SLIDE 1

Text Indexing

Arun Chauhan COMP 314

Lecture 15, 16 Mar 4, Mar 6, 2003

SLIDE 2

Searching Text

grep utility on Unix
specify a regular expression
search all specified files

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 3

Searching Text

grep utility on Unix
specify a regular expression
search all specified files
what happens if
the files are very big, and
many repeated searches need to be carried out

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 4

Searching Text

grep utility on Unix
specify a regular expression
search all specified files
what happens if
the files are very big, and
many repeated searches need to be carried out
can we do better?

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 5

Indexing

split the search process
create an index of frequently used terms (also called a

concordance)

handle the search as a query to lookup the index

amortize indexing time over a large number of queries

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 6

Full-text Retrieval

full-text retrieval ≡ searching large text databases

using automatically constructed concordances

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 7

Full-text Retrieval

full-text retrieval ≡ searching large text databases

using automatically constructed concordances

Questions
How is this different from a library catalog?
Can we rely on high-speed modern processors to do

exhaustive searches?

What kind of indexing would be required for full-text

retrieval?

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 8

Indexing: A General Technique

no large database can be searched without indexes
there may be primary and secondary indexes
elaborate data structures to hold the index to

support rapid queries

e.g., B+ trees
other issues
separate structures for separate indexes?
rapid reindexing for addition, deletion, update
size of the index

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 9

Applications

databases
every database has elaborate index generation schemes
web search
search engines, e.g., google, yahoo!, lycos
also the issue of ranking and displaying the results
disk search
Apple’s Sherlock creates index files for filesystem search

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 10

Inverted File Index

term ≡ keywords of interest
lexicon ≡ list of all terms occurring in the text

index[term] = document1, document2, . . .

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 11

Inverted File Index

term ≡ keywords of interest
lexicon ≡ list of all terms occurring in the text

index[term] = document1, document2, . . .

How do you index non-text data (e.g., PDF files, images)?

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 12

An Example

Document Text 1 Pease porridge hot, pease porridge cold 2 Pease porridge in the pot 3 Nine days old 4 Some like it hot, some like it cold 5 Sole like it in the pot 6 Nine days old find the lexicon and build the inverted index

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 13

Example (contd.)

Number Term Documents 1 cold 2; 1, 4 2 days 2; 3, 6 3 hot 2; 1, 4 4 in 2; 2, 5 5 it 2; 4, 5 6 like 2; 4, 5 7 nine 2; 3, 6 9

ld

2; 3, 6 10 pease 2; 1, 2 11 porridge 2; 1, 2 12 pot 2; 2, 5 13 some 3; 4, 5 14 the 2; 2, 5

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 14

Using the Inverted Index

simple lookup is trivial
for large documents, may have to maintain the location

within each document

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 15

Using the Inverted Index

simple lookup is trivial
for large documents, may have to maintain the location

within each document

compound queries?
conjunctive and disjunctive queries, e.g., “term1 AND

term2”, “term1 OR term2”

complement, “NOT term1”

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 16

Using the Inverted Index

simple lookup is trivial
for large documents, may have to maintain the location

within each document

compound queries?
conjunctive and disjunctive queries, e.g., “term1 AND

term2”, “term1 OR term2”

complement, “NOT term1”
near queries?

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 17

Using the Inverted Index

simple lookup is trivial
for large documents, may have to maintain the location

within each document

compound queries?
conjunctive and disjunctive queries, e.g., “term1 AND

term2”, “term1 OR term2”

complement, “NOT term1”
near queries?
potentially huge index files
should we worry about the index size?

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 18

Trimming the Index

case folding
mostly, case is immaterial
stemming
are “search”, “searching”, “searches” different?
strategy: maintain only the neutral form of the term
eliminate stop words
frequently occurring terms ≡ stop list
e.g., “a”, “the”, “in”, “to”, etc.

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 19

Effectiveness: Precision

Precision = r t r: number of relevant documents retrieved t: total number of documents retrieved

if 50 documents are retrieved, 35 are relevant, then the precision is 70%

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 20

Effectiveness: Recall

Recall = r n r: number of relevant documents retrieved n: total number of relevant documents in the collection

if 50 documents are retrieved, 35 are relevant, then the precision is 70% if there are 140 relevant documents then the recall is 25%

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 21

Search Engines

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 22

Indexing the Web

more than 2 billion documents on the web
google claims to index 1.5 billion documents
two indexing approaches
search engines (e.g., google)
hierarchical directories (e.g., Yahoo!)

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 23

Web Search Characteristics

bulk
rapidly changing content
about one-third changes every year
heterogeneous content
duplication, as much as 30%
high linkage
wide variety of users
varying user behavior
85% only look at the first screen
78% never modify their first query

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 24

Query Characteristics

0 term in query 21% 1 term in query 26% 2 terms in query 26% 3 terms in query 15% > 3 terms in query 12%

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 25

Goals of a Search Engine

speed
recall
precision
precision in the top result page

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 26

Search Engine Architecture

crawler
collects pages from the Web
indexer
indexes the collected pages
query server
accepts and processes queries and returns the results

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 27

The Crawler

base ← set of known working hyperlinks queue ← base while (! queue.empty()) { p = first element of queue process p for each page, q, referenced from p add q to queue; }

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 28

Indexing

inverted index
most common, used by google
superimposed coding is another technique
term extraction
title or the whole document
document analysis to identify keywords

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 29

Query Processing

keyword vs concept-based searching
concept-based searching uses “clustering”
Excite used concept-based searching
searching “similar” results
ranking the hits

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 30

Rankings

google’s page-popularity based rankings
combined with proximity of search keywords to those in the

document let page P be pointed to by pages T1, T2, T3, etc. let L(x) be the number of links going out of page x let R(x) be the page rank of page x R(P) = (1 − d) + d × (R(T1) L(T1) + R(T2) L(T2) + . . . + R(Tk) L(Tk)) where, d is a damping factor

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 31

Solving the Rankings

R(P1) = (1 − d) + d × ( 1 L(T p1

1 )R(T p1 1 ) +

1 L(T p1

2 )R(T p1 2 ) + . . . +

1 L(T p1

k1 )R(T p1 k1 ))

R(P2) = (1 − d) + d × ( 1 L(T p2

1 )R(T p2 1 ) +

1 L(T p2

2 )R(T p2 2 ) + . . . +

1 L(T p2

k2 )R(T p2 k2 ))

. . . R(Pn) = (1 − d) + d × ( 1 L(T pn

1 )R(T pn 1 ) +

1 L(T pn

2 )R(T pn 2 ) + . . . +

1 L(T pn

kn )R(T pn kn )) Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003

SLIDE 32

Solving the Rankings

R(P1) = (1 − d) + d × ( 1 L(T p1

1 )R(T p1 1 ) +

1 L(T p1

2 )R(T p1 2 ) + . . . +

1 L(T p1

k1 )R(T p1 k1 ))

R(P2) = (1 − d) + d × ( 1 L(T p2

1 )R(T p2 1 ) +

1 L(T p2

2 )R(T p2 2 ) + . . . +

1 L(T p2

k2 )R(T p2 k2 ))

. . . R(Pn) = (1 − d) + d × ( 1 L(T pn

1 )R(T pn 1 ) +

1 L(T pn

2 )R(T pn 2 ) + . . . +

1 L(T pn

kn )R(T pn kn ))

L × R = C

Lecture 15, 16: Text Indexing Mar 4, Mar 6, 2003
