SLIDE 1

PATTERN RECOGNITION AND MACHINE LEARNING

Slide Set 2: Estimation Theory October 2019 Heikki Huttunen heikki.huttunen@tuni.fi

Signal Processing Tampere University

SLIDE 2

default

Classical Estimation and Detection Theory

Before the machine learning part, we will take a look at classical estimation theory.
Estimation theory has many connections to the foundations of modern machine

learning.

Outline of the next few hours:

1 Estimation theory:

Fundamentals
Maximum likelihood
Examples

2 Detection theory:

Fundamentals
Error metrics
Examples

2 / 37

SLIDE 3

default

Introduction - estimation

Our goal is to estimate the values of a group of parameters from data.
Examples: radar, sonar, speech, image analysis, biomedicine, communications,

control, seismology, etc.

Parameter estimation: Given an N-point data set x = {x[0], x[1], . . . , x[N − 1]} which

depends on the unknown parameter θ ∈ R, we wish to design an estimator g(·) for θ ˆ θ = g(x[0], x[1], . . . , x[N − 1]).

The fundamental questions are:

1 What is the model for our data? 2 How to determine its parameters? 3 / 37

SLIDE 4

default

Introductory Example – Straight line

Suppose we have the illustrated time series and

would like to approximate the relationship of the two coordinates.

The relationship looks linear, so we could assume

the following model: y[n] = ax[n] + b + w[n], with a ∈ R and b ∈ R unknown and w[n] ∼ N(0, σ2)

N(0, σ2) is the normal distribution with mean 0

and variance σ2.

10.0 7.5 5.0 2.5 0.0 2.5 5.0 7.5 10.0 x 0.2 0.0 0.2 0.4 0.6 0.8 1.0 1.2 y

4 / 37

SLIDE 5

default

Introductory Example – Straight line

Each pair of a and b represent one line.
Which line of the three would best describe the

data set? Or some other line?

10.0 7.5 5.0 2.5 0.0 2.5 5.0 7.5 10.0 x 0.25 0.00 0.25 0.50 0.75 1.00 1.25 y Model candidate 1 (a = 0.07, b = 0.49) Model candidate 2 (a = 0.06, b = 0.33) Model candidate 3 (a = 0.08, b = 0.51)

5 / 37

SLIDE 6

default

Introductory Example – Straight line

It can be shown that the best solution (in the maximum likelihood sense; to be defined

later) is given by ˆ a = − 6 N(N + 1)

N−1

n=0

y(n) + 12 N(N2 − 1)

N−1

n=0

x(n)y(n) ˆ b = 2(2N − 1) N(N + 1)

N−1

n=0

y(n) − 6 N(N + 1)

N−1

n=0

x(n)y(n).

Or, as we will later learn, in an easy matrix form:

ˆ θ = ˆ a ˆ b

= (XTX)−1XTy

6 / 37

SLIDE 7

default

Introductory Example – Straight line

In this case, ˆ

a = 0.07401 and ˆ b = 0.49319, which produces the line shown on the right.

The line also minimizes the squared distances

(green dashed lines) between the model (blue line) and the data (red circles).

10.0 7.5 5.0 2.5 0.0 2.5 5.0 7.5 10.0 x 0.2 0.0 0.2 0.4 0.6 0.8 1.0 1.2 y Best Fit y = 0.0740x+0.4932 Sum of Squares = 3.62

7 / 37

SLIDE 8

default

Introductory Example 2 – Sinusoid

Consider transmitting the sinusoid below.

20 40 60 80 100 120 140 160 4 3 2 1 1 2 3 4

8 / 37

SLIDE 9

default

Introductory Example 2 – Sinusoid

When the data is received, it is corrupted by noise and the received samples look like

below.

20 40 60 80 100 120 140 160 4 3 2 1 1 2 3 4

Can we recover the parameters of the sinusoid?

9 / 37

SLIDE 10

default

Introductory Example 2 – Sinusoid

In this case, the problem is to find good values for A, f0 and φ in the following model:

x[n] = A cos(2πf0n + φ) + w[n], with w[n] ∼ N(0, σ2).

10 / 37

SLIDE 11

default

Introductory Example 2 – Sinusoid

It can be shown that the maximum likelihood estimator; MLE for parameters A, f0 and φ

are given by ˆ f0 = value of f that maximizes

N−1
n=0

x(n)e−2πifn

,

ˆ A = 2 N

N−1
n=0

x(n)e−2πiˆ

f0n

ˆ

φ = arctan − N−1

n=0 x(n) sin(2πˆ

f0n) N−1

n=0 x(n) cos(2πˆ

f0n) .

11 / 37

SLIDE 12

default

Introductory Example 2 – Sinusoid

It turns out that the sinusoidal parameter estimation is very successful:

20 40 60 80 100 120 140 160 4 3 2 1 1 2 3 4

ˆ f0 = 0.068 (0.068); ˆ A = 0.692 (0.667); ˆ φ = 0.238 (0.609)

The blue curve is the original sinusoid, and the red curve is the one estimated from

the green circles.

The estimates are shown in the figure (true values in parentheses).

12 / 37

SLIDE 13

default

Introductory Example 2 – Sinusoid

However, the results are different for each realization of the noise w[n].

20 40 60 80 100 120 140 160 4 3 2 1 1 2 3 4

ˆ f0 = 0.068; ˆ A = 0.652; ˆ φ = -0.023

20 40 60 80 100 120 140 160 4 3 2 1 1 2 3 4

ˆ f0 = 0.066; ˆ A = 0.660; ˆ φ = 0.851

20 40 60 80 100 120 140 160 4 3 2 1 1 2 3 4

ˆ f0 = 0.067; ˆ A = 0.786; ˆ φ = 0.814

20 40 60 80 100 120 140 160 4 3 2 1 1 2 3 4

ˆ f0 = 0.459; ˆ A = 0.618; ˆ φ = 0.299 13 / 37

SLIDE 14

default

Introductory Example 2 – Sinusoid

Thus, we’re not very interested in an individual case, but rather on the distributions of

estimates

What are the expectations: E[ˆ

f0], E[ˆ φ] and E[ˆ A]?

What are their respective variances?
Could there be a better formula that would yield smaller variance?
If yes, how to discover the better estimators?

14 / 37

SLIDE 15

default

LEAST SQUARES

15 / 37

SLIDE 16

default

Least Squares

The general solution for linear case is easy to remember.
Consider the line fitting case: y[n] = ax[n] + b + w[n].
This can be written in matrix form as follows:

     y[0] y[1] . . . y[N − 1]     

y

=        x[0] 1 x[1] 1 x[2] 1 . . . . . . x[N − 1] 1       

X
a

b

θ

+w.

16 / 37

SLIDE 17

default

Least Squares

Now the model is written compactly as

y = Xθ + w

Solution: The value of θ minimizing the error wTw is given by:

ˆ θLS =

XTX

−1 XTy.

See sample Python code here: https:

//github.com/mahehu/SGN-41007/blob/master/code/Least_Squares.ipynb

17 / 37

SLIDE 18

default

LS Example with two variables

Consider an example, where microscope images

have an uneven illumination.

The illumination pattern appears to have the

highest brightness at the center.

Let’s try to fit a paraboloid to remove the effect:

z(x, y) = c1x2 + c2y2 + c3xy + c4x + c5y + c6, with z(x, y) the brightness at pixel (x, y).

18 / 37

SLIDE 19

default

LS Example with two variables

In matrix form, the model looks like the following:

     z1 z2 . . . zN     

z

=      x2

1

y2

1

x1y1 x1 y1 1 x2

2

y2

2

x2y2 x2 y2 1 . . . . . . . . . . . . . . . . . . x2

N

y2

N

xNyN xN yN 1     

H

·         c1 c2 c3 c4 c5 c6        

c

+ǫ, (1) with zk the grayscale value at k’th pixel (xk, yk).

19 / 37

SLIDE 20

default

LS Example with two variables

As a result we get the LS fit by ˆ

c =

HTH

−1 HTz, ˆ c = (−0.000080, −0.000288, 0.000123, 0.022064, 0.284020, 106.538687)

Or, in other words

z(x, y) = − 0.000080x2 − 0.000288y2 + 0.000123xy + 0.022064x + 0.284020y + 106.538687.

20 / 37

SLIDE 21

default

LS Example with two variables

Finally, we remove the illumination component by subtraction.

21 / 37

SLIDE 22

default

MAXIMUM LIKELIHOOD

22 / 37

SLIDE 23

default

Maximum Likelihood Estimation

Maximum likelihood (MLE) is the most popular estimation approach due to its

applicability in complicated estimation problems.

Maximization of likelihood also appears often as the optimality criterion in machine

learning.

The method was proposed by Fisher in 1922, though he published the basic principle

already in 1912 as a third year undergraduate.

The basic principle is simple: find the parameter θ that is the most probable to have

generated the data x.

The MLE estimator may or may not be optimal in the minimum variance sense. It is

not necessarily unbiased, either.

23 / 37

SLIDE 24

default

The Likelihood Function

Consider again the problem of estimating the mean level A of noisy data.
Assume that the data originates from the following model:

x[n] = A + w[n], where w[n] ∼ N(0, σ2): Constant plus Gaussian random noise with zero mean and variance σ2.

50 100 150 200 4 3 2 1 1 2 3

24 / 37

SLIDE 25

default

The Likelihood Function

The key to maximum likelihood is the likelihood function.
If the probability density function (PDF) of the data is viewed as a function of the

unknown parameter (with fixed data), it is called likelihood function.

Often the likelihood function has an exponential form. Then it’s usual to take the

natural logarithm to get rid of the exponential. Note that the maximum of the new log-likelihood function does not change.

4 2 2 4 6 8 10 A 0.00 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40

PDF of A assuming x[0] = 3

20 15 10 5

Likelihood Log-likelihood

25 / 37

SLIDE 26

default

MLE Example

In our case of estimating the mean of a signal:

x[n] = A + w[n], n = 0, 1, . . . , N − 1, the likelihood function is easy to construct.

The noise samples w[n] ∼ N(0, σ2) are assumed independent, so the PDF of the

whole batch of samples x = (x[0], . . . , x[N − 1]) is obtained by the product rule: p(x; A) =

N−1

n=0

p(x[n]; A) = 1 (2πσ2)

N 2 exp

− 1

2σ2

N−1

n=0

(x[n] − A)2

When we have observed the data x, we can turn the problem around and consider

what is the most likely parameter A to have generated the data.

26 / 37

SLIDE 27

default

MLE Example

Some authors emphasize this by turning the order around: p(A; x) or give the function

a different name such as L(A; x) or ℓ(A; x).

So, consider p(x; A) as a function of A and try to maximize it.

27 / 37

SLIDE 28

default

MLE Example

The picture below shows the likelihood function and the log-likelihood function for
ne possible realization of data.
The data consists of 50 points, with true A = 5.
The likelihood function gives the probability of observing these particular points with

different values of A.

2 3 4 5 6 7 8 A 1 2 3 4 5 6 1e 31

Likelihood of A (max at 5.17)

350 300 250 200 150 100 50

Samples Likelihood Log-likelihood

28 / 37

SLIDE 29

default

MLE Example

Instead of finding the maximum from the plot, we wish to have a closed form solution.
Closed form is faster, more elegant, accurate and numerically more stable.
Just for the sake of an example, below is the code for the stupid version.

# The samples are in array called x0 x = np.linspace(2, 8, 200) likelihood = [] log_likelihood = [] for A in x: likelihood.append(gaussian(x0, A, 1).prod()) log_likelihood.append(gaussian_log(x0, A, 1).sum()) print ("Max likelihood is at %.2f" % (x[np.argmax(log_likelihood)]))

29 / 37

SLIDE 30

default

MLE Example

Maximization of p(x; A) directly is nontrivial. Therefore, we take the logarithm, and maximize it

instead: p(x; A) = 1 (2πσ2)

N 2

exp

−

1 2σ2

N−1

n=0

(x[n] − A)2 ln p(x; A) = −N 2 ln(2πσ2) − 1 2σ2

N−1

n=0

(x[n] − A)2

The maximum is found via differentiation:

∂ ln p(x; A) ∂A = 1 σ2

N−1

n=0

(x[n] − A)

30 / 37

SLIDE 31

default

MLE Example

Setting this equal to zero gives

1 σ2

N−1

n=0

(x[n] − A) =

N−1

n=0

(x[n] − A) =

N−1

n=0

x[n] −

N−1

n=0

A =

N−1

n=0

x[n] − NA =

N−1

n=0

x[n] = NA A = 1 N

N−1

n=0

x[n] 31 / 37

SLIDE 32

default

Conclusion

What did we actually do?
We proved that the sample mean is the maximum likelihood estimator for the

distribution mean.

But I could have guessed this result from the beginning. What’s the point?
We can do the same thing for cases where you can not guess.

32 / 37

SLIDE 33

default

Example: Sinusoidal Parameter Estimation

Consider the model

x[n] = A cos(2πf0n + φ) + w[n] with w[n] ∼ N(0, σ2). It is possible to find the MLE for all three parameters: θ = [A, f0, φ]T.

The PDF is given as

p(x; θ) = 1 (2πσ2)

N 2 exp

  − 1 2σ2

N−1

n=0

(x[n] − A cos(2πf0n + φ)

w[n]

)2   

33 / 37

SLIDE 34

default

Example: Sinusoidal Parameter Estimation

Instead of proceeding directly through the log-likelihood function, we note that the

above function is maximized when J(A, f0, φ) =

N−1

n=0

(x[n] − A cos(2πf0n + φ))2 is minimized.

The minimum of this function can be found although it is a nontrivial task (about 10

slides).

We skip the derivation, but for details, see Kay et al. "Statistical Signal Processing:

Estimation Theory," 1993.

34 / 37

SLIDE 35

default

Sinusoidal Parameter Estimation

The MLE of frequency f0 is obtained by maximizing the periodogram over f0:

ˆ f0 = arg max

f

N−1
n=0

x[n] exp(−j2πfn)

Once ˆ

f0 is available, proceed by calculating the other parameters: ˆ A = 2 N

N−1
n=0

x[n] exp(−j2πˆ f0n)

ˆ

φ = arctan     −

N−1

n=0

x[n] sin 2πˆ f0n

N−1

n=0

x[n] cos 2πˆ f0n     

35 / 37

SLIDE 36

default

Sinusoidal Parameter Estimation—Experiments

Four example runs of the estimation algorithm are

illustrated in the figures.

The algorithm was also tested for 10000 realizations
f a sinusoid with fixed θ and N = 160, σ2 = 1.2.
Note that the estimator is not unbiased.

0.0 0.1 0.2 0.3 0.4 0.5 1000 2000 3000 4000 5000 6000 7000 8000

10000 estimates of parameter f0 (true = 0.07)

0.4 0.6 0.8 1.0 1.2 100 200 300 400 500 600

10000 estimates of parameter A (true = 0.67)

2.0 1.5 1.0 0.5 0.0 0.5 1.0 1.5 2.0 100 200 300 400 500 600 700 800 900

10000 estimates of parameter φ (true = 0.61)

36 / 37

SLIDE 37

default

Estimation Theory—Summary

We have seen a brief overview of estimation theory with particular focus on

Maximum Likelihood.

If your problem is simple enough to be modeled by an equation, the estimation

theory is the answer.

Estimating the frequency of a sinusoid is completely solved by classical theory.
Estimating the age of the person in picture can not possibly be modeled this simply and

classical theory has no answer.

Model based estimation is the best answer when a model exists.
Machine learning can be understood as a data driven approach.

37 / 37
