Specifications & motivation

2

• Lowering integration time would significantly reduce background
• Lowering power would significantly reduce material budget

UPPER LIMIT lower much better !

• Nr of bits to code a hit : 35
• Fake hit : 10-5 /event

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014

Status

• Low power :
• Front-end (20.5nA/pixel), shaping(a few μs) determines integration time
• Data driven readout (see Cesar’s presentation)
• Two early submissions + Two engineering runs shared with the other
• groups. Present engineering run delayed to April 9th.
• Several chips:
• Explorer : sequential analog readout for pixel sensor optimization
• Investigator : parallel fast (~10ns rise time) analog readout for pixel

sensor optimization

• pAlpide : small scale (512x64 array of 22x22 micron pixels) prototypes

to optimize circuit

• pAlpide_fs : full scale prototype (1024x512 of 28x28 micron pixels)

prototype for system studies

3

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014

• Analog readout for pixel characterization
• Readout time decoupled from integration time
• Possibility to reverse bias the substrate
• Sequential readout with correlated double sampling
• Contains two 1.8x1.8mm2 matrices of 20x20 and

30x30 micron pixels with different geometries

Explorer

4 PULSED ROWS

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014

Explorer-1 (April 2013) vs Explorer-0 (July 2012)

5

• Comparison of 55Fe cluster signal for Explorer-0 and Explorer-1
• Explorer-1 shows ~ 2x signal increase, and similar noise level
• Confirms correction on input capacitance, circuit contribution reduced

from ~4.6 fF to ~2 fF

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014

Efficiency & fake hit rate (Explorer-0)

6

• High efficiency at low fake

hit rates

• Reverse substrate bias

gives extra margin

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014

Efficiency & fake hit rate (Explorer-1)

7 Explorer-1 results after tests with electrons at DESY, averaged on all diode geometries

• after irradiation drop of 10 - 20% in CCE, recovered with back bias
• better performance of larger diodes with larger spacing to electronics
• wider distance  wider depletion volume  lower input capacitance
• better performance of 20 x 20 µm2 at low back bias voltage
• detection efficiency above 99% up to 10σ cut, also after irradiation

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014

pALPIDE pixel circuit diagram

8

Thanushan Kugathasan - WP3, ITS-MFT mini-week, 10 March 2014

Memory cell, hit enabled during the strobe window. Priority encoder – Reset decoder:

• nly zero-suppressed data are

transferred to the periphery. Low Power Analog Front End (< 40 nW/pixel) based on a single stage amplifier/current comparator. Pixel State Register

Priority encoder

state reset

STROBE

set

Front-end

• utput pulse
• Circuit capacitance is even smaller than on explorer 1.
• First prototype pAlpide-0 works, but two issues:
• Source to nwell diode of transistor inside collection electrode

competes with resetting diode, “fixed” with light (> 10fA/pixel !!)

• Amplifier/comparator stops working for reverse substrate biases > 2

V, due to loss of inversion in NMOS capacitor => could not operate at minimum sensor capacitance

• Note: doubling the Pixel State Register significantly reduces dead time

(cfr Adam’s simulations)

pALPIDE first results

9

• Minimum detectable charge <130 e-
• At nominal bias (20.5 nA/pixel) and

threshold setting:

• Threshold spread 17 e-
• Noise ~ 7 e-
• 99.6% efficiency in beam test

Analog output of one pixel under 55Fe Noise Threshold

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014

pALPIDEfs Low Power Front-End

10

Thanushan Kugathasan - WP3, ITS-MFT mini-week, 10 March 2014

VRESET PWELL IBIAS source curfeed VCASP AVDD AVSS VCASN ITHR IDB M0b D1 M1 M2 M3 Cc M4 M5 IRESET pix_in pix_out PIX_OUT_B VPULSE Cinj 160 aF VAUX D0 Diode Reset PMOS Reset AVSS M0a

Fixes for two issues:

• Input PMOS transistor outside collection electrode (also for pAlpide1)
• Replace for some sectors resetting diode with PMOS transistor

Cost: additional capacitance, will have to evaluate impact

• Implement capacitor with PMOS instead of NMOS
• Also for faster clipping PMOS instead of NMOS clipping transistor

Still exploring other alternatives in pAlpides: avoid/minimize the penalty of additional capacitance, further reduce shaping time

pALPIDEfs reset scheme

Thanushan Kugathasan - WP3, ITS-MFT mini-week, 10 March 2014

11

Sector Columns nwell diameter spacing pwell

• pening

Reset 1 0 to 255 2 µm 1 µm 4 µm PMOS 2 256 to 511 2 µm 2 µm 6 µm PMOS 3 512 to 767 2 µm 2 µm 6 µm Diode 4 768 to 1023 2 µm 4 µm 10 µm PMOS

PMOS reset Diode reset

Collection electrode example

Pulsing capacitor: 160 aF Input routing line Input PMOS

pwell opening = nwell diameter + 2 . spacing

Please note that in pALPIDE_fs the nwell is

• ctagonal and the p+ ring is squared

pALPIDE_fs: 30x15.3mm 1024x512 pixels

12

gianluca.aglieri.rinella@cern.ch

30 mm 15.3 mm

Pads over the matrix

PADs over matrix: pixel routing 4 metals only

• Region of 8x8 pixels allocated for pad over matrix
• Provide by-pass for row select and power routing
• First results on explorer with metal pads over the matrix promising
• Large design effort

13 8 x 28 µm = 224 µm

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014

Periphery

14

gianluca.aglieri.rinella@cern.ch

Matrix DACs Readout I/O pads

Pixels and Priority Encoders

15

gianluca.aglieri.rinella@cern.ch

Priority Encoder Analog Routing

Readout and I/O pads

16

gianluca.aglieri.rinella@cern.ch

Investigator

17

Thanushan Kugathasan - WP3, ITS-MFT mini-week, 10 March 2014

• 135 mini-matrices
• Each mini-matrix has 8x8 pixels.
• 64 analog outputs to read all the pixels in a

mini-matrix.

• Different pixel designs:
• Pixel width: from 20 x 20 um2 up to 50 x 50

um2

• Input transistor inside/outside collection n-

well

• Continuous diode reset and active PMOS

switch reset

• Deep-p-well (minimum and maximum)

5.0 mm x 5.8 mm

Present engineering run: expected April 9th

18

 CERN/INFN/WUHA

N/YONSEI



pALPIDE_fs



pALPIDE (3)



EXPLORER (3)



INVESTIGATOR



TEST STRUCTURES

 RAL



CHERWELL3



2 OTHER TEST CHIPS

 IPHC



2 AROM



1 OTHER CHIP

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014

Conclusions

• Low power front-end (20.5nA/pixel) with data-driven readout, integration time of a few μs

determined by shaping time of the front end

• Analog: 20mW/4.5cm2, digital not optimized (100mW+200mW)/4.5cm2 for total chip, serializer

to be added

• This year one more submission for a further iteration before final decision
• Full scale chip : Currently defining features, including interface (see Gianluca’s

presentation)

• Several additional building blocks (also on separate test chips):
• Bandgap reference & temperature sensor (Nikhef)
• Biasing DAC (Yonsei &CERN, already done for first pALPIDE_fs)
• Monitoring ADC (INFN, Yonsei, CERN)
• Serializer (with PLL) & LVDS driver (INFN) (see Gianni’s presentation)
• pAlpide(s) : further front-end optimization (reduce C and shaping time)
• Investigator & Explorer : further sensor optimization if needed
• Front-end & sensor: Benefit of low C clearly established, still measuring different structures

and starting materials, issues with front end have forced us to take a penalty for pALPIDE_fs, still exploring further improvements also for reduced shaping time

• For further details on digital part, see Cesar’s and Alberto’s presentations

19

Walter Snoeys - WP3, ITS-MFT mini-week, 10 March 2014
