SLIDE 1
1
Cryptographic Elections: Challenges and Opportunities
Alon Rosen IDC Herzliya June 9, 2010
2
1 Cryptographic Elections: Challenges and Opportunities Alon Rosen - - PowerPoint PPT Presentation
1 Cryptographic Elections: Challenges and Opportunities Alon Rosen - - PowerPoint PPT Presentation
1 Cryptographic Elections: Challenges and Opportunities Alon Rosen IDC Herzliya June 9, 2010 2 Thanks Ben Adida (Harvard University) Yuval Kedem (Gallileo) David Movshovitz (IDC Herzlyia) Shimon Schocken (IDC Herzlyia)
SLIDE 2
SLIDE 3
Thanks
- Ben Adida (Harvard University)
- Yuval Kedem (Gallileo)
- David Movshovitz (IDC Herzlyia)
- Shimon Schocken (IDC Herzlyia)
- Amnon Ta-Shma (T
el Aviv University)
3
SLIDE 4
This Talk
Part I
➡ Electronic voting in US ➡ The Israeli perspective
Part II
➡ Why is voting so hard? ➡ Cryptographic voting.
4
SLIDE 5
http://www.nytimes.com/2008/01/06/magazine/06Vote-t.html 5
SLIDE 6
Voting in the US
http://www.cs.uiowa.edu/~jones/voting/pictures/ 6
SLIDE 7
Voting in the US
http://www.cs.uiowa.edu/~jones/voting/pictures/ 6
SLIDE 8
Voting in the US
http://www.cs.uiowa.edu/~jones/voting/pictures/ 6
SLIDE 9
Voting in the US
http://www.cs.uiowa.edu/~jones/voting/pictures/ 6
SLIDE 10
Voting in the US
http://www.cs.uiowa.edu/~jones/voting/pictures/ 6
SLIDE 11
Voting in the US
http://www.cs.uiowa.edu/~jones/voting/pictures/ 6
SLIDE 12
Voting in the US
http://www.cs.uiowa.edu/~jones/voting/pictures/ 6
SLIDE 13
7
SLIDE 14
- HAVA - Help America
Vote Act
- 4 Billion dollars allocated
- Mostly to replace voting machines
7
SLIDE 15
- HAVA - Help America
Vote Act
- 4 Billion dollars allocated
- Mostly to replace voting machines
7
SLIDE 16
The Princeton Report
- Diebold touch-screen runs
executable code loaded from memory card
- All audit logs modified
to be consistent
- Can spread virally by
memory card.
[FHF2006]
8
SLIDE 17
- New Mexico (March 2006)
- California (August 2007)
- Florida (December 2007)
- Ohio (January 2008)
- Iowa (March 2008)
- ...
- States that mandate paper trail.
9
SLIDE 18
10
SLIDE 19
Debra Bowen
10
SLIDE 20
- Simple and reliable system
- Voter secrecy
- Quick count
- And in addition: transparency (open audit).
What does Everbody Want?
11
SLIDE 21
What is Transparency?
Anyone can verify that:
- their vote was cast as intended
- the votes were count as cast
12
SLIDE 22
Paper vs. Electronic
Electronic elections today:
- Global attacks
- Undetectable
- Unrecoverable
- No transparency
Paper elections:
- Local attacks
- No transparency
13
SLIDE 23
Paper vs. Electronic
Electronic elections today:
- Global attacks
- Undetectable
- Unrecoverable
- No transparency
Paper elections:
- Local attacks
- No transparency
Ideally:
- No local/global attacks
- Full transparency
13
SLIDE 24
Aviation and Banking?
http://www.sxc.hu/photo/206579 http://commons.wikimedia.org/wiki/Image:738100.jpg 14
SLIDE 25
Aviation and Banking?
http://www.sxc.hu/photo/206579 http://commons.wikimedia.org/wiki/Image:738100.jpg 14
SLIDE 26
Aviation and Banking?
http://www.sxc.hu/photo/206579 http://commons.wikimedia.org/wiki/Image:738100.jpg
- Little defense against insiders
14
SLIDE 27
Aviation and Banking?
http://www.sxc.hu/photo/206579 http://commons.wikimedia.org/wiki/Image:738100.jpg
- Little defense against insiders
- Failures are obvious
14
SLIDE 28
Aviation and Banking?
http://www.sxc.hu/photo/206579 http://commons.wikimedia.org/wiki/Image:738100.jpg
- Little defense against insiders
- Failures are obvious
14
SLIDE 29
Aviation and Banking?
http://www.sxc.hu/photo/206579 http://commons.wikimedia.org/wiki/Image:738100.jpg
- Little defense against insiders
- Failures are obvious
- Complete audit logs
14
SLIDE 30
Aviation and Banking?
http://www.sxc.hu/photo/206579 http://commons.wikimedia.org/wiki/Image:738100.jpg
- Little defense against insiders
- Failures are obvious
- Complete audit logs
- Transferability of claims
14
SLIDE 31
Aviation and Banking?
http://www.sxc.hu/photo/206579 http://commons.wikimedia.org/wiki/Image:738100.jpg
- Little defense against insiders
- Failures are obvious
- Complete audit logs
- Transferability of claims
These are poor analogies.
14
SLIDE 32
Open-Source?
15
SLIDE 33
Software Independence [Rivest, Wack’06]
“A voting system is software independent if an undetected change or error in its software cannot cause an undetectable change or error in an election outcome”
16
SLIDE 34
Examples
http://www.youtube.com/watch?v=zeHmsrLc4jc 17
SLIDE 35
Examples
http://www.youtube.com/watch?v=zeHmsrLc4jc 17
SLIDE 36
Non-example
18
SLIDE 37
The Israeli Perspective
- Nov ’07: Pilot of electronic voting with
touch screens in several municipalities.
- Nov ’07: Minister of interior announces plan
to move to electronic elections
- Apr ’08: TEHILA are given mandate to run
pilot in 3 municipalities.
- Sep’08 - today: Legislation underway to
accommodate pilot.
19
SLIDE 38
The process:
- No public scrutiny
- No open design
The result:
- No paper trail
- No software independence
20
SLIDE 39
Why is Voting so Hard?
21
SLIDE 40
The Point of An Election
“The People have spoken.... the bastards!”
Dick Tuck 1966 Concession Speech
22
SLIDE 41
The Point of An Election
“The People have spoken.... the bastards!”
Dick Tuck 1966 Concession Speech
Provide enough evidence to convince the loser.
22
SLIDE 42
http://www.cs.uiowa.edu/~jones/voting/pictures/ 23
SLIDE 43
Secret Ballot vs. Verifiability
24
SLIDE 44
Secret Ballot vs. Verifiability
Voting System
24
SLIDE 45
Secret Ballot vs. Verifiability
Voting System Alice convince
24
SLIDE 46
Secret Ballot vs. Verifiability
Voting System Alice convince
Carl the Coercer
24
SLIDE 47
Secret Ballot vs. Verifiability
Voting System Alice convince
Carl the Coercer
24
SLIDE 48
Desired Properties
(1)Alice verifies her vote. (2)Everyone verifies tallying. (3)Alice cannot be coerced by Eve.
25
SLIDE 49
http://www.cs.uiowa.edu/~jones/voting/pictures/
1892 - Australian Ballot
26
SLIDE 50
The Ballot Handoff
Alice the Voter
Sweet
27
SLIDE 51
The Ballot Handoff
Alice the Voter
Sweet
27
SLIDE 52
The Ballot Handoff
Alice the Voter
Sweet
27
SLIDE 53
The Ballot Handoff
Alice the Voter
Sweet
27
SLIDE 54
Salty Sweet Salty Sweet Sweet
The Ballot Handoff
Alice the Voter
Sweet
27
SLIDE 55
Salty Sweet Salty Sweet Sweet
The Ballot Handoff
Alice the Voter
Sweet
Black Box
27
SLIDE 56
Chain of Custody
28
SLIDE 57
Chain of Custody
Vendor
/* * source * code */ if (...
1
28
SLIDE 58
Chain of Custody
Voting Machine 2
Vendor
/* * source * code */ if (...
1
28
SLIDE 59
Chain of Custody
Voting Machine 2
Vendor
/* * source * code */ if (...
1 Polling Location 3
28
SLIDE 60
Chain of Custody
Voting Machine 2
Vendor
/* * source * code */ if (...
1 Polling Location 3 4
Alice
28
SLIDE 61
Chain of Custody
Voting Machine 2
Vendor
/* * source * code */ if (...
1 Polling Location 3 4
Alice
28
SLIDE 62
Chain of Custody
Voting Machine 2
Vendor
/* * source * code */ if (...
1 Polling Location 3 Ballot Box Collection 5 4
Alice
28
SLIDE 63
Chain of Custody
Voting Machine 2
Vendor
/* * source * code */ if (...
1 Polling Location 3 Ballot Box Collection 5 Results ..... 6 4
Alice
28
SLIDE 64
Chain of Custody
Voting Machine 2
Vendor
/* * source * code */ if (...
1 Polling Location 3 Ballot Box Collection 5 Results ..... 6 4
Alice
This is where paper trail helps
28
SLIDE 65
Chain of Custody
Voting Machine 2
Vendor
/* * source * code */ if (...
1 Polling Location 3 Ballot Box Collection 5 Results ..... 6 4
Alice
This is where paper trail helps Black box (even with paper trail)
28
SLIDE 66
Threat Model
29
SLIDE 67
Threat Model
Who is the attacker?
29
SLIDE 68
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
29
SLIDE 69
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
29
SLIDE 70
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
What is the Benefit?
29
SLIDE 71
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
What is the Benefit?
29
SLIDE 72
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
What is the Benefit? How will the attacks be carried out?
29
SLIDE 73
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
What is the Benefit? How will the attacks be carried out?
➡ corruption of input, ballot box, transport, tallying
29
SLIDE 74
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
What is the Benefit? How will the attacks be carried out?
➡ corruption of input, ballot box, transport, tallying ➡ coercion of voters
29
SLIDE 75
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
What is the Benefit? How will the attacks be carried out?
➡ corruption of input, ballot box, transport, tallying ➡ coercion of voters
Where will the attacks be hidden?
29
SLIDE 76
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
What is the Benefit? How will the attacks be carried out?
➡ corruption of input, ballot box, transport, tallying ➡ coercion of voters
Where will the attacks be hidden?
➡ honest mistakes: randomly distributed in the process
29
SLIDE 77
Threat Model
Who is the attacker?
➡ administration officials, candidates, poll workers, even voters
What is the Benefit? How will the attacks be carried out?
➡ corruption of input, ballot box, transport, tallying ➡ coercion of voters
Where will the attacks be hidden?
➡ honest mistakes: randomly distributed in the process ➡ malicious intent: hiding where you least defend
29
SLIDE 78
So what can we do?
30
SLIDE 79
Wooten got the news from his wife, Roxanne, who went to City Hall on Wednesday to see the election results. “She saw my name with zero votes by it. She came home and asked me if I had voted for myself or not. I told her I did,” said Wooten, owner of local bar.
31
SLIDE 80
Open audit elections
Cryptography provides more than confidentiality. Cryptography can provide both verifiability and ballot secrecy Anyone can audit!
32
SLIDE 81
Bulletin Board
Public Ballots
Bridget: Sweet Carol: Salty
33
SLIDE 82
Bulletin Board
Public Ballots
Bridget: Sweet Carol: Salty
Alice
33
SLIDE 83
Bulletin Board
Public Ballots
Alice: Sweet Bridget: Sweet Carol: Salty
Alice
33
SLIDE 84
Bulletin Board
Public Ballots
Alice: Sweet Bridget: Sweet Carol: Salty
Tally Sweet.......2 Salty..........1
Alice
33
SLIDE 85
Encrypted Public Ballots
Bulletin Board
Alice: Rice Bridget: Clinton Carol: Rice
Tally Sweet.......2 Salty..........1
Alice
34
SLIDE 86
Encrypted Public Ballots
Bulletin Board
Alice: Rice Bridget: Clinton Carol: Rice
Tally Sweet.......2 Salty..........1
Alice
Alice verifies her vote
34
SLIDE 87
Encrypted Public Ballots
Bulletin Board
Alice: Rice Bridget: Clinton Carol: Rice
Tally Sweet.......2 Salty..........1
Alice
Alice verifies her vote Everyone verifies the tally
34
SLIDE 88
Public-Key Encryption
35
SLIDE 89
Public-Key Encryption
Keypair consists of a public key and a secret key .
sk pk
35
SLIDE 90
Public-Key Encryption
Keypair consists of a public key and a secret key .
sk pk
"Salty" 8b5637
Encpk
35
SLIDE 91
Public-Key Encryption
Keypair consists of a public key and a secret key .
sk pk
"Salty" 8b5637
Encpk
c5de34
Encpk
"Sweet"
35
SLIDE 92
Public-Key Encryption
Keypair consists of a public key and a secret key .
sk pk
"Salty" 8b5637
Encpk
c5de34
Encpk
"Sweet" a4b395
Encpk
"Salty"
35
SLIDE 93
Threshold Decryption
8b5637
Secret key is shared amongst multiple parties: all (or at least a quorum) need to cooperate to decrypt.
36
SLIDE 94
Threshold Decryption
8b5637 b739cb
Decsk1
Secret key is shared amongst multiple parties: all (or at least a quorum) need to cooperate to decrypt.
36
SLIDE 95
Threshold Decryption
8b5637 b739cb
Decsk1
261ad7
Decsk2
Secret key is shared amongst multiple parties: all (or at least a quorum) need to cooperate to decrypt.
36
SLIDE 96
Threshold Decryption
8b5637 b739cb
Decsk1
261ad7
Decsk2
7231bc
Decsk3
Secret key is shared amongst multiple parties: all (or at least a quorum) need to cooperate to decrypt.
36
SLIDE 97
Threshold Decryption
8b5637 b739cb
Decsk1
261ad7
Decsk2
7231bc
Decsk3
8239ba
Decsk4
Secret key is shared amongst multiple parties: all (or at least a quorum) need to cooperate to decrypt.
36
SLIDE 98
Threshold Decryption
8b5637 b739cb
Decsk1
261ad7
Decsk2
7231bc
Decsk3
8239ba
Decsk4
"Salty"
Secret key is shared amongst multiple parties: all (or at least a quorum) need to cooperate to decrypt.
36
SLIDE 99
Tallying Method I: Homomorphic Tabulation [Benaloh’87]
Enc(m1) × Enc(m2) = Enc(m1 + m2)
37
SLIDE 100
Tallying Method I: Homomorphic Tabulation [Benaloh’87]
Yes = Enc(1) No = Enc(0) Enc(m1) × Enc(m2) = Enc(m1 + m2)
37
SLIDE 101
Tallying Method I: Homomorphic Tabulation [Benaloh’87]
Yes = Enc(1) No = Enc(0)
Bulletin Board
Alice:
Bridget:
Carol:
Enc(ma) Enc(mb) Enc(mc)
Enc(m1) × Enc(m2) = Enc(m1 + m2)
37
SLIDE 102
Tallying Method I: Homomorphic Tabulation [Benaloh’87]
Yes = Enc(1) No = Enc(0)
Bulletin Board
Alice:
Bridget:
Carol:
Enc(ma) Enc(mb) Enc(mc)
EncryptedTally = Enc(ma) × Enc(mb) × Enc(mc) = Enc(ma + mb + mc) Enc(m1) × Enc(m2) = Enc(m1 + m2)
37
SLIDE 103
Tallying Method II: Mixnet [Chaum‘81]
Labor Likkud Supreme court
38
SLIDE 104
Tallying Method II: Mixnet [Chaum‘81]
Labor Likkud Supreme court
Each mix server shuffles the encrypted votes.
38
SLIDE 105
How can we verify
- perations on
encrypted data?
39
SLIDE 106
Verifying Validity of Encryption/Mixing
Given Enc(m) How can I verify:
- 1. that it is not an encryption of more than one vote?
- 2. that the encryption of my vote wasn’t “dropped”?
Zero-Knowledge proofs: Can prove validity of Enc(m) without revealing anything else! The crucial point: only need to verify that machine is computing right functionality...
40
SLIDE 107
Verifying Validity of Encryption/Mixing
Given Enc(m) How can I verify:
- 1. that it is not an encryption of more than one vote?
- 2. that the encryption of my vote wasn’t “dropped”?
Zero-Knowledge proofs: Can prove validity of Enc(m) without revealing anything else! The crucial point: only need to verify that machine is computing right functionality...
40
SLIDE 108
Voting Process Example
[Chaum’81, Sako-Kilian’95, Neff’04, Chaum’04, etc...]
41
SLIDE 109
Alice
Identification
2
Polling station committee
42
SLIDE 110
Alice
Identification
2
ID Polling station committee
42
SLIDE 111
Alice
Identification
2
ID Ballot(s) Polling station committee
42
SLIDE 112
The Ballot
Fold Tear
43
SLIDE 113
Alice
+ Producing Encrypted Ballot
44
SLIDE 114
Alice
+ Producing Encrypted Ballot
44
SLIDE 115
Alice
+ Producing Encrypted Ballot
44
SLIDE 116
Alice
+ Producing Encrypted Ballot
Sweet
44
SLIDE 117
Encrypted Ballot
Sweet Sweet
45
SLIDE 118
Ballot Casting
1
46
SLIDE 119
Ballot Casting
1 2
46
SLIDE 120
Ballot Casting
4
Alice
3 1 2
46
SLIDE 121
Ballot Casting
4
Alice
3 1 2
Receipt
4
46
SLIDE 122
Verifying Consistency [Benaloh]
http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg 47
SLIDE 123
Verifying Consistency [Benaloh]
Alice
http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg 47
SLIDE 124
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg 47
SLIDE 125
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg 47
SLIDE 126
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg 47
SLIDE 127
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg 47
SLIDE 128
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
Decrypted Ballot http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg 47
SLIDE 129
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
Decrypted Ballot http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg Decrypted Ballot Encrypted Ballot VERIFICATION 47
SLIDE 130
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
Decrypted Ballot http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg Decrypted Ballot Encrypted Ballot VERIFICATION 47
SLIDE 131
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
Decrypted Ballot http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg Decrypted Ballot Encrypted Ballot VERIFICATION 47
SLIDE 132
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
Decrypted Ballot
Alice
http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg Decrypted Ballot Encrypted Ballot VERIFICATION 47
SLIDE 133
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
Decrypted Ballot
Alice "CAST"
http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg Decrypted Ballot Encrypted Ballot VERIFICATION 47
SLIDE 134
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
Decrypted Ballot
Alice "CAST"
Signed Encrypted Ballot http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg Decrypted Ballot Encrypted Ballot VERIFICATION 47
SLIDE 135
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
Decrypted Ballot
Alice "CAST"
Signed Encrypted Ballot
Alice
http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg Decrypted Ballot Encrypted Ballot VERIFICATION 47
SLIDE 136
"AUDIT"
Verifying Consistency [Benaloh]
Alice "Vote for Sweet"
Encrypted Ballot
Alice
Decrypted Ballot
Alice "CAST"
Signed Encrypted Ballot
Alice
http://en.wikipedia.org/wiki/Image:Barcode-scanner.jpg Signed Encrypted Ballot Decrypted Ballot Encrypted Ballot VERIFICATION 47
SLIDE 137
The Tallying Process
- Paper tally
- Electronic tally
- 1. Homomorphic public-key encryption or mixnets
- 2. Zero-knowledge proofs
48
SLIDE 138
Putting It Together
Voting Equipment & Ballot Flow Verification 49
SLIDE 139
Putting It Together
Voting Equipment & Ballot Flow Verification
Polling Location Voting Machine
Vendor
/* * source * code */ if (... 49
SLIDE 140
Putting It Together
Voting Equipment & Ballot Flow Verification
Polling Location Voting Machine
Vendor
/* * source * code */ if (...
Public Ballot Box
Alice
49
SLIDE 141
Putting It Together
Voting Equipment & Ballot Flow Verification
Polling Location Voting Machine
Vendor
/* * source * code */ if (...
Results ..... Public Ballot Box
Alice
49
SLIDE 142
Putting It Together
Voting Equipment & Ballot Flow Verification
Polling Location Voting Machine
Vendor
/* * source * code */ if (...
Receipt 1 Results ..... Public Ballot Box
Alice
49
SLIDE 143
Putting It Together
Voting Equipment & Ballot Flow Verification
Polling Location Voting Machine
Vendor
/* * source * code */ if (...
Receipt 1 2 Results ..... Public Ballot Box
Alice
49
SLIDE 144
Open-Audit Elections
- Alice verifies her vote.
- Everyone verifies the tally.
- Incoercibility is enforced.
50
SLIDE 145
Open-Audit Elections
- Alice verifies her vote.
- Everyone verifies the tally.
- Incoercibility is enforced.
Anyone can Audit.
50
SLIDE 146
Open Audit Voting:Helios (Ben Adida, 2009)
51
SLIDE 147
Open Audit Voting: Scantegrity II (Chaum et al., 2009)
52
SLIDE 148
Questions?
53
