The problem

— Address the problem of stopping determined attackers

from exploiting our software

— Interest in Control Flow Integrity(CFI)

— Data execution prevention (DEP), stack smashing

protection (SSP), address space layout randomization (ASLR)

2 ¡

Data execution prevention (DEP)

— Hardware-enforced DEP

— Marks all memory locations in a process as non-

executable unless the location explicitly contains executable code(NX bit term)

— Software-enforced DEP

— Software-enforced DEP performs additional checks on

exception handling mechanisms in Windows.

3 ¡

Stack smashing protection (SSP)

— Prevents changes to return addresses:

— detecting the change of the return address before the

function returns

— preventing the write to the return address

— Checks the canary word is intact before jumping to the

address

— The return address is read-only

(invariant)while the function is active

4 ¡

Address space layout randomization (ASLR)

— Randomly arranging the positions

— The base of the executable — Position of libraries — Heap and stack

— Only guessing with brute force

— Program crashes at wrong guessing

5 ¡

Attacks

— Guessing attacks

— Brute force attacks

— Information leakage

— An information leak occurs when system data or

debugging information leaves the program through an

• utput stream or logging function.

— Control flow hijacking

— Return-to-libc — ROP — JOP

6 ¡

Contributions

— Evaluate fast, state-of-the-art CFI techniques and show that they do

not protect against advanced ROP exploits

— Develop a methodology for performing code-reuse attacks against

CFI-protected software

— Demonstrate the chaining of gadgets using function calls to perform

useful actions, i.e., call-oriented programming (COP)

— Construct a working exploit for Internet Explorer 8 on Windows 7 with

DEP and ASLR on, and assuming CCFIR is in place;

— Assess the availability of gadgets required to launch such attacks

against other popular software on Windows 7, such as Internet Explorer 9, Acrobat Reader XI, the Microsoft Office 2013 suite of programs, and Firefox 24.

7 ¡

Control flow integrity (Ideal CFI)

— CFI thwarts control-hijacking attacks by keeping control

flow in the control-flow graph (CFG)

— All programs usually contain two types of control-flow

transfers: direct and indirect

— For every control-flow transfer

is assigned a ID and checks are inserted before control-flow instructions to ensure that only valid targets are allowed.

8 ¡

Control flow integrity (Ideal CFI)

— There are two major challenges for the adoption of CFI in

its ideal form.

— it requires a complete and precise CFG of the

protected application in order to accurately identify all indirect transfer targets and assign IDs.

— it incurs a non-negligible performance overhead

caused by the introduced checks before indirect control-flow instructions

9 ¡

Compact Control Flow Integrity and Randomization (CCFIR)

— Distinguishes between calls and returns, and prevents

unauthorized returns into sensitive functions

— Directing indirect control

transfers through a dedicated “Springboard section” that encodes target restrictions via code alignment

10 ¡

CFI approaches

11 ¡

Gadgets in CFI

— Two types of gadgets:

— Call – site gadgets(CS)

— Blocks of instructions right after a call instruction that

terminate with a return instruction.

— Entry – point gadgets (EP)

— Blocks of instructions starting at a function’s entry

point and ending with an indirect call or jump

— Begin at an allowable control-transfer pointer. — Their length is large and may contain instructions

unrelated to the ones performing the desire functionality.

— In larger gadgets may include code branches within them. — Generally we prioritize gadgets based on their size,

examining smaller ones first.

12 ¡

Locating the Gadgets

— There is two – stage attacks.

1.

Learn information about the layout of the target application.

2.

Use that information to locate the gadget in the payload.

— ASLR becomes a key component in modern systems. — CFI checking for the three different targets supported.

— Each entry is 8 or 16 bytes long and their location within

the spring board is randomized at load time.

— In CCFIR the attacker has to identify the location of the

appropriate entries in the springboard.

13 ¡

Calling Functions

— Options under CFI :

— Through Indirect Calls :

Indirect call instructions are always to jump to a certain function.

— Calling through Gadgets :

Look for gadgets that include an indirect or fixed functions call in their body

14 ¡

Linking Gadgets

— We cannot link the gadgets available to us in arbitrary

ways, since not all control flows are permitted.

— Different ways to link the gadgets.

— Transfer control to CS gadget and set up the stack to

chain multiple gadgets of the same type together.

—

Receive control with a call instruction, we can only link EP gadgets.

15 ¡

— Moving from EP – to CS – gadget linking. — Moving from CS – to EP – gadget linking.

— Link CS gadget to a CS – IC gadget, where we control

the operand of an indirect call. Use that to redirect control to an EP gadget.

— Gadget uses data: one of its instructions uses the data

before it is set.

16 ¡

From Code – reuse to Code - injection

— Goal is to link the gadgets and bypass DEP. — Find a vulnerable function and put our injection code to

the stack.

— Gadget set data : any data un registers or memory that

are set by the gadget before exiting.

— Calling a function in a gadget chain depends on our ability

to set up its arguments on the stack.

— Achieve it by linking available gadgets to move arguments

from the controlled buffer to the appropriate registers or memory location.

17 ¡

Proof-of-Concept Exploitation

— System protected with CCFIR (strictest of the loose CFI

frameworks)

— Generic exploit, applicable to similar frameworks (bin-

CFI)

— Heap overflow in Internet Explorer, gives control to an

indirect jump.

— The vulnerability is triggered by accessing the span and

width attributes of a column, in an HTML table, through JavaScript.

¡

18 ¡

<html> <body> <table style="table-layout:fixed" > <col id="132" width="41" span="1" >&nbsp </col> </table> <script> function over_trigger() { var obj_col = document.getElementById("132");

• bj_col.width = "42765";
• bj_col.span = 1000;

} setTimeout("over_trigger();",1); </script> </body> </html>

— Overwrite a virtual function table (VFT) pointer in a button,

leading to the control of an indirect jump instruction.

— Overwrite the size of a string object (add reference to the

• bject and manipulate size, for memory disclosure).

— Trigger it multiple times, as long as the process does not

crush.

19 ¡

— CCFIR replaces the function pointers in the binary with

pointers to the function stubs.

— Replaces indirect calls with direct jump to the springboard. — Information flow is enforced by aligning the call and return

stubs, and by checking that the function’s address and the return address follow the alignment (emulate 2 IDs).

— Only for non-sensitive functions. Returns from sensitive

functions are omitted.

Gadgets Location in CCFIR

20 ¡

Gadgets Location in CCFIR

CCFIR checks indirect control-flow transfers through its springboard section (special memory layout) call function stub return address stub placed in springboard.

21 ¡

— Heap Feng Shui à Positioning the vulnerable buffer, the string

• bject and button object, in the right order in the heap.

— 1st buffer overflow: string object’s size property is

• verwritten to build the memory disclosure

— 2nd buffer overflow: the button object’s VTF pointer is

• verwritten.

— Heap Spraying à injects multiple instances of a specially

crafted buffer in memory.

— Copies of the buffer are allocated at reliable addresses. — One is written to the VTF pointer of the button. — The buffer guides the chaining of gadgets, from the initial

indirect transfer instruction to code injection.

To succesfully Perform the Explotation

22 ¡

Memory Disclosure

— Constraints to bypass:

— ASLR is used

— need to find the base address of modules of interest

(DLLs containing the gadgets)

— CCFIR springboard for indirect transfers

— need to find the addresses of function call and return

stubs, for the used gadgets. If not, CFI check fails.

23 ¡

Memory Disclosure ¡

— Find base address gadgets from mshtml.dll and

ieframe.dll

—

— mshtml.dll: revealed by the VFT pointer within the

button.

— pointer at constant relative offset from string the object. — pointer at a constant known offset in mshtml.dll (base)

— ieframe.dll: read the address of a function that is

contained in ieframe.dll and imported in mshtml.dll.

— button object, fixed relative distance to the string object. — after knowing string’s address, relative distance from string

to the imported address

24 ¡

— CCFIR stubs

— Have the base address of the 2 modules — Have the offsets for the EP and CS gadgets — CS have direct references to their stubs

— references can be resolved as offsets are know

— EP offsets are known, but they do not reveal stub address

in the springboard.

— EP that have a stub in springboard, have a relocation entry

in the code, which is altered by CCFIR to point the stubs of EP gadgets in springboard.

Memory Disclosure ¡

25 ¡

Gadgate Chaining

— Phase 1: Converting the indirect jump to a return

instruction.

— The exploit grand us control of an indirect jump instruction.

In CCFIR, we can use only longlmp (sensitive function)

26 ¡

Gadgate Chaining ¡

— Phase 2: Stack pivoting – to the stack hosting ROP

chain.

— A pop instruction before the first controlled return. — Then, a Gadget points esp to the sprayed buffer.

— Phase 3: Change memory permissions

— code-injection attack, overwrite program’s code with

shellcode.

— Making code area writable with VirtualProtect.

(sensitive)

— Overwrite area code with shellcode, using memcpy

27 ¡

Evaluation

— We selected and analyzed six widely used applications

(Win 7 x86)

— Internet Explorer 9.0.20 — Firefox 24.0 — Adobe Reader XI 11.0.5 — Microsoft Office Professional Plus 2013 suite:

— Word, Excel, PowerPoint

— Dataset including applications and libraries consisted of

164 unique PE files

— CS gadget definition -usable under CFI-: (EP/CS)-R, (EP/

CS)-IC-R, (EP/CS)-F-R,, (EP/CS)-IJ and (EP/CS)-IC

28 ¡

Distribution of gadget types

— Different types of gadgets found

in Internet Explorer 9

— Gadgets with (w/) and with out

(w/o) branches

— We count all paths from a

particular CS or EP to an exit Instruction.

— Number of w/ gadgets is larger

than w/o

29 ¡

Gadget Distribution

— Number and types of w/o gadgets in various

applications.

30 ¡

Calling sensitive function

— Number of gadgets with fixed calls to sensitive functions

(i.e. CS-F-R or EP-F-R)

31 ¡

Frequency ¡of ¡gadgets ¡

— Frequency of w/o and w/ branches in IE 9 based

• n their length (instruction count)

32 ¡

Possible Defenses

— kBouncer (vulnerable defense)

— Can be potentially bypassed by using CS-F-R or CS-

IC-R

— Tracking a shadow stack

— Not trivial. Not every call instruction matched by a ret

— ROPDefender

— Also using a shadow stack. Aims to enforce a call-ret

pairing policy

— Control-Flow Locking (CFL)

— Promising direction using locks to preserve CFG

integrity

33 ¡

Conclusion

— Examined security implications of CCFIR. — Bypass ASLR with memory leackage. — ROP for bypassing DEP. — Virtual Protect – Shellcode Injection
