Tables and Priority Queues Tables Previously: each node stored one item Now: Groups of related information in records Records indexed by key Key is just one of the pieces of information the one you want to be able to search on

slide-1
SLIDE 1

Tables and Priority Queues

slide-2
SLIDE 2

Binary searching & introduction to trees

2 CMPS 12B, UC Santa Cruz

Tables

Previously: each node stored one item Now: Groups of related information in records

Records indexed by key Key is just one of the pieces of information – the one you

want to be able to search on

Support fast searching by key – O(logn) Also support scanning for other information in

records

But not as fast – O(n) instead of O(logn)

Examples

Student records List of pirated MP3s

slide-3
SLIDE 3

Binary searching & introduction to trees

3 CMPS 12B, UC Santa Cruz

Table ADT – Operations

  • 1. Create an empty table
  • 2. Determine whether a table is empty
  • 3. Determine the number of items in a table
  • 4. Insert a new item into the table
  • 5. Delete the item with a given search key from the

table

  • 6. Retrieve the item with a given search key from the

table

  • 7. Traverse the items in a table in sorted search-key
  • rder
slide-4
SLIDE 4

Binary searching & introduction to trees

4 CMPS 12B, UC Santa Cruz

SearchKeys

public abstract class KeyedItem { private Comparable searchKey; public KeyedItem(Comparable key) { searchKey = key; } public Comparable getKey() { return searchKey; } }

slide-5
SLIDE 5

Binary searching & introduction to trees

5 CMPS 12B, UC Santa Cruz

City extends KeyedItem

public class City extends KeyedItem { private String country; private int population; public City(String theCity, String theCountry, int pop) { super(theCity); country = theCountry; population = pop; } public String toString() { return getKey() + ", " + country + " " + population; } public void setPopulation(int pop) { population = pop; } public int getPopulation() { return population; } public String getCountry() { return Country; } }

slide-6
SLIDE 6

Binary searching & introduction to trees

6 CMPS 12B, UC Santa Cruz

TableInterface

import searchkeys.*; public interface TableInterface { public boolean tableIsEmpty(); public int tableLength(); public void tableInsert(KeyedItem newItem) throws TableException; public boolean tableDelete(Comparable searchKey); public KeyedItem tableRetrieve( Comparable searchKey); }

slide-7
SLIDE 7

Binary searching & introduction to trees

7 CMPS 12B, UC Santa Cruz

Implementing the Table

Linear implementations

Unsorted array Unsorted linked list Sorted (by key) array Sorted (by key) linked list

Non-linear implementations

Binary search tree

Criteria

What operations are needed? How often will different operations be used? How important are the different operations?

slide-8
SLIDE 8

Binary searching & introduction to trees

8 CMPS 12B, UC Santa Cruz

Examples

Small, unsorted data, fixed size

Array

Small, unsorted data, variable size

Linked list

Small, sorted data, variable size

Linked list

Large, unsorted data, variable size

Linked list

Large, sorted data, variable size

Binary search tree

slide-9
SLIDE 9

Binary searching & introduction to trees

9 CMPS 12B, UC Santa Cruz

Comparison of Implementation Alternatives

O(n) O(n) O(n) O(1) Unsorted array Traversal Retrieval Deletion Insertion O(n) O(logn) O(logn) O(logn) Binary search tree O(n) O(n) O(n) O(n) Sorted linked list O(n) O(logn) O(n) O(n) Sorted array O(n) O(n) O(n) O(1) Unsorted linked list

slide-10
SLIDE 10

Binary searching & introduction to trees

10 CMPS 12B, UC Santa Cruz

See Table Code

slide-11
SLIDE 11

Binary searching & introduction to trees

11 CMPS 12B, UC Santa Cruz

Priority Queue

It is often useful to assign a priority to different data

items

so that urgent items can be processed first

Examples

Time in a todo list Importance in a list of phone calls to make …

slide-12
SLIDE 12

Binary searching & introduction to trees

12 CMPS 12B, UC Santa Cruz

Priority Queue ADT

  • 1. Create an empty priority queue
  • 2. Determine whether a priority queue is empty
  • 3. Insert a new item into a priority queue
  • 4. Retrieve and then delete the item in a priority queue

with the highest priority

slide-13
SLIDE 13

Binary searching & introduction to trees

13 CMPS 12B, UC Santa Cruz

Implementing Priority Queues: Heaps

A complete binary tree that is

Empty, or Whose root has heaps as its subtrees, and whose root contains a key greater than or equal to the key

  • f each of its children

Heaps are always balanced There is no order on the values of the keys of the two

children of a node

Unlike binary search trees

slide-14
SLIDE 14

Binary searching & introduction to trees

14 CMPS 12B, UC Santa Cruz

Array-based Implementation of a Heap

10 9 6 5 2 3

Breadth-first order in the array Complete tree ⇒ no gaps in array

2 5 3 6 9 10

slide-15
SLIDE 15

Binary searching & introduction to trees

15 CMPS 12B, UC Santa Cruz

Inserting into the Heap

10 9 6 5 2 3

Breadth-first order in the array Complete tree ⇒ no gaps in array

1 2 5 3 6 9 10 1

slide-16
SLIDE 16

Binary searching & introduction to trees

16 CMPS 12B, UC Santa Cruz

Deleting from the Heap (1)

10 9 6 5 2 3

Always delete the root

It has the highest priority

1 2 5 3 6 9 10 1

slide-17
SLIDE 17

Binary searching & introduction to trees

17 CMPS 12B, UC Santa Cruz

Deleting from the Heap (2)

9 6 5 2 3

Oops, now we have two heaps

1 2 5 3 6 9 1

slide-18
SLIDE 18

Binary searching & introduction to trees

18 CMPS 12B, UC Santa Cruz

Deleting from the Heap (3)

9 6 5 2 3

Repairing the heap: Move the last element to the top

1 2 5 3 6 9 1

slide-19
SLIDE 19

Binary searching & introduction to trees

19 CMPS 12B, UC Santa Cruz

Deleting from the Heap (4)

9 6 5 2 3

Repairing the heap: Now “trickle down” by comparing

and swapping until heap is restored

2 5 3 6 9 1 1

slide-20
SLIDE 20

Binary searching & introduction to trees

20 CMPS 12B, UC Santa Cruz

Deleting from the Heap (5)

1 6 5 2 3

Repairing the heap: Now “trickle down” by comparing

and swapping until heap is restored

2 5 3 6 1 9 9

slide-21
SLIDE 21

Binary searching & introduction to trees

21 CMPS 12B, UC Santa Cruz

Deleting from the Heap (6)

3 6 5 2 1

Calculating indices:

leftchild = 2*parent+1 Rightchild = 2*parent+2

2 5 1 6 3 9 9

slide-22
SLIDE 22

Binary searching & introduction to trees

22 CMPS 12B, UC Santa Cruz

Deleting from the Heap (7)

6 3 5 2 1

Now it’s a heap again Total time O(logn)

2 5 1 3 6 9 9

slide-23
SLIDE 23

Binary searching & introduction to trees

23 CMPS 12B, UC Santa Cruz

Inserting to a heap

The opposite of deleting Insert at the bottom, then “trickle up”

slide-24
SLIDE 24

Binary searching & introduction to trees

24 CMPS 12B, UC Santa Cruz

Heapsort

  • One way
  • Insert everything into the heap, then
  • Take everything back out
  • Faster way
  • 1. Make it a heap

for(int index = n/2; n >= 0; n--) { heapRebuild(array, index, n); }

  • 2. Swap the first item (largest) with the last (last--)
  • 3. heapRebuild(array, index, last);
  • 4. Repeat until all items are in the right place
slide-25
SLIDE 25

Binary searching & introduction to trees

25 CMPS 12B, UC Santa Cruz

Heapsort

Make it a heap by doing

heapRebuild to each node

Starting with leaf nodes

2 5 1 3 6 9

slide-26
SLIDE 26

Binary searching & introduction to trees

26 CMPS 12B, UC Santa Cruz

Heapsort

Swap first and “last”

2 9 1 3 6 5

LAST

slide-27
SLIDE 27

Binary searching & introduction to trees

27 CMPS 12B, UC Santa Cruz

Heapsort

last = last – 1 heapRebuild()

2 9 1 3 5 6

LAST

slide-28
SLIDE 28

Binary searching & introduction to trees

28 CMPS 12B, UC Santa Cruz

Heapsort

Swap first and “last”

6 9 1 3 5 2

LAST

slide-29
SLIDE 29

Binary searching & introduction to trees

29 CMPS 12B, UC Santa Cruz

Heapsort

last = last - 1 heapRebuild()

6 9 1 3 2 5

LAST

slide-30
SLIDE 30

Binary searching & introduction to trees

30 CMPS 12B, UC Santa Cruz

Heapsort

Swap first and “last”

6 9 5 3 2 1

LAST

slide-31
SLIDE 31

Binary searching & introduction to trees

31 CMPS 12B, UC Santa Cruz

Heapsort

last = last - 1 heapRebuild()

6 9 5 1 2 3

LAST

slide-32
SLIDE 32

Binary searching & introduction to trees

32 CMPS 12B, UC Santa Cruz

Heapsort

Swap first and “last”

6 9 5 3 2 1

LAST

slide-33
SLIDE 33

Binary searching & introduction to trees

33 CMPS 12B, UC Santa Cruz

Heapsort

last = last – 1 heapRebuild()

6 9 5 3 1 2

LAST

slide-34
SLIDE 34

Binary searching & introduction to trees

34 CMPS 12B, UC Santa Cruz

Heapsort

Swap first and “last” Done!

6 9 5 3 2 1

LAST
