • If the stream is too lean, Pilot will J.V.
  • Or
  • If the stream is really rich, Pilot will process for a fixed

fee and give Producer all production

  • Or ???
slide-27
SLIDE 27

Contact Information

Eric Prim, President ericprim@pilotllc.com Naomi Baker, Director Engineering/Operations naomibaker@pilotllc.com pilotllc.com 281-448-4890
