Revisiting the Area under the ROC

Berry de Bruijn

Institute for Information Technology National Research Council, Canada

Revisiting the Area Under the ROC

Purpose

• Take a look at the Area under the ROC curve from

a different perspective…

• give it an additional interpretation…
• which might lead to options for extending the AUC.

So, an old story with a new twist…

Revisiting the Area Under the ROC

Introduction: Tests and Classifiers

30-second tutorial

Revisiting the Area Under the ROC

Introduction: Tests and Classifiers

Fresh or not fresh!?!?…. Sniff test !!

Revisiting the Area Under the ROC

Introduction: Classifiers

Sniff test.. all subjects sniffed & scored

0.999 0.801

0.722

0.879 0.544 0.666

0.8

0.305

… then rank ordered

Revisiting the Area Under the ROC

Introduction: Classifiers

All subjects - rank order by score, then apply a threshold

0.879 0.999 0.801 0.722

0.6



Fresh Not Fresh

Eaten

TP FP

Not Eaten

FN TN

Sensitivity = fresh shrimps eaten / all fresh shrimps; Specificity = non-fresh shrimps not-eaten / all non-fresh shrimps;

Revisiting the Area Under the ROC

Introduction: Classifiers

All sensitivity/specificity pairs form the ROC curve

Revisiting the Area Under the ROC

Introduction: Classifiers

   AUC   

All sensitivity/specificity pairs form the ROC curve AUC = 0.9332 à One metric about the performance of the classifier or test..

Revisiting the Area Under the ROC

The new part….

Our classifier can be modeled with a stochastic process: model - sampling, without replacement, from a biased urn with marbles î marbles do not have equal chance to be drawn distribution: Fisher Non-Central Hypergeometric Distribution. TP = f(k, Pos, Neg, bias).

Revisiting the Area Under the ROC

Statistical modeling

‘cond.-vs.-poss.’ data:

Observed:

• 1054 cases

171 positives 883 negatives

• AUC = 0.9332

Fisher NCHypG distr. curve

TP = f(Pos, Neg, k, bias)

• k

= [0 .. 1054]

• Pos = 171,
• Neg = 883,
• bias = 0.9332*

Revisiting the Area Under the ROC

Statistical modeling

See the paper for actual and synthesized ROCs from other data sets.

Revisiting the Area Under the ROC

Conclusions

AUC + non-central hypergeometric distribution = new? interpretation of AUC, stronger theoretical support. Additional statistical properties can be useful for comparing classifiers on the same data set Opens door to extensions for multi-class classification and non-uniform populations. Tusen takk - Thank you

Revisiting the Area Under the ROC

Bonus features…

‘binormal’ approximation
