Viruses based on slides by Vitaly Shmatikov and Ninghui Li Malware - - PowerPoint PPT Presentation

based on slides by Vitaly Shmatikov and Ninghui Li

Viruses

Malware

• Malicious code often masquerades as good software
• r attaches itself to good software
• Some malicious programs need host programs
• Trojan horses, logic bombs, viruses
• Others can exist and propagate independently
• Worms, automated viruses
• There are many infection vectors and propagation

mechanisms

[Geer]

Remote Vulnerabilities

New vulnerabilities Exploitable targets

Trojan Horses

• A trojan horse is malicious code hidden in an

apparently useful host program

• When the host program is executed, trojan does

something harmful or unwanted

• User must be tricked into executing the host program
• In 1995, a program distributed as PKZ300B.EXE looked like a

new version of PKZIP… When executed, it formatted your hard drive.

• Trojans do not replicate
• Main difference from worms and viruses, but today many

trojans are spread by virus-like mechanisms

Viruses

• Virus propagates by infecting other programs
• Automatically creates copies of itself, but to propagate, a

human has to run an infected program

– Self-propagating malicious programs are usually called worms

• Many propagation methods
• Insert a copy into every executable (.COM, .EXE)
• Insert a copy into boot sectors of disks

– “Stoned” virus infected PCs booted from infected floppies, stayed in memory and infected every floppy inserted into PC

• Infect TSR (terminate-and-stay-resident) routines

– By infecting a common OS routine, a virus can always stay in memory and infect all disks, executables, etc.

Virus Techniques

• Macro viruses
• A macro is an executable program embedded in a word

processing document (MS Word) or spreadsheet (Excel)

• When infected document is opened, virus copies itself into

global macro file and makes itself auto-executing (e.g., gets invoked whenever any document is opened)

• Stealth techniques
• Infect OS so that infected files appear normal

– Used by rootkits (we’ll look at them later)

• Mutate, encrypt parts of code with random key

Viruses in P2P Networks

• Millions of users willingly download files
• KaZaA: 2.5 million users in May 2006
• Easy to insert an infected file into the network
• Pretend to be an executable of a popular application

– “Adobe Photoshop 10 full.exe”, “WinZip 8.1.exe”, … – ICQ and Trillian seem to be the most popular names

• Infected MP3 files are rare
• Malware can open backdoor, steal confidential information, spread

spam

• 70% of infected hosts already on DNS spam blacklists

[Shin, Jung, Balakrishnan]

Prevalence of Viruses in KaZaA

• 2006 study of 500,000 KaZaA files
• Look for 364 patterns associated with 71 viruses
• Up to 22% of all KaZaA files infected
• 52 different viruses and Trojans
• Another study found that 44% of all executable files on KaZaA

contain malicious code

• When searching for “ICQ” or “Trillian”, chances of hitting an

infected file are over 70%

• Some infected hosts are active for a long time
• 5% of infected hosts seen in February 2006 were still active in

May 2006 [Shin, Jung, Balakrishnan]

Propagation via Websites

• Websites with popular content
• Games: 60% of websites contain executable content, one-third

contain at least one malicious executable

• Celebrities, adult content, everything except news
• Most popular sites with

malicious content (Oct 2005)

• Large variety of malware
• But most of the observed programs

are variants of the same few adware applications (e.g., WhenU) [Moshchuk et al.]

Malicious Functionality

• Adware
• Display unwanted pop-up ads
• Browser hijackers
• Modify home page, search tools, redirect

URLs

• Trojan downloaders
• Download and install

additional malware

• Dialer (expensive toll numbers)
• Keylogging

[Moshchuk et al.]

Drive-By Downloads

• Website “pushes” malicious executable to user’s browser with

inline Javascript or pop-up window

• Naïve user may click “Yes” in the dialog box
• Can also install malicious software automatically by exploiting

bugs in the user’s browser

• 1.5% of URLs crawled in the Moshchuk et al. study
• Constant change
• Many infectious sites exist only for a short time or change

substantially from month to month

• Many sites behave non-deterministically

Virus: Buffer’s overflow

• Used in 1988’s Morris Internet Worm, Still extremely common

today

• Reference (not recent but still good)
• Aleph One’s “Smashing The Stack For Fun And Profit” in Phrack

Issue 49 in 1996 popularizes stack buffer overflows

http://insecure.org/stf/smashstack.html

• Buffer overflows: Attacks and defenses for the vulnerability of

the decade, Cowan et al.

Buffer Overflow

Two goals: 1. Arrange attack code in program’s address space

• Inject it: using a string that contains the malicious code

into some buffer (eg stack,heap, static area)

• It is already there: eg assume that attac code needs

execute “exec(“/bin/sh”)” and there exists code in libc that executes “exec(arg)” then only need to change “arg” with “/bin/sh” to gain shell

• 2. Get the program to jump to that code with suitable

parameters into registers and memory

• Buffer overflow: change return address of procedures,
• exploit function pointers - “void(* foo)()”-
• Checkpointing based on setjmp/lonhjmp

Buffer Overflow

• Attacker needs to know which CPU and OS are running on the

target machine.

• familiarity with machine code.
• Know how systems calls are made.
• The exec() system call.
• Our examples are for x86 running Linux.
• Details vary slightly between CPU’s and OS:
• Stack overflow
• Shell code
• Return-to-libc

– Overflow sets ret-addr to address of libc function

• Off-by-one
• Overflow function pointers & longjmp buffers
• Heap overflow

Stack Frame:

Parameters Return address Stack Frame Pointer Local variables SP Stack Growth When a procedure is called

What are buffer overflows?

• Consider the following function:

void func(char *str) { char buf[128]; strcpy(buf, str); do-something(buf); }

• When the function is invoked the stack looks like:
• What if *str is 136 bytes long? After strcpy:

str ret-addr sfp buf str *str ret

stack

Buffer overflow: example

The following example shows how to inject and jump to the attacker’s code at the same time

• Suppose *str is such that after strcpy stack looks like:
• When func() exits, the user will be given a shell !!
• Note: attack code runs in stack.
• To determine ret guess position of stack when func() is called.

top

• f

stack *str ret Code for P

Program P: exec( “/bin/sh” )

(exact shell code by Aleph One)

Some unsafe C lib functions

strcpy (char *dest, const char *src) strcat (char *dest, const char *src) gets (char *s) scanf ( const char *format, … ) printf (conts char *format, … )

Exploiting buffer overflows

• Suppose web server calls func() with given

URL.

• Attacker can create a 200 byte URL to
• btain shell on web server
• Some complications for stack overflows:
• Program P should not contain the ‘\0’ character.
• Overflow should not crash program before func()

exits.

Other control hijacking opportunities

Stack smashing attack:

• Override return address in stack activation record

by overflowing a local buffer variable.

• Function pointers: (used in attack on PHP 4.0.2)
• Overflowing buf will override function pointer.
• Longjmp buffers: longjmp(pos) (used in attack on Perl 5.003)
• Overflowing buf next to pos overrides value of pos.

Heap

• r

stack buf[128] FuncPtr

return-to-libc attack

• “Bypassing non-executable-stack during exploitation

using return-to-libs” by contex (libc: standard C libr.)

*str ret Code for P

Shell code attack: Program P: exec( “/bin/sh” )

*str ret fake_ret

system() in libc

Return-to-libc attack: “/bin/sh”

Preventing Buffer Overflow Attacks

• Static source code analysis
• Use type safe languages (Java, ML).
• Use safe library functions
• Non-executable stack
• Run time checking: StackGuard
• Randomization
• Detection deviation of program behavior
• Sandboxing
• Access control … (covered later in course)

Static source code analysis

• Statically check source code to detect buffer
• verflows.
• Several consulting companies.
• Main idea: automate the code review process.
• Several tools exist:
• Coverity (Engler et al.): Test trust inconsistency.
• Microsoft program analysis group:

– PREfix: looks for fixed set of bugs (e.g. null ptr ref) – PREfast: local analysis to find idioms for prog errors.

• Berkeley: Wagner, et al. Test constraint violations.
• Find lots of bugs, but not all.

Marking stack as non-execute

• Basic stack exploit can be prevented by marking

stack segment as non-executable.

• Support in Windows SP2. Code patches exist for Linux, Solaris.

Problems:

• Does not defend against `return-to-libc’ exploit.
• Some apps need executable stack (e.g. LISP interpreters).
• Does not block more general overflow exploits:

– Overflow on heap, overflow func pointer.

Run time checking: StackGuard

• There are many run-time checking techniques …
• Solutions 1: StackGuard
• Run time tests for stack integrity.
• Embed “canaries” in stack frames and verify their integrity

prior to function return

str ret sfp local top

• f

stack canary str ret sfp local canary Frame 1 Frame 2

Canary Types

• Random canary:
• Choose random string at program startup.
• Insert canary string into every stack frame.
• Verify canary before returning from function.
• To corrupt random canary, attacker must learn current random

string.

• Terminator canary: Canary = 0, newline, linefeed, EOF
• String functions will not copy beyond terminator.
• Hence, attacker cannot use string functions to corrupt stack.

StackGuard implemented as a GCC patch.

• Program must be recompiled.
• Minimal performance effects: 8% for Apache.
• Note: Canaries don’t offer fullproof protection.
• Some stack smashing attacks can leave canaries untouched.

Randomization: Motivations.

• Buffer overflow and return-to-libc exploits need to know the

(virtual) address to which pass control

• Address of attack code in the buffer
• Address of a standard kernel library routine
• Same address is used on many machines
• Slammer infected 75,000 MS-SQL servers using same code on every

machine

• Idea: introduce artificial diversity
• Make stack addresses, addresses of library routines, etc. unpredictable

and different from machine to machine

Address Space Layout Randomization

• Arranging the positions of key data areas randomly in a process'

address space.

• e.g., the base of the executable and position of libraries (libc), heap, and

stack,

• Effects: for return to libc, needs to know address of the key functions.
• Attacks:

– Repetitively guess randomized address – Spraying injected attack code

• Vista has this enabled, software packages available for Linux and
• ther UNIX variants

Instruction Set Randomization

• Instruction Set Randomization (ISR)
• Each program has a different and secret instruction set
• Use translator to randomize instructions at load-time
• Attacker cannot execute its own code.
• What constitutes instruction set depends on the environment.
• for binary code, it is CPU instruction
• for interpreted program, it depends on the interpreter

Anti-Virus Technologies

• Simple anti-virus scanners
• Look for signatures (fragments of known virus code)
• Heuristics for recognizing code associated with viruses

– Polymorphic viruses often use decryption loops

• Integrity checking to find modified files

– Record file sizes, checksums, MACs (keyed hashes of contents) – Often used for rootkit detection (we’ll see TripWire later)

• Generic decryption and emulation
• Emulate CPU execution for a few hundred instructions, virus will

eventually decrypt, can recognize known body

– Does not work very well against mutating viruses and viruses not located near beginning of infected executable

Polymorphic Viruses

• Encrypted viruses: virus consists of a constant decryptor,

followed by the encrypted virus body

• Relatively easy to detect because decryptor is constant
• Polymorphic viruses: constantly create new random encryptions of

the same virus body

• Marburg (Win95), HPS (Win95), Coke (Win32)
• Virus includes an engine for creating new keys and new encryptions of

the virus body

– Crypto (Win32) decrypts its body by brute-force key search to avoid explicit decryptor code

• Decryptor can start with millions of NOPs to defeat emulation

Virus Detection by Emulation

Virus body

Randomly generates a new key and corresponding decryptor code

Mutation A

Decrypt and execute

Mutation C Mutation B To detect an unknown mutation of a known virus , emulate CPU execution of until the current sequence of instruction opcodes matches the known sequence for virus body

Metamorphic Viruses

• Obvious next step: mutate the virus body, too!
• Virus can carry its source code (which deliberately contains some

useless junk) and recompile itself

• Apparition virus (Win32)
• Virus first looks for an installed compiler

– Unix machines have C compilers installed by default

• Virus changes junk in its source and recompiles itself

– New binary mutation looks completely different!

• Mutation is common in macro and script viruses
• Macros/scripts are usually interpreted, not compiled

Mutation / Obfuscation Techniques

• Goal: prevent analysis of code and signature-based

detection; foil reverse-engineering

• Insert garbage opcodes and change control structure
• Different code in each instance
• Effect of code execution is the same, but difficult to detect

by passive analysis

• Same code, different register names
• Regswap (Win32)
• Same code, different subroutine order
• BadBoy (DOS), Ghost (Win32)
• Decrypt virus body instruction by instruction, push instructions
• n stack, insert and remove jumps, rebuild body on stack
• Zmorph (Win95)

Mutation Engines

• Real Permutating Engine/RPME, ADMutate, etc.
• Large set of obfuscating techniques
• Instructions are reordered, branch conditions reversed
• Jumps and NOPs inserted in random places
• Garbage opcodes inserted in unreachable code areas
• Instruction sequences replaced with other instructions that have the

same effect, but different opcodes

– Mutate SUB EAX, EAX into XOR EAX, EAX or PUSH EBP; MOV EBP, ESP into PUSH EBP; PUSH ESP; POP EBP

• There is no constant, recognizable virus body!

Example of Zperm Mutation

• From Szor and Ferrie, “Hunting for

Metamorphic”

Putting It All Together: Zmist

• Zmist was designed in 2001 by Russian virus writer Z0mbie of

“Total Zombification” fame

• New technique: code integration
• Virus merges itself into the instruction flow of its host
• “Islands” of code are integrated

into random locations in the host program and linked by jumps

• When/if virus code is run, it infects

every available portable executable

– Randomly inserted virus entry point may not be reached in a particular execution

MISTFALL Disassembly Engine

• To integrate itself into host’s instruction flow, virus must

disassemble and rebuild host binary

• See overview at http://vx.netlux.org/lib/vzo21.html
• This is very tricky
• Addresses are based on offsets, which must be recomputed when

new instructions are inserted

• Iterative process: rebuild with new addresses, see if branch

destinations changed, then rebuild again

– Requires 32MB of RAM and explicit section names (DATA, CODE, etc.) in the host binary – doesn’t work with every file

How Hard Is It to Write a Virus?

• 2268 matches for “virus creation tool” in CA’s

Spyware Information Center

• Including dozens of poly- and metamorphic engines
• OverWritting Virus Construction Toolkit
• "The perfect choice for beginners”
• Biological Warfare Virus Creation Kit
• Vbs Worm Generator (for Visual Basic worms)
• Used to create the Anna Kournikova worm
• Many others

Reading Assignment

• Kaufman 1.12
• Buffer overflows: Attacks and defenses for the vulnerability
• f the decade, Cowan et al.

www.ece.cmu.edu/~adrian/630-f04/readings/cowan- vulnerability.pdf

• Technical (buffer overflow)
• Aleph One’s “Smashing The Stack For Fun And Profit” in Phrack

Issue 49 in 1996 popularizes stack buffer overflows

http://insecure.org/stf/smashstack.html

• Advanced:
• Hunting for metamorphic: (advanced tech. For viruses)

www.symantec.com/avcenter/reference/hunting.for.metamo rphic.pdf
