TAMPERE UNIVERSITY OF TECHNOLOGY I n s t i t u t e o f P a p e r C o n v e r t i n g Prediction of WVTR with General Regression Models Kimmo Lahtinen Session 9.1 1. Introduction Target TARGET: To establish a practical, fast and

slide-1
SLIDE 1

TAMPERE UNIVERSITY OF TECHNOLOGY

I n s t i t u t e o f P a p e r C o n v e r t i n g

Prediction of WVTR with General Regression Models

Kimmo Lahtinen Session 9.1

slide-2
SLIDE 2

Paper x.y Speakers name 2

1. Introduction

Target

  • TARGET: To establish a practical, fast and easy-to-use

computer-aided prediction model for water vapour barrier of extrusion coated paper

  • Computer-aided prediction model creates a base for

material selection cost estimation

  • ptimization
  • f a new packaging material.

Already existing packages: Modelling eases the load

  • f experimental testing.
slide-3
SLIDE 3

Paper x.y Speakers name 3

Regression models

  • Results in this study are based on statistical findings.

Experimental tests Regression analysis

  • Regression models are sort of “black-box type” models.

No theoretical linkages between variables

  • In technology, regression models are used when more

deterministic models are not efficient due to complexity and disturbances.

slide-4
SLIDE 4

Paper x.y Speakers name 4

Background of water vapour permeation

  • Mathematical treatment of water vapour transmission

rate (WVTR) Fick’s first law: Steady state diffusion → D does not depend on penetrant’s concentration. The product DS is called coefficient of permeation (P) Henry’s law: c = Sp → → The determination of WVTR: Unit: g/m2/24h

dx dc D J − =

( ) ( )

l p p P l p p DS l c c D J s

1 1 1

) ( − = − = − =

L p p P dt dQ A WVTR ) ( 1

1 2 −

= =

slide-5
SLIDE 5

Paper x.y Speakers name 5

Three external factors influencing moisture barrier of polymer film

  • temperature; effect on P
  • humidity; effect on (p2-p1)
  • thickness; effect on L
  • The effect of temperature is controlled by the Arrhenius

relationship as follows:

L p p P dt dQ A WVTR ) ( 1

1 2 −

= =

) / exp( RT E P P

p

− =

slide-6
SLIDE 6

Paper x.y Speakers name 6

  • 2. Materials and methods

Pilot line

slide-7
SLIDE 7

Paper x.y Speakers name 7

Materials

  • Modelled polymers

LDPE, density 923 kg/m3 HDPE, density 941 kg/m3 PP COC

  • Paper

One-side pigment coated paper to offer a smooth substrate for coating polymer (practically no influence on WVTR)

slide-8
SLIDE 8

Paper x.y Speakers name 8

WVTR test method

  • Cup method (SCAN-

P22:68)

  • The advantage: capable

to carry multitude of samples at the same time

  • Accurate enough for a

statistical study

slide-9
SLIDE 9

Paper x.y Speakers name 9

Test series

  • Regression modelling requires extensive experimental

testing for statistics. 5 set points with different coating weights for each coating. 4 parallel measurements with each coating weight giving 20 results total for each polymer. 16 different atmospheric conditions (T and RH):

  • 1. conditions
  • 2. conditions
  • 3. conditions
  • 4. conditions

Series 1 23°C 50% 30°C 50% 38°C 50% 45°C 50% Series 2 23°C 63% 30°C 63% 38°C 63% 45°C 63% Series 3 23°C 77% 30°C 77% 38°C 77% 45°C 77% Series 4 23°C 90% 30°C 90% 38°C 90% 45°C 90%

slide-10
SLIDE 10

Paper x.y Speakers name 10

WVTRs were measured for exact 20 g/m2 coating weight to achieve an accurate comparison between the results in different atmospheric conditions.

y = 423,67x

  • 1,0349

R

2 = 0,9888

10 20 30 40 50 10 20 30 40 50 60 coating weight (g/m

2)

WVTR (g/m

2/24h)

LDPE

Standard tropical conditions 38°C, RH 90%

Applied method

  • Power law of

regression

slide-11
SLIDE 11

Paper x.y Speakers name 11

  • 3. Results

WVTR as a function of T and RH

3D Surf ace Plot (Spreads heet2.s ta 13v *16c) WVTR = Distance Weighted Least Squares 35 30 25 20 15 10 5

50% RH 63% RH 77% RH 90% RH 23°C 3,03 3,45 4,30 4,89 30°C 5,11 6,86 8,16 9,74 38°C 9,41 12,13 15,37 19,08 45°C 14,74 18,92 25,73 32,59

WVTR results for 20 g/m2 LDPE coating

slide-12
SLIDE 12

Paper x.y Speakers name 12

Definition of mixing ratio

  • Relative humidity is not

the actual water concentration of surroundings.

  • Mixing ratio (ω) is defined

as the ratio of the amount

  • f water (kg) and the

amount of dry air (kg).

  • T and RH determine

mixing ratio from the h,ω diagram of humid air. (basic thermodynamics)

slide-13
SLIDE 13

Paper x.y Speakers name 13

  • Mixing ratio as a function of T and RH:

where µ = MH20 / Mair = 18,015/28,964 = 0,6220, p = normal air pressure = 1 bar and ph’(T) = saturated vapour pressure (function of temperature)

( ) ( )

T p RH p T p

h h

' ' − = µ ω

slide-14
SLIDE 14

Paper x.y Speakers name 14

WVTR as a function of T and ω

Observations: 1) Linear correlation between WVTR and mixing ratio 2) Temperature influences slightly on the slope of the WVTR-mixing ratio curve 3) Most likely suitable for regression estimation

WVTR vs. mixing ratio

20 g/m2 LDPE coating

23°C y = 267,24x + 0,5836 R2 = 0,9887 30°C y = 404,66x - 0,2514 R2 = 0,9953 38°C y = 532,34x - 2,1323 R2 = 0,9961 45°C y = 659,17x - 6,5855 R2 = 0,9916

5 10 15 20 25 30 35 0,02 0,04 0,06 0,08 Mixing ratio WVTR (g/m

2/24h)

slide-15
SLIDE 15

Paper x.y Speakers name 15

Model development

  • Step by step scheme for calculations

Regression

1) 2)

The influence of:

  • i. Temperature
  • ii. Mixing ratio

WVTR of 20 g/m2 single layer The influence of iii. coating weight

3)

The influence of multilayers WVTR of a single layer WVTR of a multilayer structure

slide-16
SLIDE 16

Paper x.y Speakers name 16

  • We define temperature, mixing ratio and coating weight

as independent variables (x1, x2 and x3, respectively) and WVTR as a dependent variable (y)

  • Step 1:

Several first- and second-order models were tested to obtain results for 20 g/m2 single layer. Equation including all possible terms: y = b0 + b1x1 + b2x2 + b3x1x2 + b4x1

2 + b5x2 2

We apply a spreadsheet or statistical computer program to solve the b-values and reliabilities of different models.

slide-17
SLIDE 17

Paper x.y Speakers name 17

List of the tested models and the corresponding standard errors (the best values bolded)

Model Std error LDPE Std error HDPE Std error PP Std error COC

y = b0 + b1x1 + b2x2

0,897 0,590 0,590 0,649

y = b0 + b1x1 + b2x2 + b3x1x2

0,689 0,435 0,355 0,447

y = b0 + b1x1 + b2x2 + b3x1

2

0,908 0,589 0,623 0,626

y = b0 + b1x1 + b2x2 + b3x2

2

0,353 0,203 0,234 0,310

y = b0 + b1x1 + b2x2 + b3x1x2 + b4x1

2

0,440 0,298 0,295 0,346

y = b0 + b1x1 + b2x2 + b3x1x2 + b4x2

2

0,284 0,162 0,223 0,323

y = b0 + b1x1 + b2x2 + b3x1

2 + b4x2 2

0,279 0,170 0,222 0,320

y = b0 + b1x1 + b2x2 + b3x1x2 + b4x1

2 + b5x2 2

0,291 0,170 0,232 0,331

y = b0 + b1x1 + b2x1

2 + b3x2 2

0,519 0,463 0,434 0,313

y = b0 + b1x2 + b2x1

2 + b3x2 2

0,410 0,238 0,214 0,313

y = b0 + b1x1 + b2x1x2 + b3x2

2

0,660 0,520 0,320 0,310

y = b0 + b1x2 + b2x1x2 + b3x2

2

0,476 0,286 0,278 0,316

y = b0 + b1x1

2 + b2x2 2

0,782 0,627 0,483 0,303

slide-18
SLIDE 18

Paper x.y Speakers name 18

Results of step 1

Model: WVTR=b0+b1*Temp+b2*Mix+b3*Temp*Temp+b4*Mix*Mix z=(-6,9493)+(,427809)*x+(203,756)*y +(-,00454)*x*x+(5101,53)*y *y 40 35 30 25 20 15 10 5 16 15 14 12 11 13 10 8 9 76 4 5 2 3 1

WVTR as a function of T and ω for 20 g/m2 LDPE coating

Reliability indicators SSE 0,857234 S 0,279160 S2 0,077930 R2 0,999216

slide-19
SLIDE 19

Paper x.y Speakers name 19

Step 2

  • Influence of coating weight

Coating weight has an inverse proportion on WVTR Thus for LDPE

( ) ( )

2 1 3

, 20 x x f x y =

( )

2 2 4 2 1 3 2 2 1 1 3

20 x b x b x b x b b x y + + + + =

slide-20
SLIDE 20

Paper x.y Speakers name 20

Step 3

  • Influence of multilayers
  • Provided that

All the P-values of the layers are independent of pressure and concentration There are no barriers to diffusion due to interfacial phenomena between layers Multilayer film obeys the equation

  • As partial pressure difference stays as a constant in the

WVTR test

...

3 3 2 2 1 1

P L P L P L P L

tot tot

+ + =

... 1 1 1 1 + + =

3 2 1

WVTR WVTR WVTR WVTRtot

slide-21
SLIDE 21

Paper x.y Speakers name 21

  • 4. The end result
  • A Labview based WVTR estimation computer program

User-selected input values: – Temperature (T) – Relative humidity (RH) – Polymers of layers 1-5 and the corresponding coating weights Computer aided results: – WVTR of chosen structure in selected conditions – 3D graphs; WVTR

  • f chosen structure

in different conditions – WVTR of chosen structure in standard conditions

slide-22
SLIDE 22

Paper x.y Speakers name 22

Report of the WVTR calculation program

slide-23
SLIDE 23

Paper x.y Speakers name 23

  • 5. Acknowledgements
  • Many thanks to the companies that kindly arranged their

materials for the study Stora Enso Borealis Polymers Topas Advanced Polymers

Thank you! Questions please…
