Towards Searchable and Verifjable Blockchain

Cheng Xu Ce Zhang April 8, 2019

Department of Computer Science Hong Kong Baptist University

Background

• Blockchain = Bitcoin
• Blockchain is a distributed ledger maintained

by a community of (untrusted) users

• Decentralization
• Consensus
• Immutability
• Provenance
• A wide range of applications
• Record Keeping
• Smart Contracts
• 1/17

Background

• Blockchain = Bitcoin
• Blockchain is a distributed ledger maintained

by a community of (untrusted) users

• Decentralization
• Consensus
• Immutability
• Provenance
• A wide range of applications
• Record Keeping
• Smart Contracts
• Fig. 1: Blockchain Structure [Credit: Wikipedia]

1/17

Background

• Blockchain = Bitcoin
• Blockchain is a distributed ledger maintained

by a community of (untrusted) users

• Decentralization
• Consensus
• Immutability
• Provenance
• A wide range of applications
• Record Keeping
• Smart Contracts
• · · ·
• Fig. 2: Blockchain Applications [Credit: FAHM Technology Partners]

1/17

Blockchain Database Solutions

• Increasing demand to search the data stored in blockchains
• Blockchain database solutions to support SQL-like queries

SwarmDB

• Fig. 3: Blockchain Database Solutions
• Issue: relying on a trusted party who can faithfully execute user queries

2/17

Blockchain Database Solutions

• Increasing demand to search the data stored in blockchains
• Blockchain database solutions to support SQL-like queries

SwarmDB

• Fig. 3: Blockchain Database Solutions
• Issue: relying on a trusted party who can faithfully execute user queries

2/17

Blockchain Search Problem

• Integrity assurance: query results retrieved from the blockchain should be publicly

verifjable

• Becoming full node
• High cost
• Storage: to store a complete replicate (240 GB for Bitcoin as of Mar 2019)
• Computation: to verify the consensus proofs
• Network: to synchronize with the network
• Alternative approach: becoming light node and outsource computation
• Low cost: maintaining block headers only (< 50 MB for Bitcoin)

Miner Full Node Light Node Full Node Miner

Q R Q R

• Question: how to ensure integrity?

3/17

Blockchain Search Problem

• Integrity assurance: query results retrieved from the blockchain should be publicly

verifjable

• Becoming full node
• High cost
• Storage: to store a complete replicate (240 GB for Bitcoin as of Mar 2019)
• Computation: to verify the consensus proofs
• Network: to synchronize with the network
• Alternative approach: becoming light node and outsource computation
• Low cost: maintaining block headers only (< 50 MB for Bitcoin)

Miner Full Node Light Node Full Node Miner · · ·

Q R Q R

• Question: how to ensure integrity?

3/17

Blockchain Search Problem

• Integrity assurance: query results retrieved from the blockchain should be publicly

verifjable

• Becoming full node
• High cost
• Storage: to store a complete replicate (240 GB for Bitcoin as of Mar 2019)
• Computation: to verify the consensus proofs
• Network: to synchronize with the network
• Alternative approach: becoming light node and outsource computation
• Low cost: maintaining block headers only (< 50 MB for Bitcoin)

Miner Full Node Light Node Full Node Miner · · ·

Q R Q R

• Question: how to ensure integrity?

3/17

Solution #1: Smart Contract

• A trusted program to execute user-defjned computation

upon the blockchain

• Smart Contract reads and writes blockchain data
• Execution integrity is ensured by the consensus protocol
• Offer trusted storage and computation capabilities
• Function as a trusted virtual machine

Traditional Computer Blockchain VM Storage RAM Blockchain Computation CPU Smart Contract 4/17

Solution #1: Smart Contract

• Leverage Smart Contract for trusted computation
• Users submit query parameters to blockchain
• Miners execute computation and write results into blockchain
• Users read results from blockchain

[Credit: Oscar W]

• Drawbacks
• Long latency: long time for consensus protocol to confjrm a block
• Poor scalability: transaction rate of the blockchain is limited
• Privacy concern: query history is permanently and publicly stored in blockchain
• High cost: executing smart contract in ETH requires paying gas to miners

(INFOCOM 2018 requires 4 201 232 gas 0 18 Ether 24 USD per query)

• S. Hu, C. Cai, Q. Wang, C. Wang, X. Luo, and K. Ren, “Searching an encrypted cloud meets blockchain: A

decentralized, reliable and fair realization,” in IEEE INFOCOM, Honolulu, HI, USA, 2018, pp. 792–800.

5/17

Solution #1: Smart Contract

• Leverage Smart Contract for trusted computation
• Users submit query parameters to blockchain
• Miners execute computation and write results into blockchain
• Users read results from blockchain

[Credit: Oscar W]

• Drawbacks
• Long latency: long time for consensus protocol to confjrm a block
• Poor scalability: transaction rate of the blockchain is limited
• Privacy concern: query history is permanently and publicly stored in blockchain
• High cost: executing smart contract in ETH requires paying gas to miners

(INFOCOM 2018 requires 4 201 232 gas = 0.18 Ether = 24 USD per query)

• S. Hu, C. Cai, Q. Wang, C. Wang, X. Luo, and K. Ren, “Searching an encrypted cloud meets blockchain: A

decentralized, reliable and fair realization,” in IEEE INFOCOM, Honolulu, HI, USA, 2018, pp. 792–800.

5/17

Solution #2: Verifjable Computation

• Verifjcation Computation (VC)
• Computation is outsourced to untrusted service provider
• Service provider returns results with cryptographic proof
• Users verify integrity of results using the proof
• Outsource queries to full node and verify the results using VC
• General VC: Expressive but high overhead
• Authenticated Data Structure (ADS)-based VC: Effjcient but requiring customized designs

6/17

Solution #2: Verifjable Computation

• Verifjcation Computation (VC)
• Computation is outsourced to untrusted service provider
• Service provider returns results with cryptographic proof
• Users verify integrity of results using the proof
• Outsource queries to full node and verify the results using VC
• General VC: Expressive but high overhead
• Authenticated Data Structure (ADS)-based VC: Effjcient but requiring customized designs

6/17

Our Solutions

• vChain: Enabling Verifjable Boolean Range Queries over Blockchain

Databases (SIGMOD 2019)

• GEM2-Tree: Enabling Gas-Effjcient Authenticated Range Queries for Hy-

brid Storage in Blockchain (ICDE 2019)

7/17

vChain: Enabling Verifjable Boolean Range Queries over Blockchain Databases

Cheng Xu, Ce Zhang, and Jianliang Xu ACM SIGMOD 2019

vChain — Problem Defjnition

• Problem: integrity-assured search over blockchain data
• System Model:
• Users become light nodes
• Queries are outsourced to full nodes
• Full node not trusted
• Program glitches
• Security vulnerabilities
• Commercial interest
• Miner

Full Node Light Node Full Node Miner

Q R VO Q R VO

• Security requirements
• Soundness: none of the objects returned as results have been tampered with and all of

them satisfy the query conditions

• Completeness: no valid result is missing regarding the query window or subscription period

8/17

vChain — Problem Defjnition

• Problem: integrity-assured search over blockchain data
• System Model:
• Users become light nodes
• Queries are outsourced to full nodes
• Full node not trusted
• Program glitches
• Security vulnerabilities
• Commercial interest
• Miner

Full Node Light Node Full Node Miner · · ·

Q R Q R

• Security requirements
• Soundness: none of the objects returned as results have been tampered with and all of

them satisfy the query conditions

• Completeness: no valid result is missing regarding the query window or subscription period

8/17

vChain — Problem Defjnition

• Problem: integrity-assured search over blockchain data
• System Model:
• Users become light nodes
• Queries are outsourced to full nodes
• Full node not trusted
• Program glitches
• Security vulnerabilities
• Commercial interest
• · · ·

Miner Full Node Light Node Full Node Miner · · ·

Q R Q R

• Security requirements
• Soundness: none of the objects returned as results have been tampered with and all of

them satisfy the query conditions

• Completeness: no valid result is missing regarding the query window or subscription period

8/17

vChain — Problem Defjnition

• Problem: integrity-assured search over blockchain data
• System Model:
• Users become light nodes
• Queries are outsourced to full nodes
• Full node not trusted
• Program glitches
• Security vulnerabilities
• Commercial interest
• · · ·

Miner Full Node Light Node Full Node Miner · · ·

Q R, VO Q R, VO

• Security requirements
• Soundness: none of the objects returned as results have been tampered with and all of

them satisfy the query conditions

• Completeness: no valid result is missing regarding the query window or subscription period

8/17

vChain — System Overview

• Miner: constructs each block with additional ADS

to achieve VC scheme

• Service Provider: is a full node and computes the

results with the verifjcation object (VO)

• Query User: is a light node; uses the VO and block

header to verify the results

(Full Node) . . . . . . PreBkHash . . .

• i

ti Vi Wi

• 1

t1 1 {a, b}

• 2

t2 2 {a}

• 3

t3 3 {c}

• 4

t4 5 {a, b}

• 5

t5 1 {c, d} blocki (Light Node) . . . . . . q1 : [ti, ti], [1, 2], b q2 : −, [1, 2], c ∨ d q3 : −, [1, 2], a ∧ d (Miner) Block Headers Block Headers & Data (incl. ADS) Q Service Provider (SP) Query User

{o1}, VO {o5}, VO ∅, VO

Block Header & Data Block Header

• Fig. 4: System Model of vChain

9/17

vChain — Data Model & Queries

• Data Model
• Each block contains several temporal objects {o1, o2, . . . , on}
• oi is represented by ti, Vi, Wi

(timestamp, multi-dimensional vector, set valued attribute)

• Boolean Range Queries
• Time-window queries:

q = [2018-05, 2018-06], [10, +∞], “send:1FFYc” ∧ “receive:2DAAf”

• Subscription queries:

q = −, [200, 250], “Sedan” ∧ (“Benz” ∨ “BMW”)

10/17

Cryptographic Building Block

• Merkle Hash Tree [Mer89]
• Support effjcient membership/range queries
• Limitations
• An MHT supports only the query keys on which the Merkle tree is built
• MHTs do not work with set-valued attributes
• MHTs of different blocks cannot be aggregated

N0 = H(N1|N2) N1 = H(N3|N4) N2 = H(N5|N6) N2 = H(N5|N6) N3 = H(o1) N3 = H(o1) N4 = H(o2)

• 1
• 2

N5 = H(o3) N6 = H(o4)

• 3
• 4

sig(N0) Q

• Fig. 5: Merkle Hash Tree
• Cryptographic Multiset Accumulator [PTT11]
• Map a multiset to an element in cyclic multiplicative group in a collision resistant fashion
• Utility: prove set disjoint
• Protcols:
• KeyGen 1

sk pk : generate keys

• Setup X pk

acc X : return the accumulative value w.r.t. X

• ProveDisjoint X1 X2 pk

:

• n input two multisets X1 and X2, where X1

X2 , output a proof

• VerifyDisjoint acc X1

acc X2 pk 0 1 :

• n input the accumulative values acc X1 , acc X2 , and a proof

, output 1 iff X1 X2

11/17

Cryptographic Building Block

• Merkle Hash Tree [Mer89]
• Support effjcient membership/range queries
• Limitations
• An MHT supports only the query keys on which the Merkle tree is built
• MHTs do not work with set-valued attributes
• MHTs of different blocks cannot be aggregated

N0 = H(N1|N2) N1 = H(N3|N4) N2 = H(N5|N6) N2 = H(N5|N6) N3 = H(o1) N3 = H(o1) N4 = H(o2)

• 1
• 2

N5 = H(o3) N6 = H(o4)

• 3
• 4

sig(N0) Q

• Fig. 5: Merkle Hash Tree
• Cryptographic Multiset Accumulator [PTT11]
• Map a multiset to an element in cyclic multiplicative group in a collision resistant fashion
• Utility: prove set disjoint
• Protcols:
• KeyGen(1λ) → (sk, pk): generate keys
• Setup(X, pk) → acc(X): return the accumulative value w.r.t. X
• ProveDisjoint(X1, X2, pk) → π:
• n input two multisets X1 and X2, where X1 ∩ X2 = ∅, output a proof π
• VerifyDisjoint(acc(X1), acc(X2), π, pk) → {0, 1}:
• n input the accumulative values acc(X1), acc(X2), and a proof π, output 1 iff X1 ∩ X2 = ∅

11/17

Basic Solution

• Consider a single object and boolean time-window query
• Each block stores a single object oi = ti, Wi
• ADS generation (Miner)
• Extend the block header with AttDigest
• AttDigest

acc Wi Setup Wi pk

• Constant size regardless of number of elements in Wi
• Support ProveDisjoint

& VerifyDisjoint

PreBkHash TS ConsProof ObjectHash AttDigest

blocki

• i
• Fig. 6: Extended Block Structure
• Verifjable Query
• Match:

return oi as a result; integrity is ensured by the ObjectHash in the block header

• Mismatch:

use AttDigest to prove the mismatch of oi

Example of Mismatch

• Transform query condition to a list of sets: q

“Sedan” “Benz” “BMW” “Sedan” “Benz” “BMW”

• Consider oi

“Van” “Benz” , we have “Sedan” “Van” “Benz”

• Apply ProveDisjoint

“Van” “Benz” “Sedan” pk to compute proof

• User retrieves AttDigest

acc “Van” “Benz” from the block header and uses VerifyDisjoint AttDigest acc “Sedan” pk to verify the mismatch 12/17

Basic Solution

• Consider a single object and boolean time-window query
• Each block stores a single object oi = ti, Wi
• ADS generation (Miner)
• Extend the block header with AttDigest
• AttDigest = acc(Wi) = Setup(Wi, pk)
• Constant size regardless of number of elements in Wi
• Support ProveDisjoint(·) & VerifyDisjoint(·)

. . . PreBkHash TS ConsProof ObjectHash AttDigest

blocki

• i

. . .

• Fig. 6: Extended Block Structure
• Verifjable Query
• Match:

return oi as a result; integrity is ensured by the ObjectHash in the block header

• Mismatch:

use AttDigest to prove the mismatch of oi

Example of Mismatch

• Transform query condition to a list of sets: q

“Sedan” “Benz” “BMW” “Sedan” “Benz” “BMW”

• Consider oi

“Van” “Benz” , we have “Sedan” “Van” “Benz”

• Apply ProveDisjoint

“Van” “Benz” “Sedan” pk to compute proof

• User retrieves AttDigest

acc “Van” “Benz” from the block header and uses VerifyDisjoint AttDigest acc “Sedan” pk to verify the mismatch 12/17

Basic Solution

• Consider a single object and boolean time-window query
• Each block stores a single object oi = ti, Wi
• ADS generation (Miner)
• Extend the block header with AttDigest
• AttDigest = acc(Wi) = Setup(Wi, pk)
• Constant size regardless of number of elements in Wi
• Support ProveDisjoint(·) & VerifyDisjoint(·)

. . . PreBkHash TS ConsProof ObjectHash AttDigest

blocki

• i

. . .

• Fig. 6: Extended Block Structure
• Verifjable Query
• Match:

return oi as a result; integrity is ensured by the ObjectHash in the block header

• Mismatch:

use AttDigest to prove the mismatch of oi

Example of Mismatch

• Transform query condition to a list of sets: q

“Sedan” “Benz” “BMW” “Sedan” “Benz” “BMW”

• Consider oi

“Van” “Benz” , we have “Sedan” “Van” “Benz”

• Apply ProveDisjoint

“Van” “Benz” “Sedan” pk to compute proof

• User retrieves AttDigest

acc “Van” “Benz” from the block header and uses VerifyDisjoint AttDigest acc “Sedan” pk to verify the mismatch 12/17

Basic Solution

• Consider a single object and boolean time-window query
• Each block stores a single object oi = ti, Wi
• ADS generation (Miner)
• Extend the block header with AttDigest
• AttDigest = acc(Wi) = Setup(Wi, pk)
• Constant size regardless of number of elements in Wi
• Support ProveDisjoint(·) & VerifyDisjoint(·)

. . . PreBkHash TS ConsProof ObjectHash AttDigest

blocki

• i

. . .

• Fig. 6: Extended Block Structure
• Verifjable Query
• Match: return oi as a result; integrity is ensured by the ObjectHash in the block header
• Mismatch:

use AttDigest to prove the mismatch of oi

Example of Mismatch

• Transform query condition to a list of sets: q

“Sedan” “Benz” “BMW” “Sedan” “Benz” “BMW”

• Consider oi

“Van” “Benz” , we have “Sedan” “Van” “Benz”

• Apply ProveDisjoint

“Van” “Benz” “Sedan” pk to compute proof

• User retrieves AttDigest

acc “Van” “Benz” from the block header and uses VerifyDisjoint AttDigest acc “Sedan” pk to verify the mismatch 12/17

Basic Solution

• Consider a single object and boolean time-window query
• Each block stores a single object oi = ti, Wi
• ADS generation (Miner)
• Extend the block header with AttDigest
• AttDigest = acc(Wi) = Setup(Wi, pk)
• Constant size regardless of number of elements in Wi
• Support ProveDisjoint(·) & VerifyDisjoint(·)

. . . PreBkHash TS ConsProof ObjectHash AttDigest

blocki

• i

. . .

• Fig. 6: Extended Block Structure
• Verifjable Query
• Match: return oi as a result; integrity is ensured by the ObjectHash in the block header
• Mismatch: use AttDigest to prove the mismatch of oi

Example of Mismatch

• Transform query condition to a list of sets: q

“Sedan” “Benz” “BMW” “Sedan” “Benz” “BMW”

• Consider oi

“Van” “Benz” , we have “Sedan” “Van” “Benz”

• Apply ProveDisjoint

“Van” “Benz” “Sedan” pk to compute proof

• User retrieves AttDigest

acc “Van” “Benz” from the block header and uses VerifyDisjoint AttDigest acc “Sedan” pk to verify the mismatch 12/17

Basic Solution

• Consider a single object and boolean time-window query
• Each block stores a single object oi = ti, Wi
• ADS generation (Miner)
• Extend the block header with AttDigest
• AttDigest = acc(Wi) = Setup(Wi, pk)
• Constant size regardless of number of elements in Wi
• Support ProveDisjoint(·) & VerifyDisjoint(·)

. . . PreBkHash TS ConsProof ObjectHash AttDigest

blocki

• i

. . .

• Fig. 6: Extended Block Structure
• Verifjable Query
• Match: return oi as a result; integrity is ensured by the ObjectHash in the block header
• Mismatch: use AttDigest to prove the mismatch of oi

Example of Mismatch

• Transform query condition to a list of sets: q = “Sedan” ∧ (“Benz” ∨ “BMW”) → {“Sedan”}, {“Benz”, “BMW”}
• Consider oi : {“Van”, “Benz”}, we have {“Sedan”} ∩ {“Van”, “Benz”} = ∅
• Apply ProveDisjoint({“Van”, “Benz”}, {“Sedan”}, pk) to compute proof π
• User retrieves AttDigest = acc({“Van”, “Benz”}) from the block header and uses

VerifyDisjoint(AttDigest, acc({“Sedan”}), π, pk) to verify the mismatch 12/17

Basic Solution

• Support time-window queries
• Find the blocks whose timestamp is within the query window
• Invoke previous algorithm for each object in theses blocks

Example

• q = “Sedan” ∧ (“Benz” ∨ “BMW”)
• Objects within the time window o1 : {“Van”, “Benz”}, o2 : {“Sedan”, “Audi”}, o3 : {“Van”, “Benz”}
• Query processing
• o1 is returned as a result
• ProveDisjoint(·) is applied for o2 and o3
• Mismatch condition “Benz” ∨ “BMW” for o2
• Mismatch condition “Sedan” for o3

13/17

Extension to Range Queries

• Idea: transform numerical attributes into set-valued attributes
• Numerical value can be transformed into a set of

binary prefjx elements

• Example: trans 4

1 10 100 * denotes wildcard matching operator

• Range can be transformed into a equivalent

boolean expression using a binary tree

• Example: 0 6

10 110 Equivalence set: 10 110

00 000 001 01 010 011 1 10 100 101 11 110 111 q 0 6

• Fig. 7: Example of Transformation
• Range queries can be processed in a similar manner as Boolean queries
• Transform vi

trans vi EquiSet

• Example:
• 4

0 6 1 10 100 10 110 10

• 7

0 6 1 11 111 10 110

14/17

Extension to Range Queries

• Idea: transform numerical attributes into set-valued attributes
• Numerical value can be transformed into a set of

binary prefjx elements

• Example: trans(4) = {1∗, 10∗, 100}

* denotes wildcard matching operator

• Range can be transformed into a equivalent

boolean expression using a binary tree

• Example: 0 6

10 110 Equivalence set: 10 110

00 000 001 01 010 011 1 10 100 101 11 110 111 q 0 6

• Fig. 7: Example of Transformation
• Range queries can be processed in a similar manner as Boolean queries
• Transform vi

trans vi EquiSet

• Example:
• 4

0 6 1 10 100 10 110 10

• 7

0 6 1 11 111 10 110

14/17

Extension to Range Queries

• Idea: transform numerical attributes into set-valued attributes
• Numerical value can be transformed into a set of

binary prefjx elements

• Example: trans(4) = {1∗, 10∗, 100}

* denotes wildcard matching operator

• Range can be transformed into a equivalent

boolean expression using a binary tree

• Example: [0, 6] → 0∗ ∨ 10∗ ∨ 110

Equivalence set: {0∗, 10∗, 110}

∗ 0∗ 00∗ 000 001 01∗ 010 011 1∗ 10∗ 100 101 11∗ 110 111 q = [0, 6]

• Fig. 7: Example of Transformation
• Range queries can be processed in a similar manner as Boolean queries
• Transform vi

trans vi EquiSet

• Example:
• 4

0 6 1 10 100 10 110 10

• 7

0 6 1 11 111 10 110

14/17

Extension to Range Queries

• Idea: transform numerical attributes into set-valued attributes
• Numerical value can be transformed into a set of

binary prefjx elements

• Example: trans(4) = {1∗, 10∗, 100}

* denotes wildcard matching operator

• Range can be transformed into a equivalent

boolean expression using a binary tree

• Example: [0, 6] → 0∗ ∨ 10∗ ∨ 110

Equivalence set: {0∗, 10∗, 110}

∗ 0∗ 00∗ 000 001 01∗ 010 011 1∗ 10∗ 100 101 11∗ 110 111 q = [0, 6]

• Fig. 7: Example of Transformation
• Range queries can be processed in a similar manner as Boolean queries
• Transform vi ∈ [α, β] → trans(vi) ∩ EquiSet([α, β]) = ∅
• Example:
• 4 ∈ [0, 6] → {1∗, 10∗, 100} ∩ {0∗, 10∗, 110} = {10∗} = ∅
• 7 /

∈ [0, 6] → {1∗, 11∗, 111} ∩ {0∗, 10∗, 110} = ∅

14/17

Batch Verifjcation & Subscription Queries

• Observation: objects may share common attributes that mismatch query condition
• Idea: we can aggregate them to speed up query processing
• Intra-Block Index: aggregate objects inside same block using MHT
• Inter-Block Index: aggregate objects across blocks using skip list
• Inverted Prefjx Tree: aggregate similar subscription queries from users

PreBkHash TS ConsProof MerkleRoot Nr N5 N1 N2 N6 N3 N4 hashr Wr AttDigestr hash1 W1 AttDigest1

• 1

blocki

Node Object Set Attributes N1

• 1

W1 “Sedan” “Benz” N2

• 2

W2 “Sedan” “Audi” N3

• 3

W3 “Van” “Benz” N4

• 4

W4 “Van” “BMW”

• Fig. 8: Intra-Block Index

PreBkHash MerkleRoot SkipListRoot L2 L4

PreSkippedHashL2 WL2 AttDigestL2 PreSkippedHashL4 WL4 AttDigestL4

blocki

PreBkHash

blocki

2

PreBkHash

blocki

4

• Fig. 9: Inter-Block Index

q1 q2 q3 q4 N1 N2 N3 N4 x y 1 2 3 1 2 3 N0 N1 N5 N6 N7 N8 N2 N3 N4

• i

ti 0 2 “Van” “Benz” ti 001 102 “Van” “Benz” Query Range Boolean Condition q1 0 2 1 3 “Van” “Benz” q2 0 0 1 3 “Van” “BMW” q3 0 2 0 2 “Sedan” “Audi” q4 2 0 3 3 “Sedan” “Benz” Grid Cell 0 2 1 3 0 1 1 2 RCIF: Query Cover Type q1 full q2 full q3 partial Query Condition Set Queries “Van” q1 q2 “Benz” q1 “BMW” q2 BCIF:

• Fig. 10: Inverted Prefjx Tree

15/17

Batch Verifjcation & Subscription Queries

• Observation: objects may share common attributes that mismatch query condition
• Idea: we can aggregate them to speed up query processing
• Intra-Block Index: aggregate objects inside same block using MHT
• Inter-Block Index: aggregate objects across blocks using skip list
• Inverted Prefjx Tree: aggregate similar subscription queries from users

PreBkHash TS ConsProof MerkleRoot Nr N5 N1 N2 N6 N3 N4 hashr Wr AttDigestr hash1 W1 AttDigest1

• 1

blocki

. . . . . . Node Object Set Attributes N1

• 1

W1 = {“Sedan”, “Benz”} N2

• 2

W2 = {“Sedan”, “Audi”} N3

• 3

W3 = {“Van”, “Benz”} N4

• 4

W4 = {“Van”, “BMW”}

• Fig. 8: Intra-Block Index

PreBkHash MerkleRoot SkipListRoot L2 L4

PreSkippedHashL2 WL2 AttDigestL2 PreSkippedHashL4 WL4 AttDigestL4

blocki

PreBkHash

blocki

2

PreBkHash

blocki

4

• Fig. 9: Inter-Block Index

q1 q2 q3 q4 N1 N2 N3 N4 x y 1 2 3 1 2 3 N0 N1 N5 N6 N7 N8 N2 N3 N4

• i

ti 0 2 “Van” “Benz” ti 001 102 “Van” “Benz” Query Range Boolean Condition q1 0 2 1 3 “Van” “Benz” q2 0 0 1 3 “Van” “BMW” q3 0 2 0 2 “Sedan” “Audi” q4 2 0 3 3 “Sedan” “Benz” Grid Cell 0 2 1 3 0 1 1 2 RCIF: Query Cover Type q1 full q2 full q3 partial Query Condition Set Queries “Van” q1 q2 “Benz” q1 “BMW” q2 BCIF:

• Fig. 10: Inverted Prefjx Tree

15/17

Batch Verifjcation & Subscription Queries

• Observation: objects may share common attributes that mismatch query condition
• Idea: we can aggregate them to speed up query processing
• Intra-Block Index: aggregate objects inside same block using MHT
• Inter-Block Index: aggregate objects across blocks using skip list
• Inverted Prefjx Tree: aggregate similar subscription queries from users

PreBkHash TS ConsProof MerkleRoot Nr N5 N1 N2 N6 N3 N4 hashr Wr AttDigestr hash1 W1 AttDigest1

• 1

blocki

. . . . . . Node Object Set Attributes N1

• 1

W1 = {“Sedan”, “Benz”} N2

• 2

W2 = {“Sedan”, “Audi”} N3

• 3

W3 = {“Van”, “Benz”} N4

• 4

W4 = {“Van”, “BMW”}

• Fig. 8: Intra-Block Index

PreBkHash MerkleRoot SkipListRoot L2 L4 . . .

PreSkippedHashL2 WL2 AttDigestL2 PreSkippedHashL4 WL4 AttDigestL4 . . .

blocki

. . . PreBkHash . . . . . . . . .

blocki−2

. . . PreBkHash . . . . . . . . .

blocki−4

. . . . . .

• Fig. 9: Inter-Block Index

q1 q2 q3 q4 N1 N2 N3 N4 x y 1 2 3 1 2 3 N0 N1 N5 N6 N7 N8 N2 N3 N4

• i

ti 0 2 “Van” “Benz” ti 001 102 “Van” “Benz” Query Range Boolean Condition q1 0 2 1 3 “Van” “Benz” q2 0 0 1 3 “Van” “BMW” q3 0 2 0 2 “Sedan” “Audi” q4 2 0 3 3 “Sedan” “Benz” Grid Cell 0 2 1 3 0 1 1 2 RCIF: Query Cover Type q1 full q2 full q3 partial Query Condition Set Queries “Van” q1 q2 “Benz” q1 “BMW” q2 BCIF:

• Fig. 10: Inverted Prefjx Tree

15/17

Batch Verifjcation & Subscription Queries

• Observation: objects may share common attributes that mismatch query condition
• Idea: we can aggregate them to speed up query processing
• Intra-Block Index: aggregate objects inside same block using MHT
• Inter-Block Index: aggregate objects across blocks using skip list
• Inverted Prefjx Tree: aggregate similar subscription queries from users

PreBkHash TS ConsProof MerkleRoot Nr N5 N1 N2 N6 N3 N4 hashr Wr AttDigestr hash1 W1 AttDigest1

• 1

blocki

. . . . . . Node Object Set Attributes N1

• 1

W1 = {“Sedan”, “Benz”} N2

• 2

W2 = {“Sedan”, “Audi”} N3

• 3

W3 = {“Van”, “Benz”} N4

• 4

W4 = {“Van”, “BMW”}

• Fig. 8: Intra-Block Index

PreBkHash MerkleRoot SkipListRoot L2 L4 . . .

PreSkippedHashL2 WL2 AttDigestL2 PreSkippedHashL4 WL4 AttDigestL4 . . .

blocki

. . . PreBkHash . . . . . . . . .

blocki−2

. . . PreBkHash . . . . . . . . .

blocki−4

. . . . . .

• Fig. 9: Inter-Block Index

q1 q2 q3 q4 N1 N2 N3 N4 x y 1 2 3 1 2 3 N0 N1 N5 N6 N7 N8 N2 N3 N4

• i = ti, (0, 2), {“Van”, “Benz”}

= ti, {001, 102, “Van”, “Benz”} Query Range Boolean Condition q1 [(0, 2), (1, 3)] {“Van” ∧ “Benz”} q2 [(0, 0), (1, 3)] {“Van” ∧ “BMW”} q3 [(0, 2), (0, 2)] {“Sedan” ∧ “Audi”} q4 [(2, 0), (3, 3)] {“Sedan” ∧ “Benz”} Grid Cell : [(0, 2), (1, 3)] → {0∗1 ∧ 1∗2} RCIF: Query Cover Type q1 full q2 full q3 partial Query Condition Set Υ Queries {“Van”} q1, q2 {“Benz”} q1 {“BMW”} q2 BCIF:

• Fig. 10: Inverted Prefjx Tree

15/17

Performance Evaluation

• Evaluation metrics
• Query processing cost in

terms of SP CPU time

• Query verifjcation cost in

terms of user CPU time

• Size of the VO transmitted

from the SP to the user

• Numerical range selectivity
• 10% for 4SQ & WX
• 50% for ETH
• Disjunctive Boolean function

size

• 3 for 4SQ & WX
• 9 for ETH

4SQ

100 200 300 400 2 (240) 4 (480) 6 (720) 8 (960) 10 (1200) SP CPU Time (s) Time Window (Hour)/(Blocks) nil-acc1 nil-acc2 intra-acc1 intra-acc2 both-acc1 both-acc2 0.01 0.1 1 10 100 2 (240) 4 (480) 6 (720) 8 (960) 10 (1200) User CPU Time (s) Time Window (Hour)/(Blocks) nil-acc1 nil-acc2 intra-acc1 intra-acc2 both-acc1 both-acc2 1 10 102 103 104 2 (240) 4 (480) 6 (720) 8 (960) 10 (1200) VO Size (KB) Time Window (Hour)/(Blocks) nil-acc1 nil-acc2 intra-acc1 intra-acc2 both-acc1 both-acc2

WX

5 10 15 20 (20) 40 (40) 60 (60) 80 (80) 100 (100) SP CPU Time (s) Time Window (Hour)/(Blocks) nil-acc1 nil-acc2 intra-acc1 intra-acc2 both-acc1 both-acc2 0.01 0.1 1 10 20 (20) 40 (40) 60 (60) 80 (80) 100 (100) User CPU Time (s) Time Window (Hour)/(Blocks) nil-acc1 nil-acc2 intra-acc1 intra-acc2 both-acc1 both-acc2 10 102 103 20 (20) 40 (40) 60 (60) 80 (80) 100 (100) VO Size (KB) Time Window (Hour)/(Blocks) nil-acc1 nil-acc2 intra-acc1 intra-acc2 both-acc1 both-acc2

ETH

50 100 150 2 (480) 4 (960) 6 (1440) 8 (1920) 10 (2400) SP CPU Time (s) Time Window (Hour)/(Blocks) nil-acc1 nil-acc2 intra-acc1 intra-acc2 both-acc1 both-acc2 0.01 0.1 1 10 100 2 (480) 4 (960) 6 (1440) 8 (1920) 10 (2400) User CPU Time (s) Time Window (Hour)/(Blocks) nil-acc1 nil-acc2 intra-acc1 intra-acc2 both-acc1 both-acc2 1 10 102 103 104 2 (480) 4 (960) 6 (1440) 8 (1920) 10 (2400) VO Size (KB) Time Window (Hour)/(Blocks) nil-acc1 nil-acc2 intra-acc1 intra-acc2 both-acc1 both-acc2

• Fig. 11: Time-Window Query Performance

16/17

GEM2-Tree: Enabling Gas-Effjcient Authenticated Range Queries for Hybrid Storage in Blockchain

Ce Zhang, Cheng Xu, Jianliang Xu, Yuzhe Tang, and Byron Choi IEEE ICDE 2019

GEM2-Tree

• Storing data on chain is not scalable
• Hybrid storage:
• Raw data is stored off-chain
• A hash of the data is keep on chain to ensure integrity
• Smart contract maintains on-chain index to facilitate

authenticated query processing

• Question: How to reduce transaction fee a.k.a gas?
• More details
• Section: Research (14) — Query Processing, Indexing and

Optimization

• Time: 14:35–16:05, April 10, Wednesday
• Location: 7004

... ... Hybrid Storage Cloud Service Provider Client Data Owners R, VOsp VOchain Q

Smart Contract

<key, value> ... Smart Contract <key, h(value)>

• Fig. 12: Authenticated Query Framework in

Hybrid-Storage Blockchain 17/17

GEM2-Tree

• Storing data on chain is not scalable
• Hybrid storage:
• Raw data is stored off-chain
• A hash of the data is keep on chain to ensure integrity
• Smart contract maintains on-chain index to facilitate

authenticated query processing

• Question: How to reduce transaction fee a.k.a gas?
• More details
• Section: Research (14) — Query Processing, Indexing and

Optimization

• Time: 14:35–16:05, April 10, Wednesday
• Location: 7004

... ... Hybrid Storage Cloud Service Provider Client Data Owners R, VOsp VOchain Q

Smart Contract

<key, value> ... Smart Contract <key, h(value)>

• Fig. 12: Authenticated Query Framework in

Hybrid-Storage Blockchain 17/17

GEM2-Tree

• Storing data on chain is not scalable
• Hybrid storage:
• Raw data is stored off-chain
• A hash of the data is keep on chain to ensure integrity
• Smart contract maintains on-chain index to facilitate

authenticated query processing

• Question: How to reduce transaction fee a.k.a gas?
• More details
• Section: Research (14) — Query Processing, Indexing and

Optimization

• Time: 14:35–16:05, April 10, Wednesday
• Location: 7004

... ... Hybrid Storage Cloud Service Provider Client Data Owners R, VOsp VOchain Q

Smart Contract

<key, value> ... Smart Contract <key, h(value)>

• Fig. 12: Authenticated Query Framework in

Hybrid-Storage Blockchain 17/17

GEM2-Tree

• Storing data on chain is not scalable
• Hybrid storage:
• Raw data is stored off-chain
• A hash of the data is keep on chain to ensure integrity
• Smart contract maintains on-chain index to facilitate

authenticated query processing

• Question: How to reduce transaction fee a.k.a gas?
• More details
• Section: Research (14) — Query Processing, Indexing and

Optimization

• Time: 14:35–16:05, April 10, Wednesday
• Location: 7004

... ... Hybrid Storage Cloud Service Provider Client Data Owners R, VOsp VOchain Q

Smart Contract

<key, value> ... Smart Contract <key, h(value)>

• Fig. 12: Authenticated Query Framework in

Hybrid-Storage Blockchain 17/17

Thanks Questions?

17/17

References

[HCW+18]

• S. Hu, C. Cai, Q. Wang, C. Wang, X. Luo, and K. Ren, “Searching an encrypted cloud meets blockchain: A

decentralized, reliable and fair realization,” in IEEE INFOCOM, Honolulu, HI, USA, 2018, pp. 792–800. [Mer89]

• R. C. Merkle, “A certifjed digital signature,” in CRYPTO, 1989, pp. 218–238.

[PTT11]

• C. Papamanthou, R. Tamassia, and N. Triandopoulos, “Optimal verifjcation of operations on dynamic sets,” in

CRYPTO, Santa Barbara, CA, USA, 2011, pp. 91–110. [XZX19]

• C. Xu, C. Zhang, and J. Xu, “vChain: Enabling verifjable boolean range queries over blockchain databases,” in ACM

SIGMOD, Amsterdam, Netherlands, 2019. [ZXX+19]

• C. Zhang, C. Xu, J. Xu, Y. Tang, and B. Choi, “GEM2-Tree: A gas-effjcient structure for authenticated range queries

in blockchain,” in IEEE ICDE, Macau SAR, China, 2019.
