Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Uninformed Search

Volker Sorge

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

States

In problem solving, states represent configurations of that

• problem. Thereby depending on the problem states can refer

to:

◮ The current progress towards a solution (e.g., in search) ◮ The state of the environment that is manipulated (e.g.,

game play)

◮ The internal state of an agent (e.g., knowledge)

Some important concepts are Intial State The start state of the problem. Goal State The solution of the problem or final state. State Space The space of all possible states.

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Actions

Actions are transitions from one valid state into another.

◮ Action has to be applicable in the current state of the

problem.

◮ An action has an effect that changes the state.

Some important concepts are: Path A sequence of actions leading from one state to another. Solution A path leading from the intial state to the goal state.

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Search Problem

We define a search problem as:

◮ A set of states S. ◮ An initial state s ∈ S. ◮ A set of goal or final states F ⊆ S. ◮ An action mapping A ⊆ S × S from a state to a (set

• f) new state(s).

What we are often interested in is the size of the state space |S|, which can of course be infinite. ∈

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Example: 15 Puzzle

13 10 11 6 5 7 4 8 1 12 2 14 3 15 9 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

◮ A potential initial state on the left. ◮ The goal state on the right. ◮ Actions are valid moves of the tiles. ◮ States are all valid configurations of the puzzle.

Mathematically they correspond to all even permutations.

◮ State space size is therefore 16! 2 = 10, 461, 394, 944, 000

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Graph: Definition

In this section we need the concept of a graph, a very common data structure. Graphs are used to represent relationships between objects. For example, points on a map together with roads that connect them. Generally a graph is a collection of objects together with links between some of these objects. More formally we can define a graph G as a pair (V , E), where

◮ V is a set of vertices, and ◮ E ⊆ V × V is a set of edges.

{.} × ⊆

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Graph: Example

Source: Wikipedia

V = {1, 2, 3, 4, 5, 6} E = {(1, 2), (1, 5), (2, 3), (2, 5), (3, 4), (4, 5), (4, 6)}

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Search

Search can then be defined as

◮ A graph G = (V , E), where States are vertices V = S

and actions are edges E = A.

◮ A method expanding unexplored vertices, i.e., moving

from a vertex to vertices not yet visited.

◮ Explored set of already expanded vertices. ◮ Frontier is a set of nodes yet to be expanded.

The way we expand the Frontier defines a search strategy.

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Search Tree

◮ Search algorithms effectively construct a tree while

searching the graph.

◮ Level 0 of the tree consists of the start state s. ◮ Level n of the tree are nodes whose shortest path to s

contains n edges.

◮ A leaf is reached as soon as the next has already been

explored (is an element of Explored).

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Properties of Search Strategies

Completeness If there exists a solution will we find it? Optimality Will we find the shortest possible solution? Time Complexity How long does it take to find the solution? Space Complexity How much memory will we need to find a solution? For the latter two we are usually interested in the worst possible case.

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Breadth-First Search

◮ Search from the start node in a “concentric” way. ◮ Expand all nodes of level n before expanding any nodes

• n level n + 1.

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Algorithm: BFS

Input: Graph G = (V , E), Start state s, Set of goal states F Output: Path P ⊆ E

1 begin 2

let Frontier = [s];

3

let Explored = {s};

4

while Frontier= [] do

5

let v::Frontier = Frontier;

6

if v ∈ F then

7

return Path(s,v)

8

end

9

else

10

let Frontier = Frontier@[v1, . . . , vn], where (v, vi) ∈ E and vi ∈ Explored. let Explored = {vi}∪ Explored;

11

end

12

end

13

return failure;

14 end

Usually Frontier is implemented as a priority queue. Observe that despite the algorithm being in pseudo-code, we use some Ocaml notation ::, @, let. ∈ [.] : : @ ∪

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Example

Source http://goeurope.about.com

Getting from Paris to Rome? (Explore in alphabetical order!)

◮ Solution: Paris→Copenhagen→Prague→Vienna→Rome ◮ Have to explore: Every node except Naples.

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Search Tree

Level Paris 1 Amsterdam Copenhagen London Munich Madrid 2 Prague Edinburgh Lisbon Marseille 3 Vienna Milan 4 Rome 5 Naples

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Analysis

Complete Yes, even for infinite state space. Optimal Yes, will always find the shallowest solution. Time Complexity Let b be branching factor of the tree, i.e., the maximum number of nodes expanded in

• ne move. Let d be the depth of the solution.

Then time complexity is O(bd). Space Complexity All nodes in the tree have to be kept. Hence space complexity is the same as time complexity: O(bd). O

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Breadth-First Search

◮ Search from the start node along one path as far as

possible before backtracking.

◮ Expand the first node of level n as deep as possible

before expanding the next node on level n.

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Algorithm: DFS

Input: Graph G = (V , E), Start state s, Set of goal states F Output: Path P ⊆ E

1 begin 2

let Frontier = [s];

3

let Explored = {};

4

while Frontier= [] do

5

let v::Frontier = Frontier;

6

if v ∈ F then

7

return Path(s,v)

8

end

9

else

10

let Explored = {v}∪ Explored;

11

let Frontier = [v1, . . . , vn]@Frontier, where (v, vi) ∈ E and vi ∈ Explored.

12

end

13

end

14

return failure;

15 end

Usually Frontier is implemented by a stack.

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Example

Source http://goeurope.about.com

Getting from Paris to Rome? (Explore in alphabetical order!)

◮ Solution: Paris→Copenhagen→Prague→Vienna→Rome ◮ Have to explore: Paris, Amsterdam, Copenhagen,

Prague, Vienna, Rome

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Analysis

Complete Not for infinite state space. Optimal No, will always find ’left-most’ solution. Time Complexity Let b be branching factor of the tree, i.e., the maximum number of nodes expanded in

• ne move. Let d be the depth of the solution.

Then time complexity is O(bd). Space Complexity Only the nodes on the most recent path are kept and the successors in each node in the path. Hence space complexity is with respect to the depth of the solution: O(bd).

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Iterative Deepening

◮ As we have seen depth first search is neither complete

nor optimal.

◮ But there are situations where we

◮ cannot keep the full search tree around, ◮ still want an optimal solution.

◮ The idea is to use a bounded version of iterated

deepening, i.e.,

◮ Explore to one level. ◮ If no solution is found, restart exploring to the next

level.

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Algorithm: Iterative Deepening

Input: Graph G = (V , E), Start state s, Set of goal states F Output: Path P ⊆ E

1

begin

2

let d = 0; let NextLayer = true;

3

while NextLayer do

4

let d = d + 1; let NextLayer = false;

5

let Frontier = [s]; let Explored = {s};

6

while Frontier= [] do

7

let v::Frontier = Frontier;

8

if depth(v) = d then

9

let NextLayer = true

10

end

11

else if v ∈ F then

12

return Path(s,v)

13

end

14

else

15

let Explored = {v}∪ Explored;

16

let Frontier = [v1, . . . , vn]@Frontier, where (v, vi) ∈ E and vi ∈ Explored and depth(vi) < d;

17

end

18

end

19

end

20

return failure;

21

end

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Analysis

Complete Yes, even for infinite state space. Optimal Yes, will always find the shallowest solution (if iteration factor is 1!). Time Complexity Interestingly enough the time complexity is the same is for DFS. Although we seemingly do a lot of work twice, in reality only the last layer in the exploration is really constly and any previous layer only adds a negligent factor. Thus time complexity is O(bd). Space Complexity Only the nodes on the most recent path are kept and the successors in each node. Hence space complexity is the same as for DFS: O(bd).

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Uniform Cost Search

◮ So far we have treated all edges in our graphs equally. ◮ That is, an optimal solution was one with the smallest

number of edges.

◮ In other words the cost to expand a node was always

the same, i.e., equal 1.

◮ We now assign costs to our edges (e.g., distance

between cities), i.e., E ⊂ V × V × N where N are non-negative integers.

◮ Uniform Cost Search is similar to BFS, only that it

expands the cheapest node first. ⊂ N

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Algorithm: Uniform Cost Search

Input: Graph G = (V , E), Start state s, Set of goal states F Output: Path P ⊆ E

1 begin 2

let Frontier = {s};

3

let Explored = {s};

4

while Frontier= [] do

5

let v ∈ Frontier, such that Path(s,v) has lowest cost;

6

let Frontier = Frontier\{v};

7

if v ∈ F then

8

return Path(s,v)

9

end

10

else

11

let Explored = {v}∪ Explored;

12

let Frontier = Frontier∪{v1, . . . , vn}, where (v, vi) ∈ E and vi ∈ Explored.

13

end

14

end

15

return failure;

16 end

\

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Example

Source http://goeurope.about.com

Getting from Paris to Rome? (Explore wrt. first costs!)

◮ Solution: Paris→Madrid→Marseilles→Milan→Rome (Cost:2,285) ◮ Have to explore in order:

Paris, London, Amsterdam, Munich, Edinburgh, Madrid, Copenhagen, Lisbon, Prague, Marseilles, Vienna, Milan, Rome

Intro to AI: Lecture 2 Volker Sorge States and Actions Background for Search Breadth First Search Depth First Search Iterative Deepening Uniform Cost Search

Analysis

Complete Yes, even for infinite state space. Optimal Will find optimal solution with respect to the cost function. Time and Space Complexity These are more complex to compute and we don’t bother here. In general it is more complex than BFS. In case the cost function is trivial, then it is exactly BFS.
