The Amazon Echo using Java, IoT, and AWS Lambda Jeff Ramsdale Introduction Jeff Ramsdale Solutions Architect at Dev9 Java Developer Electronics hobbyist Certified AWS Solutions Architect Associate What is the Amazon

SLIDE 1

The Amazon Echo using Java, IoT, and AWS Lambda

Jeff Ramsdale

SLIDE 2

Introduction

SLIDE 3

Jeff Ramsdale

Solutions Architect at Dev9
Java Developer
Electronics hobbyist
Certified AWS Solutions Architect Associate

SLIDE 4

What is the Amazon Echo?

A voice-controlled, internet-enabled, device providing a natural-language interface to services you may use already. A relatively easy-to-program front-end for any service requiring a simple interactive UI.

2 speakers
7 microphones
Bluetooth
WiFi

SLIDE 5

What is the Raspberry Pi?

Very small low-power single-board computer.

Runs Linux
Supports 1080p via HDMI
Provides a lot of I/O pins
Model 3 is quad-core 64-bit PC with WiFi

and Bluetooth built in

Vibrant community
$35!!!

SLIDE 6

What is IoT?

Network of everything
Often small Internet-enabled devices but

includes vehicles, back-end services, mobile devices, and appliances

50 billion objects predicted by 2020

(Cisco)

Big data nightmare opportunity
Resilient to network interruptions

SLIDE 7

Use Case: Monitoring Seed Starts

SLIDE 8

Existing Seed Starting Installation

SLIDE 9

Sensor Values

Ambient temperature
Ambient humidity
Seed bed temperature
Seed bed humidity
Light status (on/off)
Water depth (ultra-sonic)

SLIDE 10

Adafruit.io Feeds

SLIDE 11

Adafruit.io Dashboard

SLIDE 12

Architecture

SLIDE 13

Amazon Echo Demo

SLIDE 14

Code Walkthrough

SLIDE 15

Use Case: UFO LED Control

SLIDE 16

Existing Installation

Cheap plastic fiber optic LED UFO from the Nickel Arcade in Portland, OR

SLIDE 17

Architecture

SLIDE 18

Adafruit Huzzah vs Adafruit Wiced Feather

Huzzah Breakout

9 GPIO
No TLS 1.2 (i.e. no AWS IoT)
FTDI cord required ($15)
$10 ($15 in Feather form factor)

Wiced

More GPIO
TLS 1.2 (AWS IoT)
Micro USB
LIPO Battery charger built in
$35

SLIDE 19

Raspberry Pi vs Adafruit Wiced Feather

Raspberry Pi

Full Linux PC
Multi-core
Low power
Video out
$35!!!

Wiced Feather

Single core/single thread Arduino

compatible

No interrupt-based OS--better for timing-

critical I/O

Lower power
$35?!

SLIDE 20

UFO Demo

SLIDE 21

Code Walkthrough

SLIDE 22

Resources

Adafruit: https://www.adafruit.com/ - American electronics manufacturer DXSOUL: http://www.dxsoul.com/ - Chinese electronics reseller AWS IoT: https://aws.amazon.com/iot/ - AWS IoT Nickel Arcade: http://www.wunderlandgames.com/ - UFO supplies Adafruit Feathers: https://www.adafruit.com/feather - Microcontrollers Adafruit NeoPixels: https://www.adafruit.com/category/168 - Chainable LEDs COLOURlovers API: http://www.colourlovers.com/api - Color name to values

SLIDE 23

Q&A

SLIDE 24

Thanks!
