5G: From Theory to Practice

Ian C. Wong, Ph.D. Senior Manager, Advanced Wireless Research ian.wong@ni.com

slide-2
SLIDE 2

2

ni.com | NI CONFIDENTIAL

20 Gb/s 100 Mb/s everywhere 1 Gb/s hotspots 3x LTE-A 500 km/h 1 ms 106 devices/km2 100x LTE-A 10 Mb/s/m2

ITU IMT-2020 (5G) Vision

Source: ITU-R M.[IMT.VISION]

slide-3
SLIDE 3

3

ni.com | NI CONFIDENTIAL

3GPP RAN Workshop on 5G Summary

  • 550 delegates with over 70

presentations

  • New radio access technology (RAT)

should be able to support a variety of new services

  • Automotive, Health, Energy,

Manufacturing ...

  • 3 Main Use Cases:
  • Enhanced Mobile Broadband
  • Massive Machine Type Communication
  • Ultra-reliable and Low Latency

Image from 3gpp.org

slide-4
SLIDE 4

4

ni.com | NI CONFIDENTIAL

3GPP RAN1 Phase 1 and Phase 2

Phase 1 Parameter Guideline Notes Compatibility Forward only Tight LTE integration mmWave Frequencies 30..40 GHz > 100 MHz Bandwidth Access TDD, FDD and unlicensed Peak rate 20 Gbps Use Cases eMBB focus Latency 1 ms Scalable TTI TTI < 100 us Waveforms OFDM Non orthogonal options Deployments Urban Macro Urban Micro Indoor hotspots Parameter Guideline Compatibility Future proof mmWave Frequencies 6 … 100 GHz Access TDD, FDD flexible duplex Use Cases All Latency Build upon Phase 1 Waveforms Build upon Phase 1 Deployments All Phase 2

slide-5
SLIDE 5

5

ni.com | NI CONFIDENTIAL

Proposed 5G Timeline

SD#27 Jun 17 SD#26 Feb‘17 SD#31 Oct 18 SD#32 Jun 19

RAN#72 Jun 16 RAN#70 Dec 15

RAN#69 Sep 15

Evaluation Criteria Evaluation Criteria Requirements Requirements Evaluation Evaluation

IMT-2020 specifications IMT-2020 specifications

Phase 1 Phase 1

Channel Modeling Channel Modeling

Phase 2 Phase 2 Phase 2 Phase 2

RAN#86 Jan 20 Sept 18 Dec 19

RAN1 SI Evaluation of Solutions RAN1 SI Evaluation of Solutions RAN1 WG Specification of Solutions RAN1 WG Specification of Solutions Initial Submissions Initial Submissions

SD#28 Oct 17

RAN#71 Mar16 RAN#71 Mar16 RAN1 Scope / Req’s RAN1 Scope / Req’s

SD#23 Feb‘17

IMT 2020

SD#34 Feb 20 SD#36 Oct 20

slide-6
SLIDE 6

6

ni.com | NI CONFIDENTIAL

Prototyping Is Critical for Breakthrough Research

“Experience shows that the real world often breaks some of the assumptions made in theoretical research, so testbeds are an important tool for evaluation under very realistic operating conditions” “…development of a testbed that is able to test radical ideas in a complete, working system is crucial”

1NSF Workshop on Future Wireless

Communication Research

slide-7
SLIDE 7

7

ni.com | NI CONFIDENTIAL

Wireless Communications Lead User Program

  • Established in 2010
  • Goals: Further wireless research through prototyping
  • Research Institutions
  • Academic
  • Industry
  • Over 100 research papers published
slide-8
SLIDE 8

8

ni.com | NI CONFIDENTIAL

Utilize potential of extremely wide bandwidths at frequency ranges once thought impractical for commercial wireless. Consistent connectivity meeting the 1000x traffic demand for 5G Dramatically increased number of antenna elements on base station.

5G Vectors

Improve bandwidth utilization through evolving PHY Level

PHY Enhancements Massive MIMO Wireless Networks mmWave

  • GFDM
  • FBMC
  • UFMC
  • NOMA
  • Full duplex
  • Densification
  • SDN
  • NFV
  • CRAN
slide-9
SLIDE 9

9

ni.com | NI CONFIDENTIAL

Utilize potential of extremely wide bandwidths at frequency ranges once thought impractical for commercial wireless. Consistent connectivity meeting the 1000x traffic demand for 5G Dramatically increased number of antenna elements on base station.

5G Vectors

Improve bandwidth utilization through signal structure improvements such as NOMA, GFDM, FBMC, & UFMC

PHY Enhancements Massive MIMO Wireless Networks mmWave

slide-10
SLIDE 10

10

ni.com | NI CONFIDENTIAL

Massive MIMO in Cellular Networks

  • Give basestation a large array of antennas

(> 10X higher than current systems)

  • Time-division duplexing (TDD)
  • Excess antennas guarantee good channel with high probability
  • Large number of users can be served simultaneously
  • T. L. Marzetta, “Noncooperative cellular wireless with unlimited numbers of base station antennas,”

IEEE Trans. Wireless Comm., vol. 9, no. 11, 2010.

slide-11
SLIDE 11

11

ni.com | NI CONFIDENTIAL

NI and Massive MIMO

Silicon Valley Software Giant Silicon Valley Software Giant A Leading Chip Vendor A Leading Chip Vendor

INDUSTRY

slide-12
SLIDE 12

12

ni.com | NI CONFIDENTIAL

Massive MIMO in action

Lund University setup

Vieira, Joao, et al. "A flexible 100-antenna testbed for Massive MIMO." IEEE Globecom Workshops (GC Wkshps), 2014. IEEE, 2014.

Initial results: Received signal constellations – LOS & four users 2 m separation

slide-13
SLIDE 13

13

ni.com

NI and Samsung Demonstrate FD-MIMO With LabVIEW Communications and LTE App Framework

NIWeek 2015

“Samsung Demonstrates FD-MIMO In Real Time For The First Time In The World…It Accelerates Its Leadership Over Competition For 5G Standard”

english.etnews.com

slide-14
SLIDE 14

14

ni.com

slide-15
SLIDE 15

15

ni.com | NI CONFIDENTIAL

Utilize potential of extremely wide bandwidths at frequency ranges once thought impractical for commercial wireless. Consistent connectivity meeting the 1000x traffic demand for 5G Dramatically increased number of antenna elements on base station.

5G Vectors

Improve bandwidth utilization through signal structure improvements such as NOMA, GFDM, FBMC, & UFMC

PHY Enhancements Massive MIMO Wireless Networks mmWave

slide-16
SLIDE 16

16

ni.com | NI CONFIDENTIAL

Future Networks Architecture

 Highly heterogeneous and hyper dense networks that require high level of coordination

Source: 5GPPP, Why the EU is betting big on 5G, 2015

Macro cells + Small cells = Heterogeneous networks Macro Cell Small / Pico Cells

slide-17
SLIDE 17

17

ni.com | NI CONFIDENTIAL

Architecture for Full Protocol Stack Explorations

PHY/MAC Stack in LabVIEW Open Source Upper Layer Stack (e.g. ns-3) LTE 802.11 MTC IoT LTE Ref Design 802.11 Ref Design NI Hardware

slide-18
SLIDE 18

18

ni.com | NI CONFIDENTIAL

NI and CROWD Collaborate on Software-Defined Networks

Goal: Create a testbed for dense LTE/WiFi networks based on Software Defined Networking (SDN) for measuring performance of algorithms in real network environments

  • Implement cross-layer PHY/MAC algorithms
  • Explore Enhanced Interference Coordination

Technologies

  • Dynamic radio and backhaul configuration
  • Connectivity Management

Gupta, Rajesh, et al. "LabVIEW based Platform for prototyping dense LTE Networks in CROWD Project." Networks and Communications (EuCNC), 2014 European Conference on. IEEE, 2014.

slide-19
SLIDE 19

19

ni.com | NI CONFIDENTIAL

Texas A&M and NI Collaborate on Advanced MAC Research

  • Research goal
  • “Mechanism-Policy” separation

framework for MAC analysis

  • Real world verification of

advanced MAC algorithms

  • Multi-node MAC test bed
  • Each node by a USRP RIO
  • 802.11 Application Framework

modified to implement various MAC protocols

  • CSMA/CA, CHAIN, Weighted

transmission

  • Prof. P. R. Kumar and Prof. Robert Cui
  • S. Yau, et al., “WiMAC: Rapid Implementation Platform for User Definable MAC

Protocols Through Separation, ACM SigCOMM, Aug. 2015

slide-20
SLIDE 20

20

ni.com | NI CONFIDENTIAL

Open Testbed for LTE-WiFi-Coexistance (LAA, LTE-U)

Starting point:

  • Extend and modify

LTE and 802.11 Application Frameworks

Result:

  • Real over the air measurements to

verify simulation data!

“Experimental Results on Impact of Energy Detection Threshold for DL LAA,” 3GPP RAN1 contribution R1-156622 , National Instruments

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 2 4 6 8 10 Normalized Throughput LTE TxOP duration (ms) LTE Wi-Fi

slide-21
SLIDE 21

21

ni.com | NI CONFIDENTIAL

Utilize potential of extremely wide bandwidths at frequency ranges once thought impractical for commercial wireless. Consistent connectivity meeting the 1000x traffic demand for 5G Dramatically increased number of antenna elements on base station.

5G Vectors

Improve bandwidth utilization through signal structure improvements such as NOMA, GFDM, FBMC, & UFMC

PHY Enhancements Massive MIMO Wireless Networks mmWave

slide-22
SLIDE 22

22

ni.com | NI CONFIDENTIAL

NI and TU Dresden Collaborate on 5G Waveforms

  • 5G Lab and Test Bed
  • Rapid prototyping of Generalized

Frequency Division Multiplexing (GFDM)

  • World’s first 2x2 MIMO GFDM

prototype !!

  • Dr. Gerhard Fettweis

GASPAR, Ivan, et al. "FPGA implementation of Generalized Frequency Division Multiplexing transmitter using NI LabVIEW and NI PXI platform."

slide-23
SLIDE 23

23

ni.com | NI CONFIDENTIAL

NTT Docomo and NI Collaborate on NOMA Testbed

NOMA: Non-Orthogonal Multiple Access

f, t, code

"By adopting NI's cutting-edge 5G wireless rapid prototyping test system, we expect to see results on performance and capabilities faster on NOMA and higher frequencies“ Takehiro Nakamura, Managing Director of the 5G Laboratory

Exploitation of power-domain, path loss difference among users, and device processing power

slide-24
SLIDE 24

24

ni.com | NI CONFIDENTIAL

LG, Yonsei University, and NI Collaborate on Full Duplex Radio

  • Polarization separation

with digital self- interference cancellation

  • 20 MHz LTE-based

realtime PHY

  • 1.9x throughput

improvement over half- duplex PHY

  • Recent extensions to 2x2

MIMO

  • Dr. Chan-Byoung Chae

Chung, MinKeun, et al. "Prototyping Real-Time Full Duplex Radios." IEEE Communicatons Magazine, 2015.

LG Electronics - Yonsei University, Announce 'FDR' era in communications technology leader 5G – Yonhap news agency

slide-25
SLIDE 25

25

ni.com | NI CONFIDENTIAL

Utilize potential of extremely wide bandwidths at frequency ranges once thought impractical for commercial wireless. Consistent connectivity meeting the 1000x traffic demand for 5G Dramatically increased number of antenna elements on base station.

5G Vectors

Improve bandwidth utilization through signal structure improvements such as NOMA, GFDM, FBMC, & UFMC

PHY Enhancements Massive MIMO Densification mmWave

slide-26
SLIDE 26

26

ni.com | NI CONFIDENTIAL

mmWave Technology for Mobile Access

  • Existing cellular bands are crowded and expensive
  • The next frontier is mmWave frequencies to provide
  • High throughput (> 10 Gb/s)
  • Lower latency (< 1ms)
  • Enables “ultra-definition” media and “tactile” applications
  • FCC recently proposed rules for 28, 37, 39, and 66-71 GHz for mobile access

image from electronicdesign.com

slide-27
SLIDE 27

27

ni.com | NI CONFIDENTIAL

NYU Wireless and NI Collaborate on mmWave Channel Sounding and Prototyping

  • Channel sounding at 28, 38, and 72 GHz
  • mmWave link layer prototyping
  • Prof. Ted Rappaport
slide-28
SLIDE 28

28

ni.com | NI CONFIDENTIAL

Nokia and NI Collaborate on mmWave Access Technologies

“It took about 1 calendar year, less than half the time it would have taken with other tools”

  • Dr. Amitava Ghosh, Head of Broadband Wireless Innovation, Nokia Networks

Nokia Video

slide-29
SLIDE 29

29

ni.com

Nokia 5G at Mobile World Congress

Image from video on nokia.com

  • 73 GHz
  • 1 GHz bandwidth
  • 2.3 Gps peak rate

eNodeB UE

slide-30
SLIDE 30

30

ni.com

NI Week Keynote: mmWave PoC System @ 2 GHz BW supporting 10 Gbps Peak rate

NIWeek: NI partnerships with Samsung, Nokia bearing 5G fruit - RCR Wireless Nokia demos mmWave transmission for 5G at NI Week: 10Gbps @ 73GHz over 200m – Xcell Daily Blog

slide-31
SLIDE 31

31

ni.com

slide-32
SLIDE 32

32

ni.com

mmWave PoC System @ 2GHz BW supporting 10 Gbps Peak rate

New platform designed by NI to meet Nokia’s 5G specification

Parameters Value Operating Frequency 73.5 GHz Configuration 2 x 2 MIMO antenna polarization Bandwidth 2 GHz Peak Rate ~10 Gbps Modulation Null Cyclic-Prefix Single Carrier R=0.9, 16 QAM Antenna Horn Antenna

slide-33
SLIDE 33

33

ni.com

Platform Based Design for 5G

Reconfigurable Instruments High Performance IO USRP RIO SDR USRP SDR

Mult-RAT Testbeds Wireless Networks Massive MIMO mmWave

slide-34
SLIDE 34

34

ni.com

LabVIEW Communications System Design Suite

The Revolution in Rapid Prototyping

Hardware Software

Hardware Aware Design Environment Algorithmic Design Languages Design Exploration

IP Overall Winner: 2015 EDN/EETimes ACE (Annual Creativity in Electronics) Awards for Best Software

slide-35
SLIDE 35

35

ni.com

LTE and 802.11 Application Frameworks

Applications

  • Customize LTE and 802.11
  • LTE/802.11 coexistence
  • New 5G waveforms

Applications

  • Customize LTE and 802.11
  • LTE/802.11 coexistence
  • New 5G waveforms

Fastest path from algorithm to prototype

Single language for host and FPGA design in LabVIEW Documented for ease of use and understanding

Modular Open Source Design

~50% of FPGA resources available for customization Replace existing blocks with your own waveform designs

Real-time wireless system implementation

Ready to run PHY and basic MAC Communicate between devices or in loop-back mode

slide-36
SLIDE 36

ni.com | NI CONFIDENTIAL

www.ni.com/5g www.ni.com/sdr
