VULKAN- EUROPE Continuous Basalt Fiber Distributions and Products The new commodity Basalt fiber Made out of the oldest stuff on earth Basalt Stone A large part of our eurths crust consists of of Basaltstone Basalt stone i is N

slide-1
SLIDE 1

VULKAN- EUROPE

Continuous Basalt Fiber Distributions and Products

slide-2
SLIDE 2

The new commodity Basaltfiber

Made out of the oldest stuff on earth

Basalt Stone

slide-3
SLIDE 3

A large part of our eurth’s crust consists of

  • f

Basaltstone

slide-4
SLIDE 4

Basalt stone i is N Natural Stone

slide-5
SLIDE 5

The process

  • Basalt cobbles are melted to lava
  • Out of the melted rock : hairthin fibers are drawn.
  • The twisted threads are called : Continuous Basalt Fibers
  • With these fibers we can manufacture :
  • all kind of products

and with resins and epoxies we can produce all kinds of composites.

slide-6
SLIDE 6

BASALT Cobbles go into the kiln

slide-7
SLIDE 7

The fibers are reeled on bobbins

slide-8
SLIDE 8

Basaltfiber Rovin Specifications

slide-9
SLIDE 9

Basaltfiber Rovin Specifications

slide-10
SLIDE 10

Cords solid or with an internal filling

slide-11
SLIDE 11

Solid cord

slide-12
SLIDE 12

MATS , different sizes and types

slide-13
SLIDE 13

filters

slide-14
SLIDE 14

Chopped fibers

slide-15
SLIDE 15

Insulation blanket needle pinned

slide-16
SLIDE 16

insulation with a backcover of foil

slide-17
SLIDE 17

Stitched insulation mat

slide-18
SLIDE 18

Insulation panel with a coverage of basalt plates to make it fire protected

slide-19
SLIDE 19

Basalt Fiber Fabric in 3 weight performances

slide-20
SLIDE 20

Technical In Information

  • This textile is gained from continuous Basaltfibers and can be used in

all kinds of products .

  • The unique properties of basaltfiber makes it applicable in man

industries.

  • This textile is also used for injection with resins and epoxies.
  • We have 3 different interweavings :

Bf-11 plain weave of gladdle-binding , weight 370g/m2 (+/-25%) Bf-13 twill weave of keeper-binding , weight 270 g/m2 (+/-25%) Bf-100 twill weave of keeper-binding , weight 210 g/m2 (+/-25%)

slide-21
SLIDE 21

VULKAN- EUROPE

Composite products Rebars 4,6,8,10,12,14,up to 22 mm

slide-22
SLIDE 22

Rebars – composite 4mm up to to 24 mm

slide-23
SLIDE 23

BFRP- rebars

BFRP= Basalt ltFiberRein inforcePolymer

slide-24
SLIDE 24

BFRP-Profile Beams

slide-25
SLIDE 25

VULKAN EUROPE BV

BV

  • Raesbergenstraat 47
  • 2804 TJ Gouda
  • The Netherlands
  • Tel: +31 182 535520
  • Cell: +31 6 54 907 214
