48-175 Descriptive Geometry Planes in Descriptive Geometry A spatial figure is a plane whenever for any two points on the figure, the line specified by the points also lies on the figure. A plane is the set of all points that lie on any line
SLIDE 2
SLIDE 3
generating a plane
3 Line rotated about a point form a sector of a plane circle Line moving parallel to itself will generate a plane
SLIDE 4
specifying a plane 1
4
By two intersecting lines
SLIDE 5
specifying a plane 2
5
By three non-collinear points
SLIDE 6
specifying a plane 3
6
By a line and a point off the line
SLIDE 7
specifying a plane 4
7
By two parallel lines
SLIDE 8
depicting planes
8
Planes are always depicted to have limited size A plane is completely and uniquely defined by three non-collinear points
- n the plane;
That is, we can delineate a bounded portion of the plane by points that form the corners of a triangle which belong to the plane
A C B C B A
SLIDE 9
where is the point?
9
P P B C A C A B A B C P LIne XY lies on plane ABC and passes through point P, which is also in the plane ABC Y X Y Y X X
SLIDE 10
A C B P C B A
where is the point?
10
P 2 1 2 1 4 3 4 3
SLIDE 11
edge view of a plane
11
Line BY appears as a point plane ABC as an edge Line CZ appears as a point plane ABC as an edge Line AX appears as a point plane ABC as an edge
A C B Z Y X
SLIDE 12
2 1
A C B C B A
edge view of a plane
12
R S S R
TL RS seen in TL in view #3
1 3
S R B C A
ABC seen in edge view (EV) in view #4 RS seen in point view (PV in view #4
3 4
R,S A C B
SLIDE 13
edge view of a plane
13
A C B C B A
Horizontal line seen in TL Horizontal line in plane ABC
X X A
Line AX in point view Edge view of plane ABC
A,X B C
SLIDE 14
practical - view of a house showing edge view of sloping ground
14
f t l m m l b a f t l m m l
SLIDE 15
how do we draw a and b ?
15
f t l m m l b a f t l m m l
SLIDE 16
b a f t l m m l B C A A C B b a f t l m m l A,B C B C A A C B
16
b a f t l m m l
ground in edge view
SLIDE 17
#2 is an elevation view
2 1
B2 C2 C1 B1 A1
17
true slope of a plane – aka dip of the plane
HL TLHL X2 True slope angle Horizontal projection plane seen in edge view
1 3
#3 is an elevation view Plane ABC seen in edge view A,X3 C3 B3 X2 Must be seen together in the same elevation in order for true slope to appear
SLIDE 18
HL TLHL 3 1 2 1
A,X3 C3 B3 B2 A2 C2 C1 B1 A1
HL TLHL
True shape of plane ABC
3 4 3 1 2 1
X4 A4 B4 C4 A,X3 C3 B3 B2 A2 C2 C1 B1 A1
true shape of a plane
18 2 1
B2 A2 C2 C1 B1 A1
SLIDE 19
TL Frontal Line 3 2
True shape of plane ABC
2 1
C4 A4 B4 X1 B2 A2 C2 C1 B1 A1
19
2 1
X1 B2 A2 C2 C1 B1 A1
TL Frontal Line 3 2
B,X3 A3
SLIDE 20
20
true size of a roof shape
SLIDE 21
true shape of ABC slope = 41° f t C A B C B A A C B B C A f t A C B B C A
inscribing a circle in a triangle
21
SLIDE 22
constructing ellipse by using transfer distances from views 2 & 1 incircle seen in true shape
1 2 t 1 f t
B C A B A A C B B C A
incircle - last step (variation 1)
22
incircle seen in true shape
1 2 t 1 f t
B C A B A A C B B C A
SLIDE 23
incircle - last step (variation 2)
23
using construction for an ellipse within an oblique rectangle in-circle seen in true shape 1 2 t 1 f t
B C A B A A C B B C A
SLIDE 24
A problem
24
Suppose a plane is given by diagonal lines, say AB and CD. Suppose three
- f the points, say A, B and C are given by their quad paper coordinates, for
example, A (1, 2½, 5½), B (3, 2, 5), and C (2, 1¼, 3¾). In order to determine D we will need further constraints. Suppose the diagonals are of equal length, that is, AB = CD; suppose further that they intersect at right angles. to determine the slope and true shape of the plane ABCD; to find the true length and bearing of CD; and to complete the top and front views of the plane
SLIDE 25
the problem and the steps
25
- to determine the slope and true shape of the
plane ABCD;
- to find the true length and bearing of CD;
- to complete the top and front views of the plane.
8 7 6 5 4 3 2 1 2 4 6
C C A A B B
SLIDE 26
completing the views of a plane
26
8 7 6 5 4 3 2 1 2 4 6 8
TL 1 1 2 2
North slope = 33° 54' bearing of CD = N22° E true length of CD = 8'-6" constraints CD = AB CD ⊥ AB true shape of plane
edge view
- f plane
D D D C B A C C A A B B
SLIDE 27
true shape of a truncated face
27
5 6 7 2 10 3 9 8 4 11 12 1 1,4 7,10 11 12 12,11 6,5 9 8 8.9 2,3 7 10 6 3 5 2 4 1
SLIDE 28
distance between parallel lines
28
D A B C C B A D
SLIDE 29
distance between parallel lines
29
HL dA
parallel lines seen in edge view, ie., as collinear lines
3 1 2 1
D B A C X B A C D X C A
HL dD dA dC dC dA
parallel lines seen in edge view, ie., as collinear lines
4 3 3 1 2 1
A C D B D B A C X B A C D X C A
HL dD
distance between lines
dA dC dC dA
parallel lines seen in edge view, ie., as collinear lines
5 4 4 3 3 1 2 1
C,D A,B A C D B D B A C X B A C D X C A
SLIDE 30
f t f t
Two intersecting lines define a plane
HL
1 t
Edge view of the plane
f t
Two intersecting lines define a plane
what is the angle of intersection ?
30
SLIDE 31
what is the angle of intersection ?
31
TL TL HL
2 1 1 t
True angle of intersection Edge view of the plane
f t
Two intersecting lines define a plane
