Supervisory and Technical Forum Wednesday 4th October 2017

Westwood Network Rail Training and Centre, Coventry

Agenda

Registration 08.15 - 09.30 Westwood introduction and Safety Brief Video 09.45 - 09.50 Welcome and introduction – Neil Johnson, TSA Chairman 09.50 - 10.00 Looking back and Forward – Steve Featherstone 10.00 - 10.40 Benefits of using ZKL3000 RC – David Underwood 10.40 - 11.00 “Our Commitment to Safety” Back to Basics – Reflection Bill Cooke 11.00 - 11.20 Tea Break 11.20 - 11.30

TSA Work Stream overview 11.30 - 12.20 1. Prep4 Initiatives – Terry Smith 2. Environmental and Sustainability Awareness – Rachael Reilly 3. Ballast Dust – Mark Wright 4. Extraordinary Safety Programme – Saint Maur Miles 5. Fatigue – Bernie Granger and Mark Wright Work Stream wrap up – Neil Johnson and Bill Cooke 12.20 - 12.30 Lunch (Buffet served outside the auditorium) 12.30 - 13.15 Talking Balls – Andy Heather 13.15 - 13.35 Thank you – Mark Wright 13.35 - 13.40 Body Guard S&C North Cut 5 Gloves – Dave Sowter 13.40 -13.50

Agenda

Agenda

Close Call Champions “We Need You” – Adrian Fricker 13.50 - 14.10 Black Hat Feed Back – Bill Cooke 14.10 -14.30 Questions and Answer session – Open Forum 14.30 - 14.50 Closing comments and thoughts of the day – Neil Johnson, TSA Chairman 14.50 - 15.00

We have various exhibitors available for you to visit during the Day you will find them in situated around the East wing area and Outside Reception

Our Exhibitors

Westwood Safety Video

Welcome and Introduction Neil Johnson S&C North Alliance Director TSA Chairman

Welcome to the Track Safety Alliance “Supervisory and Technical Forum Conference The theme of todays Conference is “Back2Basics”

• TSA Refresh
• Update on Revised Work streams
• Current Progress
• Good Practice
• Future Focus

Welcome

Your Role

• Your role and attendance
• Respect for timings and Presenters
• Participation

Steve Featherstone

Programme Director IP Track

What’s on my mind…

4 October 2017

4-Oct-17 1 1

If you don’t know the answer ask the guys digging the hole… They have known the answer for 20 years but no-

• ne has bothered to ask them!

Safety first…

Looking back…

• Swords of Honour
• LTIFR above target
• Ballast dust – no beards
• Back to basics – black

hats Looking forward…

• 5* and Swords of

Honour

• Re-focus of the TSA
• Points run throughs
• Reduce Red Zone

working

• LTIFR improving

Standards

Looking back…

• Plant reliability
• Higher speed handbacks
• CRT management
• Taking Over Certificates
• Overrun delay minutes
• PIAF

Looking forward…

• Safe work leaders
• Track Environmental

Management Plan – ISO14001

• Globe of Honour
• Overrun delay minutes
• PIAFip

Suppliers

Looking back…

• Babcock Plain Line
• Colas Plain Line
• Carillion Plain Line
• S&C North
• S&C South
• High Output
• Route Services

Looking forward…

• Reacting to

falling order book

• Introducing new

contracts

Our customers

• CP6 contracting strategy
• CP6 funding released into

CP5

• No surprises
• Line speed handbacks on

every renewal

People

Looking back…

• Volunteering
• Award success
• IP Track re-org

Looking forward…

• Impact of reduced workbanks
• Professions launched to give

personal development a real focus

• Volunteering
• Your Voice

Continuous improvement

• Is CI really embedded?
• Can we do more?
• Taking Project Jedi to the

Supply Chain

4-Oct-17 1 8

• Difficult times ahead
• Change causes distraction
• Distraction increases risk of lapses leading to injuries
• We are in a time of high safety risk

We need to ask the people digging the hole how we take safety to the next level

What does this all mean for Safety?

Steve Featherstone Programme Director IP Track

Using Technology to Improve Safety within High Output: Safe & Efficient Access

David M Underwood Director of Engineering, Design & Improvement

21

Introduction

• Network Rail High Output Fleet:

2 Track Relaying Systems (TRS) 5 Ballast Cleaning Systems (BCS)

• Deploy 5 nights/week, with adjacent

lines open and typically handing back at 100mph.

• Delivering 70% of plain line linear

volume in Great Britain in CP5 (Apr 2014 – Mar 2019).

Blocking the Line: The Need to Change….

Handbook 8 of the rule book describes the process for taking a Line Blockage:

• 1. The signaller arranges for a protecting signal to be placed to

danger

• 2. Signaller installs reminder appliance on the panel.

If safety of the line is affected then a form of additional protection is required:

• a. Signal disconnection
• b. Detonators and Possession Limit Board (PLB)

c. Installation of a Track Circuit Operating Device (TCOD) 25

Current Protection Methods for Line Blockages

Problems with the Current Arrangements

• Protection methods require staff to be lineside.
• Complicated and relies on multiple 1 to 1 verbal communications
• Many parties all with different roles and responsibilities
• The method that tends to be the preferred option is PLB’s and detonators. The

activity is: – Potentially hazardous requiring staff to enter the 4’ every time. – Slow and time consuming utilising valuable working time 26

Safety Stats – Operational Close Calls

• RAIL INDUSTRY 2017-18 YTD - 157 operational close call incidents relating to Line

blockages.

• Protection incorrectly placed
• Miscommunication between COSS and Signaller
• Miscommunication between COSS and Possession support staff
• Signaller error

The High Output Safe & Efficient Access Project

Aims of the Safe & Efficient Access Project

• To create a step change improvement in

safety by removing staff from the 4 foot when placing and removing protection.

• To reduce the amount of time taken to take

and handback blockages of the line (possessions and line blockages)

Network Rail Safety Vision Outstanding safety performance and outstanding business performance go hand in hand

Line Blockages within High Output

• High Output activities require line

blockages of the adjacent line varying from 5-15 minutes per night. – 12 x Line blockages for TRS – 6 x Line blockages for BCS

• All of which affect safety of the line and

require a form of additional protection.

The preferred method of additional protection for High Output has been detonator protection.

Recent Success in High Output

• Introduction of ZKL3000 (RC)
• Sponsored through Product acceptance by High

Output

Visits to the 4 foot

• No. of Phone calls

Average time taken to place and remove protection Visits to the 4 foot

• No. of Phone calls

Average time taken to place and remove protection M 12 24 (2 per line block) 96 (8 per line block) 24 minutes 1 (install) 24 4 min T 12 24 96 24 minutes 24 4 min W 12 24 96 24 minutes 24 4 min T 12 24 96 24 minutes 24 4 min F 12 24 96 24 minutes 1 (remove) 24 4 min Total 60 120 480 2 hours 2 120 24 mins Using ZKL3000 (RC) as additional Protection Day Line Blocks Req Using PLB and Detonators as additional Protection

WORK PC / COSS & Workgroup Protecting Signal ZKL Signaller WORK Hand Signaller PC / COSS & Workgroup Signaller Protecting Signal

The difference to TRS since Introducing ZKL

PLB & Detonators ZKL3000 (RC)

The Logic – ZKL Vs Conventional

Protection Type Visits to the 4 foot (for 1 line blockage) Communication (for 1 line blockage) Time (for 1 line blockage) PLB & Dets 1 to take 1 to handback 2 total 4 calls to take 4 calls to handback 8 total 2 mins to deploy and remove ZKL3000 (RC) installed once prior to shift 1 call to take 1 call to handback 2 total 20 seconds to deploy and remove

TRS

• 4 foot visits = reduced by 118 (97%) per week
• Phone Calls = reduced by 360 (75%) per week
• Protection time = reduced by 1 hour 36 mins

per week BCS

• 4 foot visits = reduced by 58 (97%) per week
• Phone Calls = reduced by 180 (75%) per week
• Protection time = reduced by 48mins (80%) per

week

• Reduced the risk of exposing staff to moving

trains when placing / removing protection for line blockages.

• Reduced line blockage visits to the 4 foot by

97% per week per system

• Reduced the amount of phone calls for line

blockages by 75% per week per system

• Gained additional 96minutes (TRS) and 48 mins

(BCS) per week per system through introduction

• f ZKL3000 (RC)

Summary

The future for High Output and Network Rail

• Incab Flexible Train Arrival Point (FTAP)
• ZKL3000(RC) mobile app
• ZKL’s installed at fixed locations
• Tamping using ZKL3000 as protection
• High Output Protection Zone
• Personal Warning System (PWS)
• Wireless train warning system (SATWS, ATWS)
• Remote TSR Boards

Thank you

For further information contact: Neil Sunner Project Manager (High Output Improvement) Email: neil.sunner@networkrail.co.uk Phone:07834147559

Back2Basics “Our Commitment to Safety”

Bill Cooke

Back2Basics (cont’d)

• You might remember why I wanted us to get

back to basics……

The important numbers then

• 16 lost time injuries, including 3 broken ankles and wrists, disc cutter and chainsaw cuts
• 60 minor injuries,
• 3 near misses,
• 6 points run throughs
• 30 cable strikes

Many of these events were late reports

Back2Basics

To stop these accidents we said we need to do a few simple things……

• Remove the hazards that we fall over, down or in
• Comply with all the site rules
• Report unsafe acts and conditions

Make it safe, Keep it Safe

That’s really all I ask today,

• Make the sites safe before you start
• Keep the sites safe while you work
• Leave the sites safe when work is complete

So give me any reasons that prevents us doing any of the above?

Tea Break 11.20 – 11.30. “10 Mins Folks”

Prep4 Initiatives Work Stream Workstream Lead Terry Smith Colas Rail

Scope

Joined up and consistent approach to Prep4 Campaigns

Aim

to improve Safety &Sustainable Development (S&SD), through education to reduce accidents and incidents, with a key focus on Back2Basics.

Prep4 Safety

On site safety is one of our key areas of risk when we look at our incidents and accidents. We often start a job with inherited hazards and risk, such as:

– scrap rail, – left over materials, – broken/missing catch pit lids – Etc., to name but a few;

this can have a significant impact on those working in the site. This is where Prep4 Safety can help, it’s all about planning and preparation, making sure our sites are clear and ready for our workers before they arrive. P4S is part of the Grip4Track process its aim is to raise and close out hazards on site before site works start

Current Campaigns

Prep4 Summer

Focussed on specific areas identified as high risk during the summer

• Health & Well Being – Weather and Hydration
• Trespassing – School Holidays
• Driving – More Drivers on Unfamiliar Roads, Traffic Jams
• Site Set Up and Welfare – Water – Increased Fire Risk
• Line side Neighbours – Longer Days, Open Windows, Washing,

Current Campaigns

Current Campaigns

Prep4 Winter

Focussed on specific areas identified as high risk during the winter

• Welfare –
• Using local accommodation to prevent long journeys
• Planning to allow rotation of work activities and adequate breaks
• Adequate welfare facilities on all sites
• Driving
• Driver Competence
• Vehicle Checks
• Low sun/ Sun glare
• Health
• Sustenance
• Keeping warm
• Personal Protective Equipment (PPE)
• Keeping visible
• Keeping clean and dry
• Correct PPE

Prep4 Spring Prep4 Site Set Up Prep4 Sustainabilty Prep4 New Standard Change Prep4 Your Ideas are welcome Speak Up

New Campaigns

Looking out for each other this summer

Slide title

Text and pictures

Sustainability working group Rachael Riley Carillion Rail Workstream Lead

Sustainability working group

• Rachael Riley, Professional Head of Sustainability, Carillion rail
• Call to action: members needed to re-establish the working

group

• TSA members survey, November, to identify priority areas

– Review outputs to date – Members’ top issues for collaborative working

• Align with RSSB sustainable development principles and ISLG

priority areas

• Knowledge share and coordination with RISF (formally RIEF)

Extraordinary Safety Programme Saint Maur Miles S&C North Alliance Workstream Lead

Extraordinary Safety Programme

What are we trying to achieve?

• Having Safety Leaders at all levels and all staff

having accountability for safety.

• Black hat behavioural briefings at the beginning of

every shift.

Extraordinary Safety Programme

What needs to be done?

• Improve reporting
• Make challenge comfortable for people
• Accountability at all levels
• Safety has no rank
• Share best practise

Extraordinary Safety Programme

How we will achieve it?

• Supervisor development and support
• Visible safety leadership on site
• Buddying/mentoring
• Accept honest mistakes without reprisals

Extraordinary Safety Programme

How we will deliver it?

• Identify leaders within all levels/teams
• Celebrate success

Ballast Dust Workstream Mark Wright Network Rail David Butler Network Rail Workstream Lead

Ballast Dust Work Stream

Work Stream Lead Identify what we are trying to achieve? Ballast Dust David Butler To gather a solid data set that highlights a true reflection of the risk to our workers of ballast dust inhalation.

• Challenging conditions of high dust through Close Calls
• Critically reviewed the AECOM report which was commissioned by

SCO

• Part of SCO internal BDWG to help them consider final customer

concerns and opportunities for improvement

• Competence for “face fitter and face fitted” added to Sentinel
• Reviewing possibility of retro fitted suppression systems
• Use of fixed point suppression in blockades
• Completed sampling on IP-Track and High Output activities using

4Rail Services

Ballast Dust Sampling

Site Date/ time PC Function Comments Moreton Cutting Junction, Didcot 20th August Babcock PL Shift cancelled Osmaston Road, Derby 27th August Amey Sersa S&C North 12 samples obtained Bristol Parkway 6-7th Sept Colas S&C South 18 samples obtained Anston, Worksop 10th Sept Carillion PL 15 samples obtained Dunbar, Scotland 17th Sept Amey Sersa S&C North 12 samples obtained Old Oak Common 20th Sept Colas S&C South Sampling undertaken - awaiting flash report Severn Tunnel 23rd Sept Babcock PL Shift cancelled Severn Tunnel Date TBC Babcock PL Possible future sampling site - rescheduled

What we need from you?

• Challenge non compliance with RPE, its your friends and

colleagues we are trying to protect

• COSS review of Sentinel card for appropriate “face fit

competence”

• Does the worker have the right mask to match the

competence above?

• Continued support with innovation such as the following

JSP Air Fed Trials

The trial of the prototype JSP fully helmet mounted Air Fed RPE has been received well. We are working with JSP to make these helmets which can be supplied in any colour viable.

Fatigue Workstream Bernie Grainger Babcock Rail Mark Wright Network Rail Workstream Leads

Fatigue Work Stream

Work Stream Lead Identify what we are trying to achieve? Fatigue Bernard Grainger To increase awareness, knowledge and management of fatigue within the workforce. The improvement plan aims to understand the factors which directly and indirectly affect people’s fatigue and to provide guidance and tools to stakeholders to better control, manage and prevent the risk.

• Change of lead from Mark Wright to Bernie Grainger
• Collaborated with the RPCG (RIAG) and ISLG
• Developed closer ties with the RSSB to help bring about change across the

industry, this will see links to ORR, TOCs and FOCs

• Engaging in new technologies to reduce fatigue when trying to gain information

e.g. RSSB Rule Book App

• Advertised use of Fatigue video short on TSA share site
• Worked with NR to critically review the pending Fatigue Process
• Completed a Survey to gain front line concerns/good practice and knowledge

Fatigue Survey Results

Common trends from 303 surveys:

• 37% advised their average shift excluding travel time is 8 hours, 26% advised theirs

was up to 10 hours and 12% advised they were working 12+ hours.

• 22% advised they use energy drinks regularly to combat fatigue.
• 70% advised they know how to report fatigue, however 30% advised they were still

unsure.

• 65% advised nothing would stop them reporting fatigue.
• 22% of our staff were advised they were working their shift within the last 24 hours,

12% within the last week and 10% 2 weeks prior to their shift.

• 41% advised they way we could improve fatigue is by: better planning, local work,

regular/mandated breaks, advanced notice of shifts and driver rest periods. 12% advised that designated drivers would help reduce fatigue.

A few things you said we could do to improve fatigue

What we need from you?

• Challenge non compliance with arrangements supplied for

pre/post shift hotels etc.

• Use your team mentality to challenge each other, you know each
• ther better than anyone and should feel comfortable in

challenging one another

• Close Call “Fatigue” in all its forms, e.g. home/work life balance,

mental or physical capability

• Continued support with innovation and work streams

Work Stream wrap up

Neil Johnson and Bill Cooke

Buffet style Lunch served outside the auditorium

12.3O – 13.15

Andy Heather

“Talking Balls”

Who are we? Why are we here?

• We are Andy and Graham.
• We are from the charity It’s in the Bag.
• We are here to talk about Testicular Cancer.
• We are both glad to be here in more than ways than
• ne, as we have both had Testicular Cancer and

survived.

Our Story’s

Testicular Cancer

• Testicular cancer is a relatively rare disease
• Around 2,400 cases diagnosed in the UK each year
• Out of every 100 cancers diagnosed in men, only 1 or 2

are testicular cancer

• Accounts for approximately 0.7% of all cancers
• Around 70 people die every year from testicular cancer

Testicular Cancer

• Different from many other types of cancer
• Most cancers tend to affect older people, where as testicular

cancer is more common in young and middle-aged men

• Most common cancer of men aged 15-49 in the UK
• Rates of testicular cancer peak in the 25-34 age group

Testicular Cancer

• Cancer of the testicles is also one of

the most treatable forms of cancer

And now a short film:

Click here

Testicular Cancer Symptoms

A LUMP (WHICH MIGHT BE PAINLESS) INCREASED SIZE HARDNESS PAIN OR HEAVINESS IN THE BALL SACK

Testicular Cancer Symptoms

• Discomfort or pain; dull ache in the

affected testicle or in the lower abdomen

• Symptoms that the cancer has

spread to the lymph nodes; back pain

• Symptoms that the cancer has

spread to other parts of the body; cough, short of breath, difficulty swallowing

How to self examine

• Get to know your

balls

• Once a month

check for any changes

• After a bath or

shower

• Rest balls in

hand

• Gently roll each
• ne between

thumb & finger

• Avoid doing it in

public!

What to do if something is not quite right

• Don’t panic!
• Do not stew
• ver it
• Go straight to

your GP

Remember: 9 out of 10 ball problems are not testicular cancer. Your symptoms are likely caused by something much less

• serious. But because early diagnosis of

TC means better cure rates and more straightforward treatment, you should get yourself to the doctor ASAP.

Risk Factors

• More common in white men than

African-Caribbean or Asian men

• Being taller than average

increases the risk

• Undescended testicle(s) as a baby
• Hyperspadia as a baby
• Low Fertility
• Previous testicular cancer

Myth Busters

• Can’t be caused by knocks or

injuries to the balls (but any lump or swelling

after an injury should be checked by your GP)

• Vasectomy does not increase

chances

• Testicular Cancer is not infectious

and cannot be passed on to other people

Our Campaigns

What we want you to do

• It’s quite

simple……

• Keep checking every

month

• ANY worries see your

GP

• Don’t put it off!
• Take the pledge

The Pledge

Join the winning team in the battle against testicular cancer! A few minutes once a month to check your balls out – that’s all it takes. Thinking it’s a good idea is one thing, remembering to get round to it is another. But we’re here to help. Pledge to check your balls today, and we’ll send you a free reminder every month via your preferred method, so you can make sure you get it done. Sign up now at http://itsinthebag.org.uk/ball-checking/pledge-to- check/

Useful Resources

• www.nhs.uk
• www.cancerresearchuk.org
• www.macmillan.org.uk

Thank you for listening

Dave Sowter S&C North Working with Bodyguard Cut 5 Gloves

New Samurai CUT 5 Gloves

• Bodyguard Workwear Launches New Samurai CUT 5

Hand Protection for Rail Industry Features Inc:

• Touchscreen Sync
• Thermal Insulation
• Waterproof
• Metal Free
• Outstanding Dexterity

CLOSE CALL CHAMPIONS

Our senior leaders have each made a personal commitment to fully supporting anyone who reports a Close Call

We need to hear from all Close Call Champions

Key contacts needed for all Close Call Champion companies

Please send all names and contact details to adrian.fricker@networkrail.co.uk

P

• Are you a Close Call Champion?
• Do you know your Close Call Champion?
• Have you recently attended any TSA CCC

training?

L

Marketing and Communications - Social Media

Adrian Fricker

TSA Social Media

@TSA_NWR 917 Facebook Followers Track Safety Alliance - TSA @tracksafetyalliance

Social Media Plan Q4

• 2-3 TSA targeted and relevant posts a week
• Sharing of industry and member news
• Interactive posts

– Q&A – Surveys – Videos

Recent Social Media

Black Hat Feedback Bill Cooke

Questions and Answer session

Open forum

Closing Comments and thoughts on the day!

Neil Johnson TSA Chairman
