Statistical Analysis of Computer Program Text

Charles Sutton University of Edinburgh

Source code is a means of human communication

Development “out in the open”

Year Count (x1000)

2011 2012 2013 2014 1000 2000 3000 4000 5000 6000

Pull requests

(Github)

Posts

(Stack Overflow)

Repositories

(Sourceforge)

Probabilistic modelling

Problem Model

(family of distributions)

Distribution Do stuff

Predict y from x “Explore” x Inspect distribution p(y|xtest) p(z|xtest) p(z|x1…xn)

Learning

(objective function)

Data

Source files Source files Source files Source files Source files

Supervised (x1,y1)…(xn,yn) Unsupervised x1…xn

Learning Natural Coding Conventions

[Allamanis, Barr, Bird, Sutton; FSE 2014]

junit/src/test/java/junit/tests/runner/TextRunnerTest.java
 public class TextRunnerTest extends TestCase {
 void execTest(String testClass, boolean success) throws Exception {
 ...
 InputStream i = p.getInputStream();
 while ((i.read()) != -1);
 ...
 }
 ...
 }


junit/src/test/java/junit/tests/runner/TextRunnerTest.java
 public class TextRunnerTest extends TestCase {
 void execTest(String testClass, boolean success) throws Exception {
 ...
 InputStream i = p.getInputStream();
 while ((i.read()) != -1);
 ...
 }
 ...
 }


Suggest alternate names

input inputStream is stream

Score and threshold

input (81.93%)

Language Models for Source Code

Probability distribution over token sequences: Consider naive estimator: In Naturalize : Choose the name other programmers use in similar contexts

Naming Methods and Classes

[Allamanis, Barr, Bird, Sutton; FSE 2015]

Name that Tune Java Method

1 private void createDefaultShader () { 2

String vertexShader = "literal_1";

3

String fragmentShader = "literal_2";

4

shader = new ShaderProgram(vertexShader,

5

fragmentShader);

6

if(shader.isCompiled() == false)

7

throw new IllegalArgumentException(

8

"literal_3" + shader.getLog());

9 }

Figure 1: This method is from libgdx’s CameraGroupStrategy

http://libgdx.badlogicgames.com

from libgdx

“Desktop/Android/Blackberry/iOS/HTML5 Java game development framework”

Embedding Identifiers

Log Bilinear Context Model

qcreateDefaultShader qhashCode ˆ rc

(private, void, (, ), {, String, vertexShader, =, “literal_1”, ;, String, …) c =

P(t|c1:m) = exp{sθ(t, c1:m)} P

t0 exp{sθ(t0, c1:m)}

t = createDefaultShader

sθ(t, c1:m) = q>

t ˆ

rc + bt qv ∈ RD are “embeddings” ::: model parameters More complex, we need to summarize many tokens What about ? ˆ rc

[Mnih, Hinton, 2007; Mnih, Teh, 2012; Mnih, Kavukcuoglu, 2013; Maddison, Tarlow, 2014]

Mining Idioms from Code

[Allamanis and Sutton; FSE 2014]

Defining a String constant Creating a logger for a class Looping through lines from a BufferedReader Iterate through the elements of an Iterator

Mined Idioms (General Java)

Mined Idioms (Library-Specific)

Get an HTML Document in jsoup Show a small popup in Android Get the distance between two points in Android Database transaction in node4j

Model: Tree substitution grammars

Mining API Patterns

[Fowkes and Sutton; NIPS WS 2014]

http://arxiv.org/abs/1510.04130

TwitterFactory.getInstance TwitterFactory.<init> Twitter.setOAuthConsumer Twitter.setOAuthAccessToken

API patterns from code

TwitterFactory.getInstance TwitterFactory.<init> Status.getUser Status.getText ConfigurationBuilder.<init> ConfigurationBuilder.build ConfigurationBuilder.<init> TwitterFactory.<init> ConfigurationBuilder.<init> ConfigurationBuilder.setOAuthConsumerKey ConfigurationBuilder.<init> ConfigurationBuilder.setOAuthConsumerKey ConfigurationBuilder.build ConfigurationBuilder.setOAuthConsumerKey ConfigurationBuilder.build User.getId User.getId User.getId User.getScreenName ConfigurationBuilder.<init> ConfigurationBuilder.setOAuthConsumerKey ConfigurationBuilder.setOAuthConsumerSecret TwitterFactory.getInstance TwitterFactory.<init> TwitterFactory.getInstance Twitter.setOAuthConsumer TwitterFactory.<init> Twitter.setOAuthConsumer TwitterFactory.getInstance TwitterFactory.<init> Twitter.setOAuthConsumer Status.getUser Status.getText Twitter.setOAuthConsumer Twitter.setOAuthAccessToken ConfigurationBuilder.<init> ConfigurationBuilder.build TwitterFactory.<init> Twitter.setOAuthAccessToken TwitterFactory.getInstance Twitter.setOAuthAccessToken ConfigurationBuilder.<init> TwitterFactory.<init> TwitterFactory.getInstance TwitterFactory.<init> Status.getUser Status.getText TwitterFactory.getInstance TwitterFactory.<init> Twitter.setOAuthConsumer Twitter.setOAuthAccessToken auth.AccessToken.getToken auth.AccessToken.getTokenSecret ConfigurationBuilder.<init> ConfigurationBuilder.setDebugEnabled ConfigurationBuilder.build TwitterFactory.getInstance TwitterFactory.<init> Twitter.setOAuthConsumer Twitter.setOAuthAccessToken Twitter.updateStatus ConfigurationBuilder.<init> ConfigurationBuilder.setOAuthConsumerKey ConfigurationBuilder.setOAuthConsumerSecret ConfigurationBuilder.build http.AccessToken.getToken http.AccessToken.getTokenSecret TwitterFactory.<init> TwitterFactory.getInstance Status.getId Status.getId

MAPO [Zhong et al, 2009] UP-Miner [Wang et al, 2013] IIM (actually a slight extension)

Model

z(j)

S

X(j)

S ∈ I S ∈ I

πS

j ∈ 1, ..., m

• 1. For each itemset, sample

To sample a transaction,

zS ∼ Bernoulli(πS).

• 2. Deterministically set

X =

• zs=1

S.

Parameters:

I

Collection of “interesting” itemsets

πS ∈ [0, 1]

S ∈ I for each probability of occurrence

Stepping Back

Local conventions (naming, formatting) Mining idioms

(probabilistic grammars) (ngram models)

Itemset mining

(latent-variable modelling)

Method naming

(word embeddings)

• Miltiadis Allamanis
• Jaroslav Fowkes
• Hao Peng
• Chris Bird, MSR
• Earl Barr, UCL

Thanks!

TwitterFactory.getInstance TwitterFactory.<init> Twitter.setOAuthConsumer Twitter.setOAuthAccessToken

Key concepts in probabilistic modelling

• Sufficiency
• what statistics of the data am I memorizing?
• Latent variables, e.g.,
• what tree macros were used to generate AST?
• what item sets were used in a transaction?

Why patterns in software?

Surface-semantic correspondence

void addOne (int[] arr) { for (int i = 0; i < arr.length; i++) { arr[i] += 1; } } void foo (int[] bar) { int baz = 0; while (true) { bar[baz] = bar[baz] + 1; baz = baz + 1; if (baz > bar.length) break; } }

Semantics available from glancing rather than reading

Orthogonal interfaces

Tools that “do one thing well” need to be combined well

Natural code: Code with good correspondence?

“Semantic retreat” NLP —> statistical NLP PL analysis —> statistical PL analysis

A new type of program analysis

Static analysis

Construct program abstraction (loses information) Why abstract: Exact decision Turing-complete Then logical inference

Statistical analysis

Construct program abstraction (loses information) Why: Data sparsity, inductive bias Then statistical inference
