A Framework for Scientific Workflow Reproducibility in the Cloud

Rawaa Qasha, Jacek Cała, Paul Watson

Newcastle University, Newcastle upon Tyne, UK Email: {r.qasha, jacek.cala, paul.watson}@newcastle.ac.uk

In this paper

• A new framework for repeatability and reproducibility of

scientific workflow

• Integrating

logical and physical preservation approaches

• Offering Workflow/tasks repositories with version

control

• Supporting automatic deployment and image capture of

workflows and tasks

2

• Background
• Challenges for workflow reproducibility
• Our solution for logical and physical preservations
• Overview of reproducibility framework
• Experiments and results
• Conclusions

Outline

3

Workflows & Reproducibility

4 92 1443 18 (~20%) 341 (~24%) 200 400 600 800 1000 1200 1400 1600

study1* study2**

Number of workflows

total no. of workflows Workflows can be re-excuted *Zhao et al, “Why workflows break Understanding and combating decay in Taverna workflows,” 2012

**Mayer et al, “A Quantitative Study on the Re-executability of Publicly Shared Scientific Workflows”, 2015

• Insufficiently detailed workflow description
• Insufficient description of the execution

environment

• Unavailable execution environments
• Absence of & changes in the external

dependencies

• Missing input data

5

Challenges for workflow reproducibility

6

Common reproducibility approaches

T1 T2 T4 T3 Logical preservation Physical preservation

Using TOSCA as a logical preservation

7

Node Type T1 T2 T4 T3 Relationship Type Node Template (T4) Node Template (T1) Node Template (T3) Node Template (T2)

Service Template

Workflow and execution environment description

8

Image creation Container With Depend.

base image Task image

Container creation

Data

Task artifact Tools & Libs.

(a) Initial task deployment & execution

Task image

Container creation

Data

(b) Task deployment & execution with task image

Using Docker for physical preservation

Preserving execution environment and dependencies, tracking changes

9

Task/WF Repository (GitHub) Images Repository (Docker Hub)

LifeCycle Scripts Basic Types

Workflow Deployment & Enactment Engine (TOSCA Runtime Environment: Cloudify) Automated Image Creation

Target Execution Environment (Docker over local VM, AWS, Azure, GCE, …)

Core Repository (GitHub)

Reproducibility Framework

10

Multi-container deployment

11

Single container deployment

12

Time line of workflow devOps

13

Workflow repository

Preserving description, input data, tracking changes and deployment instructions

14

Experiments and Results

15

1- Repeatability of a workflow on different clouds

16

2- Automatic image capture for improved performance

17

3- Reproducibility in the face of development changes

Conclusions

18

• Full workflow reproducibility is a long-standing issue
• TOSCA description is used for logical preservation
• Docker images for tasks/workflows support physical

preservation

• Changes tracking and automatic deployment also contribute to

a comprehensive solution of the problem

• Integration of these techniques addresses majority of the

issues related to workflow decay
