Towards a compliance audit of SLAs for data replication in Cloud - - PowerPoint PPT Presentation

Towards a compliance audit of SLAs for data replication in Cloud storage J. Leneutre B. Djebaili, C. Kiennert, J. Leneutre, L. Chen, Data Integrity and Availability Verification Game in Untrusted Cloud Storage, Conference on Decision and Game


slide-1
SLIDE 1

Institut Mines-Télécom

Towards a compliance audit of SLAs for data replication in Cloud storage

  • J. Leneutre
  • B. Djebaili, C. Kiennert, J. Leneutre, L. Chen, Data Integrity and Availability Verification Game in Untrusted Cloud

Storage, Conference on Decision and Game Theory for Security (GameSec), Los Angeles, CA, USA, November 2014, LNCS.

slide-2
SLIDE 2

Institut Mines-Télécom

Outline

  • Introduction
  • Background
  • Assumptions
  • Contributions
  • Game Models
  • Conclusion

30/06/15

Data Integrity Verification Game in Cloud Storage 2

slide-3
SLIDE 3

Institut Mines-Télécom

Outline

  • Introduction
  • Background
  • Contributions
  • Game Models
  • Conclusion

30/06/15

Data Integrity Verification Game in Cloud Storage 3

slide-4
SLIDE 4

Institut Mines-Télécom

Introduction

n Cloud features:

  • On-demand services
  • Resource pooling via multi-tenancy
  • Elasticity via dynamic provisioning of resources
  • Device and location independence

➡ Source of security problems

─ Reduced control over software and data ─ Potential Interference between security and cloud optimization mechanisms

30/06/15

Data Integrity Verification Game in Cloud Storage 4

n Security of data storage:

  • Privacy / Confidentiality
  • Integrity/availability

─ External (hackers) threats for data integrity or availability ─ Cloud Provider (CP) might behave unfaithfully ➡ Users need strong evidence that their data have not been tampered or partially deleted

slide-5
SLIDE 5

Institut Mines-Télécom

Problem Statement

n Case of an Untrusted CP

  • Economically-motivated CP that may be tempted to erase (copies of) data to use

less storage space ➡ How to check compliance of SLAs with regard to data replication?

30/06/15

Data Integrity Verification Game in Cloud Storage 5

n Efficient schemes for remote data integrity checking exist

  • New cryptographic protocols: proof of data possession (PDP), proof of retrieval (POR) …

➡ However verification costs computing resources

n How to optimize their use ?

  • Frequency of the verification process ?
  • Which data to check in priority ?
  • Are there data not worth checking at all ?

➡ Optimal verification policies needed

  • Trade-off between security & cost of verification
  • Obtained by a Game Theoretical analysis modelling interactions between Verifier & CP
slide-6
SLIDE 6

Institut Mines-Télécom

Underlying assumptions

n Data replication rate is specified in SLAs

  • Usually not covered in a cloud storage service provider's SLA

➡ Rather provide guarantees in terms of uptime, or allowed number of retries,

  • r how long a read request can take to be serviced

➡ Offer some sort of tiered credits the users if the guarantees are not satisfied

  • May be negociated in the case of storage backup or cloud archive

services

➡ Possible definition of precise retention policies

n User is allowed to access to different copies of same data

  • May be necessary to check geographical location of data

30/06/15

Data Integrity Verification Game in Cloud Storage 6

slide-7
SLIDE 7

Institut Mines-Télécom

Outline

  • Introduction
  • Background
  • Contributions
  • Game Models
  • Conclusion

30/06/15

Data Integrity Verification Game in Cloud Storage 7

slide-8
SLIDE 8

Institut Mines-Télécom

Background: Integrity verification of outsourced data

n Usual techniques for integrity control

  • Hash functions, error-correcting code, checksum, …

➡ … not suited for intentional modification of data !

30/06/15

Data Integrity Verification Game in Cloud Storage 8

D

Hash(D) Audit Hash(D)

User Cloud storage

No detection of modification

Hash(D)

D: Data

slide-9
SLIDE 9

Institut Mines-Télécom

Background: Integrity verification of outsourced data

n Need for a new cryptographic primitive

➡ Integrity checking challenge response protocol

30/06/15

Data Integrity Verification Game in Cloud Storage 9

  • Metadata may also be outsourced
  • Verification may be delegated to a

third party auditor (TPA)

slide-10
SLIDE 10

Institut Mines-Télécom

Background: Integrity verification of outsourced data

n A naive scheme

30/06/15

Data Integrity Verification Game in Cloud Storage 10

  • Requires large metadata size
  • Consumes too much bandwidth

and computation

  • Verifications limited to the number
  • f precomputed hash values
slide-11
SLIDE 11

Institut Mines-Télécom

Background: Integrity verification of outsourced data

n A simple protocol based on DLP [Deswarte & alii, 2004]

  • Metadata: Tag computed using an homomorphic function

30/06/15

Data Integrity Verification Game in Cloud Storage 11

Deswarte, Y., Quisquater, J.-J., and Saïdane, A.. Remote Integrity Checking. In Proceedings of 6th Working Conference on Integrity and Internal Control in Information Systems (IICIS), 2004. “d”: data “T”: tag (metadata) “C”: challenge “R”: response “n”: RSA modulus “r”: random integer “DLP”: discrete logarithm problem

Storage provider Verifier

d C=gr mod n R=Cd mod n

Tr = Cd?

F(d) T=gd mod n

DLP problem à à security

slide-12
SLIDE 12

Institut Mines-Télécom

Background: Integrity verification of outsourced data

n Two main approaches for data verification schemes

  • Deterministic protocols: checks entire data
  • Probabilistic protocols: randomly checks blocks of data

➡ reduce the computing time of verification

30/06/15

Data Integrity Verification Game in Cloud Storage 12

[Ateniese & alii 2011] Ateniese, G., Burns, R., Curtmola, R., Herring, J., Khan, O., Kissner, L., ... & Song,

  • D. (2011). Remote data checking using provable data possession. ACM TISSEC, 14(1), 12.

[Juels, Kaliski 2007] Juels, A., & Kaliski Jr, B. S. (2007, October). PORs: Proofs of retrievability for large

  • files. In Proceedings of the 14th ACM conference on Computer and communications security.

n Main efficient verification schemes

  • PDP (Provable Data Possession) [Ateniese & alii 2011]

─ Minimize bandwith

  • POR (Proofs of Retriability) [Juels, Kaliski 2007]

─ Ability to recover corrupted files by using error correcting codes

n Other features

  • Public verification
  • Management of dynamic data
  • Verification of multiple copies of a data
slide-13
SLIDE 13

Institut Mines-Télécom

Background: Game Theory

n Game theory: aims at modeling situations in which

decision makers have to make specific actions that have mutual, possibly conflicting consequences

30/06/15

Data Integrity Verification Game in Cloud Storage 13

n Glossary:

  • Players: a strategic decision maker (can be a person, a machine, etc.)
  • Actions: a move that can be carried out by the player at any given time
  • Utility function: assigns a numerical value for every possible outcome of the

game for a given player taking into account other players’ actions

  • Strategy: a plan of actions taken in the game
  • Nash Equilibrium: strategy from which no player has an incentive to deviate

unilaterally

slide-14
SLIDE 14

Institut Mines-Télécom

Background: Game Theory

n Example: Forwarder’s dilemma

30/06/15

A strategic approach to manage security risks 14

  • Utility function:

─ c (0<c<<1): cost representing the energy and computation spent for the forwarding action ─ Reward when forwarding : 1

  • Nash equilibrium: (D,D)
  • Goal: device p1 (resp. p2) wants to send

a packet to his receiver r1 (resp. r2) using p2 (resp. p1) as a forwarder, in each time slot

  • Actions: Forward (F) or Drop (D) a packet
slide-15
SLIDE 15

Institut Mines-Télécom

Outline

  • Introduction
  • Game Theory
  • Contributions
  • Game Models
  • Conclusion

30/06/15

Data Integrity Verification Game in Cloud Storage 15

slide-16
SLIDE 16

Institut Mines-Télécom

Contributions

n Define a basic model

  • Static game with deterministic verification protocol
  • CP stores only one copy of the data

30/06/15

Data Integrity Verification Game in Cloud Storage 16

n Study different extensions of the model

  • Dynamic game with deterministic verification (Stackelberg game)
  • Static game with probabilistic verification protocol
  • Extension where CP stores multiple copies of data
  • Repeated game (multiple consecutive interactions over time)

n For each model :

  • Prove the existence of an attractive data set on which both attacker

and verifier should focus exclusively

  • Find the Nash Equilibrium
  • Analyze the results in terms of expected behaviours & deduce

guidelines for optimal TPA data checking

slide-17
SLIDE 17

Institut Mines-Télécom

Outline

  • Introduction
  • Game Theory
  • Contributions
  • Game Models
  • Conclusion

30/06/15

Data Integrity Verification Game in Cloud Storage 17

slide-18
SLIDE 18

Institut Mines-Télécom

Generic game Model

n Non-cooperative game n Two rational players

  • Attacker (CP)
  • Verifier (TPA)

n Two actions per player for each data :

  • Attacker : Not replicating / Do nothing
  • Verifier : Check data integrity / Do nothing

n Strategies: distribution of attack/verification resources

  • For each data Di, the attacker decides to not replicate data with

probability pi, and the verifier checks data with probability ti

  • Available resources for attacker (resp. verifier) : P (resp. T)

30/06/15

Data Integrity Verification Game in Cloud Storage 18

Lin Chen and Jean Leneutre. A game theoretical framework on intrusion Detection in heterogeneous networks.IEEE TIFS, 4(2):165-178, 2009

slide-19
SLIDE 19

Institut Mines-Télécom

Generic game Model

n Game parameters

  • Amount of data stored at the CP : N
  • Size of data Di : Si
  • Importance (integrity level) of data Di : Fi
  • Overall TPA probability of detecting fraud when checking data : a

─ a = 1 for deterministic verification protocols ─ a < 1 for probabilistic verification protocols

  • Computing costs for CP and TPA : Cs and Ct
  • Hypothesis : Players are perfectly rational

─ Each players aims at maximizing his payoff

30/06/15

Data Integrity Verification Game in Cloud Storage 19

slide-20
SLIDE 20

Institut Mines-Télécom

Generic game model

30/06/15

Data Integrity Verification Game in Cloud Storage 20

Data Di Verify resource Attack resource Size Sensibility & value Cost of verification (TPA) Cost of executing verification (CP)

CP \ TPA Check Not check Correct/Available data 0, -Ct Si – Cs Si 0, 0 Incorrect/unavailable data – Cs Si – Si, – Ct Si + Fi Si, -Fi

n Utility functions of static game for deterministic verification

TPA payoff: CP payoff: and Ressource constraints:

slide-21
SLIDE 21

Institut Mines-Télécom

Generic game model

30/06/15

Data Integrity Verification Game in Cloud Storage 21

Movie S=15 Compressed file S=11 Compressed file S=5 Photo S=3 Text S=2 Text S=1 Audio S=7

n Data distribution

  • Does a rational attacker (CP) attack all data ?

Existence of an Attractive Dataset Actually, a rational attacker will only attack data with large enough sizes Si

Guideline 1: A rational defender has only to verify data in the attractive dataset

slide-22
SLIDE 22

Institut Mines-Télécom

Generic game model

n Nash equilibrium: analytical result when all resources are used by both players ( )

30/06/15

Data Integrity Verification Game in Cloud Storage 22

(Attractive dataset) Guideline 2: Verification resources to data should be allocated accordingly to the values of ti*

slide-23
SLIDE 23

Institut Mines-Télécom

Generic game model : numerical analysis

30/06/15

Data Integrity Verification Game in Cloud Storage 23

Defender (TPA) Attacker (CP)

  • 0.13976
  • 0.34721
  • 0.61456

Table 1: Payoff at the Nash Equilibrium (NE) Table 2: Payoff Degradation due to deviation from NE

Number of data

n=20

TPA random strategy CP best response TPA best & maximum gain TPA average gain TPA minimal gain

slide-24
SLIDE 24

Institut Mines-Télécom

Game with multiple data copies

n Multiple copies of the same data on the CP servers

  • Parameters : same than generic game plus

─ Number of copies of data Di: Ri ─ Reward the CP gets if he acts honestly: ε (ε>0)

30/06/15

Data Integrity Verification Game in Cloud Storage 24

CP \ TPA Check Not check Correct/Available copy

ε, -Ct Si – Cs Si

0, 0 Incorrect/unavailable copy – Cs Si – Si, – Ct Si + Fi Si, -Fi

n Strategies

  • Probability that the CP deletes i copies of data Dm (0≤i≤Rm): pi

m

  • Probability that the TPA checks i copies of data Dm (0≤i≤Rm): qi

m

slide-25
SLIDE 25

Institut Mines-Télécom

Game with multiple data copies

30/06/15

Data Integrity Verification Game in Cloud Storage 25

Data Di Verify resource Attack resource Size Sensibility & value Cost of verification (TPA) Cost of executing verification (CP)

n Utility functions of game with multiple copies

TPA payoff: CP payoff:

qi

Notation: denotes the indicator function

Si

slide-26
SLIDE 26

Institut Mines-Télécom

Game with multiple data copies

30/06/15

Data Integrity Verification Game in Cloud Storage 26

n Two game settings

  • Player’s strategy fo each data does not depend on other data:

─ for each data Dm:

  • Player’s strategy fo each data depends on strategies for other data:

─ for N data: ➡ There exists a unique NE in both settings ➡ Characterization of the NE in the corresponding stackelberg game (TPA is the leader) ➡ Current study: extension to an infinite repeated game

slide-27
SLIDE 27

Institut Mines-Télécom

Outline

  • Introduction
  • Game Theory
  • Contributions
  • Game Models
  • Conclusion

30/06/15

Data Integrity Verification Game in Cloud Storage 27

slide-28
SLIDE 28

Institut Mines-Télécom

Conclusion

n Remote data integrity verification in the cloud

  • Modeling the interaction between the verifier and the cloud provider

as a non cooperative game

  • Verification of a single copy / multiple copies

➡ Give some guidelines to define an optimal verification strategy for data replication compliance checking

n Perspectives

  • Take into account location requirements for data

➡ May be used to define “ ALAs (Audit Level Agreements)”

30/06/15

Data Integrity Verification Game in Cloud Storage 28

slide-29
SLIDE 29

Institut Mines-Télécom

Outline

  • Introduction
  • Game Theory
  • Contributions
  • Game Models
  • Conclusion
  • Appendices

30/06/15

Data Integrity Verification Game in Cloud Storage 29

slide-30
SLIDE 30

Institut Mines-Télécom

Background: Game Theory

n Some type of games

  • Deterministic vs. Stochastic games

─ Stochastic game: game involving probabilistic transitions between different states of the system

  • Static vs. Dynamic games

─ Static game (one-shot game): all players choose their strategies simultaneously ─ Dynamic game (Stackelberg game, leader & follower game): players choose their actions in more than one stage

  • Complete information vs. Incomplete information game

─ Complete Information game: players know each others’ strategies and payoffs ─ Incomplete Information game (Bayesian game): information about the characteristics (strategies, payoffs) of other players are incomplete

  • Pure strategies vs. Mixed strategies

30/06/15

Data Integrity Verification Game in Cloud Storage 30

slide-31
SLIDE 31

Institut Mines-Télécom

Stackelberg game for deterministic verification

n Players have sequential interaction: the move of one player is conditioned by the move of the other player n Game principle :

  • The leader moves first
  • The follower observes the leader’s choice, then chooses his

strategy

n Three cases analyzed :

  • Case 1: Leader: CP, Follower: TPA
  • Case 2: Leader: TPA, Follower: CP
  • Case 3: Which strategy will be better for both TPA & CP ?

─ Actually, Case 1 corresponds to the best strategy for both

30/06/15

Data Integrity Verification Game in Cloud Storage 31

Guideline 3: TPA should choose the follower strategy in order to maximize his payoff, while leader is the best strategy for the CP

slide-32
SLIDE 32

Institut Mines-Télécom

Data Di Verify resource Attack resource Size Sensibility & value Cost of verification (TPA) Cost of executing verification (CP) Detection proba a Storage loss

Static game for probabilistic verification

30/06/15

Data Integrity Verification Game in Cloud Storage 32

CP \ TPA Check Not check Correct/Available copy 0, -Ct Si – Cs Si Incorrect/unavailable copy (1–2a) Si – aCs Si,

–(1–2a) Fi – (1–a)CsSi–Ct Si

Si,

  • Fi
slide-33
SLIDE 33

Institut Mines-Télécom

Numerical Analysis

30/06/15

Fig 1: Payoff at the Nash Equilibrium (NE)

30/06/15

33
