Relational Interfaces and Refinement Calculus for Compositional System Reasoning

Viorel Preoteasa Joint work with Stavros Tripakis and Iulia Dragomir

08.12.2015 1 Computational Logic Day 2015

Overview

• Motivation
• General refinement
• Relational interfaces
• Refinement calculus for reactive systems
• Liveness properties
• Modeling Simulink Diagrams

08.12.2015 2 Computational Logic Day 2015

Motivation

• Is the system correct?
• Can we replace a subsystem by another

subsystem, preserving the functionality?

• Compatibility. Is the composition of two

systems meaningful?

• Can we model liveness properties?

We are interested in reactive systems – systems that repeatedly take some input from the environment and produce some

• utput

08.12.2015 3 Computational Logic Day 2015

Refinement

Refinement (denoted 𝐵 ⊑ 𝐶):

• System 𝐵 is refined by system 𝐶 or
• Informally: 𝐶 can replace 𝐵 in any context
• Formally:
• 1. If 𝐵 satisfies a property 𝑄 then 𝐶 satisfies 𝑄
• 2. If 𝐵 ⊑ 𝐵’ and 𝐶 ⊑ 𝐶’ then 𝐵  𝐶 ⊑ 𝐵’  𝐶’

𝐵  𝐶 denotes some composition of systems 𝐵 and 𝐶

08.12.2015 4 Computational Logic Day 2015

Refinement

• Correctness:

– Specification ⊑ Implementation

• Substitutability:

– If we have 𝐶 ⊑ 𝐶′, then – 𝐵  𝐶  𝐷 ⊑ 𝐵  𝐶’  𝐷 – The system 𝐵  𝐶’  𝐷 satisfies all properties satisfied by 𝐵  𝐶  𝐷

• (In)Compatibility:

– 𝐵  𝐶 = 𝐺𝑏𝑗𝑚 or 𝐵  𝐶 ⊑ 𝐺𝑏𝑗𝑚 where – 𝐺𝑏𝑗𝑚 = while true do skip, or 𝐺𝑏𝑗𝑚 = unhandled exception,

• r 𝐺𝑏𝑗𝑚 = assertion on input is false for every input

08.12.2015 5 Computational Logic Day 2015

Interface theories

• Interface theories can express some of the properties

presented above, but not liveness

– Relational interface introduced by Tripakis et al, A Theory

• f Synchronous Relational Interfaces, ACM TOPLAS, 2011

– Interface automata introduced by Alfaro et al, Interface Automata, FSE, ACM, 2009

• On the other hand there are frameworks capable of

expressing liveness properties, but they cannot express compatibility of systems.

– Focus framework, Broy et al, Specification and development of interactive systems: focus on streams interfaces and refienemt, Springer, 2001

08.12.2015 Computational Logic Day 2015 6

Relational Interfaces - Example

• Division component:
• Contract: 𝑧 ≠ 0 ∧ 𝑨 = 𝑦/𝑧
• The condition 𝑧 ≠ 0 introduces a

requirement on input 𝑧

• If input 𝑧 = 0, then 𝐸𝑗𝑤𝑗𝑒𝑓 fails (this is

different from 𝐺𝑏𝑗𝑚 = fails for all inputs).

𝐸𝑗𝑤𝑗𝑒𝑓 𝑦 𝑧 𝑨

08.12.2015 7 Computational Logic Day 2015

Relational Interfaces – Composition

• Output of one component becomes the input of

the second component

• The requirement on 𝑧 is propagated to 𝑏 and 𝑐
• Choosing 𝑏 and 𝑐 properly we can ensure 𝑧 ≠ 0
• The composition fails if 𝑏 = −𝑐 (the composition

is not 𝐺𝑏𝑗𝑚)

𝑧 ≠ 0 𝑨 = 𝑦/𝑧 𝑦 𝑧 𝑨 𝑧 = 𝑏 + 𝑐 𝑦 > 10 𝑏 𝑐

08.12.2015 8 Computational Logic Day 2015

Relational Interfaces - Incompatibility

• The two systems are incompatible
• The component 𝑈𝑠𝑣𝑓 produces non-

deterministically values 𝑦 and 𝑧

• By controlling 𝑏 there is no possibility of ensuring

𝑧 ≠ 0

• The composition of these systems is 𝐺𝑏𝑗𝑚,

because the composition fails for every input.

𝑧 ≠ 0 𝑨 = 𝑦/𝑧 𝑦 𝑧 𝑨 𝑈𝑠𝑣𝑓 𝑏

08.12.2015 9 Computational Logic Day 2015

Relational Interfaces – Limitations

• Relational interfaces cannot model liveness

properties

• Semantics of relational interfaces:

– prefix closed sets of finite input output traces

08.12.2015 10 Computational Logic Day 2015

Reactive systems

• A reactive system is a machine that takes as

input an infinite sequence 𝑦0, 𝑦1, 𝑦2, … and it

• utputs an infinite sequence 𝑧0, 𝑧1, 𝑧2, …
• Assume a system that counts and outputs how

many input values seen so far are true.

• Then

– Input: 0,1,0,0,1,1,1,0,0, … – Output: 0,1,1,1,2,3,4,4,4, …

08.12.2015 11 Computational Logic Day 2015

Our Goal

A compositional theory for reactive systems with both safety and liveness

08.12.2015 12

𝑦 □(𝑦 ≥ 0) 𝐵 □ ◊ (𝑦 = 1) 𝐶

• 𝐵 specifies that its output 𝑦 is always greater or equal than

zero

• 𝐶 requires that its input is infinitely often equal to one.
• The output of 𝐵 is connected to the input of 𝐶.
• In our framework: these components are incompatible
• We want to be able to use LTL formulas in specifications

Computational Logic Day 2015

Refinement Calculus for Reactive Systems

• Monotonic property transformers

– Functions mapping sets of infinite output sequences into sets of output sequences – Property = set of infinite sequences

• A system 𝐵 applied to a set of output sequences

𝑅 is the set of all input sequences that do not fail and produce an output sequence in 𝑅.

• Based on Refinement Calculus introduced by

Back, On the correctness of refinement in program development, 1978

08.12.2015 13 Computational Logic Day 2015

Refinement Calculus for Reactive Systems

This semantics enables reasoning about all features that we mentioned at the beginning:

• Correctness
• Substitutability
• Compatibility
• And also liveness properties

08.12.2015 14 Computational Logic Day 2015

Reactive systems – Operations

The operations on reactive systems are defined in the same way as for predicate transformers

• Sequential composition = function composition:

– 𝐵 ∘ 𝐶 𝑅 = 𝐵 𝐶 𝑅 – where 𝑅 is a set of infinite sequences.

• Refinement = point-wise subset:

– 𝐵 ⊑ 𝐶 ⇔ (∀𝑅 ∶ 𝐵 𝑅 ⊆ 𝐶(𝑅))

• 𝐺𝑏𝑗𝑚(𝑅) = ∅

08.12.2015 15 Computational Logic Day 2015

Simulink Example

08.12.2015 Computational Logic Day 2015 16

𝑨 ≠ 0 𝑧 ≔ 𝑦/𝑨

𝑦 𝑨 𝑧

Delay 𝑏 𝑨 ≔ 𝑣 − 𝑦

𝑦 𝑣 𝑨 𝑨

• 𝑢 = 0: 𝑦0;

𝑣0 ≔ 𝑏; 𝑨0 ≔ 𝑣0 − 𝑦0; 𝑧0 ≔ 𝑦0/𝑨0; 𝑨0 = 𝑣0 − 𝑦0 ≠ 0

• 𝑢 = 1: 𝑦1;

𝑣1 ≔ 𝑧0; 𝑨1 ≔ 𝑣1 − 𝑦1; 𝑧1 ≔ 𝑦1/𝑨1; 𝑨1 = 𝑣1 − 𝑦1 ≠ 0

Simulink Example

• The variable 𝑣 after the delay is calculated by:

𝑣0 ≔ 𝑏; 𝑣𝑜 + 1 ≔ 𝑦𝑜/(𝑣𝑜 − 𝑦𝑜)

• The output is given by:

𝑨𝑜 ≔ 𝑣𝑜 − 𝑦𝑜

• The input 𝑦𝑜 must satisfy the following

property: (∀𝑜 ∶ 𝑣𝑜 ≠ 𝑦𝑜)

08.12.2015 Computational Logic Day 2015 17

Simulink Example as Property Transformer

• Our tool produces the following property

transformer

{∀𝑣: (𝑣0 = 𝑏) ∧ ∀𝑜 ∶ 𝑣𝑜 + 1 =

𝑦𝑜 𝑣𝑜−𝑦𝑜 ⇒ (∀𝑜 ∶ 𝑣𝑜 ≠ 𝑦𝑜)}

∘ [𝑨 ∶ ∃𝑣 ∶ 𝑣 = 𝑏 ∧ □ (𝑣1 =

𝑦 𝑣−𝑦 ∧ 𝑨 = 𝑣 − 𝑦)]

08.12.2015 Computational Logic Day 2015 18

Simulink Example as Property Transformer

• Using Linear Temporal Logic

{∀𝑣 ∶ 𝑣 = 𝑏 ∧ □ 𝑣1 =

𝑦 𝑣−𝑦 ⇒ □(𝑣 ≠ 𝑦)} ∘

[𝑨 ∶ ∃𝑣 ∶ 𝑣 = 𝑏 ∧ □ (𝑣1 = 𝑦 𝑣 − 𝑦 ∧ 𝑨 = 𝑣 − 𝑦)]

08.12.2015 Computational Logic Day 2015 19

Conclusions

• We can model a number of desired features

– Correctness – Substitutability – Compatibility – Liveness properties – … and many more

• We can use linear temporal logic to specify and reason

about these systems

• We built a tool that translates Simulink models to

property transformers.

• The results were formalized in Isabelle theorem prover

08.12.2015 20 Computational Logic Day 2015
