Technische Universitt Mnchen Parallel Programming and High-Performance Computing Part 1: Introduction Dr. Ralf-Peter Mundani CeSIM / IGSSE Technische Universitt Mnchen 1 Introduction General Remarks materials: http: //

slide-1
SLIDE 1

Technische Universität München

Parallel Programming and High-Performance Computing

Part 1: Introduction

  • Dr. Ralf-Peter Mundani

CeSIM / IGSSE

slide-2
SLIDE 2

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−2

1 Introduction

General Remarks

  • materials: http://www5.in.tum.de/lehre/vorlesungen/parhpp/SS08/
  • Ralf-Peter Mundani

– email mundani@tum.de, phone 289–25057, room 3181 (city centre) – consultation-hour: Tuesday, 4:00—6:00 pm (room 02.05.058)

  • Ioan Lucian Muntean

– email muntean@in.tum.de, phone 289–18692, room 02.05.059

  • lecture (2 SWS)

– weekly – Tuesday, start at 12:15 pm, room 02.07.023

  • exercises (1 SWS)

– fortnightly – Wednesday, start at 4:45 pm, room 02.07.023

slide-3
SLIDE 3

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−3

1 Introduction

General Remarks

  • content

– part 1: introduction – part 2: high-performance networks – part 3: foundations – part 4: programming memory-coupled systems – part 5: programming message-coupled systems – part 6: dynamic load balancing – part 7: examples of parallel algorithms

slide-4
SLIDE 4

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−4

1 Introduction

Overview

  • motivation
  • classification of parallel computers
  • levels of parallelism
  • quantitative performance evaluation

I think there is a world market for maybe five computers. —Thomas Watson, chairman IBM, 1943

slide-5
SLIDE 5

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−5

1 Introduction

Motivation

  • numerical simulation: from phenomena to predictions

physical phenomenon technical process

  • 1. modelling

determination of parameters, expression of relations

  • 2. numerical treatment

model discretisation, algorithm development

  • 3. implementation

software development, parallelisation

  • 4. visualisation

illustration of abstract simulation results

  • 5. validation

comparison of results with reality

  • 6. embedding

insertion into working process mathematics computer science application discipline

slide-6
SLIDE 6

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−6

1 Introduction

Motivation

  • why parallel programming and HPC?

– complex problems (especially the so called “grand challenges”) demand for more computing power

  • climate or geophysics simulation (tsunami, e. g.)
  • structure or flow simulation (crash test, e. g.)
  • development systems (CAD, e. g.)
  • large data analysis (Large Hadron Collider at CERN, e. g.)
  • military applications (crypto analysis, e. g.)
  • …

– performance increase due to

  • faster hardware, more memory (“work harder”)
  • more efficient algorithms, optimisation (“work smarter”)
  • parallel computing (“get some help”)
slide-7
SLIDE 7

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−7

1 Introduction

Motivation

  • bjectives (in case all resources would be available N-times)

– throughput: compute N problems simultaneously

  • running N instances of a sequential program with different data sets

(“embarrassing parallelism”); SETI@home, e. g.

  • drawback: limited resources of single nodes

– response time: compute one problem at a fraction (1/N) of time

  • running one instance (i. e. N processes) of a parallel program for

jointly solving a problem; finding prime numbers, e. g.

  • drawback: writing a parallel program; communication

– problem size: compute one problem with N-times larger data

  • running one instance (i. e. N processes) of a parallel program, using

the sum of all local memories for computing larger problem sizes; iterative solution of SLE, e. g.

  • drawback: writing a parallel program; communication
slide-8
SLIDE 8

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−8

1 Introduction

Overview

  • motivation
  • classification of parallel computers
  • levels of parallelism
  • quantitative performance evaluation
slide-9
SLIDE 9

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−9

1 Introduction

Classification of Parallel Computers

  • definition: “A collection of processing elements that communicate and

cooperate to solve large problems” (ALMASE and GOTTLIEB, 1989)

  • possible appearances of such processing elements

– specialised units (steps of a vector pipeline, e. g.) – parallel features in modern monoprocessors (superscalar architectures, instruction pipelining, VLIW, multithreading, multicore, …) – several uniform arithmetical units (processing elements of array computers, e. g.) – processors of a multiprocessor computer (i. e. the actual parallel computers) – complete stand-alone computers connected via LAN (work station or PC clusters, so called virtual parallel computers) – parallel computers or clusters connected via WAN (so called metacomputers)

slide-10
SLIDE 10

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−10

1 Introduction

Classification of Parallel Computers

  • reminder: dual core, quad core, manycore, and multicore

– observation: increasing frequency (and thus core voltage) over past years – problem: thermal power dissipation increases linearly in frequency and with the square of the core voltage

slide-11
SLIDE 11

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−11

1 Introduction

Classification of Parallel Computers

  • reminder: dual core, quad core, manycore, and multicore (cont’d)

– 25% reduction in frequency (and thus core voltage) leads to 50% reduction in dissipation

dissipation performance normal CPU reduced CPU

slide-12
SLIDE 12

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−12

1 Introduction

Classification of Parallel Computers

  • reminder: dual core, quad core, manycore, and multicore (cont’d)

– idea: installation of two cores per die with same dissipation as single core system

dissipation performance single core

  • dual core
slide-13
SLIDE 13

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−13

1 Introduction

Classification of Parallel Computers

  • commercial parallel computers

– manufacturers: starting from 1983, big players and small start-ups (see tabular; out of business: no longer in the parallel business) – names have been coming and going rapidly – in addition: several manufacturers of vector computers and non- standard architectures

company country year status in 2003 Sequent U.S. 1984 acquired by IBM Intel U.S. 1984

  • ut of business

Meiko U.K. 1985 bankrupt nCUBE U.S. 1985

  • ut of business

Parsytec Germany 1985

  • ut of business

Alliant U.S. 1985 bankrupt

slide-14
SLIDE 14

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−14

1 Introduction

Classification of Parallel Computers

  • commercial parallel computers (cont’d)

company country year status in 2003 Encore U.S. 1986

  • ut of business

SUN Microsystems U.S. 1993 active Floating Point Systems U.S. 1986 acquired by SUN Myrias Canada 1987

  • ut of business

Ametek U.S. 1987

  • ut of business

Silicon Graphics U.S. 1988 active C-DAC India 1991 active Kendall Square Research U.S. 1992 bankrupt IBM U.S. 1993 active NEC Japan 1993 active Cray Research U.S. 1993 active

1 Introduction

Classification of Parallel Computers

  • commercial parallel computers (cont’d)
slide-15
SLIDE 15

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−15

1 Introduction

Classification of Parallel Computers

  • arrival of clusters

– in the late eighties, PCs became a commodity market with rapidly increasing performance, mass production, and decreasing prices – growing attractiveness for parallel computers – 1994: Beowulf, the first parallel computer built completely out of commodity hardware

  • NASA Goddard Space Flight Centre
  • 16 Intel DX4 processors
  • multiple 10 Mbit Ethernet links
  • Linux with GNU compilers
  • MPI library

– 1996: Beowulf cluster performing more than 1 GFlops – 1997: a 140-node cluster performing more than 10 GFlops

slide-16
SLIDE 16

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−16

1 Introduction

Classification of Parallel Computers

  • arrival of clusters (cont’d)

– 2005: InfiniBand cluster at TUM

  • 36 Opteron nodes (quad boards)
  • 4 Itanium nodes (quad boards)
  • 4 Xeon nodes (dual boards) for interactive tasks
  • InfiniBand 4× Switch, 96 ports
  • Linux (SuSE and Redhat)
slide-17
SLIDE 17

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−17

1 Introduction

Classification of Parallel Computers

  • supercomputers

– supercomputing or high-performance scientific computing as the most important application of the big number crunchers – national initiatives due to huge budget requirements

  • Accelerated Strategic Computing Initiative (ASCI) in the U.S.

– in the sequel of the nuclear testing moratorium in 1992/93 – decision: develop, build, and install a series of five supercomputers of up to $100 million each in the U.S. – start: ASCI Red (1997, Intel-based, Sandia National Laboratory, the world’s first TFlops computer) – then: ASCI Blue Pacific (1998, LLNL), ASCI Blue Mountain, ASCI White, …

  • meanwhile new high-end computing memorandum (2004)
slide-18
SLIDE 18

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−18

1 Introduction

Classification of Parallel Computers

  • supercomputers (cont’d)

– federal “Bundeshöchstleistungsrechner” initiative in Germany

  • decision in the mid-nineties
  • three federal supercomputing centres in Germany (Munich,

Stuttgart, and Jülich)

  • one new installation every second year (i. e. a six year upgrade cycle

for each centre)

  • the newest one to be among the top 10 of the world

– overview and state of the art: Top500 list (updated every six month), see http://www.top500.org

slide-19
SLIDE 19

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−19

1 Introduction

Classification of Parallel Computers

  • MOORE’s law

– observation of Intel co-founder Gordon E. MOORE, describes important trend in history of computer hardware (1965)

number of transistors that can be placed on an integrated circuit is increasing exponentially, doubling approximately every two years

slide-20
SLIDE 20

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−20

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500
slide-21
SLIDE 21

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−21

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500 (cont’d)
slide-22
SLIDE 22

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−22

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500 (cont’d)

cluster: #nodes > #processors/node constellation: #nodes < #processors/node

slide-23
SLIDE 23

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−23

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500 (cont’d)
slide-24
SLIDE 24

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−24

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500 (cont’d)
slide-25
SLIDE 25

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−25

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500 (cont’d)
slide-26
SLIDE 26

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−26

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500 (cont’d)
slide-27
SLIDE 27

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−27

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500 (cont’d)
slide-28
SLIDE 28

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−28

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500 (cont’d)
slide-29
SLIDE 29

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−29

1 Introduction

Classification of Parallel Computers

  • some numbers: Top500 (cont’d)
slide-30
SLIDE 30

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−30

1 Introduction

Classification of Parallel Computers

  • The Earth Simulator – world’s #1 from 2002—04

– installed in 2002 in Yokohama, Japan – ES-building (approx. 50m × 65m × 17m) – based on NEC SX-6 architecture – developed by three governmental agencies – highly parallel vector supercomputer – consists of 640 nodes (plus 2 control & 128 data switching)

  • 8 vector processors (8 GFlops each)
  • 16 GB shared memory

5120 processors (40.96 TFlops peak performance) and 10 TB memory; 35.86 TFlops sustained performance (Linpack) – nodes connected by 640×640 single stage crossbar (83,200 cables with a total extension of 2400km; 8 TBps total bandwidth) – further 700 TB disc space and 1.6 PB mass storage

slide-31
SLIDE 31

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−31

1 Introduction

Classification of Parallel Computers

  • BlueGene/L – world’s #1 since 2004

– installed in 2005 at LLNL, CA, USA (beta-system in 2004 at IBM) – cooperation of DoE, LLNL, and IBM – massive parallel supercomputer – consists of 65,536 nodes (plus 12 front-end and 1204 I/O nodes)

  • 2 PowerPC 440d processors (2.8 GFlops each)
  • 512 MB memory

131,072 processors (367 TFlops peak performance) and 33.5 TB memory; 280.6 TFlops sustained performance (Linpack) – nodes configured as 3D torus (32 × 32 × 64); global reduction tree for fast operations (global max / sum) in a few microseconds – 1024 Gbps link to global parallel file system – further 806 TB disc space; operating system SuSE SLES 9

slide-32
SLIDE 32

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−32

1 Introduction

Classification of Parallel Computers

  • HLRB II (world’s #6 for 04/2006)

– installed in 2006 at LRZ, Garching – installation costs 38 M€ – monthly costs approx. 400,000 € – upgrade in 2007 (finished) – one of Germany’s 3 supercomputers – SGI Altix 4700 – consists of 19 nodes (SGI NUMA link 2D torus)

  • 256 blades (ccNUMA link with partition fat tree)

– Intel Itanium2 Montecito Dual Core (12.8 GFlops) – 4 GB memory per core 9728 processor cores (62.3 TFlops peak performance) and 39 TB memory; 56.5 TFlops sustained performance (Linpack) – footprint 24m × 12m; total weight 103 metric tons

slide-33
SLIDE 33

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−33

1 Introduction

Classification of Parallel Computers

  • standard classification according to FLYNN

– global data and instruction streams as criterion

  • instruction stream: sequence of commands to be executed
  • data stream: sequence of data subject to instruction streams

– two-dimensional subdivision according to

  • amount of instructions per time a computer can execute
  • amount of data elements per time a computer can process

– hence, FLYNN distinguishes four classes of architectures

  • SISD: single instruction, single data
  • SIMD: single instruction, multiple data
  • MISD: multiple instruction, single data
  • MIMD: multiple instruction, multiple data

– drawback: very different computers may belong to the same class

slide-34
SLIDE 34

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−34

1 Introduction

Classification of Parallel Computers

  • standard classification according to FLYNN (cont’d)

– SISD

  • one processing unit that has access to one data memory and to one

program memory

  • classical monoprocessor following VON NEUMANN’s principle

processor program memory data memory

slide-35
SLIDE 35

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−35

1 Introduction

Classification of Parallel Computers

  • standard classification according to FLYNN (cont’d)

– SIMD

  • several processing units, each with separate access to a (shared or

distributed) data memory; one program memory

  • synchronous execution of instructions
  • example: array computer, vector computer
  • advantages: easy programming model due to control flow with a

strict synchronous-parallel execution of all instructions

  • drawbacks: specialised hardware necessary, easily becomes out-

dated due to recent developments at commodity market

processor program memory data memory data memory processor

slide-36
SLIDE 36

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−36

1 Introduction

Classification of Parallel Computers

  • standard classification according to FLYNN (cont’d)

– MISD

  • several processing units that have access to one data memory;

several program memories

  • not very popular class (mainly for special applications such as Digital

Signal Processing)

  • operating on a single stream of data, forwarding results from one

processing unit to the next

  • example: systolic array (network of primitive processing elements

that “pump” data)

processor program memory data memory processor program memory

slide-37
SLIDE 37

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−37

1 Introduction

Classification of Parallel Computers

  • standard classification according to FLYNN (cont’d)

– MIMD

  • several processing units, each with separate access to a (shared or

distributed) data memory; several program memories

  • classification according to (physical) memory organisation

– shared memory shared (global) address space – distributed memory distributed (local) address space

  • example: multiprocessor systems, networks of computers

processor program memory data memory data memory processor program memory

slide-38
SLIDE 38

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−38

1 Introduction

Classification of Parallel Computers

  • processor coupling

– cooperation of processors / computers as well as their shared use of various resources require communication and synchronisation – the following types of processor coupling can be distinguished

  • memory-coupled multiprocessor systems (MemMS)
  • message-coupled multiprocessor systems (MesMS)

global memory distributed memory shared address space MemMS, SMP Mem-MesMS (hybrid) distributed address space ∅ MesMS

slide-39
SLIDE 39

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−39

1 Introduction

Classification of Parallel Computers

  • processor coupling (cont’d)

– central issues

  • scalability: costs for adding new nodes / processors
  • programming model: costs for writing parallel programs
  • portability: costs for portation (migration), i. e. transfer from one

system to another while preserving executability and flexibility

  • load distribution: costs for obtaining a uniform load distribution

among all nodes / processors – MemMS are advantageous concerning scalability, MesMS are typically better concerning the rest – hence, combination of MemMS and MesMS for exploiting all advantages distributed / virtual shared memory (DSM / VSM) – physical distributed memory with global shared address space

slide-40
SLIDE 40

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−40

1 Introduction

Classification of Parallel Computers

  • processor coupling (cont’d)

– uniform memory access (UMA)

  • each processor P has direct access via the network to each memory

module M with same access times to all data

  • standard programming model can be used (i. e. no explicit send /

receive of messages necessary)

  • communication and synchronisation via shared variables

(inconsistencies (write conflicts, e. g.) have to prevented in general by the programmer) M … … network P P P M M

slide-41
SLIDE 41

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−41

1 Introduction

Classification of Parallel Computers

  • processor coupling (cont’d)

– symmetric multiprocessor (SMP)

  • only a small amount of processors, in most cases a central bus, one

address space (UMA), but bad scalability

  • cache-coherence implemented in hardware (i. e. a read always

provides a variable’s value from its last write)

  • example: double or quad boards, SGI Challenge

C: cache M C … P C C P P

slide-42
SLIDE 42

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−42

1 Introduction

Classification of Parallel Computers

  • processor coupling (cont’d)

– non-uniform memory access (NUMA)

  • memory modules physically distributed among processors
  • shared address space, but access times depend on location of data

(i. e. local addresses faster than remote addresses)

  • differences in access times are visible in the program
  • example: DSM / VSM, Cray T3E

P M … network M P

slide-43
SLIDE 43

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−43

1 Introduction

Classification of Parallel Computers

  • processor coupling (cont’d)

– cache-coherent non-uniform memory access (ccNUMA)

  • caches for local and remote addresses; cache-coherence

implemented in hardware for entire address space

  • problem with scalability due to frequent cache actualisations
  • example: SGI Origin 2000

C M … network P M C P

slide-44
SLIDE 44

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−44

1 Introduction

Classification of Parallel Computers

  • processor coupling (cont’d)

– cache-only memory access (COMA)

  • each processor has only cache-memory
  • entirety of all cache-memories = global shared memory
  • cache-coherence implemented in hardware
  • example: Kendall Square Research KSR-1

P C … network C C P P

slide-45
SLIDE 45

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−45

1 Introduction

Classification of Parallel Computers

  • processor coupling (cont’d)

– no remote memory access (NORMA)

  • each processor has direct access to its local memory only
  • access to remote memory only via explicit message exchange (due

to distributed address space) possible

  • synchronisation implicitly via the exchange of messages
  • performance improvement between memory and I/O due to parallel

data transfer (Direct Memory Access, e. g.) possible

  • example: IBM SP2, ASCI Red / Blue / White

M P … network M P M P

slide-46
SLIDE 46

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−46

1 Introduction

Overview

  • motivation
  • classification of parallel computers
  • levels of parallelism
  • quantitative performance evaluation
slide-47
SLIDE 47

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−47

1 Introduction

Levels of Parallelism

  • the suitability of a parallel architecture for a given parallel program strongly

depends on the granularity of parallelism

  • some remarks on granularity

– quantitative meaning: ratio of computational effort and communication / synchronisation effort (≈ amount of instructions between two necessary communication / synchronisation steps) – qualitative meaning: level on which work is done in parallel

program level process level block level instruction level sub-instruction level coarse-grain parallelism fine-grain parallelism

slide-48
SLIDE 48

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−48

1 Introduction

Levels of Parallelism

  • program level

– parallel processing of different programs – independent units without any shared data – no or only small amount of communication / synchronisation – organised by the OS

  • process level

– a program is subdivided into processes to be executed in parallel – each process consists of a larger amount of sequential instructions and has a private address space – synchronisation necessary (in case all processes in one program) – communication in most cases necessary (data exchange, e. g.) – support by OS via routines for process management, process communication, and process synchronisation – term of process often referred to as heavy-weight process

slide-49
SLIDE 49

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−49

1 Introduction

Levels of Parallelism

  • block level

– blocks of instructions are executed in parallel – each block consists of a smaller amount of instructions and shares the address space with other blocks – communication via shared variables; synchronisation mechanisms – term of block often referred to as light-weight-process (thread)

  • instruction level

– parallel execution of machine instructions – optimising compilers can increase this potential by modifying the order

  • f commands (better exploitation of superscalar architecture and

pipelining mechanisms)

  • sub-instruction level

– instructions are further subdivided in units to be executed in parallel or via overlapping (vector operations, e. g.)

slide-50
SLIDE 50

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−50

1 Introduction

Overview

  • motivation
  • classification of parallel computers
  • levels of parallelism
  • quantitative performance evaluation
slide-51
SLIDE 51

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−51

1 Introduction

Quantitative Performance Evaluation

  • execution time

– time T of a parallel program between start of the execution on one processor and end of all computations on the last processor – during execution all processors are in one of the following states

  • compute

– computation time TCOMP – time spent for computations

  • communicate

– communication time TCOMM – time spent for send and receive operations

  • idle

– idle time TIDLE – time spent for waiting (sending / receiving messages) – hence T = TCOMP + TCOMM + TIDLE

slide-52
SLIDE 52

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−52

1 Introduction

Quantitative Performance Evaluation

  • parallel profile

– measures the amount of parallelism of a parallel program – graphical representation

  • x-axis shows time, y-axis shows amount of parallel activities
  • identification of computation, communication, and idle periods

– example

  • proc. C
  • proc. B
  • proc. A

compute communicate idle 1 2 3 time amount of processes

slide-53
SLIDE 53

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−53

1 Introduction

Quantitative Performance Evaluation

  • parallel profile (cont’d)

– degree of parallelism

  • P(t) indicates the amount of processes (of one application) that can

be executed in parallel at any point in time (i. e. y-values of the previous example for any time t) – average parallelism (often referred to as parallel index)

  • A(p) indicates the average amount of processes that can be

executed in parallel, hence

  • r

where p is the amount of processes and ti is the time when exactly i processes are busy , t t i A(p)

p 1 i i p 1 i i

∑ ∑

= = ⋅

=

∫

⋅ − =

2 1

t t 1 2

P(t)dt t t 1 A(p)

slide-54
SLIDE 54

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−54

1 Introduction

Quantitative Performance Evaluation

  • parallel profile (cont’d)

– previous example: A(p) = (1⋅18 + 2⋅4 + 3⋅13) / 35 = 65/35 = 1.86 – for A(p) exist several theoretical (typically quite pessimistic) estimates,

  • ften used as arguments against parallel systems

– example: estimate of MINSKY (1971)

  • problem: amount of used processors is halved in every step
  • parallel summation of 2p numbers on p processors, e. g.
  • result?

P(t) 1 2 3 5 10 15 20 25 30 35 40 45 time

slide-55
SLIDE 55

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−55

1 Introduction

Quantitative Performance Evaluation

  • comparison multiprocessor / monoprocessor

– correlation of multi- and monoprocessor systems’ performance – important: program that can be executed on both systems – definitions

  • P(1): amount of unit operations of a program on the monoprocessor

system

  • P(p): amount of unit operations of a program on the multiprocessor

systems with p processors

  • T(1): execution time of a program on the monoprocessor system

(measured in steps or clock cycles)

  • T(p): execution time of a program on the multiprocessor system

(measured in steps or clock cycles) with p processors

slide-56
SLIDE 56

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−56

1 Introduction

Quantitative Performance Evaluation

  • comparison multiprocessor / monoprocessor (cont’d)

– simplifying preconditions

  • T(1) = P(1)

– one operation to be executed in one step on the monoprocessor system

  • T(p) ≤ P(p)

– more than one operation to be executed in one step (for p ≥ 2)

  • n the multiprocessor system with p processors
slide-57
SLIDE 57

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−57

1 Introduction

Quantitative Performance Evaluation

  • comparison multiprocessor / monoprocessor (cont’d)

– speed-up

  • S(p) indicates the improvement in processing speed
  • in general, 1 ≤ S(p) ≤ p

– efficiency

  • E(p) indicates the relative improvement in processing speed
  • improvement is normalised by the amount of processors p
  • in general, 1/p ≤ E(p) ≤ 1

T(p) T(1) S(p) = p S(p) E(p) =

slide-58
SLIDE 58

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−58

1 Introduction

Quantitative Performance Evaluation

  • comparison multiprocessor / monoprocessor (cont’d)

– speed-up and efficiency can be seen in two different ways

  • algorithm-independent

– best known sequential algorithm for the monoprocessor system is compared to the respective parallel algorithm for the multiprocessor system absolute speed-up absolute efficiency

  • algorithm-dependent

– parallel algorithm is treated as sequential one to measure the execution time on the monoprocessor system; “unfair” due to communication and synchronisation overhead relative speed-up relative efficiency

slide-59
SLIDE 59

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−59

1 Introduction

Quantitative Performance Evaluation

  • comparison multiprocessor / monoprocessor (cont’d)

– overhead

  • O(p) indicates the necessary overhead of a multiprocessor system

for organisation, communication, and synchronisation

  • in general, 1 ≤ O(p)

– parallel index

  • I(p) indicates the amount of operations executed on average per time

unit

  • I(p) ≈ relative speed-up (taking into account the overhead)

P(1) P(p) O(p) = T(p) P(p) I(p) =

slide-60
SLIDE 60

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−60

1 Introduction

Quantitative Performance Evaluation

  • comparison multiprocessor / monoprocessor (cont’d)

– utilisation

  • U(p) indicates the amount of operations each processor executes on

average per time unit

  • conforms to the normalised parallel index

– conclusions

  • all defined expressions have a value of 1 for p = 1
  • the parallel index is an upper bound for the speed-up

1 ≤ S(p) ≤ I(p) ≤ p

  • the workload is an upper bound for the efficiency

1/p ≤ E(p) ≤ U(p) ≤ 1 p I(p) U(p) =

slide-61
SLIDE 61

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−61

1 Introduction

Quantitative Performance Evaluation

  • comparison multiprocessor / monoprocessor (cont’d)

– example (1)

  • a monoprocessor systems needs 6000 steps for the execution of

6000 operations to compute some result

  • a multiprocessor system with five processors needs 6750 operations

for the computation of the same result, but it needs only 1500 steps for the execution

  • thus P(1) = T(1) = 6000, P(5) = 6750, and T(5) = 1500
  • speed-up and efficiency can be computed as

S(5) = 6000/1500 = 4 and E(5) = 4/5 = 0.8 there is an acceleration of factor 4 compared to the monoprocessor system, i. e. on average an improvement of 80% for each processor of the multiprocessor system

slide-62
SLIDE 62

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−62

1 Introduction

Quantitative Performance Evaluation

  • comparison multiprocessor / monoprocessor (cont’d)

– example (2)

  • parallel index and utilisation can be computed as

I(5) = 6750/1500 = 4.5 and U(5) = 4.5/5 = 0.9

  • n average 4.5 processors are simultaneously busy, i. e. each

processor is working only for 90% of the execution time

  • overhead can be computed as

O(5) = 6750/6000 = 1.125 there is an overhead of 12.5% on the multiprocessor system compared to the monoprocessor system

slide-63
SLIDE 63

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−63

1 Introduction

Quantitative Performance Evaluation

  • scalability

– objective: adding further processing elements to the system shall reduce the execution time without any program modifications – i. e. a linear performance increase with an efficiency close to 1 – important for the scalability is a sufficient problem size

  • one porter may carry one suitcase in a minute
  • 60 porters won’t do it in a second
  • but 60 porters may carry 60 suitcases in a minute

– in case of a fixed problem size and an increasing amount of processors saturation will occur for a certain value of p, hence scalability is limited – when scaling the amount of processors together with the problem size (so called scaled problem analysis) this effect will not appear for good scalable hard- and software systems

slide-64
SLIDE 64

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−64

1 Introduction

Quantitative Performance Evaluation

  • AMDAHL’s law

– the probably most important and most famous estimate for the speed- up (even if quite pessimistic) – underlying model

  • each program consists of a sequential part s, 0 ≤ s ≤ 1, that can only

be executed in a sequential way; synchronisation, data I/O, e. g

  • furthermore, each program consists of a parallelisable part 1−s that

can be executed in parallel by several processes; finding the maximum value within a set of numbers, e. g. – hence, the execution time for the parallel program executed on p processors can be written as T(1) p s 1 T(1) s T(p) ⋅ − + ⋅ =

slide-65
SLIDE 65

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−65

1 Introduction

Quantitative Performance Evaluation

  • AMDAHL’s law (cont’d)

– the speed-up can thus be computed as – when increasing p → ∞ we finally get AMDAHL’s law speed-up is bounded: S(p) ≤ 1/s – the sequential part can have a dramatic impact on the speed-up – therefore central effort of all (parallel) algorithms: keep s small – many parallel programs have a small sequential part (s < 0.1) p s 1 s 1 T(1) p s 1 T(1) s T(1) T(p) T(1) − + = ⋅ − + ⋅ = = S(p) s 1 p s 1 s 1 lim S(p) lim

p p

= − + =

∞ → ∞ →

slide-66
SLIDE 66

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−66

1 Introduction

Quantitative Performance Evaluation

  • AMDAHL’s law (cont’d)

– example

  • s = 0.1 and, thus, S(p) ≤ 10
  • independent from p the speed-up is bounded by this limit
  • where’s the error?

10 5 15 20 25 5 10 S(p) p s = 0.1

slide-67
SLIDE 67

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−67

1 Introduction

Quantitative Performance Evaluation

  • GUSTAFSON’s law

– addresses the shortcomings of AMDAHL’s law as it states that any sufficient large problem can be efficiently parallelised – instead of a fixed problem size it supposes a fixed time concept – underlying model

  • execution time on the parallel machine is normalised to 1
  • this contains a non-parallelisable part σ, 0 ≤ σ ≤ 1

– hence, the execution time for the sequential program on the monoprocessor can be written as T(1) = σ + p⋅(1−σ) – the speed-up can thus be computed as S(p) = σ + p⋅(1−σ) = p + σ⋅(1−p)

slide-68
SLIDE 68

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−68

1 Introduction

Quantitative Performance Evaluation

  • GUSTAFSON’s law (cont’d)

– difference to AMDAHL

  • sequential part s(p) is not constant, but gets smaller with increasing p

s(p) ∈ ]0, 1[

  • often more realistic, because more processors are used for a larger

problem size, and here parallelisable parts typically increase (more computations, less declarations, …)

  • speed-up is not bounded for increasing p

, ) (1 p s(p) σ − ⋅ + σ σ =

slide-69
SLIDE 69

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−69

1 Introduction

Quantitative Performance Evaluation

  • GUSTAFSON’s law (cont’d)

– some more thoughts about speed-up

  • theory tells: a superlinear speed-up does not exist

– each parallel algorithm can be simulated on a monoprocessor system by emulating in a loop always the next step of a processor from the multiprocessor system

  • but superlinear speed-up can be observed

– when improving an inferior sequential algorithm – when a parallel program (that does not fit into the main memory

  • f the monoprocessor system) completely runs in cache and

main memory of the nodes from the multiprocessor system

slide-70
SLIDE 70

Technische Universität München

  • Dr. Ralf-Peter Mundani - Parallel Programming and High-Performance Computing - Summer Term 2008

1−70

1 Introduction

Quantitative Performance Evaluation

  • communication—computation-ratio (CCR)

– important quantity measuring the success of a parallelisation

  • gives the relation of pure communication time and pure computing

time

  • a small CCR is favourable
  • typically: CCR decreases with increasing problem size

– example

  • N×N matrix distributed among p processors (N/p rows each)
  • iterative method: in each step, each matrix element is replaced by

the average of its eight neighbour values

  • hence, the two neighbouring rows are always necessary
  • computation time: 8N⋅N/p
  • communication time: 2N
  • CCR: p/4N – what does this mean?
