3D compact profiler Table top instrument with fixed configuration Key hardware features Compact design All integrated: Sensor head, Controller and Support Stand New developments Key hardware features B&W camera 1360x1024 One LED
SLIDE 2
SLIDE 3
New developments
Key hardware features
Compact design All integrated: Sensor head, Controller and Support Stand
SLIDE 4
New developments
Key hardware features
Encoded nosepiece One LED (white) B&W camera 1360x1024 Passive vibration Isolation pads
SLIDE 5
New developments
Key hardware features
Manual XY Stage & tip-tilt goniometer 6” x 4” range Motorized Z Stage 40 mm range
SLIDE 6
New developments
Key hardware features
Adaptable height Three possible heights (Max. 150mm)
SLIDE 7
New developments
Key hardware features
- HP computer (64bit, 8Gb RAM, 27’’
monitor) + keyboard + mouse
- Joystick (Space Navigator from 3D
connection)
- Calibration mirror
SLIDE 8
New developments
Key software capabilities
Часть рисунка с идентификатором отношения rId3 не найдена в файле.SensoSCAN 6
GUI adapted for
- ne LED and
manual stage
SLIDE 9
New developments
Key software capabilities
- Technologies: Confocal, Interferometry (VSI) & FV
- Measurement types: 3D, Image and Thickness
(not color)
- Single area measurements
- Automated measurements (MMR single point)
SLIDE 10
New developments
Options
- Objectives
- SensoMAP
- SensoPRO LT
