The innovative technology

• f glass heating

TOUCH THE HEAT

What is ThermoGlass?

The transparent electroconductive layer provides uniform heating

• f the glass surface.

In combination with the thermostat the temperature of the room can be set with high precision easily and quickly. ThermoGlass can be used in any system with all kinds of profjles (wood, plastic, metal). ThermoGlass connects to 230V AC/DC electricity without using voltage transformers.

ThermoGlass is an absolutely transparent continuous, conductive surface (layer) which functions as a heat- ing element by a unique and innovative techonology applied on the glass surface. Visually ThermoGlass is no difgerent from standard glass, yet it has a number of useful features that you will not fjnd in standard

• glass. What is the operating principle of ThermoGlass?

ThermoGlass can be used as a primary or secondary heat source. It is often used in situations where

• ther heating systems can not be used.

The features of ThermoGlass

The possibilities of the usage of the ThermoGlass are practically unlimited. Using an unique patented nanotechnology we are able to fjnd solutions for a wide range of technical and functional require- ments: from the production of windows and glass panels of various sizes to the production of heating glass roofs and facades for the largest buildings. What makes this product unique? And what features does ThermoGlass ofger?

Anti-icing and fast snow melting Heating

When an electric current fmows through ThermoGlass, it heats the snow and ice which then melts uniformly over the entire surface of the glass structure.

Comfort Zone

When the outdoor temperature is lower than the inside temperature, there is a “cold window efgect“. ThermoGlass is eliminating this efgect and creates a comfort zone.

Anti-condensation

The humidity increases inside modern, well-insulated buildings due to insuffjcient ventilation. On larger glass surfaces water condensation appears. With ThermoGlass, the condensation is eliminated and the glass surface remains dry. The special ThermoGlass surface provides selective properties: during cold weather, even when the electricity is turned ofg, the heat is refmected back into a room. At the same time, when it is warm

• utside, ThermoGlass blocks the heat outside from fjnding its way inside.

t

Good insulation properties

Electrical conductivity of the glass surface layer can be used as a intrusion sensor and may be directly connected to the alarm (security) system.

Safety

ThermoGlass Basic Products

t T = t + 3×0,76 mm + t t 3×0,76 mm

T S T T T S S T T1 S T2 T1 S T2 T1 T2 S S T3 T1 T2 S S T3 T1 S T2 T1 S T2

• 1. TG Triplex SP
• 2. TG DP
• 5. TG Triplex DP TGH
• 8. TG Triplex DP TGH- TXH
• 3. TG TP
• 6. Triplex TP TXH
• 9. TG Triplex DP 2TXH
• 4. TG Triplex DP TXH
• 7. TG Triplex TP TGH

• 1. ThermoGlass Triplex Single Pane

Tempered safety heating glass ESG+3×0,76+ThermoESG.P.G* t(4,6,8,10,12), T (10,28-22,28 mm)

*ESG - Tempered glass, S – Spacer, ThermoESG.P.G-Tempered glass with heating layer+Planibel G function

• The glazed roof over the entrance to buildings
• Partition walls in offjces and apartments
• Heating of ready meals in restaurants and bars
• Well designed radiators
• Front and side heating glasses (boats, cars and trains)
• Glass for street security cameras
• Heated public transport stops
• Terrariums
• Maxium dimensions - 2000x3000 mm
• Minimum dimensions - 300x400 mm
• Maximum surface temperature: +90°C
• The coeffjcient of the heat transfer resistance - 1,00 m2 °C/W
• The coeffjcient of the sound insulation - 31 dB
• The coeffjcient of directed light transmittance - 63 %
• The coeffjcient of the solar energy transmittance - 47 %

Technical characteristics Usage: Interior and exterior

t T = t + 3×0,76 mm + t t 3×0,76 mm

from 450 €/m2

price withou VAT.

Tempered heating double pane glass ESG.P.G/S/ThermoESG.P.G T(4-12 mm), S(9,10,12,14,16,20,24) Tempered heating triple pane glass ESG/S/ESG.P.G/S/ThermoESG.P.G T(4,6,8,10 mm), S(9,10,12,14,16,24)

*ESG.P.G - Tempered glass with coating Planibel G, S – Spacer, ThermoESG.P.G-Tempered glass with heating layer+Planibel G function

• Maxium dimensions - 2000x3000 mm
• Minimum dimensions - 300x400 mm
• Maximum surface temperature: +55°C
• Maxium dimensions - 2000x3000 mm
• Minimum dimensions - 300x400 mm
• Maximum surface temperature: +55°C
• Large glass windows for shops, hotels and restaurants
• Winter gardens
• Bestseller version of large dimension windows and doors

with superior insulating features

• Partition walls in offjces and apartments
• Heating glasses with anti-condensation efgect

to refrigerators and ice boxes

• Large glass windows for shops, hotels and restaurants
• Winter gardens

Technical characteristics Technical characteristics Usage: Interior and exterior Usage: Exterior

• 2. ThermoGlass Double Pane
• 3. ThermoGlass Triple Pane

T S T T T S S T

from 350 €/m2

price withou VAT.

from 400 €/m2

price withou VAT.

Laminated safety heating double pane glass with higher resistance of the external glass (ThermoGlass heating) 3.3.1/S/ThermoESG.P.G T1 (7-30 mm), T2 (4-12 mm), S(9,10,12,14,16,20,24) Laminated safety heating double pane glass with higher resistance of the internal glass (Triplex heating) ESG/S/ESG+3×0,76+ThermoESG.P.G T1 (4-12 mm), T2 (10,28-22,28 mm), S(9,10,12,14,16,20,24)

*ESG - Tempered glass, S – Spacer, ThermoESG.P.G-Tempered glass with heating layer+Planibel G function

• Maxium dimensions - 2000x3000 mm
• Minimum dimensions - 300x400 mm
• Maximum surface temperature: +55°C
• Maxium dimensions - 2000x3000 mm
• Minimum dimensions - 300x400 mm
• Maximum surface temperature: +55°C
• Winter gardens, glazed outdoor seating for restaurants

and hotels (higher altitude)

• Roofs, facades and skylights
• Loggias and balconies
• Winter gardens, glazed outdoor seating for restaurants

and hotels (higher altitude)

• Roofs, facades and skylights
• Loggias and balconies

Technical characteristics Technical characteristics Usage: Interior and exterior Usage: Exterior

• 4. ThermoGlass Triplex Double Pane TGH
• 5. ThemoGlass Triplex Double Pane TXH

T1 S T2 T1 S T2

from 440 €/m2

price withou VAT.

from 490 €/m2

price withou VAT.

Laminated safety heating triple pane glass with higher resistance of the external glass (ThermoGlass heating) 3.3.1/S/ESG.P.G/S/ThermoESG.P.G T1 (7-30 mm), T2 (4-12mm), T3(4-12), S(9,10,12,14,16,20,24) Laminated safety heating triple pane glass with higher resistance of the internal glass (Triplex heating) ESG/S/ESG.P.G/S/ESG+3×0,76+ThermoESG.P.G T1 (4-12 mm), T2 (4-12 mm), T3 (10,28-22,28 mm), S(9,10,12,14,16,20,24)

*ESG.P.G - Tempered glass with coating Planibel G, S – Spacer, ThermoESG.P.G-Tempered glass with heating layer+Planibel G function

• Maxium dimensions - 2000x3000 mm
• Minimum dimensions - 300x400 mm
• Maximum surface temperature: +55°C
• Maxium dimensions - 2000x3000 mm
• Minimum dimensions - 300x400 mm
• Maximum surface temperature: +55°C
• Windows, balconies, loggias in fmats and houses

with premium insulation and safety characteristics

• Roofs, facades and skylights with superior safety

properties in residential buildings and non-residential buildings

• Exclusive winter gardens
• Windows, balconies, loggias in fmats and houses
• Roofs, facades and skylights in residential buildings

and non-residential buildings

• Exclusive winter gardens

Technical characteristics Technical characteristics Usage: Interior and exterior Usage: Exterior

• 6. ThermoGlass Triplex Triple Pane TGH
• 7. ThermoGlass Triplex Triple Pane TXH

T1 T2 S S T3 T1 T2 S S T3

from 550 €/m2

price withou VAT.

from 640 €/m2

price withou VAT.

Tempered safety heating dual pane glass with higher resistance of the internal glass (Both sides heating) ThermoESG.P.G/S/ESG+3×0,76+ThermoESG.P.G T1 (4-12 mm),Т2(10,28-22,28 mm), S(9,10,12,14,16,20,24) Tempered safety heating dual pane glass with higher resistance of both sides glasses (Both sides heating) ESG+3×0,76+ThermoESG.P.G/S/ESG+3×0,76+ThermoESG.P.G Т1(10,28-22,28 mm),Т2(10,28-22,28 mm), S(9,10,12,14,16,20,24)

*ThermoESG.P.G-Tempered glass with heating layer+Planibel G function, S – Spacer

• Maxium dimensions - 2000x3000 mm
• Minimum dimensions - 300x400 mm
• Maximum surface temperature: +90°C
• Maxium dimensions - 2000x3000 mm
• Minimum dimensions - 300x400 mm
• Maximum surface temperature: +90°C
• Roofs and skylights in diffjcult climatic conditions with

superior strength characteristics

• Roofs and skylights in diffjcult climatic conditions

Technical characteristics Technical characteristics Usage: Interior and exterior Usage: Exterior

• 8. ThermoGlass Triplex Dual Pane TGH-TXH
• 9. ThermoGlass Triplex Dual Pane 2TXH

T1 S T2 T1 S T2

from 740 €/m2

price withou VAT.

from 790 €/m2

price withou VAT.

Windows, balconies, loggias

• The main or supplementary heating
• Elimination of the “cold window efgect“
• Removal of condensation form the glass surface
• Replacement of ineffjcient and aesthetically

inappropriate fmoor convector

• Minimization of heat loss
• Energy savings while cooling rooms
• Can be connected to the security system of the building

Power consumption Heating temperature Type of the heating glass 50 - 500 W/m2 +25...+55°С Interior

Advantages

ThermoGlass solves the “cold window efgect” problem. It creates an area of comfort, prevents con- densation, and can be used as a main heat source.

t

Examples of ThermoGlass usage

?

ThermoGlass intended for use in skylights are manufactured in any shape and size. According to an individual request, it is possible to produce dual pane or triple pane glass with either

• ne heating glass or both heating glasses.

Skylights

t

Examples of ThermoGlass usage

• The main or supplementary heating
• Snow and ice melting
• Good insulation characteristics (properties) at high

temperatures in the summer months.

Advantages

Power consumption Heating temperature Type of the heating glass 50 - 800 W/m2 +25...+90°С Interior/exterior

Winter gardens and other glass construction

Advantages

The dominant amount of glass used in winter garden construction predisposes ThermoGlass to be the

• nly logical way of heating. ThermoGlass prevents formation of water condensation while humidity

remains high, which is a prerequisite for the use of heating glass in greenhouses with subtropical fmora (botanical gardens).

• Logically the only major source of heat
• Elimination of the “cold window efgect”
• Removal of condensation from the glass surface
• Maximum use of the natural lighting
• Can be connected to the security system of the building

Examples of ThermoGlass usage

Power consumption Heating temperature Type of the heating glass 50 - 500 W/m2 +30...+55°С Interior

• The maximal thermal comfort
• Elimination of condensation
• Avoiding mold and fungus
• Can be connected to the security system of the building

Swimming pool

Advantages

Using ThermoGlass heating double pane or triple pane glasses for swimming pool glazing allows you to create for visitors a sense of natural sunlight. With ThermoGlass we can create large glass surfaces without the condensation efgect.

Power consumption Heating temperature Type of the heating glass 50-500 W/m2 +25...+55°С Interior

Examples of ThermoGlass usage

SUBURBAN RESPONSE

Heating roof windows in Moscow Region, Mytischi Heating windows installed in the house in Moscow Region, Ramensky district Heating windows installed in the house in Tver Region, Konakovo village Kitchen heating windows, Moscow Region, Ramenski district

SUBURBAN RESPONSE SUBURBAN RESPONSE

Glazed living room, Moscow Region, Korolev Warmed glassed pavilion in Moscow Region, Balashikha Installation of the hea in Moscow Region, M Panoramic windo Moscow Region, K

tion of the heating windows and doors ion, Mytyschi

SUBURBAN RESPONSE

ThermoGlass is a regular partner of the “Suburban Response” program

• n the channel NTV. This is quite

undersatnable in that the designers

• f “Suburban Response” use only the

best materials and products to create their interiors.

SUBURBAN RESPONSE

SUBURBAN RESPONSE SUBURBAN RESPONSE

Glazed attic Moscow Region, Ramenskoe Heating windows in Moscow Region, Igumnovo village amic windows, Trade Center ion, Krasnogorsk Glazed swimming pool in Moscow Region, Mytischi Heating windows veranda in Moscow Region, Dzerzhinski Heated skylight Moscow Region, Podolsk
