Verifying the seL4 Microkernel

Formal Proof in Mathematics and Computer Science

Lukas Stevens 21st June 2018

Outline

• 1. What is a µ-kernel?
• 2. Design process of seL4
• 3. Formal methods of the correctness proof
• 4. Layers of the correctness proof
• 5. Conclusion

1

What is a µ-kernel?

What is a kernel anyway?

• Necessary abstractions for applications
• Interaction via system calls
• Loaded into protected memory region

Bugs are potentially fatal

2

What is a kernel anyway?

• Necessary abstractions for applications
• Interaction via system calls
• Loaded into protected memory region

Bugs are potentially fatal

2

What is a kernel anyway?

• Necessary abstractions for applications
• Interaction via system calls
• Loaded into protected memory region

Bugs are potentially fatal

2

What is a kernel anyway?

• Necessary abstractions for applications
• Interaction via system calls
• Loaded into protected memory region

Bugs are potentially fatal

2

What is a kernel anyway?

• Necessary abstractions for applications
• Interaction via system calls
• Loaded into protected memory region

⇒ Bugs are potentially fatal

2

Defjnition: Microkernel

A concept is tolerated inside the µ-kernel only if mov- ing it outside the kernel, i.e. permitting competing implementations, would prevent the implementation

• f the system’s required functionality.

— Jochen Liedtke

3

Monolithic kernels and µ-kernels

Device Drivers File System IPC, Virtual Memory, Scheduling etc. Basic IPC, Virtual Memory, Scheduling UNIX- Server Device Drivers File System Application IPC Applications Hardware Hardware

OS based on Monolithic Kernel OS based on Microkernel

Applications User Mode Kernel mode

4

The seL4 µ-kernel

• Member of the L4
• kernel family
• Correctness verifjed with Isabelle
• High performance

5

The seL4 µ-kernel

• Member of the L4 µ-kernel family
• Correctness verifjed with Isabelle
• High performance

5

The seL4 µ-kernel

• Member of the L4 µ-kernel family
• Correctness verifjed with Isabelle
• High performance

5

The seL4 µ-kernel

• Member of the L4 µ-kernel family
• Correctness verifjed with Isabelle
• High performance

5

Design process of seL4

Design process for verifjcation

Requirements Haskell Prototype Executable Specifjcation Abstract Specifjcation C imple- mentation Proof Proof Implementation Implementation Design Improvement Automatic Translation Stage 1 Stage 2 6

Design process for verifjcation

Requirements Haskell Prototype Executable Specifjcation Abstract Specifjcation C imple- mentation Proof Proof Implementation Implementation Design Improvement Automatic Translation Stage 1 Stage 2 6

Design process for verifjcation

Requirements Haskell Prototype Executable Specifjcation Abstract Specifjcation C imple- mentation Proof Proof Implementation Implementation Design Improvement Automatic Translation Stage 1 Stage 2 6

Design process for verifjcation

Requirements Haskell Prototype Executable Specifjcation Abstract Specifjcation C imple- mentation Proof Proof Implementation Implementation Design Improvement Automatic Translation Stage 1 Stage 2 6

Design process for verifjcation

Requirements Haskell Prototype Executable Specifjcation Abstract Specifjcation C imple- mentation Proof Proof Implementation Implementation Design Improvement Automatic Translation Stage 1 Stage 2 6

Design process for verifjcation

Requirements Haskell Prototype Executable Specifjcation Abstract Specifjcation C imple- mentation Proof Proof Implementation Implementation Design Improvement Automatic Translation Stage 1 Stage 2 6

Design process for verifjcation

Requirements Haskell Prototype Executable Specifjcation Abstract Specifjcation C imple- mentation Proof Proof Implementation Implementation Design Improvement Automatic Translation Stage 1 Stage 2 6

Formal methods of the correctness proof

Hoare logic

P {x = 1} C

• x := x + 1

Q {x = 2}

7

More Hoare logic

{x = 0 ∧ x = 1} y := 2 ∗ x { x and y are even }

8

More Hoare logic

{x is even} y := 2 ∗ x { x and y are even }

8

More Hoare logic

{x is even} y := 2 ∗ x {x and y are even}

8

Partial correctness of Hoare logic

{ } WHILE true DO c { }

9

Data refjnement

A concrete system C refjnes an abstract specifjcation A if the behaviour of C is contained in that of A.

10

Data refjnement

A concrete system C refjnes an abstract specifjcation A if the behaviour of C is contained in that of A.

10

Data refjnement: Examples

• The scheduler selects runnable threads
• System calls return non-zero values on error

11

Layers of the correctness proof

Proof structure

Executable Specifjcation Abstract Specifjcation C implementation (Semantics) Haskell prototype C implementation Isabelle/HOL Proof Automatic translation

12

Abstract specifjcation

The abstract specifjcation is the most high-level layer still fully encapturing the behaviour of the kernel.

13

Scheduler on the abstract level

schedule ≡ do threads ← all_active_tcbs; thread ← select threads; switch_to_thread thread

• d OR switch_to_idle_thread

14

Executable specifjcation

Fill in the details left open by the abstract specifjcation.

15

Haskell implementation of the scheduler

schedule = do action <- getSchedulerAction case action of ChooseNewThread -> do chooseThread setSchedulerAction ResumeCurrentThread ... chooseThread = do r <- findM chooseThread' (reverse [minBound .. maxBound]) when (r == Nothing) $ switchToIdleThread chooseThread' prio = do q <- getQueue prio liftM isJust $ findM chooseThread'' q chooseThread'' thread = do runnable <- isRunnable thread if not runnable then do tcbSchedDequeue thread return False else do switchToThread thread return True

Get runnable thread with highest priority using chooseThread' or schedule idle thread. Call chooseThread to select next thread. Try to fjnd runnable thread in Queue. Check if thread is runnable and act accordingly.

16

Haskell implementation of the scheduler

schedule = do action <- getSchedulerAction case action of ChooseNewThread -> do chooseThread setSchedulerAction ResumeCurrentThread ... chooseThread = do r <- findM chooseThread' (reverse [minBound .. maxBound]) when (r == Nothing) $ switchToIdleThread chooseThread' prio = do q <- getQueue prio liftM isJust $ findM chooseThread'' q chooseThread'' thread = do runnable <- isRunnable thread if not runnable then do tcbSchedDequeue thread return False else do switchToThread thread return True

Get runnable thread with highest priority using chooseThread' or schedule idle thread. Call chooseThread to select next thread. Try to fjnd runnable thread in Queue. Check if thread is runnable and act accordingly.

16

Haskell implementation of the scheduler

schedule = do action <- getSchedulerAction case action of ChooseNewThread -> do chooseThread setSchedulerAction ResumeCurrentThread ... chooseThread = do r <- findM chooseThread' (reverse [minBound .. maxBound]) when (r == Nothing) $ switchToIdleThread chooseThread' prio = do q <- getQueue prio liftM isJust $ findM chooseThread'' q chooseThread'' thread = do runnable <- isRunnable thread if not runnable then do tcbSchedDequeue thread return False else do switchToThread thread return True

Get runnable thread with highest priority using chooseThread' or schedule idle thread. Call chooseThread to select next thread. Try to fjnd runnable thread in Queue. Check if thread is runnable and act accordingly.

16

Haskell implementation of the scheduler

schedule = do action <- getSchedulerAction case action of ChooseNewThread -> do chooseThread setSchedulerAction ResumeCurrentThread ... chooseThread = do r <- findM chooseThread' (reverse [minBound .. maxBound]) when (r == Nothing) $ switchToIdleThread chooseThread' prio = do q <- getQueue prio liftM isJust $ findM chooseThread'' q chooseThread'' thread = do runnable <- isRunnable thread if not runnable then do tcbSchedDequeue thread return False else do switchToThread thread return True

Get runnable thread with highest priority using chooseThread' or schedule idle thread. Call chooseThread to select next thread. Try to fjnd runnable thread in Queue. Check if thread is runnable and act accordingly.

16

Haskell implementation of the scheduler

schedule = do action <- getSchedulerAction case action of ChooseNewThread -> do chooseThread setSchedulerAction ResumeCurrentThread ... chooseThread = do r <- findM chooseThread' (reverse [minBound .. maxBound]) when (r == Nothing) $ switchToIdleThread chooseThread' prio = do q <- getQueue prio liftM isJust $ findM chooseThread'' q chooseThread'' thread = do runnable <- isRunnable thread if not runnable then do tcbSchedDequeue thread return False else do switchToThread thread return True

Get runnable thread with highest priority using chooseThread' or schedule idle thread. Call chooseThread to select next thread. Try to fjnd runnable thread in Queue. Check if thread is runnable and act accordingly.

16

C implementation

Translate the Haskell implementation to C.

17

Machine Model

invalidateTLB :: unit machine_m => unit machine_m invalidateCacheRange :: unit machine_m => word => word => unit machine_m

18

Data refjnement for state machines

σ1 σ2 σn s1 s2 sn · · · Abstract operations in M1 State relation State relation · · · Concrete operations in M2

19

Data refjnement for state machines

σ1 σ2 σn s1 s2 sn · · · Abstract operations in M1 State relation State relation · · · Concrete operations in M2

19

Data refjnement for state machines

σ1 σ2 σn s1 s2 sn · · · Abstract operations in M1 State relation State relation · · · Concrete operations in M2

19

Data refjnement for state machines

σ1 σ2 σn s1 s2 sn · · · Abstract operations in M1 State relation State relation · · · Concrete operations in M2

19

Refjnement by forward simulation

σ σ′ s s′

State Relation State Relation Abstract Operation in M1 Concrete Operation in M2

20

Example for forward simulation

On the Board

21

Types of state transitions

Kernel Mode User Mode Idle Mode

22

Main result

MA ME MC refjnes refjnes refjnes

23

Main result

MA ME MC refjnes refjnes refjnes

23

Main result

MA ME MC refjnes refjnes refjnes

23

Conclusion

Expenditure of time

Artefact Efgort (py) Total (py) Haskell impl. 2.0 2.2 C impl. 0.2 Generic framework 9.0 20.5 Abstract spec. 0.3 Executable spec. 0.2 Refjnement MA ↔ ME 8.0 Refjnement ME ↔ MC 3.0

24

How does the efgort compare?

• EAL7: 1000$/LOC

seL4: 370$/LOC

• L4 Pistachio kernel: 6 py

seL4 kernel: 2.2 py

25

How does the efgort compare?

• EAL7: 1000$/LOC ↔ seL4: 370$/LOC
• L4 Pistachio kernel: 6 py

seL4 kernel: 2.2 py

25

How does the efgort compare?

• EAL7: 1000$/LOC ↔ seL4: 370$/LOC
• L4 Pistachio kernel: 6 py ↔ seL4 kernel: 2.2 py

25

Changes due to verifjcation

100 200 300 400 500 600 C Spec 16 54 34 144 44 250 250 Bugs VC Bugs VC Bugs Refjnement 1 Refjnement 2 Testing

26

What was achieved?

• Correctness proof down to binary level
• Trust in hardware
• What about Spectre and Meltdown?

27

What was achieved?

• Correctness proof down to binary level
• Trust in hardware
• What about Spectre and Meltdown?

27

The future of seL4

• More architectures
• Multicore support
• Exclude timing-channel attacks

28

The future of seL4

• More architectures
• Multicore support
• Exclude timing-channel attacks

28

Questions?

28
