PGCon 2020 Tatsuro Yamada Julien Rouhaud Who we are Tatsuro Yamada Works for NTT Comware as a Database Engineer PostgreSQL Contributor Oracle_fdw Committer pg_plan_advsr Author Member of PGConf.Asia Organizers since 2016

slide-1
SLIDE 1

PGCon 2020 Tatsuro Yamada Julien Rouhaud

slide-2
SLIDE 2

Tatsuro Yamada

  • Works for NTT Comware as a Database Engineer
  • PostgreSQL Contributor
  • Oracle_fdw Committer
  • pg_plan_advsr Author
  • Member of PGConf.Asia Organizers since 2016

Julian Rouhaud

  • Works for VMware
  • PostgreSQL Contributor
  • HypoPG Author
  • pg_qualstats Co-Author

Who we are

slide-3
SLIDE 3

Agenda

1. What is a Query plan? 2. Why inefficient plan can be chosen? 3. Our Challenges to get an efficient plan 4. Conclusion

slide-4
SLIDE 4
  • 1. What is a Query plan?
slide-5
SLIDE 5
  • 1. What is a Query plan?

SQL

  • declarative Language

Query Plan

  • planner steps to retrieve the wanted data
  • contains multiple plan nodes (e.g. scan, join, aggregate, …)
  • tree structure

Planner

  • selects a query plan it thinks is the most efficient plan based on

calculated cost

Does planner select an efficient plan every time?

slide-6
SLIDE 6

Inefficient plan

  • It tends to be a long query execution time
  • EXPLAIN command allows checking a query plan

e.g. EXPLAIN (ANALYZE, BUFFERS) select ….

slide-7
SLIDE 7

Inefficient plan

In this example, using an Index can reduce the execution time

QUERY PLAN

  • Nested Loop ([...] rows=313475000 width=16) ([...] rows=0 loops=1)
  • > Seq Scan on pgqs t2 ([...] rows=25078 width=8) ([...] rows=25000 loops=1)

Filter: (val1 = 0) Rows Removed by Filter: 25000

  • > Materialize ([...] rows=12500 width=8) ([...] rows=0 loops=25000)
  • > Seq Scan on pgqs t1 ([...] rows=12500 width=8) ([...] rows=0 loops=1)

Filter: ((val1 = 0) AND (val2 = 0)) Rows Removed by Filter: 50000

Why inefficient plan can be chosen?

https://rjuju.github.io/postgresql/2020/02/28/pg_qualstats-2-selectivity-error.html

slide-8
SLIDE 8
  • 2. Why inefficient plan

can be chosen?

slide-9
SLIDE 9
  • 2. Why inefficient plan can be chosen?

Inefficient plan Bad scan method Bad join method Bad join order

Inaccurate statistics

Reasons Root causes Problem

Index deficiency Planner specification

slide-10
SLIDE 10

2.1. Index deficiency or not working

Problems

  • No suitable index available
  • Good candidate index can't be used

Solutions

  • Create suitable index and check query writing
  • Better to create a minimum number of indexes to achieve better performance
  • If you have thousands of queries, it’s a tough work
slide-11
SLIDE 11

Plan Plan

What are statistics?

  • Sampled data from a table

e.g.

  • Number of rows
  • Number of unique values
  • Most common values

How does planner use statistics?

  • To calculate the cardinality/selectivity of nodes, and cost of query plans
  • Planner assumes the lowest cost plan is the most efficient plan

2.2. Inaccurate statistics

Query Stats

Planner

Plan

In what cases can statistics be inaccurate?

slide-12
SLIDE 12

2.2. Inaccurate statistics

Cases

  • a. Autovacuum not properly tuned
  • b. Usage of temporary tables
  • c. Massive imports directly followed by queries or in the same transaction
slide-13
SLIDE 13

2.2. Inaccurate statistics

  • a. autovacuum not properly tuned

Problem

  • autovacuum appears to not work properly

Solution

  • Tune the threshold for executing analyze by using GUC parameters:
  • autovacuum_analyze_threshold
  • autoavacuum_analyze_scale_factor
  • And ideally on a per-table basis
  • ALTER TABLE tbl SET (autovacuum_analyze_... TO …)
slide-14
SLIDE 14

2.2. Inaccurate statistics

  • b. Usage of temporary tables

Problem

  • Temporary tables have no statistics by default, as autovacuum won’t

see them

  • Planner uses Default rows number to calculate a cost

Solution

  • Run manual ANALYZE on temporary tables
slide-15
SLIDE 15

2.2. Inaccurate statistics

  • c. Massive imports followed by queries in the same

transaction

Problem

  • A query executed just after importing a large number of rows can lead to

inefficient plan since planner can’t use up to date statistics

Solutions

  • Execute analyze manually is better than waiting for autovacuum
  • Divide the transaction in three processing steps, such as import, analyze,

and query processing, if possible

imports + query imports analyze query

slide-16
SLIDE 16

2.3. Planner specification

Selectivity estimation for AND-ed quals

Problem

  • The planner by default assumes that columns are totally independent

for selectivity estimation

Example WHERE zipcode = 75 AND city = ‘Paris’

  • Paris zipcode is 75, so both predicate are actually redundant
  • If both predicates retain 1% of the rows, applying both should also

retain 1% of the rows

  • But the planner will by default multiply the selectivity, assuming that
  • nly 0.01% of the rows will be retained
slide-17
SLIDE 17

2.3. Planner specification

Solution

  • Detect those correlated columns
  • Create extended statistics (CREATE STATISTICS)
slide-18
SLIDE 18

Causes and Solutions

Inefficient plan Bad scan method Bad join method Bad join order Inaccurate statistics

Reasons Root causes Problem

Index deficiency Planner specification Create Index Appropriate setting Create Extended Stats

Solutions

Is it possible to apply the solutions easily?

Plan Tuning

slide-19
SLIDE 19
  • 3. Our Challenges

to get efficient plan

slide-20
SLIDE 20
  • 3. Our Challenges to get an efficient plan

3.1. Automatic indexing tool

  • pg_qualstats

3.2. Auto query plan tuning tool

  • pg_plan_advsr

3.3. What's next?

slide-21
SLIDE 21

3.1. Auto index and extended statistics advising tool: pg_qualstats

3.1.a What is it? 3.1.b How does index suggestion work? 3.1.c Demo 3.1.d Summary

slide-22
SLIDE 22

3.1.a What is pg_qualstats

  • PostgreSQL extension that keeps track of predicates

(WHERE/JOIN clauses) statistics during query execution

  • Selectivity, error in selectivity estimation, number of execution, type of

scan…

  • Aggregate per unique query (same as pg_stat_statements)
  • And a global index advisor using those statistics
  • Take into account the server actual workload
  • Use multiple heuristics to suggest the minimum number of new index
  • E.g. Preference for multi-column indexes
  • Returns new index suggestion and list predicates that can

automatically be optimized

  • E.g. Operator that don’t have any index AM compatibility
slide-23
SLIDE 23

3.1.b How does index suggestion work

  • Retrieve the list of “interesting” predicates
  • Filter more than 50% of the rows
  • Using a sequential scan
  • For queries run more than 10 times
  • …
slide-24
SLIDE 24

3.1.b How does index suggestion work

  • Build the full set of paths, with each AND-ed predicates

combination

slide-25
SLIDE 25

3.1.b How does index suggestion work

  • Compute a score for each path, giving a weight to each

predicate corresponding to the number of « simple » predicate

slide-26
SLIDE 26

3.1.b How does index suggestion work

  • Highest score is the « best »index
  • a single index optimizing the higher number of predicate
  • Generate the index DDL given the predicate list
  • The correct column order correspond to the ascending weight in the

path!

  • Remove all optimized predicates from the list, and start again

until all predicates are optimized

slide-27
SLIDE 27

3.1.c Demo – the queries

slide-28
SLIDE 28

3.1.c Demo – optimizable predicates

slide-29
SLIDE 29

3.1.c Demo – non optimizable predicates

  • The ILIKE (~~*) can’t be optimized automatically. DBA

attention is required here to know how to properly handle this.

slide-30
SLIDE 30

3.1.d Summary

  • Useful extension to extract knowledge on your production

workload

  • Helps DBA to focus on the “complex” optimization part thanks to

the global index suggestion

  • But also gives a lot of other information that can be used for
  • ther parts of optimization
  • Automatically find correlated columns
  • Automatically find problematic statistics
  • …
slide-31
SLIDE 31

3.2. Auto query plan tuning tool: pg_plan_advsr

3.2.a What is this? 3.2.b How it works 3.2.c Demo 3.2.d Summary

slide-32
SLIDE 32

3.2.a What are pg_plan_advsr and its merit

pg_plan_advsr

  • allows automatic tuning of a query plan by using a feedback loop

Advantages

  • The Machine performs the tuning, rather than humans
  • Tuning is possible even when there is no expert.
  • For experts, it is possible to gain new awareness
  • Can find an optimal plan
  • Since it can controls each plan node, It can create an optimal plan that

might not be selected by Vanilla PostgreSQL

  • Availability of all plan history in tuning process
  • Moreover, able to reproduce any plan from the history
slide-33
SLIDE 33

3.2.a What are pg_plan_advsr and its merit

Use-cases

  • System development field
  • Tuning during performance tests and performance troubles
  • Regular reporting process
  • Analytical processing
  • Batch processing
  • Field of study
  • Verify planner's capability
  • You can check the performance of the selected plan when there is no estimation error

How did this tool achieve automatic tuning?

Note: - pg_plan_advsr is in POC phase, so recommend to use it in a verification environment

  • Refer to the manual for details due to functional restrictions
slide-34
SLIDE 34

3.2.b How does Auto plan tuning work

Parser Planner Executer

pg_plan_advsr

Query Result

  • 1. Detect

estimation error

  • 2. Correct

estimation error by using feedback info on next query execution

Feedback Info Error Info [1]

  • 3. Record

[1] The difference between Estimated rows and Actual rows

  • EXPLAIN Analyze
  • PDCA cycle
  • Add Feedback Loop
slide-35
SLIDE 35

How to correct an estimation error

3.2.b Rough concept of pg_plan_advsr

Hash Join estimate:1000 actual: 1000

Seq Scan Index Scan

Nest Loop estimate: 1 actual: 1000

(A B) A B

1st iteration

Seq Scan Index Scan (A B) A B

2nd iteration

Fix

Feedback Info

(Hints)

slide-36
SLIDE 36

3.2.c Short Demonstration

  • 31c.sql from Join Order Benchmark
  • Analytical query
  • Join count: 10
  • Aggregate functions: 4
  • Data size: 10GB
  • Parameters
  • max_parallel_workers_per_gather = 0
  • max_parallel_workers = 0
  • geqo_threshold = 20
  • from_collapse_limit = 16
  • join_collapse_limit = 16
  • random_page_cost = 2
  • Environment
  • PG118
  • CentOS 7.8 on VirtualBox
  • i5-6300U 2.4GHz 2core / 4thread
  • Mem 16GB
  • SSD 512GB
slide-37
SLIDE 37

3.2.c Short Demonstration

Scenario

  • 1. Prewarm all tables (done)
  • 2. Execute “psql –f 31c.sql” 17 times for Auto plan tuning
  • > auto_tune.sh
  • 3. Check Plan history table to see plan changes
  • 4. Re-verification:
  • > Baseline plan: 31c_org.sql
  • > Tuned plan: 31c_hinted.sql
slide-38
SLIDE 38

Demo: Auto Plan Tuning

3x speed Iterations Execution Time Plan history Table

slide-39
SLIDE 39

Plan history table shows some changes

id pgsp_queryid pgsp_planid diff_of_joins execution_time (ms) 87 1458904999

863916075 943869

9444.67

88 … 1204820903 119616 1839.69 89 … 3427660743 83425 1403.17 90 … 916206257 41572 3709.36 91 … 1314881321 124359 2327.76 92 … 3744232778 12080 1582.87 93 … 1330829809 101159 1579.09 94 … 1610196430 110410 1634.02 95 … 2071239096 120713 2021.11 96 … 3418115224 25800 3000.66 97 … 3498353310 75603 2629.61 98 … 245020999 8996 1971.09 99 … 2367663326 337358 3799.11 100 1458904999 2565516663

1152.47

… … … … …

Performance Improved 8.2 times

(9.4s -> 1.1s)

Baseline Tuned

slide-40
SLIDE 40

Optimizer Hints to reproduce the Optimized plan

/*+ LEADING( ((((((it1 ((it2 ((cn mc )mi_idx ))mi ))ci )n )t )mk )k ) ) HASHJOIN(ci cn it1 it2 k mc mi mi_idx mk n t) NESTLOOP(ci cn it1 it2 mc mi mi_idx mk n t) NESTLOOP(ci cn it1 it2 mc mi mi_idx n t) NESTLOOP(ci cn it1 it2 mc mi mi_idx n) NESTLOOP(ci cn it1 it2 mc mi mi_idx) NESTLOOP(cn it1 it2 mc mi mi_idx) NESTLOOP(cn it2 mc mi mi_idx) NESTLOOP(cn it2 mc mi_idx) NESTLOOP(cn mc mi_idx) NESTLOOP(cn mc) SEQSCAN(it1) SEQSCAN(it2) SEQSCAN(cn) INDEXSCAN(mc) INDEXSCAN(mi_idx) INDEXSCAN(mi) INDEXSCAN(ci) INDEXSCAN(n) INDEXSCAN(t) INDEXSCAN(mk) SEQSCAN(k) */

  • -2565516663

You can bring the hints to other environments to reproduce the plan!

slide-41
SLIDE 41

Demo: Re-verification

Original query (Baseline plan) Hinted query (Optimized plan)

slide-42
SLIDE 42

Result of Re-verification

Query Plan Execution time (ms) Performance Improved 31c_org.sql Baseline plan 9398.37

  • 31c_hinted.sql

Optimized plan (Tuned) 1109.77

Proved the effectiveness of auto plan tuning!

8.4x faster

slide-43
SLIDE 43

3.2.d Summary of pg_plan_advsr

Merit for DBA

  • It is possible to improve query performance by automatically optimizing

the query plan (OK even without an expert)

  • The optimized plan can be reproduced on other environments

How it works

  • Optimize the plan by using a feedback loop to improve the cost

calculation each time query execution.

Demo

  • Ten joins query performance improved 8 times by auto plan tuning.
slide-44
SLIDE 44

3.3. What's next?

Work together the both extensions

Causes of inefficient plan Solutions pg_qualstats pg_plan_advsr Both Index deficiency Find missing Index

✔

  • ✔

Inaccurate statistics Appropriate setting

  • Planner

specification Find correlated columns

possible

  • possible

Plan tuning

  • ✔

✔

slide-45
SLIDE 45

3.3. Make the extensions work together

  • Recommend using the following procedure to get an efficient plan

Step 1. Test your queries Step 2. Extract appropriate index with pg_qualstats and add them Step 3. Find queries with multiple join and bad estimate to feed pg_plan_advsr Step 4. Optimize the plans with pg_plan_advsr

slide-46
SLIDE 46
  • 4. Conclusion
slide-47
SLIDE 47
  • 4. Conclusion
  • 1. What is a Query plan? and 2. Why inefficient plans can be chosen?
  • Explained query plans, what caused inefficient plans, and how to resolve them
  • 3. Our Challenges to get efficient plan
  • pg_qualstats:

Automatic index advising tool, and bad selectivity estimate query detection

  • pg_plan_advsr:

Automatic optimized query plan advising tool

  • Propose to PostgreSQL community
  • Advising feature, Adaptive query or estimate have large merit for DBA,

We’d like to propose creating it in Vanilla PostgreSQL

slide-48
SLIDE 48

Thanks

yamatattsu at gmail.com rjuju123 at gmail.com

"elephants beach walk" by Senorhorst Jahnsen is licensed under CC BY 2.0

slide-49
SLIDE 49

Q&A See you in Zoom!

slide-50
SLIDE 50

References

  • Query text of 31c.sql
  • Feedback Info of 31c.sql (example)
  • Source code
  • Related Talk and Extension
  • Tools to help inspect query plans
slide-51
SLIDE 51

Query text of 31c.sql

EXPLAIN ANALYZE SELECT MIN(mi.info) AS movie_budget, MIN(mi_idx.info) AS movie_votes, MIN(n.name) AS writer, MIN(t.title) AS violent_liongate_movie FROM cast_info AS ci, company_name AS cn, info_type AS it1, info_type AS it2, keyword AS k, movie_companies AS mc, movie_info AS mi, movie_info_idx AS mi_idx, movie_keyword AS mk, name AS n, title AS t WHERE ci.note IN ('(writer)', '(head writer)', '(written by)', '(story)', '(story editor)') AND cn.name LIKE 'Lionsgate%' AND it1.info = 'genres' AND it2.info = 'votes' AND k.keyword IN ('murder', 'violence', 'blood', 'gore', 'death', 'female-nudity', 'hospital') AND mi.info IN ('Horror', 'Action', 'Sci-Fi', 'Thriller', 'Crime', 'War') AND t.id = mi.movie_id AND t.id = mi_idx.movie_id AND t.id = ci.movie_id AND t.id = mk.movie_id AND t.id = mc.movie_id AND ci.movie_id = mi.movie_id AND ci.movie_id = mi_idx.movie_id AND ci.movie_id = mk.movie_id AND ci.movie_id = mc.movie_id AND mi.movie_id = mi_idx.movie_id AND mi.movie_id = mk.movie_id AND mi.movie_id = mc.movie_id AND mi_idx.movie_id = mk.movie_id AND mi_idx.movie_id = mc.movie_id AND mk.movie_id = mc.movie_id AND n.id = ci.person_id AND it1.id = mi.info_type_id AND it2.id = mi_idx.info_type_id AND k.id = mk.keyword_id AND cn.id = mc.company_id;

slide-52
SLIDE 52

Feedback Info of 31c.sql (example)

ROWS(ci cn it1 it2 k mc mi mi_idx mk n t #2825) ROWS(ci cn it1 it2 mc mi mi_idx mk n t #107406) ROWS(ci cn it1 it2 mc mi mi_idx n t #1017) ROWS(ci cn it1 it2 mc mi mi_idx n #1017) ROWS(ci cn it1 it2 mc mi mi_idx #1017) ROWS(cn it1 it2 mc mi mi_idx #1235) ROWS(cn it2 mc mi mi_idx #1295) ROWS(cn it2 mc mi_idx #1449) ROWS(cn mc mi_idx #4370) ….

slide-53
SLIDE 53

Source code

  • pg_qualstats

https://github.com/powa-team/pg_qualstats

  • pg_plan_advsr

https://github.com/ossc-db/pg_plan_advsr

slide-54
SLIDE 54

Related Talk and Extension

Talk

  • PGConf.Russia 2019
  • Auto plan tuning using feedback by Tatsuro Yamada

https://pgconf.ru/en/2019/242844

  • PGConf.Eu 2018
  • Auto plan tuning using feedback by Tatsuro Yamada

https://www.postgresql.eu/events/pgconfeu2018/schedule/session/2132-auto- plan-tuning-using-feedback-loop/

Extension

  • AQO by Postgres Professional
  • https://github.com/postgrespro/aqo
slide-55
SLIDE 55

Tools to help inspect query plans

  • Visualization tools
  • explain.depesz.com
  • pev2
  • pg_flame
