TensorFlow Marco Serafini COMPSCI 532 Lecture 20
Motivations • DistBelief: Previous iteration • Parameter server • Limitations: • Monolithic layers, difficult to define new ones • Difficult to offload computation with complex dependencies to parameter servers • E.g. Apply updates based on gradients accumulated over multiple iterations • Fixed execution pattern • Read data, compute loss function (forward pass), compute gradients for parameters (backward pass), write gradients to parameter server • Not optimized for single workstations and GPUs 3 3
TensorFlow • Dataflow graph of operators, but not a DAG • Loops and conditionals • Deferred (lazy) execution • Enables optimizations, e.g. pipelining with GPU kernels • Composable basic operators • Matrix multiplication, convolution, ReLu • Concept of devices • CPUs, GPUs, mobile devices • Different implementations of the operators 4 4
Difference with Parameter Server • Parameter server • Separate worker nodes and parameter nodes • Different interfaces • TensorFlow: only tasks • Shared parameters (called operators ): variables and queues • Tasks managing them are called PS tasks • PS task are regular tasks: they can run arbitrary operators • Uniform programming interface 5 5
Example stateful operators b_1 stateful operators 6 6
Example • Data-parallel training looks like this Stateful variables Stateful queues Concurrent steps for data parallelism 7 7
Dataflow Graph • Vertex: unit of local computation • Called operation in TensorFlow • Edges: inputs and outputs of computation • Values along edges are called tensors 8 8
Tensors • Edges in dataflow graph • Data flowing among operators • Format • n -dimensional arrays • Elements have primitive types (including byte arrays) • Tensors are dense • All elements are represented • User must find ways to encode sparse data efficiently 9 9
Operations • Vertices in dataflow graph • State is encapsulated in operations • Variables and queues • Access to state (and tensors) • Variable op: Returns unique reference handle • Read op: Take reference handle, produce value of variable • Write ops: Take reference and value and update. • Queues are also stateful operators • Get reference handle, modify through operations • Blocking semantics, backpressure, synchronization 10 10
Execution Model • Step: client executes a subgraph by indicating: • Edges to feed the subgraph with input tensors • Edges to fetch the output tensors • Runtime prunes the subgraph to remove unnecessary steps • Subgraphs are run asynchronously by default • Can execute multiple partial, concurrent subgraphs • Example: concurrent batches for data-parallel training 11 11
Distributed Execution • Tasks: named processes that send messages • PS tasks: store variables, but can also run computations • Worker tasks: the rest • Note: “informal” categories, not enforced by TensorFlow • Devices: CPU, GPU, TPU, mobile, … • CPU is the host device • Device executes kernel for each operation assigned to it • Same operation (e.g. matrix multiplication) has different kernels for different devices • Requirements for a device • Must accept kernel for execution • Must allocate memory for inputs and outputs • Must transfer data to and from host memory 12 12
Distributed Execution • Each operation • Resides on a device • Corresponds to one or more kernel • More kernel can be specialized for different devices • Operations are executed within a task 13 13
Distributed Scheduling • TensorFlow runtime places operations on devices • Implicit constraints: stateful operation on same device as state • Explicit constraints: dictated by the user • Optimal placement still open question • Obtain per-device subgraphs • All operations assigned to device • Send and Receive operations to replace edges • Specialized per-device implementations • CPU – GPU: CUDA memory copy • Across tasks: TCP or RDMA • Placement preserved throughout session 14 14
Dynamic Control Flow • How do enable dynamic control flow with static graph? • Example: recurrent neural network • Train network for sequence of variable length without unrolling • Conditional: Switch and Merge input op op Output one Switch Merge Data input non-dead dead input op op Control input 15 15
Loops • Uses three additional operators NextIteration Enter Exit Data input op op 16 16
Scaling to Large Models • Model parallelism • Avoids moving terabytes of parameters every time • Operations (typically implemented by library) • Gather: reads tensor data from shard and computes • Part: Partitions the input across shards of parameters • Stitch: Aggregates all partitions parameters inputs 17
Fault Tolerance • Long running tasks face failures and pre-emption • Sometimes run at night on idle machines • Small operations, no need to tolerate individual failures • Even RDDs are overkill • User use Save operation for checkpointing • Each variable in a task connected to same save for batching • Asynchronous, not consistent • Restore operation executed by clients at startup • Other use cases: transfer learning 18 18
Coordination • TensorFlow is asynchronous by default • Stochastic Gradient Descent tolerates asynchrony • Asynchrony increases throughput • But synchrony has benefits • Using stale parameters slows down convergence • System must support user-defined synchrony 19 19
Synchronous Coordination • Use blocking queues for synchrony • Redundant tasks for stragglers different colors = blocking queues on different versions inputs and outputs proactive (not of parameter reactive) backup workers 20 20
Implementation • Distributed master • Obtain subgraphs for each participating device • Dataflow executor • Handles requests from master • Schedules the execution of the kernels of local subgraph • Data transfer to device and over network 21 21
Single-Machine Performance • Similar to COST analysis • Comparison with single-server (not single-threaded) tools • Four convolutional models using one GPU 22 22
Synchronous Microbenchmarks • Null training steps • Sparse performance is close to optimal (scalar) 23
Scalability • Scalability bound by access to PS tasks (7 in the exp) • Synchronous coordination scales well • Backups are beneficial (but expensive way to do FT) 24 24
