Week 3 - Monday

slide-2
SLIDE 2

 What did we talk about last time?  Graphics rendering pipeline

  • Rasterizer Stage
slide-3
SLIDE 3
slide-4
SLIDE 4
slide-5
SLIDE 5
slide-6
SLIDE 6
slide-7
SLIDE 7

 The final screen data containing the colors for each pixel is

stored in the color buffer

 The merging stage is responsible for merging the colors from

each of the fragments from the pixel shading stage into a final color for a pixel

 Deeply linked with merging is visibility: The final color of the

pixel should be the one corresponding to a visible polygon (and not one behind it)

slide-8
SLIDE 8

 To deal with the question of visibility, most modern systems

use a Z-buffer or depth buffer

 The Z-buffer keeps track of the z-values for each pixel on the

screen

 As a fragment is rendered, its color is put into the color buffer

  • nly if its z value is closer than the current value in the z-buffer

(which is then updated)

 This is called a depth test

slide-9
SLIDE 9

 Pros

  • Polygons can usually be rendered in any order
  • Universal hardware support is available

 Cons

  • Partially transparent objects must be rendered in back to front order

(painter's algorithm)

  • Completely transparent values can mess up the z buffer unless they

are checked

  • z-fighting can occur when two polygons have the same (or nearly the

same) z values

slide-10
SLIDE 10

 A stencil buffer can be used to record a rendered polygon

  • This stores the part of the screen covered by the polygon and can be

used for special effects

 Frame buffer is a general term for the set of all buffers  Different images can be rendered to an accumulation buffer

and then averaged together to achieve special effects like blurring or antialiasing

 A back buffer allows us to render off screen to avoid popping

and tearing

slide-11
SLIDE 11

 This pipeline is focused on interactive graphics

  • Micropolygon pipelines are usually used for film production
  • Predictive rendering applications usually use ray tracing renderers

 The old model was the fixed-function pipeline which gave

little control over the application of shading functions

 The book focuses on programmable GPUs which allow all

kinds of tricks to be done in hardware

slide-12
SLIDE 12
slide-13
SLIDE 13

 An effect says how things should be rendered on the screen  We can specify this in details using shader programs  The BasicEffect class gives you the ability to do effects without

creating a shader program

  • Less flexibility, but quick and easy

 The BasicEffect class has properties for:

  • World transform
  • View transform
  • Projection transform
  • Texture to be applied
  • Lighting
  • Fog
slide-14
SLIDE 14

 Vertices can be stored in many different formats depending

  • n data you want to keep
  • Position is pretty standard
  • Normals are optional
  • Color is optional

 We will commonly use the VertexPositionColor type to

hold vertices with color

slide-15
SLIDE 15

 The GPU holds vertices in a buffer that can be indexed into  Because it is special purpose hardware, it has to be accessed in special ways  It seems cumbersome, but we will often create an array of vertices, create an

appropriately sized vertex buffer, and then store the vertices into the buffer

VertexPositionColor[] vertices = new VertexPositionColor[3] { new VertexPositionColor(new Vector3(0, 1, 0), Color.Red), new VertexPositionColor(new Vector3(+0.5f, 0, 0), Color.Green), new VertexPositionColor(new Vector3(-0.5f, 0, 0), Color.Blue) }; vertexBuffer = new VertexBuffer(GraphicsDevice, typeof(VertexPositionColor), 3, BufferUsage.WriteOnly); vertexBuffer.SetData<VertexPositionColor>(vertices);

slide-16
SLIDE 16

 In order to draw a vertex buffer, you have to:

  • Set the basic effect to have the appropriate transformations
  • Set the vertex buffer on the device as the current one being drawn
  • Loop over the passes in the basic effect, applying them
  • Draw the appropriate kind of primitives

effect.World = world; effect.View = view; effect.Projection = projection; effect.VertexColorEnabled = true; GraphicsDevice.SetVertexBuffer(vertexBuffer); foreach (EffectPass pass in effect.CurrentTechnique.Passes) { pass.Apply(); GraphicsDevice.DrawPrimitives(PrimitiveType.TriangleList, 0, 1); }

slide-17
SLIDE 17

 Sometimes a mesh will repeat

many vertices

 Instead of repeating those

vertices, we can give a list of indexes into the vertex list instead

short[] indices = new short[3] {0, 1, 2}; indexBuffer = new IndexBuffer(GraphicsDevice, typeof(short), 3, BufferUsage.WriteOnly); indexBuffer.SetData<short>(indices);

slide-18
SLIDE 18

 Once you have the index buffer, drawing with it is very similar to drawing

without it

 You simply have to set it on the device  Then call DrawIndexedPrimitives() instead of DrawPrimitives()

  • n the device

basicEffect.World = world; basicEffect.View = view; basicEffect.Projection = projection; GraphicsDevice.SetVertexBuffer<VertexPositionColor>(vertexBuffer); GraphicsDevice.Indices = indexBuffer; foreach (EffectPass pass in basicEffect.CurrentTechnique.Passes) { pass.Apply(); GraphicsDevice.DrawIndexedPrimitives(PrimitiveType.TriangleList, 0, 0, 1); }

slide-19
SLIDE 19

 An icosahedron has 20 sides, but it

  • nly has 12 vertices

 By using an index buffer, we can use

  • nly 12 vertices and 60 indices

 Check out the XNA tutorial on RB

Whitaker's site for the data:

  • http://rbwhitaker.wikidot.com/index-

and-vertex-buffers

 There are some minor changes

needed to make the code work

slide-20
SLIDE 20

 It is very common to define primitives in terms of lists and

strips

 A list gives all the vertex indices for each of the shapes drawn

  • 2n indices to draw n lines
  • 3n indices to draw n triangles

 A strip gives only the needed information to draw a series of

connected primitives

  • n + 1 indices to draw a connected series of n lines
  • n + 2 indices to draw a connected series of n triangles
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23

 GPU stands for graphics processing unit  The term was coined by NVIDIA in 1999 to differentiate the

GeForce256 from chips that did not have hardware vertex processing

 Dedicated 3D hardware was just becoming the norm and

many enthusiasts used an add-on board in addition to their normal 2D graphics card

  • Voodoo2
slide-24
SLIDE 24

 Modern GPU's are generally responsible for the geometry and

rasterization stages of the overall rendering pipeline

 The following shows color-coded functional stages inside

those stages

  • Red is fully programmable
  • Purple is configurable
  • Blue is not programmable at all

Vertex Shader Geometry Shader Clipping Screen Mapping Triangle Setup Triangle Traversal Pixel Shader Merger

slide-25
SLIDE 25
slide-26
SLIDE 26

 GPU architecture

  • Vertex shading
  • Geometry shading
  • Pixel shading
slide-27
SLIDE 27

 Keep reading Chapter 3  Keep working on Assignment 1, due this Friday by 11:59  Keep working on Project 1, due Friday, September 27 by 11:59  CS Club

  • Tonight from 4-6 p.m. in The Point 113!
