Trends in Gold Transaction Values 2014-17

Current Trends in Mining Finance New York SME Conference

William E. Roscoe and Paul Chamois RPA Inc. May 2, 2017

Toronto Denver London Vancouver Quebec City

www.rpacan.com Rock Solid Resources. Proven Advice.

2

Gold Property Transaction Values Agenda

• Gold property transaction data
• $/oz of gold equivalent as common comparison metric
• Trends in gold property transaction values by:
• Producing vs non-producing properties
• Date of transaction
• Proportion of Reserves in total Reserves + Resources
• Western vs non-Western countries

www.rpacan.com Rock Solid Resources. Proven Advice.

3

Gold Property Transaction Data

• Search SNL Financial database of property transactions
• Publicly disclosed transactions globally
• Screen for gold property deals with Mineral Reserves and Resources
• Compile information on each transaction from 2014 to 2017 Q1
• Analyze transactions to derive value in US$ for 100% property interest
• Compile contained oz of gold equivalent (AuEq) in Reserves+Resources
• Calculate $/oz AuEq to use as common comparison metric
• Transaction value for 100% property interest divided by total

contained ounces = $/oz AuEq

• Streamline dataset by eliminating small deals, small resources, low gold

in AuEq, and small acquired interest

• 179 transactions in 35 countries on 43 producing properties and

136 non-producing properties

www.rpacan.com Rock Solid Resources. Proven Advice.

4

Gold Property Transaction Values - $/oz AuEq

10 20 30 40 50 60 0.3 to 1 1 to 3 3 to 10 10 to 30 30 to 100 100 to 300

Frequency $/oz AuEq Ranges

All Transaction Data 2014 to 2017 Q1

Mean = $31/oz Median = $14/oz N = 179

www.rpacan.com Rock Solid Resources. Proven Advice.

5

Gold Property Transactions - Property Values

5 10 15 20 25 30 35 40 45 50 <1M 1M to 3M 3M to 10M 10M to 30M 30M to 100M 100M to 300M >300M

Frequency Property Value

All Transactions 2014 to 2017 Q1

Mean = $51.9M Median = $6.8M N = 179

www.rpacan.com Rock Solid Resources. Proven Advice.

6

Gold Property Transactions – Contained oz AuEq

10 20 30 40 50 60 70 <100K 100K to 300K 300K to 1M 1M to 3M 3M to 10M >10M

Frequencey Contained oz AuEq

All Transactions 2014 to 2017 Q1

Mean = 1.56M oz Median = 0.48M oz N = 179

www.rpacan.com Rock Solid Resources. Proven Advice.

7

Gold Property Transaction Values

Overall downward trend over the period 2014 to 2017 Q1

• Spike in 2015 Q2 is due to 5 producing property transactions >$80/oz

10 20 30 40 50 60 70 80 Q1 2014 Q2 Q3 Q4 Q1 2015 Q2 Q2 Q4 Q1 2016 Q2 Q3 Q4 Q1 2017

$/oz AuEq Quarter

All Transactions

Mean Median

www.rpacan.com Rock Solid Resources. Proven Advice.

8

Gold Property Transaction Values

Producing vs Non-Producing Properties – overall data

• Producing properties have significantly higher $/oz AuEq values, higher property

values, and more contained ounces AuEq overall

Producing Properties N = 43 Non-Producing Properties N = 136 Mean Median Middle 50% Mean Median Middle 50% $/oz AuEq 56 33 13 to 89 23 11 5 to 29 Property Value $M 160 38 5 to 253 18 5 2 to 15 M oz AuEq 2.7 1.7 0.4 to 3.2 1.2 0.4 0.2 to 1.0

www.rpacan.com Rock Solid Resources. Proven Advice.

9

Gold Property Transaction Values

Producing vs Non-Producing Properties

• Producing properties have significantly higher $/oz values, higher property

values, and more contained gold in Reserves + Resources than non-producing properties

• Note geometric progression with many low $/oz values and few high values.

2 4 6 8 10 12 14 16

0.3 to 1 1 to 3 3 to 10 10 to 30 30 to 100 100 to 300

Frequency $/oz AuEq Ranges

All Producing Properties

Mean = $56/oz Median = $33/oz N = 43

5 10 15 20 25 30 35 40 45

0.3 to 1 1 to 3 3 to 10 10 to 30 30 to 100 100 to 300

Frequency $/oz AuEq Ranges

All Non-ProducingProperties

Mean = $23/oz Median = $11/oz N = 136

www.rpacan.com Rock Solid Resources. Proven Advice.

10

Gold Property Transaction Values over Time

Trends in Producing and Non-Producing $/oz Values over Time

• Producing and non-producing $/oz values similar in 2014
• Producing properties increased in $/oz from 2014 to 2015 and 2016, then

decreased

• Non-producing properties decreased in $/oz from 2014 to 2016-17
• The number of non-producing property deals increased in 2016 and 2017
• Dominated by low $/oz value transactions

Producing Properties Non-Producing Properties Mean Median N Mean Median N 2014 33 19 11 32 24 36 2015 79 82 13 25 13 27 2016 58 39 15 17 6 57 2017 Q1 35 37 4 24 9 15

www.rpacan.com Rock Solid Resources. Proven Advice.

11

Gold Property Transaction Values over Time

Producing properties - slight upward trend ca $30/oz to $50/oz ? Non-producing properties - downward trend ca $30/oz to $15/oz ?

• Producing properties spike in 2015 Q2 is due to 5 transactions >$80/oz
• Producing properties spike in 2016 Q2 is due to 2 deals >$100/oz

20 40 60 80 100 120 140 160 Q1 2014 Q2 Q3 Q4 Q1 2015 Q2 Q2 Q4 Q1 2016 Q2 Q3 Q4 Q1 2017

$/oz AuEq Quarter

All Transactions - $/oz Average by Quarter

Prod Mean Non-Prod Mean

www.rpacan.com Rock Solid Resources. Proven Advice.

12

Gold Property Transaction Values – over Time

0.00 50.00 100.00 150.00 200.00 250.00 1-Jan-14 28-Oct-14 24-Aug-15 19-Jun-16 15-Apr-17

$/oz AuEq Transaction Date

Producing Properties

0.00 50.00 100.00 150.00 200.00 250.00 01-Jan-14 28-Oct-14 24-Aug-15 19-Jun-16 15-Apr-17

$/oz Transaction Date

Non-Producing Properties

• Producing properties $/oz values increased from 2014 to 2015

and 2016, then decreased in late 2016 and 2017 Q1

• Non-producing properties $/oz values decreased from 2014 to

2016 and 2017 Q1

www.rpacan.com Rock Solid Resources. Proven Advice.

13

Gold Property Transaction Values - Reserves

Proportion of Reserves in Total Reserves and Resources

• For no Resources only, producers are similar to non-producers at $20/oz AuEq
• For producing properties, $/oz AuEq increases with % of Reserves
• For non-producing properties, no change in $/oz with % of Reserves
• Apparently the market values Reserves in producers only

0.00 50.00 100.00 150.00 200.00 250.00 300.00 0% 20% 40% 60% 80% 100%

$/oz AuEq Percent of Reserves in Total Reserves & Resources

Producing Properties

0.00 50.00 100.00 150.00 200.00 250.00 0% 10% 20% 30% 40% 50% 60% 70%

$/oz AuEq Percent of Reserves in Total Reserves&Resources

Non-Producing Properties

www.rpacan.com Rock Solid Resources. Proven Advice.

14

Gold Property Transaction Values – Producing Properties by Country

• For Western countries, Australia and Canada have similar $/oz values, but USA

$/oz values are higher

• For non-Western countries, $/oz values in Asia are higher than Latin American

and African countries, which are similar

• Overall, $/oz values are similar for Western and non-Western countries

Producing Properties Country/Region Mean Median N Australia 45 20 15 Canada 29 19 3 USA 58 56 9 Western Countries 54 20 29 Latin America 37 19 5 Asia 94 89 6 Africa 33 33 3 Non-Western Countries 61 43 14

www.rpacan.com Rock Solid Resources. Proven Advice.

15

Gold Property Transaction Values – Producing Properties by Region over Time

• Both Western and non-Western properties show the same hump trend
• For Western properties, $/oz values peak in 2015
• For non-Western properties, $/oz values peak in 2016

0.00 50.00 100.00 150.00 200.00 250.00 300.00 1-Jan-14 28-Oct-14 24-Aug-15 19-Jun-16 15-Apr-17

$/oz AuEq Transaction Date

Producing Western Countries

0.00 50.00 100.00 150.00 200.00 250.00 300.00 1-Jan-14 28-Oct-14 24-Aug-15 19-Jun-16 15-Apr-17

$/oz AuEq Transaction Date

Producing Non-Western Countries

www.rpacan.com Rock Solid Resources. Proven Advice.

16

Gold Property Transaction Values – Non-Producing Properties by Country

• For Western countries, Australia and Canada have nearly identical $/oz values,

but USA $/oz values are significantly higher

• For non-Western countries, Latin American and Asian $/oz values are higher

than African and Russian $/oz values

• Overall $/oz values for non-Western countries are very similar to Western

countries

Non-Producing Properties Country/Region Mean Median N Australia 16 9 34 Canada 16 8 31 USA 47 23 21 Western Countries 23 10 88 Latin America 28 23 19 Asia 31 32 6 Africa 19 11 18 Russia 11 9 5 Non-Western Countries 23 12 48

www.rpacan.com Rock Solid Resources. Proven Advice.

17

Gold Property Transaction Values

• Non-Producing Properties by Region over Time
• Downward trend for Western and non-Western countries $/oz values from 2014

to 2017 Q1

• In both cases, from ca $30/oz in 2014 to ca $15/oz in 2017 Q1
• Increased number of transactions in 2016 and 2017 Q1 in both Western and

non-Western countries, dominantly at low $/oz values

0.00 50.00 100.00 150.00 200.00 250.00 1-Jan-14 28-Oct-14 24-Aug-15 19-Jun-16 15-Apr-17

$/oz AuEq Transaction Date

Non-Producing Western Countries

0.00 50.00 100.00 150.00 200.00 250.00 1-Jan-14 28-Oct-14 24-Aug-15 19-Jun-16 15-Apr-17

$/oz AuEq Transaction Date

Non-Producing Non-Western Countries

www.rpacan.com Rock Solid Resources. Proven Advice.

18

Gold Property Transaction Values Summary and Conclusions

• Data on 179 property transactions compiled for the period 2014-2017 Q1
• The $/oz AuEq value for each property is used as a comparison metric
• The $/oz values covers a wide range and follows a geometric

progression, with many low values and fewer high values

• The property values and the contained ounces also exhibit a geometric

progression with many lows and fewer highs

• The producing and non-producing properties differ significantly in $/oz

values

• 43 producing properties average $56/oz with median of $33/oz
• 136 non-producing properties average $23/oz with median of $11/oz

www.rpacan.com Rock Solid Resources. Proven Advice.

19

Gold Property Transaction Values Summary and Conclusions - continued

• Producing and non-producing properties had similar $/oz values in 2014,

but their trends diverged after 2014

• Producing properties $/oz values increased in 2015 and decreased in late

2016 and 2017 Q1

• Non-producing properties values decreased from 2014 to 2016 and 2017 Q1

due to increased number of transactions with low $/oz values

• The market pays higher $/oz values for reserves in producing properties,

but not in non-producing properties

• Overall, $/oz values are similar for Western and non-Western countries
• $/oz values for USA properties are higher than Australia and Canada for

both producing and non-producing properties

• Overall market transaction data should not be used to value individual

properties

www.rpacan.com Rock Solid Resources. Proven Advice.

20

Gold Property Transaction Values

Contact us: Bill Roscoe Tel: +1 (416) 947-0907 Email: william.roscoe@rpacan.com Paul Chamois Tel: +1 (416) 947-0907 Email: paul.chamois@rpacan.com

Toronto Denver London Vancouver Quebec City

www.rpacan.com Rock Solid Resources. Proven Advice.

21

About RPA

• Advice to the mining industry for over 25 years
• The specialty firm of choice for resource and reserve work
• All stages:
• exploration and resource evaluation
• scoping, prefeasibility and feasibility studies
• financing, permitting, construction, operation, closure and rehabilitation.
• Clients are financial institutions, governments, major mining companies,

exploration and development firms, law firms, individual investors, and private equity ventures

• Offices in Canada, United States and United Kingdom
• Head office in Toronto
• 100% employee owned

www.rpacan.com Rock Solid Resources. Proven Advice.

22

RPA Capabilities

• Mineral resource/reserve estimates

and audits, compliant with worldwide reporting codes

• Mine design and optimization
• Metallurgical assessment and

process review

• Estimation of project capital and
• perating costs, financial modeling

and analysis

• Preliminary economic

assessments, scoping, prefeasibility, and feasibility studies

• Valuation of mineral properties
• M&A due diligence reviews of

mining and exploration projects

• Lender advisory services
• Expert witness services
• Design and management of

exploration programs

• Reporting for public disclosure,

including NI43-101 Technical Reports, Competent Persons Reports, and Mineral Expert Reports

• QA/QC audits and reporting
• Operations benchmarking,
• ptimization programs and

troubleshooting

• Strategic planning and advice for

boards and senior management
