SLIDE 1
100’ 6 ’ 12’ Existing Aerial, Setbacks per Code Buildable Area Less Than 50 Square Feet
0’ 25’
6 0 Existing Aerial, Setbacks per Code A House Setback, Rear / - - PowerPoint PPT Presentation
6 0 Existing Aerial, Setbacks per Code A House Setback, Rear / - - PowerPoint PPT Presentation
0 25 Buildable Area Less Than 50 Square Feet 12 100 6 0 Existing Aerial, Setbacks per Code A House Setback, Rear / Lake (60 required, requesting 40.7) B House Setback, Creek (100 required, requesting 25,
SLIDE 2
SLIDE 3
House Setback, Rear / Lake (60’ required, requesting 40.7’) House Setback, Creek (100’ required, requesting 25’, existing 25’) House Height (25’ max., requesting 26.51’) Garage Setback, North Property Line / Side (12’ required, requesting 5.2’, existing 0-4.7’) Garage Setback, West Property Line / Front (60’ required, requesting 5.2’, existing 1.6’) Garage Setback, Creek (100’ required, requesting 18.5’, existing 20.5’) Garage Height (16’ max., requesting 18.64’) A B C D E F G
7 Requested Variances
4 are equivalent to variances previously granted in 2013
SLIDE 4
Existing Aerial Lot Width Constraint Conforming Lot Width Area
125’ 125’ usable
Non-Conforming Lot Width Area
0’ 25’
SLIDE 5
0’ 25’
Sketch Plan Existing House Overlay (red) Proposed Setbacks
40.7’ 63.2’
SLIDE 6
0’ 25’
Sketch Plan Proposed Lake Setback & Average Setback
40.7’
Average Lake Setback 50.6’
Based on setback to closest point at 5’ increments along entire lake front facade
SLIDE 7
Sketch Plan w/ Setback Relative to Neighboring Structures
House is consistently set back 10+ feet behind range line of adjacent neighbors
SLIDE 8
18’ 12’ 34’ 48’ 42’ 34’ 36’ 21’ 45’ 42’ 45’ 21’ 41’ 48’ 45’ 121’ 94’ 128’ 62’ 40.7’ (MHWL) 63’
12/2015 Shoreline
Lake Setbacks
Visible shoreline (2016 Pictometry Measurements) Ontario County GIS
Average setback of 19 adjacent properties: ~49.3’ Average setback of 17 properties (two 120’+
- utliers removed): ~40.4’
SLIDE 9
Fall 2015 Previous Proposal
Southerly views blocked in prior proposal. Worked with neighbor and pulled back house 10’
0’ 25’
SLIDE 10
0’ 25’
Sketch Plan Creek Setback
Request equivalent to previously granted creek setback (2013) 25’
SLIDE 11
SLIDE 12
0’ 25’
Sketch Plan Garage Setbacks
18.5’ 5.7’ 5.7’
SLIDE 13
SLIDE 14
Adjacent Owner Garage ~19.7’ above average finished grade Proposed Garage 18.64’ above average finished grade
SLIDE 15
