REPPIR Approach to Consequence Assessment and Associated Risk Framework Authors: C Boyd Version 1. 15.2.2020 Contents Summary of Previous REPPIR Approach IAEA Approach REPPIR ACOP and the Risk Framework Uncertainties in


slide-1
SLIDE 1

REPPIR Approach to Consequence Assessment and Associated Risk Framework

Authors: C Boyd

Version 1.– 15.2.2020

slide-2
SLIDE 2

Slide 2 of 50

Contents

  • Summary of Previous REPPIR Approach
  • IAEA Approach
  • REPPIR ACOP and the Risk Framework
  • Uncertainties in Consequence Assessment
  • Relevant Good Practice in Consequence Assessment
  • How licensees have addressed REPPIR Consequence

Assessment

  • Results/Conclusions
slide-3
SLIDE 3

Slide 3 of 50

Summary of Previous REPPIR Approach

  • Reasonably foreseeable event
  • NRPB-M-1311
  • Schedule 2 values determined (ground level, 30 minute

release, D5 best estimate Gaussian dispersion, 100 meter distance, 1 year dose)

  • Criteria: 5 mSv effective dose, 50 mSv organ dose.
  • If exceeded then Emergency Plan required. DEPZ based
  • n the 5 mSv dose contour (typically 1-7 km).
slide-4
SLIDE 4

Slide 4 of 50

5 mSv contour DEPZ

Town and village bisected Vulnerable group Political/ county boundary Boundary marked by geographical landmarks, roads, postcodes, etc.

A B

Vulnerable group

Pre REPPIR 2019

4

slide-5
SLIDE 5

Slide 5 of 50

IAEA Approach

IAEA-GS-G 2.1

  • The Precautionary Action Zone (PAZ) is the area within

which arrangements should be made to implement precautionary urgent protective actions before or shortly after a major release with the aim of preventing or reducing the occurrence of severe deterministic effects.

  • The Urgent Protective Action planning Zone (UPZ) area

where preparations are made to promptly shelter in place, to perform environmental monitoring and to implement urgent protective actions on the basis of the results of monitoring within a few hours following a release.

slide-6
SLIDE 6

Slide 6 of 50

IAEA Approach

  • Examples
  • Reactors > 1000 MWth PAZ 3-5 km UPZ 5-30 km.
  • For radioactive sources where A = Activity and D2 =

“Dangerous quantity”, A/D2 100 to 1000 (For Pu-239 this would be a dispersible quantity of >6 TBq), No PAZ and UPZ 0.5 km

slide-7
SLIDE 7

Slide 7 of 50

REPPIR19 ACOP

  • First assess inventories against schedule 1 (also

schedule 2 for fissile quantities). If < then REPPIR19 does not need to be considered further.

  • If > then assess dose (using PHE data tables for low risk

sites) and appropriate methods (at least 2 day and 1 year doses) for other sites to show <1 mSv.

  • If > 1 mSv, Risk Framework
slide-8
SLIDE 8

Slide 8 of 50

REPPIR19 Risk Framework

Minor Moderate Significant

Lower ERL - Sheltering

Very Low Low Medium High Very High

Events not considered in the design

Impact

REPPIR RISK FRAMEWORK

Limited

No emergency planning required by REPPIR Outline planning required Detailed emergency planning required Region where regulatory action taken to prohibit or curtail activity - Detailed emergency planning required

Catastrophic

Likelihood

slide-9
SLIDE 9

Slide 9 of 50

REPPIR19 ACOP

  • DEPZ determined for events with a predicted return

frequency from around >1x10-6 to 1x10-5 per annum. (REPPIR19 Guidance 5(1)-5(2) 152).

  • DEPZ determined at lower shelter ERL for averted dose

(also thyroid dose).

  • Outline planning as per schedule 5 or as specified by
  • MOD. For sites regulated by HSE, the risk framework is

used to determine whether an outline planning zone is required.

slide-10
SLIDE 10

Slide 10 of 50

REPPIR19 ACOP

  • Present results to local authorities for DEPZ for faults

with shelter, evacuation and thyroid blocking distances.

  • Also provide dose to emergency workers, food restriction

distances and long term residual dose.

slide-11
SLIDE 11

Slide 11 of 50

ERL contour DEPZ

Town and village bisected Vulnerable group Political/ county boundary Boundary marked by geographical landmarks, roads, postcodes, etc.

A B

Vulnerable group

OPZ

11

REPPIR 2019

slide-12
SLIDE 12

Slide 12 of 50

Uncertainties in Consequence

  • Source Term
  • Dispersion/Deposition
  • Food transfer
  • Dosimetric combined (inhalation/ingestion/physiology

etc…)

slide-13
SLIDE 13

Slide 13 of 50

Source Term

slide-14
SLIDE 14

Slide 14 of 50

Release to Water Release to Air

Shoreline Irradiation Consumption (Water) Ingestion Consumption (Fish / Seaweed) Ingestion Ingestion (Milk) Ground Irradiation Ingestion (Foods) Air Submersion Air Inhalation Deposition

Exposure Pathways for Man

Direct irradiation

SRP South West Conference – 16th & 17th October 2019

slide-15
SLIDE 15

Slide 15 of 50

Some food transfer and dosimetric factors

  • Transfer rates from soil to food
  • Removal rates from soil by erosion etc…
  • Processing times for food
  • Animal food source (pasture or feedstock)
  • Fraction of food sourced locally
  • Consumption rates
  • Inhalation rates
  • Indoor/outdoor occupancy, building reduction factors
  • Physiology
  • Dose/risk factors
slide-16
SLIDE 16

Slide 16 of 50

Uncertainties in Consequence Assessment

  • From ONR TAG-45 (*Dosimetric combined);

Uncertainty in best estimate of risk from I-131 released from a large break loss of coolant at a PWR Uncertainty in best estimate of risk from Pu-239 released from a fire at a fuel reprocessing facility Source term 5 to 50 10 to 1000 Dispersion 10 20 Food transfer 2 to 20 2 to 20 Dosimetric (ingestion, inhalation, physiological etc…)* 4 12

slide-17
SLIDE 17

Slide 17 of 50

Combining Uncertainties

  • Consequence = source x dispersion x uptake x dose per

unit uptake x risk per unit dose

  • Uncertainties are then combined as;
  • =√{(uncertainty source)2+(uncertainty dispersion)2

+(uncertainty food transfer)2+(uncertainty dosimetric)2}

  • So for iodine LOCA release using geometric means of

17 for source term and 6 for food uptake, with a dispersion uncertainty of factor of 10 and 4 for dosimetric; the uncertainty in the consequence assessment is √{172+102 +62+42} = 20. With a theoretical yet to exist dispersion and deposition model with a factor

  • f 1 to 2 uncertainty, this reduces to 18.
slide-18
SLIDE 18

Slide 18 of 50

Relevant Good Practice in Consequence Assessment

  • R-91 is a Gaussian plume methodology developed by

NRPB with associated subsequent reports (R-157, R- 322, W-41 etc…) dealing with building wake, wet and dry deposition, habits etc…

  • ONR TAG-45 states “R-91 is a “medium” range model,

considered reliable between 100 metres to several tens

  • f kilometres from the release point in constant

conditions..”

  • Provided sensitivities are performed, this is fit for

purpose for REPPIR19 consequence assessment.

slide-19
SLIDE 19

Slide 19 of 50

Relevant Good Practice in Consequence Assessment

  • ONR recognise that for long range assessment (e.g

societal risk target in SAPs, which require modelling of the entire UK), or post fault consequence predictions, Gaussian plume modelling is limited in it’s applicability.

  • ONR are currently assessing whether advanced

methods can be used for societal risk safety assessments (awaiting V&V status).

  • For the very near field, ONR await research work by

Imperial College (ADMLC contract).

slide-20
SLIDE 20

Slide 20 of 50

How licensees have addressed REPPIR19 Consequence Assessment

  • One licensee has performed screening using Gaussian

plume methods and then on higher consequence faults, used advanced methods (NAME/PACE 95th percentile dose) to determine the geographical extent for Local Authorities to determine DEPZ etc…

  • Some lower hazard sites have performed hazard

analysis to determine release fractions of inventories and then shown that these are less than schedule 1 of REPPIR19.

slide-21
SLIDE 21

Slide 21 of 50

Results/Conclusions

  • The minimum recommended DEPZ for sites has

changed – Some have slightly decreased due to the removal of hazards e.g. Magnox defueling – Others have increased due to the use of more pessimistic weather categories in the methodology recommended by PHE

  • In most locations the Local Authority proposes to

maintain a similar DEPZ to that currently in place, but modifying to try to use physical features to set boundaries, and aiming to try to prevent bisecting communities

slide-22
SLIDE 22

Slide 22 of 50

Results/Conclusions

  • Outline planning has been brought into emergency

planning.
