orfenster Systems (India) Pvt.Ltd. (TSIL) Technical Presentation - - PowerPoint PPT Presentation

• rfenster Systems (India) Pvt.Ltd.

(TSIL) Technical Presentation

 Why uPVC  Benefits of UPVC windows  Company Profile  What makes of Good UPVC

Windows

 Product Range & Types of

Windows

 Infrastructure  Valued Clients  Question & Answers

Agenda

 uPVC - un plasticized Poly vinyl Chloride.

Attributes:

 Safe.  Not attacked by termites.  Does not rot.  Non corrosive.  T

• ugh and durable.

 Longevity 40 to 50 yrs.  Insulating Material

Why uPVC ?

Windows have to meet a lot of requirements

Aesthetics

• Does it

have the right style?

• How will it

look after being

• utside for

5 years? Structure

• Does it leak?
• Is it easy to
• pen?
• Is it strong

enough? Safety

• Is it big enough to

escape through?

• What is the best sill

height?

• Does it need safety

glass? Energy

• Does it keep in the cool?
• Does it keep out the hot?
• Does it bring enough sunlight

Insulation

• Does it keep Rain Water Out?
• Does it keep Dust Out?
• Does it give sound insulation?

• Water Tightness
• Sound Insulation
• Minimal Maintenance
• Longevity
• Aesthetics
• Energy Efficient
• Thermal Insulation
• Impact Resistance
• Wind Resistance
• Fire Retardant
• UV Stable
• Custom Made

Torfenster Superiorities

 Torfenster systems (India) Pvt. Ltd. (TSIL) with the technical tie up

with Profine group of Germany setup a state of art Fabrication unit at Bangalore in the year 2007 to manufacture world class UPVC Doors &

• Windows. Profine Group is one of the Leading manufacturer of UPVC

profile systems in the world, marketing its product under the Brand name

• f KOMMERLING , TROCAL & KBE and has production base in 21 countries

with over all production capacity of 4,50,000 MT and turnover of Euro 850 million per annum. It commands over 23% of market share of UPVC extrusion worldwide.

 TSIL is first in India to have fully automated machinery for fabrication of

windows without much human intervention and has the largest capacity to fabricate UPVC Doors & Windows with a capacity of 350 windows per 8 Hours shift under one roof.

 Expanding to 550 Windows production.

Company Profile

What makes Good UPVC Window

• 1. Profile System & Design
• 2. Hardware
• 3. Manufacturing Facilities
• 4. Limitation-Size and Product

Sr No Ingredients Ratio 1 PVC Resin 100 2 Impact Modifier 6 3 Processing Aids 0.5 4 Stabiliser 4.5 5 Titanium Dioxide 4 6 Filler (CaCO3) 6-10. uPVC Formulation

 Titanium Dioxide gives white colour and UV

• Stabilization. If % is less profiles are not white

and over a period profiles Crack or bend due to weathering effects.

 Fillers are added to increase volume of the Resin,

world standard is 6-10 %, some profile manufacturer use as high as 50 %, which reduces the cost of profile, but over a period of time profiles crack or bend as they become hard.

uPVC Formulation

 Profiles are multi chambered for maximum Heat

Insulation.

 Reinforcement chamber is large to accommodate

large section, hence window is strong.

 Casement windows are also possible inward

• pening, not available with most of the

manufacturers.

uPVC Profile Design

 Sliding door/window -Euro groove is just enough

to fit rollers, hence gap between Outer frame track and Sash is minimum. It is sealed with good quality Silica wool pile. Sound insulation remains constant over years, which may not be possible with other profiles, where Euro groove is big to accommodate manufacturing deficiencies, which is sealed with Big Wool pile, the hair of same breaks reducing sound and dust insulation.

 Drainage holes are Zig Zag, which prevents water

to come in due to wind pressure.

uPVC Profile Design

 We have India's biggest manufacturing unit under 1 roof

(350-400 windows per day- 2 shift basis) spanning 40000 sq. ft., and expanding the capacity to 550 windows per day 2 shift basis.

 All machines are Fully Automatic CNC ( Computer Numerical

Control)

 We have Machining Center-Pratically windows are not touch.  All above ensure Good Quality and Faster deliveries.  We are only one in India to offer Painted windows, warranty

for painted windows is 15 years. In next 6 months will also introduce painted windows with wood finish texture.

Manufacturing Facility

 Fully trained full fledged experienced

installation technicians.

 Manpower are well verse and experienced

in uPVC window segment.

Installation Infrastructure

 We only use recommended and tested hardware.  Hardware are tested for 30000 cycles ( we

generally open window 4 times in a day, 1460 times in a year, in short 20 yrs.

 Casement windows comes with Easy clean

hinges, so we can clean both sides of the window.

 Casement windows has Male-Female locking

arrangement apart from the Lock given, and also have block fitted at the bottom of the sash which as spring loaded rollers for perfect fittment.

Harware

 All window manufacturer only have 2 types of

rollers, window and door. For big size and with DGU Glass we give special Signet rollers, which ensures smooth operation.

 EPDM Gaskets mosted exposed to atmosphere.

Good EPDM gaskets ensure glass is perfectly hold and windows are sealed perfectly . Low quality EPDM gaskets become hard in few months as a result glass may come out of the sash and sealing may not be proper, leading to decrease in dust and sound insulation.

Harware

HARDWARE DETAILS Sl No. Hardware Material Type company company 1 Espag (multi point locking) ROTO / Guoqiang 2 Friction Hinge Stainless Steel - 304 8M (korean) / Pulse (Indian) 3 Gaskets EPDM EPDM 4 Handles Zamak 5, Powder coated laquered Guoqiang Hardware 5 Fastners Carbon Steel T aiwan 6 Strikers / keeps Zinc (Zamak 05) Zinc (Zamak 05) 7 Screws SS T aiwan 8 Rollers Nylon VBH / ROTO (german) 9 High Load Bearing Rollers Nylon Signet 10 T

• uch lock (single poing

locking) Zamak 5, powder coated laquered Guoqiang Hardware Zamak 5, powder Guoqiang

 We have the maximum product range in UPVC.  Sliding Windows and Door-With or without Bug

mesh.

 Casements ( Internal & External opening). Blinds in

the glass can also be provided.

 Pull down bug screen for casement outside

• penable can be provided.

 Louvers.  Slide & Fold-18 ft. x 9 ft.- almost 100 % opening  Lift and Slide-single panel 10 ft. x 10 ft.  All above are available in White and Painted Option.

Product Range

Window Types Signature Product Painted Windows

Infrastructure

Profile Cut Machine

4 Head Weld Machine

Corner Cleaning Machine

Hardware Assembly Machine

Corner Strength Measuring Machine

LIST OF COMPLETED PROJECTS CITY / LOCATION APPROX AREA in Sq.ft Rohan Jharoka Karnataka 33000 Rohan Ishita Maharastra 21000 HRG Karnataka 6250 Live 100 Hospital Karnataka 7000 Nanjappa Hospital Karnataka 4500 Plama Oceanic Karnataka 18000 Plama Icon Karnataka 8000 Novotel Hotel Andhra Pradesh 11000 Silver Streak Karnataka 6000 Ajmeera Hotel Karnataka 5500 Harsha Reality Gujarat 14000 Venus Developers Gujarat 7500 Devonshire Greens Kerala 6400 Sunshine International School Tamil Nadu 6000 Heritage Goa 8200 Amidhara Developers- Phase I Gujarat 20000 Kalairasi Educational Trust Tamil Nadu 5900

Valued Clients

Plama Heights Karnataka 36000 ETA Karnataka 9700 Silver Streak Karnataka 6000 Laksh Cycles Gujarat 18000 Wonderla Karnataka 7900 Iscon - Venizia / Platinum Gujarat 162000 KCD Projects Gujarat 25000 Sgr G.R.Lavender Karnataka 7400 Amidhara Developers- Phase II Gujarat 43000 Grandstand - Kundan one Ventures Maharastra 30000 Rehana Homes Kerala 9000 Ginger Hotel Across India 30000 Ajmeera Infinity Karnataka 101000

LIST OF ONGOING PROJECTS CITY / LOCATION APPROX AREA in Sq.ft Century Wintersun Karnataka 45000 Ginger Hotel Across India 50000 Annually Heritage - II Goa 11000 Ganesh Housing Sky garden Rajkot 85000 Ozone Metro zone Chennai 130000 Adwalpalkar Horizon 8000 Godrej Anandam Nagpur 130000

Project In Pipeline CITY / LOCATION APPROX AREA in Sq.ft Rajasthan Bhavan Navi Mumbai 8000 Indus Lonavala 50750 Metro Corp Karnataka 91000 Indra Prastha Gujarat 49000 Orion Villas Andhra Pradesh 45000 Atlanta Palm Gujarat 31000 Sri Hari Mangala Gujarat 18000 L & T - Halol Gujarat 16000 Pinnacle Dreams Madhya Pradesh 190000 Madhuram Gujarat 17000 G Corp Karnataka in Progress

GOVERNMENT PROJECTS CITY / LOCATION APPROX AREA in Sq.ft CANARA BANK Karnataka 8000 Apex Bank Karnataka 3000 Toll Plaza( L&T) NHAI Gujrat 4300

Providing better than THE Best

Product & Customer Delight

Thank You

We aspire to having long term business relation
