DIGESTATE FROM MANURE RECYCLING TECHNOLOGIES

Digesmart project – DIGEState from MAnure Reciclying Technologies

Contract Nr. ECO/12/332882

• 1. INTRODUCTION
• 2. DIGESMART TECHNOLOGICAL SOLUTION
• 3. BENEFITS: ECONOMICAL AND ENVIRONMENTAL
• 4. PRACTICAL RESULTS
• 5. COMING ACTIVITIES
• 6. PARTNERS

Content

• 1. INTRODUCTION

ENVIRONMENTAL IMPACT OF ANIMAL MANURE/SLURRY FROM INTENSIVE LIVESTOCK FARMING

MANAGEMENT ANIMAL MANURE/SLURRY HIGH TRANSPORT COSTS IN AREAS WITH HIGH LIVESTOCK DENSITY

BIOGAS TECHNOLOGY NON REDUCTION OF NUTRIENTS (NPK) AND LOW REDUCTION OF INITIAL VOLUME OF ANIMAL MANURE/SLURRY USE OF EFFLUENT FROM BIOGAS PLANTS (DIGESTATE), MEANS ALSO: HIGH TRANSPORT COSTS IN AREAS WITH HIGH LIVESTOCK DENSITY

• 1. INTRODUCTION

AT THE SAME TIME

• 1. INTRODUCTION

RISING COSTS OF ARTIFICIAL FERTILIZERS

NEED OF SOLUTIONS TO FACILITATE LOCAL USE OF NUTRIENTS FROM DIGESTATE RISING COSTS OF ARTIFICIAL FERTILIZERS

• 1. INTRODUCTION

P mainly in solid fraction, while N and K are mainly retained in the liquid fraction (effluent from biogas plants)

• 2. DIGESMART TECHNOLOGICAL SOLUTION

DIGESMART: SOLUTION OF VALORIZATION OF DIGESTATE FROM BIOGAS PLANTS PROCESSING ANIMAL MANURE AND SLURRY MAINLY

LIQUID FRACTION OF DIGESTATE

• 2. DIGESMART TECHNOLOGICAL SOLUTION

• 2. DIGESMART TECHNOLOGICAL SOLUTION

• 1. STRIPPING ( temperature >60ºC)
• 2. ABSORPTION (nitric acid)

Main innovations from DETRICON: a) Lower costs of the stripping plant b) High energy efficiency of the process

• 2. DIGESMART TECHNOLOGICAL SOLUTION. STRIPPING. N-RECOVERY.

PRODUCT = GREEN FERTILIZER Product Ammonium nitrate a GREEN FERTILIZER (GF)

• R

e d u c t i

• n
• f

8 7 , 5 %

• f

N t h a n k s t

• s

t r i p p i n g ( 4 a , 5 k g N

• N

H 4 / t ) .

ADVANTAGES

• 1. Lower transports costs of residual fraction of

digestate after stripping

• 2. Production GF replacing artificial fertilizers. Extra

incomes for biogas plants + lower fertilizers prices for farmers

• 3. Treatment capacity of stripping plant:

4000 – 60 000 t/year liquid digestate fraction

• 2. DIGESMART TECHNOLOGICAL SOLUTION

Plant located in Belgium

HIGHLIGHT OF DIGESMART SOLUTION (SOLAR DRYING)

• 1. Lower transports costs of residual fraction of

digestate after solar drying

• 2. Production of a K-rich fraction
• 3. Treatment capacity / Performance
• 2. DIGESMART TECHNOLOGICAL SOLUTION

Still not ready – under test at DISAFA – University of Turin

• 3. BENEFITS
• 1. - Circular economy. Facilitating rational use of all the

different waste streams from intensive livestock farming/biogas plants

• 2. - Reduction of environmental impact of animal manure of

intensive livestock exploitations

• 3. Reduction of Nitrogen pressure in the area where the

plant is located

• 4. - Fostering BIOGAS using animal manure
• 5. - Green fertilizers (product) with low carbon footprint
• 6. - Rural development encouragement and diversification
• f activities in rural areas. New jobs related to green

fertilizers production.

• 7. - Improvement of competitiveness of biogas plants and

livestock exploitations – agrifood companies

• 3. BENEFITS. ESTIMATION OF BENEFITS FOR EACH DIGESMART PLANT CONNECTED TO

A SMALL-MEDIUM SIZE BIOGAS PLANT (30 000 t/year liquid digestate fraction). Environmental indicators

16

• Nutrients recovered (N) for each installation (stripping): 239 976 kgN/ year
• Reduction of more than 87,5%
• f ammonia emissions (stripping process make

possible to reduce 87,5%

• f ammonia from digestate)
• Fostering BIOGAS

at small-medium size. A biogas plant running mainly with animal manure, 350 kWe installed Energy production 7000 MWh/ year

• New direct (1 biogas plant+digesmart plant operator) and indirect jobs

(maintenance service of the plant, local providers)

Nitrogen content: 16-18 %

• N. (50%

nitric, 50% ammonia)

Sustainable source of nitrogen Without odours or impurities Chemically stable: easy storage and transport Low environmental impact Application in fertigation or as a foliar fertilizer (no spreading on

land).

• 4. PRACTICAL RESULTS.

USE OF GREEN FERTILIZER ON AGRICULTURAL FIELDS

Use in fertirrigation Use as foliar fertilizer Crops: Maize Tomato for processing industry Horticultural crops on the field Horticultrual crops in greenhouse Floriculture

18

• 4. PRACTICAL RESULTS.

USE OF GREEN FERTILIZER ON AGRICULTURAL FIELDS. OPTIONS

Trials fertirrigation: Maize fertirrigated on the field Lettuce cultivation in spring and winter

(greenhouse)

Trials foliar fertilization Common wheat to increase grain

quality

19

• 4. PRACTICAL RESULTS. EXAMPLE: TRIALS IN ITALY

20

Trials on lettuce (spring) fertilized with conventional fertilizers and alternative fertilizer (green fertilizer) shower very similar results in respect of weight

• 4. PRACTICAL RESULTS. EXAMPLE: TRIALS IN ITALY

CONCLUSIONS USE OF GREEN FERTILIZER

The green fertilizer is a liquid product and has a low concentration of

nitrogen (18% N) in comparison with existing artificial fertilizers.

After trials of work package 3, it is important to mention that a possible

solution can be horticulture (both open field and in green-house), because fertilizer amount are smaller and there is a higher probability to find small tank of liquid fertilizers. Nevertheless, the GF can be applied in fertirrigation in combinable crops as well.

Also, the low carbon footprint of the GF could be valorised over the

value chain, as the harvested product, mainly fresh consumed, can hold a label telling the consumer “ Produced with S ustainable inputs” .

The product can be used by the owner/producer by complying to the

legislation on digestate management.

• 4. PRACTICAL RESULTS

• 4. PRACTICAL RESULTS.

REGULATIONS, COMMERCIALIZATION AND DISTRIBUTION OF THE PRODUCT

Registration of the product (ammonium nitrate/k-rich fraction) Storage Transport Commercialization (network of distributors managed by Detricon) Distribution of the product: (microirrigation, liquid type very pure) Seasonality to spread the product (no problem on this potentially Potential problems of use of the K-rich fraction (hygienic quality, amount of heavy

metals, etc.)

• 3. Life cycle assessment

LCA of 1 kg Ammonia S

till preliminary results

Process Electricity [MJ/kg N] Other [MJ/kg N] Total energy requirements [MJ/kg N] Average ammonia productionprocess Europe ‐ 43 43 Detricon ammonia stripping 6,3 13,9 34,2

Which economic value? ... Digestate distribution costs

• Distance reduction distribution cost reduction

www.bi

• energy

farm.eu

Padiglione 2 – stand 214

Digestate distribution costs

distance km 5 10 15 20 25 30 Distribution cost €/ ha 337,58 501,43 665,28 829,13 992,98 1156,83 Area and distances ha 130 100 70 50 20 10 Digestate distribution cost (total) €/ year 43885,4 50143 46569,6 41456,5 13901,72 8097,81 Digestate distribution cost €/ m3 dig 4,05 6,02 7,99 9,95 11,92 13,89 Total cost €/ year 204054,03 total costs (unitary) €/ m3 dig 6,80

www.bi

• energy

farm.eu

Padiglione 2 – stand 214

The advantage is for location where the nitrogen has to be moved far away Saving 89000 EUR/year for 30000 m3/year of processed digestate

Potential sales of green fertilizer

• Plant 30000 m3/ year selling of fertilizer 170 EUR/ t (1300 t/ year)221 000 EUR/ year –

40000 EUR/ year distribution cost

• The distribution costs could be avoided if sold to a fertilizer producer (but may be we have

to lower the price as well)

• Total investment (plant for 30 000 m3/ year) 353 000 EUR
• Net present value of investment 277 000 EUR (11 years amortization plan)

www.bi

• energy

farm.eu

Padiglione 2 – stand 214

Advantages and problems

• Potential advantages

What the value for the market? Is the product use sustainable and logistically viable? Could we have some label (e.g. green..) on our main business process or on the fertilizer?

• Potential problems

It is economically sustainable j ust the internal use?

(reduction of transportation costs)

Registration process of the green fertilizer and costs?

27

REGULATIONS (Major driver in Europe on many issues)

• ITALY

Decreto Legislativo 29 aprile 2010, n.75 In addition, any fertilizer producer should subscribe to the “ Fertilizer producer Registry” Today, it is possible to submit the registration request through an on-line form called “ S

IC procedure” , linked to MiPAAF website

Moreover, for the Italian Legislation, the Green Fertilizer might be considered as a

digestate, and therefore subj ected to all limits and legislation concerning it

Digestate cannot be sold to other farms, but only applied to the land with special permit

and application plans.

The registration is free but the analysis has an average cost comprised between 3000 and

4 000 € and it can take from 2 to 3 years

28

REGULATIONS

• BELGIUM

The service Pesticides and Fert ilizers is in charge of the permits. After the request,

mentioned service will send an invoice for payment of the fee of 1500 € to the Fund of the raw materials and products.

The exemption is granted for a maximum period of five years and may be renewed for

additional periods of up to 5 years

29

• S

PAIN

The Fertilizer Register of the S

panish Ministry of Agriculture, Food and Environment (MAGRAMA) is in charge of the permits to register fert ilizers from organic sources.

The register is for free and it can take from 2 to 3 months.

• 5. COMING ACTIVITIES

Guided tour to the stripping plant (Location: IVACO, Belgium). Estimated date: May 2016 Register people from Belgium/France BIOGAS-E (jonathan.de.mey@biogas-e.be) Register people from Spain AINIA (pgomez@ainia.es) Register people from Italy UNITO (remigio.berruto@unito.it ) Target group of the visit: owners of biogas plants, policy makers, technical press journalists

and scientists, consultants, experts

DETRICON (Belgium). BIOGAS

• E (Belgium)

AINIA (S

pain)

UNITO (Italy) S

ATA (Italy)

• 6. PARTNERS

Subscription to the newsletter:

http://www.digesmart.eu/esp/newsletter.html

Thanks to all the partners involved in DIGESMART project

MORE INFORMATION
